Philips PET2008/93 Manuel utilisateur

www.philips.com/welcome

User manual

PET738/PET2008

Portable DVD player

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 1

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 2

16 17

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 3

CH-

CH+

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 4

English

1Control elements and

functional components

1.1 Main unit controls

1.2 Front of player

1.4 Right of player

1.5 Left of player

1.6 Back of the player

1.7 Remote Control

2 Introduction

2.1 Your portable DVD player

2.2 Unpacking

2.3 Placement

2.4 Playable disc formats

2.4.1 DVD-Video

2.4.2 Video CD

2.4.3 Audio CD / MP3 CD /

WMA CD

2.4.4 CD with JPEG files

2.4.5 DivX video discs

2.5 Zero Bright DotTM

3General information

4Charging the units

4.1 Charge the DVD player

4.2 Powering your remote

control

5Start up

5.1 Setup

5.2 Playback DVD

5.3 Playback VCD

5.4 Playback Super (S)-VCD

5.5 Playback Music CD

5.6 Playback Music

MP3/WMA-CD

5.7 Playback Picture-CD

5.8 Playback from USB

5.9 Analog TV

5.9.1 First Time Installation

5.9.2 Setup TV channels

5.9.3 Setup TV channels

Congratulations on your purchase and welcome to Philips!

To fully benefit from the support that Philips offers,

Content

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 5

1Control elements and functional components

1.1 Main unit controls (see figure 1)

1 OPEN Open disc door to insert or remove disc

2POWER Switch the player on / off

39Press once to stop playback and store the stop

position. Press twice to stop playback completely.

2; Start / pause / resume playback

4J( / )K Search backward (J( ) or search forward ()K )

- VOL +

Volume control

6 OPTION Access additional functions

MENU Display MENU page

73,4,1,2Up / down / left / right cursor

Function of CH +/-

OK Confirm selection

1.2 Front of player (see figure 1)

POWER/

/CHR

Power / Remote sensor / charging indicator

1.4 Right of player (see figure 1)

PHONE 1 & 2

Headphones jack

10 AV OUT Audio/Video output

11 AV IN Audio video input

12 USB USB connector

13 COAXIAL Digital audio output

6Addition Functions

6.1 DISPLAY Menu

6.2 Connection

6.2.1 Headphone

6.2.2 TV

6.2.3 AV input

6.2.4 USB

6.2.5 Coaxial

7Troubleshooting

8Technical data

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 6

14 DC IN 9V Power supply socket

1.5 Left of the player (see figure 1)

15 Antenna terminal

connect antenna

1.6 Back of the player (see figure 1)

16 Reset Reset the player when it is hanged up

17 Car mounting screw hole

1.7 Remote Control (see figure 2)

1 MENU Display MENU page

23,4Up / down / left / right navigation key

J( ,)K Skip to previous/next chapter, track or title

OK Confirm selection

CH + / -Change channel

3 DISPLAY Adjust the display value of the system

4 OPTION Access additional functions or title

52; Start / pause / resume playback

69Press twice to stop playback

70- 9Numeric keypad

SUBTITLE

Subtitle language selector

9 RETURN For VCD menu page

10 A - B To r epeat or loop a sequence in a title

11 SETUP Enter SETUP menu

12 VOL+ / -Volume control

13 sMute player volume

14 AUDIO Audio language selector

15 ZOOM Enlarge video image

CAUTION Use of controls or adjustments or performance of

procedures other than herein may result in hazardous radiation

exposure or other unsafe operation.

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 7

2 Introduction

2.1 Your portable DVD player

Your portable DVD player plays digital video discs conforming to

the universal DVD Video standard.With it, you will be able to enjoy

full-length movies with true cinema picture quality, and stereo or

multichannel sound (depending on the disc and on your playback

set-up).

The unique features of DVD-Video, such as selection of soundtrack

and subtitle languages, and of different camera angles (again depend-

ing on the disc), are all included.

What’s more, parental lock lets you decide which discs your chil-

dren will be able to see.You will find your player remarkably easy

to use with the On-Screen Display and player display in combina-

tion with the remote control.

2.2 Unpacking

First check and identify the contents of your package, as listed

below:

•Portable DVD player • Remote Control (AY5511)

•Car adaptor (12V) (AY4115) • AC power adaptor (AY4117)

•User manual • Antenna

•Car headrest mounting kit (AY4246) • AV cable

2.3 Placement

•Place the player on a firm, flat surface.

•Keep away from domestic heating equipment and direct sunlight.

•If the player cannot read CDs/DVDs correctly, try using a com-

monly available cleaning CD/DVD to clean the lens before taking

the player to be repaired. Other cleaning methods may destroy

the lens.

•Always keep the disc door closed to avoid dust on the lens.

•The lens may cloud over when the player is suddenly moved

from cold to warm surroundings. It is then not possible to play a

CD/DVD. Leave the player in a warm environment until the

moisture evaporates.

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 8

2.4 Playable disc formats

In addition to DVD-Video disc, you will also be able to play all

Video CDs, CDs, CDR, CDRW,DVD±R and DVR±RW.

2.4.1 DVD-Video

Depending on the material on the disc (a movie, video

clips, a drama series, etc.) these discs may have one or

more Titles, and each Title may have one or more Chapters.To

make access easy and convenient, your player lets you move

between Titles, and also between Chapters.

2.4.2 Video CD

Depending on the material on the disc (a movie, video

clips, a drama series, etc.) these discs may have one or

more Tracks, and tracks may have one or more indexes, as indicated

on the disc case.To make access easy and convenient, your player

lets you move between tracks and between indexes.

2.4.3 Audio CD / MP3 CD / WMA CD

Audio CDs / MP3 CD / WMA CD contain music tracks

only.You can play them in the conventional way

through a stereo system using the keys on the

remote control and/or main unit, or via the TV

using the On Screen Display (OSD).

2.4.4 CD with JPEG files

You can also view JPEG still photos on this player.

2.4.5 DivX video discs

DivX is a popular media technology created by DivX, Inc.

DivX media files contain highly compressed video with high visual

quality that maintains a relatively samll file size. DivX files can also

include advanced media features like menus, subtitles, and alternate

audio tracks. Many DivX media files are available for download

online, and you can create your own using your personal content

and easy-to-use tools from DivX.com.

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 9

2.5 Zero Bright DotTM

Enjoy highest-quality images that are free from annoying

blank spots on the LCD screen. LCD displays commonly have

imperfections, termed as 'bright dots' by the LCD industry.A limit-

ed number of bright dots were once considered an inevitable side

effect of LCD mass production.With Philips' strict quality control

procedures used in our Portable DVD Players, our LCD displays

are produced with zero tolerance for bright dots. Select Portable

DVD Players come with Philips Zero Bright DotTM Policy to guaran-

tee optimal screen quality.

Warranty service varies from region to region. Contact your local

Philips representative for more detailed information.

3General information

Power Sources

This unit operates on a supplied AC adaptor, car adapter, or a

rechargeable battery pack.

•Make sure that the input voltage of the AC adaptor is in line

with the local voltage. Otherwise, the AC adaptor and unit may

be damaged.

•Do not touch the AC adaptor with wet hands to prevent elec-

tric shock.

•When connecting with car power (cigarette lighter) adaptor, be

sure the input voltage of the adaptor is identical with car voltage.

•Unplug the AC adaptor from the outlet or remove the battery

pack when the unit is not used for long periods of time.

•Hold the plug to disconnect the AC adaptor. Do not pull the

power cord.

Please always use supplied AC/DC adaptor

Safety and maintenance

•Do not disassemble the unit for laser rays are dangerous to

eyes.

Any service should be done by qualified service personnel.

PET2008_738_93_CCR_Eng 2008.4.2 15:41 Page 10
