Philips SHQ6300 Manuel utilisateur

www.philips.com/support

User manual

Always there to help you

SHQ6300

Question?

Contact

Philips

1EN

Contents

1 Important 2

Hearing Safety 2

General information 2

2 Your Bluetooth sports headphones 3

What's in the box 3

Other devices 3

Overview of your Bluetooth wireless

headphones 3

3 Get started 4

Charge your headphones 4

Pair the headphones with your mobile

phone 4

4 Use your headphones 5

Connect the headphones to a

Bluetooth device 5

Use your headset 5

Clip the headset 6

5 Technical data 7

6 Notice 8

Declaration of conformity 8

Disposal of your old product and battery 8

Compliance with EMF 8

Trademarks 9

7 Frequently asked questions 10

2EN

1 Important

Hearing Safety

Danger

• To avoid hearing damage, limit the time you use

headphones at high volume and set the volume to a

safe level.The louder the volume, the shorter the safe

listening time is.

Be sure to observe the following guidelines

when using your headset.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your hearing

adapts.

• Do not turn up the volume so high that

you can’t hear what’s around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

• Excessive sound pressure from earphones

and headphones can cause hearing loss.

• Using headphones with both ears covered

while driving is not recommended and may

be illegal in some areas while driving.

• For your safety, avoid distractions from

music or phone calls while in trafc or

other potentially dangerous environments.

General information

To avoid damage or malfunction:

Caution

• Do not expose headphones to excessive heat.

• Do not drop your headphones.

• Headphones shall not be exposed to dripping or

splashing.

• Do not allow your headphones to be submerged in

water.

• Do not use any cleaning agents containing alcohol,

ammonia, benzene, or abrasives.

• If cleaning is required use a soft cloth, if necessary

dampened with a minimum amount of water or diluted

mild soap, to clean the product.

• The integrated battery shall not be exposed to

excessive heat such as sunshine, re or the like.

• Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

About operating and storage temperatures

and humidity

• Operate or store in a place where

temperature is between -15ºC (5ºF) and

55ºC (131ºF) (up to 90% relative humidity.

• Battery life may be shorter in high or low

temperature conditions.

3EN

2 Your Bluetooth

sports

headphones

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product

at www.philips.com/welcome.

With this Philips sports headphones, you can:

• enjoy convenient wireless handsfree calls;

• enjoy and control wireless music;

• switch between calls and music.

What's in the box

Philips Bluetooth sports headphones SHQ6300

USB charging cable (for charging only)

Quick start guide

Other devices

A mobile phone or device (e.g. notebook, PDA,

Bluetooth adapters, MP3 players etc) which

supports Bluetooth and is compatible to the

headphones.

Overview of your Bluetooth

wireless headphones

a Microphone

b On/off, music/call control button

c LED light

d Audio jack

e Micro USB charging slot

f Volume/track control

4EN

3 Get started

Charge your headphones

Note

• Before you use your headphones for the rst time,

charge the battery for 4 hours for optimum battery

capacity and lifetime.

• Use only the original USB charging cable to avoid any

damage.

• Finish your call before charging the headset, as

connecting the headphones for charging will power the

headphones off.

Connect the supplied USB charging cable to:

• the USB connector of the headphones

and;

• USB power source.

» LED turns white during charging and

turns off when the headphones are

fully charged.

Tip

• Normally, a full charge takes 3 hours.

Pair the headphones with

your mobile phone

Before you use the headphones with your

mobile phone for the rst time, pair the

headphones with a mobile phone. A successful

pairing establishes a unique encrypted link

between the headphones and mobile phone.

The headphones store the last 4 devices in the

memory. If you try to pair more than 4 devices,

the earliest paired device is replaced by the

new one.

1 Make sure that the headphones are fully

charged and turned off.

2 Press and hold until the blue and

white LED ashes alternately.

» The headphones are in pairing mode

for 5 minutes.

3 Make sure that the mobile phone is turned

on and its Bluetooth feature is activated.

4 Pair the headphones with the mobile

phone. For detailed information, refer to

the user manual of your mobile phone.

The following example shows you how to pair

the headphones with your mobile phone.

1 Activate the Bluetooth feature of your

mobile phone, select Philips SHB5000.

2 Enter the headphones password "0000"

(4 zeros) if prompted. For those mobile

phones featuring Bluetooth 2.1+EDR or

higher, no need to enter a password.

Settings

Select

Back

Connectivity

10:37

Enter Password

****

0000

Settings

Bluetooth

Select Back

Connectivity

10:35

Add

Bluetooth

device

Settings

Devices Found

Select Back

10:36

Philips SHB6000

Settings

Select

Back

Connectivity

10:37

Enter Password

****

0000

Settings

Bluetooth

Select Back

Connectivity

10:35

Add

Bluetooth

device

Settings

Devices Found

Select Back

10:36

Philips SHB5000

5EN

4 Use your

headphones

Connect the headphones to a

Bluetooth device

1 Turn on your mobile phone/Bluetooth

device.

2 Press and hold to turn the headset

on.

» The blue LED ashes.

» The headphones are reconnected

to the last connected mobile phone/

Bluetooth device automatically. If

the last one is not available, the

headphones try to reconnect to the

second last connected device.

Tip

• If you turn on the mobile phone/Bluetooth device or

activate the Bluetooth feature after turning on the

headphones, you have to reconnect the headphones

and mobile phone/Bluetooth device manually.

Note

• If the headphones fail to connect to any Bluetooth

device within range in 5 minutes, it will switch off

automatically to save the battery life.

Use your headset

Task Operation Sound or

LED Indicator

Turn the

headphones

on.

Press and hold

for 1

second

• 4 scale

tones from

low to high

• Blue LED

ashes

Turn the

headphones

off.

Press and hold

for 4

seconds.

• 4 scale

tones from

high to low

• White LED

ashes and

goes out

Play or pause

music.

Press .

Pick up or

terminate a

call.

Press . 1 short beep

Reject a call. Press and hold

for 1

second.

1 long beep

Redial the

last number.

Press

twice.

2 short beeps

Switch caller

in a call.

Press and hold

1 long beep

Adjust

volume.

Press ●●/●. Beep at max/

min level

Skip forward. Press and hold

●●.

Skip

backward.

Press and

hold ●.

6EN

Other headphones indicator status

Headphones status Indicator

The headphones are

connected to a Bluetooth

device, while the

headphones in standby

mode or while you are

listening to music.

The blue LED

ashes for every

6 seconds.

The headphones are ready

for pairing.

The LED ashes

blue and white

alternately.

The headphones are on

but not connected to a

Bluetooth device.

The blue LED

ashes quickly.

There is an incoming call. The blue LED

ashes twice per

second.

The battery level is low. The white LED

ashes.

The battery is fully charged. The white LED

is off.

Clip the headset

Note

• To keep the high sound quality, clip the headphones

within 20cm from your mouth.

7EN

5 Technical data

• Up to 9 hours of play time or talk time

• Up to 200 hours of standby time

• Normal time for a full charge: 3 hours

• Rechargeable Lithium-Polymer battery

(200 mAh)

• Bluetooth 3.0, Bluetooth mono support

(Headset Prole - HSP, Hands-Free

Prole - HFP), Bluetooth stereo supported

(Advanced Audio Distribution Prole

- A2DP; Audio Video Remote Control

Prole - AVRCP)

• Operating range: Up to 15 meters (50

feet)

• Digital echo & noise reduction

Note

• Specications are subject to change without notice.

8EN

6 Notice

Declaration of conformity

Hereby,WOOX Innovations declares that this

product is in compliance with the essential

requirements and other relevant provisions

of Directive 1999/5/EC. You can nd the

Declaration of Conformity on www.p4c.philips.

com.

This product has been designed, tested and

manufactured according the European R&TTE

directive 1999/5/EC.

Disposal of your old product

and battery

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

This symbol on a product means that the

product is covered by European Directive

2012/19/EU.

This symbol means that the product contains

a built-in rechargeable battery covered by

European Directive 2013/56/EU which cannot

be disposed of with normal household waste.

We strongly advise you to take your product to

an ofcial collection point or a Philips service

centre to have a professional remove the

rechargeable battery.

Inform yourself about the local separate

collection system for electrical and electronic

products and rechargeable batteries. Follow

local rules and never dispose of the product

and rechargeable batteries with normal

household waste. Correct disposal of old

products and rechargeable batteries helps

prevent negative consequences for the

environment and human health.

Remove the integrated battery

Warning

• Make sure the headphones are disconnected from the

USB charging cable before removing the battery.

If there is no collection/recycling system for

electronic products in your country, you can

protect the environment by removing and

recycling the battery before disposing the

headphones.

Compliance with EMF

This product complies with all applicable

standards and regulations regarding exposure to

electromagnetic elds.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

Table des matières

Autres manuels Philips Lecteur MP3

Philips

Philips GoGEAR SA4DOT02 Manuel utilisateur

Philips

Philips SA238/00 Manuel utilisateur

Philips

Philips GoGear SA2VBE04 Manuel utilisateur

Philips

Philips GoGear HDD1630 Manuel utilisateur

Philips

Philips SA2323 - 2 GB Digital Player Manuel utilisateur

Philips

Philips GoGear SA2815 Manuel utilisateur

Philips

Philips GoGear KEY016 Manuel utilisateur

Philips

Philips EXP101/11 Manuel utilisateur

Philips

Philips GoGEAR SA4MIN 04 Manuel utilisateur

Philips

Philips GoGear SA1MUS16K 16GB Manuel utilisateur

Philips

Philips GoGear SA2MUS08S Manuel utilisateur

Philips

Philips GoGear SA3245 Manuel utilisateur

Philips

Philips GO GEAR SA3RGA02 Manuel utilisateur

Philips

Philips GoGEAR SA5AZU Manuel utilisateur

Philips

Philips Ledino 44992/31/16 Manuel utilisateur

Philips

Philips GoGear SA9100 Manuel utilisateur

Philips

Philips GoGear SA2VBE04WW Manuel utilisateur

Philips

Philips GoGear SA2928 Manuel utilisateur

Philips

Philips SA3115 Manuel utilisateur

Philips

Philips GoGear Digital Audio Player Manuel utilisateur

Philips

Philips GoGear SA2SPK04K Manuel utilisateur

Philips

Philips SA3RGA04KS/37 Manuel utilisateur

Philips

Philips SA3104 Manuel utilisateur

Philips

Philips SA3MXX04VW/37 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
