User Manual

www.philips.com/welcome

AZ302CD Soundmachine

This Manual: http://www.manuallib.com/file/2518225

ALL

PROG

This Manual: http://www.manuallib.com/file/2518225

6 x R14 • UM-2 • C-CELLS

OFF

MWFM

DBB

ON OFF

LINE-IN

This Manual: http://www.manuallib.com/file/2518225

Congratulations on your purchase and

welcome to Philips!

To fully benefit from the support that

Philips offers, register your product at

www.philips.com/welcome.

Supplied Accessories

– AC power cord

Top/front panels (See 1)

VOLUME

–

adjusts volume level.

43 – For MP3-CD only: select albums.

MODE

–

selects different play modes:

e.g. REPEAT or SHUFFLE (random

order).

2 ;

–

starts or pause CD playback

§ ∞

–

selects the next/previous track

– searches forwards/backwards (press and

hold the button) within the current track

–

stops CD playback;

–

erases a CD program

5PROG – programs tracks and reviews the

program

6LIFT TO OPEN – opens/closes the CD

door.

TUNING

– tunes to radio stations

Display

–

shows the CD functions

Back panel (See 1

and

Source selector: CD, FM, MW, OFF

–

selects CD or radio source of sound

–

power off switch

0Telescopic antenna - improves FM

reception.

!AC MAINS~ - inlet for power cord.

DBB

–

turns the bass enhancement on/off.

LINE-IN

– inlet for external audio source.

Bottom panel

$Battery door –

Press on the arrow and

push to

insert 6 x 1.5V R-14/ UM-2/

C-cells.

CAUTION

- Visible and invisible laser radiation.

If the cover is open, do not look at

the beam.

- High voltage! Do not open.You run

the risk of getting an electric shock.

The machine does not contain any

user-serviceable parts.

- Modification of the product could

result in hazardous radiation of

EMC or other unsafe operation.

- Use of controls or adjustments or

performance of precedures other

than herein may result in unsafe

operation.

This set complies with the radio

interference requirements of the

European Union.

English Controls

This Manual: http://www.manuallib.com/file/2518225

Power Supply General Operation

Power Supply

Whenever convenient, use the power supply

cord if you want to conserve battery life.

Make sure you remove the plug from the

set and wall outlet before inserting batteries.

Batteries (not included)

1 Open the battery door and insert 6 batteries,

type R-14, UM-2 or C-cells, (preferably

alkaline) with the correct polarity as indicated

by the "+" and "–" symbols inside the

compartment.

2 Replace the battery door, making sure the

batteries are firmly and correctly in place. The

set is now ready to operate.

Batteries contain chemical substances, so

they should be disposed of properly.

• Incorrect use of batteries can cause electrolyte

leakage and will corrode the compartment or

cause the batteries to burst:

• Do not mix battery types: e.g. alkaline with

carbon zinc. Only use batteries of the same type

for the set.

• When inserting new batteries, do not try to mix

old batteries with the new ones.

• Remove the batteries if the set is not to be used

for a long time.Using AC power

WARNING: Always check you have

completely switched off the set, before

you change or disconnect power supply.

1 Check if the power voltage, as shown on

the type plate located on the bottom

of the set, corresponds to your local

power supply. If it does not, consult your

dealer or service center.

2 Connect the power cord to the AC

MAINS~ inlet and the wall socket. The set

is now connected and ready for use.

3 To switch the set off completely, withdraw

the power cord from the wall socket.

4 Install the unit near the AC outlet and

where the AC power plug can be easily

reached.

• Disconnectthepowercordfromthewall

socket to protect your set during heavy

thunderstorms. Children could seriously

injure themselves as the free end of the

cable may still be live if only the connector

is removed from the MAINS socket at the

back of the unit.

The type plate is located on the bottom

of the set.

Helpful hints:

–

To avoid unnecessary energy consumption,

always adjust the

Source selector

OFF

after using the set.

General operation

Switching on and off and selecting the

function

1 To select your sound source, adjust the

Source selector to: CD, FM or

MW.

2To switch off the set, adjust the Source

selector to

OFF

position.

3To switch to LINE IN mode, connect

an external audio source to the LINE-

IN inlet.

Helpful hints:

• ThesetswitchestoLINE IN mode

automatically when an external audio source

is connected, no matter the set is in CD,

FM or

mode.

• TheLINE-IN inlet is not for earphones.

Adjusting volume and sound

Adjust the sound with the VOLUME and

DBB controls.

This Manual: http://www.manuallib.com/file/2518225

Radio reception

1 Adjust the Source selector to FM or

MW.

2 Turn TUNING to tune to a station.

Helpful hints:

To improve radio reception

• ForFM, extend, incline and turn the

telescopic antenna for best reception.

Reduce its length if the signal is too strong.

• For MW, the set uses a built-in antenna.

Direct this antenna for best reception by

turning the whole set.

About MP3

The music compression technology MP3

(MPEG1 Audio Layer 3) significantly reduce

the digital data of an audio CD while

maintaining CD quality sound.

• Getting MP3 files: you can either

download legal music files from the internet

to your computer hard disc, or create such

files by converting audio CD files in your

computer through appropriate encoder

software. (128kbps bit rate or higher is

recommended for MP3 files.)

• CreatingaMP3CD:burnthemusicfiles

from your computer hard disc on a CDR or

CDRW using your CD burner.

Helpful hints:

–

Make sure that the file names of the MP3 files

end with .mp3 .

– Total number of music files and albums: around

400 (with a typical file name length of 20

characters)

– The length of file names affects the number

of tracks for playback.With shorter file names,

more files can be burned on a disc.

Playing a disc

• ThisCDplayerplaysAudioDiscsincluding

CD-Recordables (CD-R), CD-Rewritables

(CD-RW) and MP3 CD.

• CD-ROM,CD-I,CDV,VCD,DVDor

computer CDs are not possible for playback.

IMPORTANT!

CDs encoded with copyright protection

technologies by some record companies

may be unplayable by this product.

1Adjust the Source selector to CD.

2Open the CD door, and insert a CD with

the printed side facing up, then press the

CD door gently to close.

Display shows

Ü---, and later the total number

of tracks. (See 3)

3Press

to start playback.

4To pause playback, press

Display:

Ü2ﬂashes.

(See 4)

5 To resume, press

again.

6To stop CD playback, press

Helpful hints:

CD play will also stop when:

–

you open the CD door;

– you select

OFF

sound source;

– the CD has reached the end.

Tuner MP3-CD/CD Player

This Manual: http://www.manuallib.com/file/2518225

Selecting a different track

• Press

∞

once or repeatedly until the

desired track number appears in the display.

For MP3-CD: First press 34 once or more

to find your album.

• In the pause/stop position, press 2; to start

playback.

Finding a passage within a

track

1During playback, press and hold ∞or § .

The CD is played at high speed and with reduced

volume.

2When you recognize the passage you want,

release ∞or §to resume normal playback.

Helpful hints:

– When your searching reaches the end of the

last track, the CD goes to stop mode.

Programming track

numbers

You may store up to 20 tracks in the desired

sequence. If you like, store any track more

than once.

1In the stop position, press PROG to

activate programming.

Display:

ÜPROG and 00 ﬂash. (See 5)

2Press

∞

to select your desired track

number.

3Press PROG to store the desired track

number.

Display:

ÜPROG and 00 ﬂash for you to

program the next track.

4Repeat steps 2 to 3to select and store all

desired tracks in this way.

If you attempt to store more than 20 tracks, no

track can be selected and the display

shows ---.

5To play your program, press

;

Helpful hints :

– When playback of your program comes

to the stop position, your set will

return to normal playback. To re-enter

program mode, press PROG in the stop

position.

Reviewing the program

In the stop position, press PROG repeatedly

to see your stored tracks.

Erasing a program

You can erase the contents of the memory by:

– in the stop position, press PROG to

enter program mode, and then press

– selecting

OFF

;

– opening the CD door;

Different play modes:

REPEAT. and SHUFFLE

(See 6,7)

You can play the current track or the whole

disc repeatedly, and combine REPEAT

modes with PROG (PROGRAM).

– plays the current track continuously.

– repeats the entire CD/program.

For MP3:

ALB –plays all tracks of current album

repeatedly.

– plays all tracks in random order.

1 To select play mode, press MODE once or

more.

The display shows the related icon.

2 Press 2; to start playback if in the stop/

pause position.

3 To return to normal playback, press MODE

repeatedly until the modes are no longer

displayed.

– You can also press 9to cancel your play mode.

MP3-CD/CD Player

This Manual: http://www.manuallib.com/file/2518225

CD player and CD handling

• IftheCDplayercannotreadCDscorrectly,

use a cleaning CD to clean the lens before

taking the set to repair.

• ThelensoftheCDplayershouldneverbe

touched!

• Suddenchangesinthesurrounding

temperature can cause condensation on the

lens of your CD player. Playing a CD is then

not possible. Do not attempt to clean the

lens but leave the set in a warm environment

until the moisture evaporates.

• AlwaysclosetheCDdoortoavoidduston

the lens.

• TocleantheCD,wipeinastraightlinefrom

the center towards the edge using a soft,

lint-free cloth. Do not use cleaning agents as

they may damage the disc.

• NeverwriteonaCDorattachanystickers

to it.

Safety information

• Placethesetonaflat,hardandstable

surface so that the system does not tilt.

• WheretheMAINSplugoranappliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Donotexposetheset,batteries,CDsto

humidity, rain, sand or excessive heat caused

by heating equipment or direct sunlight.

• Theapparatusshallnotbeexposedto

dripping or splashing.

• Adequateventilationwithaminimumgap

of 15cm (6 inches) between the ventilation

holes and surrounding surfaces is necessary

to prevent heat build-up.

• Donotcovertheventilationopeningswith

items such as newspapers, table-cloths,

curtains, etc.

• Noobjectsfilledwithliquids,suchasvases,

shall be placed on the apparatus.

• Nonakedflamesources,suchaslighted

candles, should be placed on the apparatus.

• Themechanicalpartsofthesetcontainself-

lubricating bearings and must not be oiled or

lubricated.

• Tocleantheset,useadrycloth.Donot

use any cleaning agents containing alcohol,

ammonia, benzene or abrasives as these may

harm the housing.

Maintenance & Safety (See 8)

This Manual: http://www.manuallib.com/file/2518225

Autres manuels pour AZ302

Table des matières

Autres manuels Philips Lecteur MP3

Philips

Philips SA3RGA04K Manuel utilisateur

Philips

Philips GoGear SA2VBE04 Manuel utilisateur

Philips

Philips GoGear SA1VBE Manuel utilisateur

Philips

Philips Micro jukebox HDD085 Manuel utilisateur

Philips

Philips Soundmachine AZ100C Manuel utilisateur

Philips

Philips GoGear SA054 Manuel utilisateur

Philips

Philips SA1212 Manuel utilisateur

Philips

Philips GoGear SA5285 Manuel utilisateur

Philips

Philips SA261/17B Manuel utilisateur

Philips

Philips GOGEAR VIBE SA2VBE04RC Manuel utilisateur

Philips

Philips GoGear SA2525 Manuel utilisateur

Philips

Philips ACT200 Manuel utilisateur

Philips

Philips SA1ARA08K - GoGear Aria - 8 GB Digital... Manuel utilisateur

Philips

Philips GoGear KEY011 Mode d’emploi

Philips

Philips GoGear SA1345 Manuel utilisateur

Philips

Philips GoGear KEY016 Manuel utilisateur

Philips

Philips KEY 003 Manuel utilisateur

Philips

Philips GoGear SA1OPS08 Manuel

Philips

Philips SA2115 Manuel utilisateur

Philips

Philips GoGear LUXE SA2447BT Manuel utilisateur

Philips

Philips SA4005 Manuel utilisateur

Philips

Philips GoGear SA170/93 Mode d’emploi

Philips

Philips SA3020 - GoGear 2 GB Manuel utilisateur

Philips

Philips AZ1308-37B Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
