Philips TSU9200/79 Guide de sécurité

TSU9200

www.pronto.philips.com

EN Starter’s Guide 3

Installing and conﬁguring

ES Manual de inicio 18

Instalación y conﬁguración

FR Guide de démarrage 33

Installation et conﬁguration

Concept and realisation of the Guide:

Concepto y elaboración de este Manual de inicio:

Documentation et élaboration de ce Guide de démarrage :

Human Interface Group, De Regenboog 11, 2800 Mechelen (Belgium)

www.higroup.com

Pronto Remote Control Starter’s Guide

3001 Leuven (Belgium)

Remarks:

All rights are reserved. Reproduction in whole or in part is prohibited without prior consent

of the copyright owner.

Royal Philips Electronics is not liable for omissions or for technical or editorial errors in this

manual or for damages directly or indirectly resulting from the use of the Pronto Remote

Control.

The information in this Starter’s Guide may be subject to change without prior notice.

All brand or product names are trademarks or registered trademarks of their respective

companies or organizations.

ENGLISH

3Contents

Contents

1 Before You Start 4

2 Unpacking the Pronto Remote Control 6

3 Preparing for Conﬁguration 8

3.1 Inserting the Battery 8

3.2 Charging the Remote Control 8

3.3 Preparing Your PC 9

4 Conﬁguring the Pronto Remote Control 9

4.1 Using Pronto Dashboard 9

4.2 Using the Wizard to Conﬁgure the Remote Control 9

5 Doing More with the Conﬁguration 12

5.1 Starting from an Existing Conﬁguration 12

5.2 Managing My Database 12

5.3 Advanced Editing 13

6 Using the Service Menu 14

7 Support 15

7.1 Troubleshooting 15

7.2 FAQ Information and Latest Updates 16

8 Speciﬁcations 17

4Before You Start

1 Before You Start

Based on a long experience and successful business in the custom installation market, the

Pronto line of touch-screen Remote Controls has been extended with the TSU9200, a hard

button based LCD remote. Like its bigger brothers, it is designed by custom installers and

built by Philips. It includes all technology and features that are needed to operate any home

theater in an easy and straightforward way.

The system is based on a very reliable 2.4 GHz digital RF link and can work wirelessly with

the RFX9200 Extender as well as with the PCX9200 PC extender. It ships with a wizard based

Conﬁguration Program with which you can create personalized conﬁgurations for your clients

in minutes, including icon based channel selection using the extensive built-in icon database.

ENGLISH

5Before You Start

A/V equipment

USB

The Pronto System

The Pronto System contains a variety of equipment that is connected and conﬁgured to

interact with each other. The scheme below shows a possible connection with several

A/V devices.

To set up a Pronto System and conﬁgure the Remote Control as the central unit of

the system, you need different components. The scheme below indicates the different

components, their signiﬁcance in the conﬁguration of the Pronto system and their

mutual connection.

TSU9200

RFX9200

PCX9200

More information is available:

• In the Conﬁguration Program’s Online Help:

•On how to set up the Remote Control.

•On how to incorporate Extenders in the setup.

• In the Starter’s Guides for the PCX9200 and RFX9200 Extenders:

•On how to conﬁgure and install an Extender in the Pronto System.

DNote

The PCX9200 and the RFX9200 Extenders are optional accessories.

6Unpacking the Pronto Remote Control

2 Unpacking the Pronto Remote Control

Navigation keys:

Media - More - Fav - Home

Cursor keys

Rotary wheel

Check mark key

Transport keys

Alphanumeric keys

Clear key

Off key

Menu key

USB connector

Use this connector

to download the

conﬁguration from

the PC to the Remote

Control.

Remote Control

ENGLISH

7Unpacking the Pronto Remote Control

Docking contacts

Docking Station

Power Adapter

CD with the conﬁguration software

USB Cable

8Preparing for Conﬁguration

3 Preparing for Conﬁguration

3.1 Inserting the Battery

To insert the battery:

1Place the battery in the battery compartment, making sure to match the contacts of the

battery to the contacts of the Remote Control.

2Click the battery into place.

3Position the cover and press ﬁrmly until you hear a click.

3.2 Charging the Control Panel

It is advised to charge the Remote Control to its maximum before you start conﬁguring it.

This can take 3 to 4 hours.

DNote

The Remote Control always functions when it is placed in the docking station.

Place the Remote Control in the docking station.

A red Charging LED on the front of the docking station lights up while the Remote

Control is charging. When the Charging LED fades out, the Remote Control is fully

charged.

ENGLISH

9Preparing for Conﬁguration

3.3 Preparing Your PC

In the box you ﬁnd an installation CD for the Conﬁguration Program.

To install the Conﬁguration Program:

Insert the CD in the PC and follow the instructions on the screen.

DNotes

It is advised to check for updates for the Conﬁguration Program. See

www.pronto.philips.com in the Downloads section (PC Software).

You can install the Conﬁguration Program next to other Philips Pronto editors on the

same operating system. Your ﬁles are automatically placed in a separate directory.

To uninstall the Conﬁguration Program, use the Windows uninstall feature.

(Start > Control Panel > Add/Remove Programs)

DNote

It is recommended to back up MyDatabase and the conﬁgurations regularly.

4 Conﬁguring the Pronto Remote Control

4.1 Using Pronto Dashboard

Pronto Dashboard is the starting point for managing conﬁgurations for a wide variety of

Pronto Remote Controls. It presents the tasks you can perform depending on the installed

programs:

• New Project Wizard.

• Manage MyDatabase. See Managing MyDatabase on page 12.

• Classic ProntoEdit to conﬁgure other products of the Pronto line.

4.2 Using the Wizard to Conﬁgure the Remote Control

The Conﬁguration Program is a wizard for conﬁguring the TSU9200. It is very easy to use

and it creates a valid conﬁguration in just a few steps.

To start the wizard:

Select the New Project wizard in Pronto Dashboard.

-or-

Start the wizard from the Windows Start Menu.

10 Conﬁguring the Pronto Remote Control

Creating a Conﬁguration

The wizard will guide you through the following ﬁve steps:

Step 1: Deﬁne the project details.

• The project details will be automatically stored on your PC.

Step 2: Identify the components in the project.

• The contents of a project are based on your client’s A/V equipment. Every piece of

equipment is a component and must be added to the project.

ETip

Enter the component in the Search ﬁeld to check for matching patterns of devices,

brands and model numbers.

Step 3: Deﬁne the activities in the project.

DNote

An activity is a sequence of commands you can conﬁgure. For example, you can program

the TSU9200 to activate the TV, DVD and surround system when Watch DVD is

selected. So by selecting an activity, it executes all these steps with just one press.

• Select an icon and a name for the activity in the wizard.

• Link the components.

• Create the activity command sequence.

Step 4: Add favorites to activities.

• Depending on the activity, you can program favorites. These can be TV or radio channels.

Step 5: Link extenders to components.

• Extenders are optional accessories. Please refer to the documentation of the Extender

for setting it up.

By following these 5 steps, you create a basic conﬁguration. To create an advanced

conﬁguration, see Doing More with the Conﬁguration on page 12.
