Philips DCP851 Manuel utilisateur

DVD Portable Player DCP851

All version

3141 785 32601

Version 1.1

TABLE OF CONTENTS

Chapter

Technical Specification & Service Tips…………..……….. 1

Safety Instructions…………………………………………….. 2

Instruction for Use………………………………………………3

Mechanical Instructions………………………………………. 4

Troubleshooting …………………………………………………5

Overall Block Diagram………………………………………….6

Electrical Diagram……………………………………………… 7

Service Part List………………………………...……………….8

Revision List……………………………………………………. 9

retrieval system or transmitted, in any form or by any means, electronics,

mechanical, photocopying, or otherwise without the prior permission of Philips

Service Manual

1.0 TECHNICAL SPECIFICATION

General

Dimensions (W x H x D): 210 x 39 x 178 mm

Bear Unit Weight: 1.1 kg +/- 5%

Power supply:

Supply voltage Input: 100~240V + / - 10%

50/60Hz 0.3A

Output: DC 9V 1A

Supply Power

consumption (AC adaptor

100/240VAC) 9W + 10%

Operating Temperature -10 ~ 50degC

Video System NTSC

Frequency response 20-20kHz +/-1dB

THD 20-20kHz (%): </=3%

Dynamic range 1kHz >/=80dB

Signal/Noise ratio: >/=80dB

Channel Separation 1kHz >=60dB

Channel Balance 1kHz <3dB

Current consumption

Playback time

Capacity--- Refer to battery

spec 2400mAH

Battery discharge cut-off

current 40mA

Max.battery charge

current(continue charge) of

DCP850 & DCP750

450mA

Charging time 5 +/- 0.5H

Headphone out (headphone output load 2x16 ohm)

Maximum output power: 1.5mW

Frequency response: +/-3dB

SNR (A-wght): >65dB

THD (0.2-20kHz):3%

Left-Right Channel

Separation: >/=50dB

Left-Right Channel

Balance: </=1dB

Supported disc type

Video Playback

Formats:

Audio Playback

Formats:

Playback disc type: DVD, Picture-CD,

SVCD, Video CD, MP3-

CD, CD-R/CD-RW,

WMA-CD, DVD-R, DVD-

RW, DVD+R, DVD+RW

Video Playback Format: DVD / VCD / SVCD / CD

/ JPEG / Divx

Audio Playback Format: CD/MP3, MP3-DVD,

DVD, Divx

Card slot: SD / MMC (memory up

to 1GB)

Disc Diameter 12cm

Pixel specification

Max. 0 bright-dot & max. 3 dark-dots

Factory Service Mode (FSM)

To check the software version and change

region code of your DVD Portable

1. Power ON the DVD player and open the DVD

door

2. Press the “SETUP” button on remote control,

then select the “Preference MENU”

3. Press the remote button in the sequence as

9 -> 6 -> 5 -> 3

4. The LCD display showed the existing region

code. Press (navigation up) or

(navigation down) repeatedly to select the

number from 0 to 6.

5. Refer below table for your region code setting

Select “0” setting = Region Free (confidential)

1.0 TECHNICAL SPECIFICATION

Procedure on how to upgrade the software of

the DVD Portable

For the best performance of your DVD Portable.

Check www.philips.com/support for latest

software upgrades available.

A) By CD-ROM

1. Download the “PHILIPS.BIN” file from the Philips

support site

2. Unzip the file and then burn it into a CD-ROM to

make a disc for upgrade

3. CD-ROM disc name must be “PHILIPS”

(otherwise it will not be recognized as a disc for

upgrade)

4. Power on the Portable DVD Player with AC/DC

adaptor

5. Play CD-ROM for firmware upgrade

Warning: Do not unplug the AC adaptor during

firmware upgrade to prevent flash corrupt of the

set!!

6. Once upgrade is completed, the player will restart

automatically and observed PHILIPS LOGO on the

screen.

7. Open the DVD door to remove the disc

B) By SD Card

1. Download the “PHILIPS.BIN” file from the Philips

support site

2. Unzip the file and then copy and paste it into a

blank SD card

3. Power on the Portable DVD Player with AC/DC

adaptor

4. Read the SD card via SD Card slot for firmware

upgrade

Warning: Do not unplug the AC adaptor during

firmware upgrade to prevent flash corrupt of the

set!!

5. Once upgrade is completed, the player will restart

automatically and observed PHILIPS LOGO on the

screen.

1.0 TECHNICAL SPECIFICATION

Service Policy on PCBA of DCP851

Type /05 /12 /37 /98

Main PCBA MLR MLR MLR MLR

TFT PCBA MLR MLR MLR MLR

KEY PCBA MLR MLR MLR MLR

BATTERY PCBA MLR MLR MLR MLR

IPOD PCBA MLR MLR MLR MLR

MLR = module swap

3.0 INSTRUCTION FOR USE

4.0 MECHANICAL INSTRUCTION

Disassembly Procedure

1. Remove 7pcs of screws on the side of bottom

cabinet.

2. Open the bottom cabinet. Carefully unplug the

housing which is connected with main board

and TFT board.

3. Open the bottom cabinet.

First, unplug all the housing which are connected

the main board with battery board, key board and

IPOD board. (include 2pcs housing and the FFC

for the DVD louder)

Second, unplug all the housing which are

connected with main board and TFT board (then

you can separate TFT board and main board)

Remove all the screws on the main board (4pcs),

take out the main board from bottom cabinet.

4.0 MECHANICAL INSTRUCTION

4. Unplug the FFC and remove 3pcs screws from

DVD louder, then you can take out the DVD

louder.

5. From this location (between the buttons and

battery) you can take out the key board easily.

6. Remove 2pcs of screws on the battery board.

You can’t take out the battery together with the

battery board yet. Due to the battery was fixed

by the IPOD plastic docking cover and the

press IPOD-lock metal piece.

If you want to take out the battery, you must

remove the IPOD plastic docking cover and the

press IPOD-lock metal piece first.

Remove 4pcs screws from the cover (shown the

left photo), after that remove these 2pcs screws

(as shown the above photo).

Note: the battery was fixed by 2pcs two side

adhesive tape!

4.0 MECHANICAL INSTRUCTION

After done above, you can take out the IPOD

plastic docking cover and IPOD docking.

7. Unplug all the housing which are connected

with main board and TFT board (don’t forget to

unplug the Panel FFC from TFT board behind

the black flannel).

8. Remove 6pcs screws on the TFT board, de-

soldering the wire connected between panel and

TFT board (don’t forget to de-soldering the black

ground wire). Then take out the TFT board

from display frame.

Remove 4pcs screws which are to fix the panel on

the display frame to take out the panel from

display frame.

To take out the IPOD board.

Remove 2pcs black screws from the bottom of IPOD

docking(as the photo shown)

4.0 MECHANICAL INSTRUCTION
