CAMERA
REFERENCE
GUIDE
www.philipscsi.com
A PERFECT MATCH
FOR EVERY
APPLICATION
CONTENTS
Selection table 4
FlexiDome I & II cameras 6
Dinion cameras 8
Indoor and outdoor camera assemblies 10
High-end digital cameras 12
VariDome cameras 14
Phortress high-impact security dome cameras 15
Frequently asked questions 16
Specification comparison table 18
www.philipscsi.com
2
PHILIPS CCTV
CAMERAS
PHILIPS CCTV CAMERAS
3
PHILIPS CCTV CAMERAS
The camera is critical for every application
Regardless of the quality or capability of the CCTV system you use, the
quality of the image you view depends heavily on the quality
of the camera. The Philips camera range offers outstanding
performance in every class – from the stylish indoor FlexiDomes™
to very high performance digital cameras for the most
demanding situations.
Introducing Dinion™
This guide also introduces the new Dinion mid-range cameras, which
offer benefits like excellent picture performance and minimum
installation time.These cameras are also available ready assembled as
factory-configured outdoor and indoor assemblies.
Whatever your application, there's a Philips camera
to match it
To help you make the best choice from the Philips range of cameras,
this guide summarizes the features and benefits, and gives clear reasons
for choosing each family for virtually all applications you may
encounter. A selection table is shown on page 4.
Committed to quality
Philips is a major player in security and observation systems, so you can
be confident that the cameras are made to the highest quality
standards. The three-year warranty and a free advance exchange
program ensure that if problems do occur, a solution is quickly found.
4
CAMERA
SELECTION TABLE
PHILIPS CCTV CAMERAS
This table summarizes the Philips CCTV camera range. Starting
from your requirements or typical application area, it is easy to
select the most appropriate model.
FlexiDome I & II Dinion
& VariDome
(see page 6 and 14) (see page 8)
APPLICATION REQUIREMENTS
Indoor applications * * * *
Outdoor applications * *
Standard lighting conditions * * * *
Dirty environments
Low and difficult
lighting conditions * *
Extreme lighting conditions *
Discreet observation * *
Vulnerable locations
Highest picture quality *
Special lenses required * *
TYPICAL APPLICATIONS
Entrances, lobbies, receptions * * * *
Cash desks, check-outs * * * *
Shops and stores * * * *
Car parks, industrial buildings * *
Commercial buildings, banks * *
Fences, gates and perimeters * *
Roads and tunnels *
Building exteriors, parking lots *
Sports stadiums, city centers *
Metro, bus & railway stations *
Housing estates, public areas *
* *
Ideally Suited
*
Recommended
5
CAMERA
SELECTION TABLE
PHILIPS CCTV CAMERAS
Outdoor Cameras High-end Cameras Phortress Domes
(see page 10) (see page 12) (see page 15)
***
* * * * * *
* * * * *
* * * *
* * * *
* * *
*
***
* *
* *
*
*
* * *
*
* * *
***
*
*****
*****
*****
FLEXIDOME I & II
CAMERAS
6
PHILIPS CCTV CAMERAS
Why select FlexiDome cameras?
•Performance – Regardless of lighting conditions, FlexiDomes
provide unmatched picture clarity. Optimum contrast and color
reproduction are achieved with an advanced digital signal
processor (DSP), which includes backlight compensation for
optimum contrast, a wide dynamic range and other image
enhancing features.
•Active deterrent – The presence of the dome 'announces'
active surveillance (as deterrent), but the camera itself is hidden
behind a lightly tinted dome. The camera can be discreetly
pointed towards sensitive areas without being visible to potential
offenders.
•Stylish innovation – The combination of stylish design,
advanced camera technology and ease of installation provides
the optimum surveillance solution for a wide range of indoor
security monitoring applications.
• Compact fixed cameras in a stylish dome
• Excellent picture clarity with true
color reproduction
• Lightly-tinted dome masks camera with minimum light loss
• Choice of integral standard or wide-angled lenses
• Easy mounting on ceiling or wall
7
PHILIPS CCTV CAMERAS
When should you use FlexiDome cameras?
• Indoor applications
• Standard lighting situations
• Where the viewing direction needs to be concealed
• Where discrete observation is desirable
Typical applications
Entrances lobbies and reception areas, cash desks and checkouts.
FlexiDome type number overview
TV Standard Resolution High Resolution
Standard Wide Angle Standard Wide Angle Standard
3mm 6mm 3mm 6mm
Color PAL LTC1412/10 LTC1413/10 LTC1412/10 LTC1423/10
NTSC LTC1412/20 LTC1413/20 LTC1412/20 LTC1423/20
Monochrome CCIR LTC1312/10 LTC1313/10 LTC1322/10 LTC1323/10
EIA LTC1312/20 LTC1313/20 LTC1322/20 LTC1323/20
8
DINION
CAMERAS
PHILIPS CCTV CAMERAS
Why select Dinion cameras?
•Perfect pictures – Dinion cameras include powerful features
like 'Backlight Compensation' for easier subject recognition against
doorways and windows, Auto Black to increase the visibility of
details even in low-contrast situations like fog, and Auto Tracking
white balance to ensure perfect color reproduction.
•Superb low-light performance – The superb sensitivity
range of the Dinion cameras is further extended in the high
resolution color version by Philips NightSense, which makes use
of the extra sensitivity of monochrome images.
•Optimal lens performance – Thanks to the unique Lens
Wizard, it is possible to set the correct (back) focusing for a
sharp picture under all lighting conditions – even when focusing
the lens in bright light.
•Ease of installation – Perfect picture out of the box. No tools
needed to install camera.
• Advanced Dinion digital video processing
• NightSense™ sensitivity boost
• Lens Wizard™ to optimize lens performance
• Color and monochrome 1/3” ccd models
• Standard and high resolution models
9
PHILIPS CCTV CAMERAS
When should you use Dinion cameras?
• For indoor and outdoor applications
• When a good quality conventional CCTV camera is required
• When special lenses are required or existing lenses are to be
used
• In standard and low light situations
Typical applications
Shops and stores, car parks, industrial and commercial buildings,
fence and gate surveillance.
Dinion type number overview
TV Standard Resolution High Resolution
Standard Low Mains Low Mains
Voltage Voltage Voltage Voltage
Color PAL LTC0435/10 LTC0435/50 LTC0455/10 LTC0455/50
NTSC LTC0435/20 LTC0435/60 LTC0455/20 LTC0455/60
Monochrome CCIR LTC0335/10 LTC0335/50 LTC0355/10 LTC0355/50
EIA LTC0335/20 LTC0335/60 LTC0355/20 LTC0355/60
10
INDOOR AND OUTDOOR
CAMERA ASSEMBLIES
PHILIPS CCTV CAMERAS
Why select Philips camera kits?
•State-of-the-art cameras – The Dinion color and
monochrome cameras are optimized for superb picture quality,
and are easy to set-up and configure. The Philips Dinion video
processing chip enables many image-enhancing features.
•Convenience – The completely assembled and tested outdoor
camera comprises camera, lens, housing with sunshield and wall
bracket, ready to connect and install. Also the lens is installed on
the indoor camera and together with mounting bracket it is
ready for installation.
•Optimized lens combinations – Both the indoor and
outdoor assemblies varifocal lens covers wide-angle and standard
views and are ideal for standard applications. The outdoor
camera is also available with a longer-range varifocal lens for
telelens applications.
• Pre-assembled units with camera, lens, bracket and housing
• Based on the Dinion camera range
• Choice of color and monochrome cameras
• Standard and high resolution models available
• Varifocal lenses allow field of view to be selected on-site
