Addendum BDL4251VS

www.philips.com/welcome

User Manual (English)

User Manual BDL4251VS, Addendum to User Manual BDL4251V

The User Manual for the BDL4251VS, autostereoscopic 3D display, consists of the User Manual for the

BDL4251V and this Addendum. This addendum states the deviations in the manual of the BDL4251VS

compared to the BDL4251V. If not described in this addendum functionality and working of the BDL4251VS is

the same as the BDL4251V.

User Manual BDL4251VS, Addendum to User Manual BDL4251V

TABLE OF CONTENTS

Contents ...............................................................................................................................................................3!

Connection & Button Overviews...........................................................................................................................3!

Setup Procedure & Connecting a PC ...................................................................................................................4!

Install the LCD Monitor in Portrait Mode...............................................................................................................5!

OSD Menu............................................................................................................................................................5!

Specifications .......................................................................................................................................................5!

User Manual BDL4251VS, Addendum to User Manual BDL4251V

Contents

In the BDL4251VS monitor pack is additionally included:

•BDL4251VS Quick Installation Guide is

•DVI-D cable

Connection & Button Overviews

The BDL4251VS has two additional components mounted at the back of the display (both encircled in red in the

picture below). The grey box at the right hand side is the Dimenco Rendering Core Premium, which is required

to render 2D-plus-Depth input into a full 3D multiview signal. The black box at the bottom center is the power

supply for the rendering box.

The BDL4251VS can only visualize in 3D when the appropriate signal (2D-plus-Depth) is sent to the display via

the rendering box. In other words, putting a video signal directly on one of the video inputs on the terminal panel

of the display will not result in a 3D picture.

The BDL4251VS is equipped with a Dimenco Rendering Core Premium, which can perform real-time multi-view

rendering of stereo (L+R) content (next to 2D-plus-Depth). The real-time stereo to auto-stereo conversion can

be enabled via an online license mechanism. More information can be found at

http://www.dimencodisplays.com/software/ (Real-time conversion License).

User Manual BDL4251VS, Addendum to User Manual BDL4251V

Setup Procedure & Connecting a PC

Connecting to an external PC:

1. Connect the provided DVI cable to the open DVI port on the blue rendering box at the backside of the

display (positioned at the blue area in the picture) and to a PC with the following minimum requirements:

•2 GHz processor,

•an NVidia graphics card (not combined with other type of graphics chips), resolution 1920x1080,

•DVI, HDMI or DisplayPort output (for the latter 2 a converter plug is not included),

•Windows XP or Windows 7 (preferred).

2. Audio can be connected as described in the BDL4251V manual. For accessing some audio inputs it may be

required to temporarily shift the additional power supply, connect the audio plug and reposition the power

supply.

3. Install the Dimenco 3D Player and Control Tool that can be downloaded from:

ftp://ftp.dimenco.eu/

User: DimencoSoftware

Password: playeranddct

Manuals for the Dimenco 3D Player and Control Tool can be downloaded from the same ftp.

4. Optionally download some sample clips from:

ftp://ftp.dimenco.eu/

User: Dimencoguest

Password: 3dconversion

5. Play out the content with the Dimenco Player and control the visualization settings with the Control Tool.

In case there are problems with either the Dimenco 3D Player or Control Tool, please refer to the respective

manuals.

A very important note:

The grey rendering box attached to the back of the display is specific for the panel and cannot be

interchanged for a rendering box of another display (even with the same product number). For this

reason the rendering box (positioned at the blue area in the picture below) has a serial number that is also

mentioned on a label (positioned at the bottom red area in the picture below) on the backside of the display.

User Manual BDL4251VS, Addendum to User Manual BDL4251V

Install the LCD monitor in portrait mode

The BDL4251VS in 3D mode cannot be used in portrait orientation; i.e. no 3D image will be visible upon using

the display in portrait mode.

OSD Menu

For optimal 3D picture quality the sharpness of the display should be set at level 41 (see page 28 of the

BDL4251V User Manual). This sharpness value is already preset, but can be checked and altered via the OSD

menu. The OSD menu can be accessed via the control panel at the backside of the display or via the remote

control.

Specifications

3D Technology

3D display type

Autostereoscopic, Fixed Lenticular

Number of views

3D viewing angle

150 degrees

3D input format

2D-plus-Depth

Multiview rendering

Dimenco rendering core

General

Set dimensions (W x H x D)

968 x 559 x 132 mm

Set dimensions in inch (W x H x D)

38.1 x 22 x 5.2

Product weight

37 kg / 81.6 lb

Note: Technical specifications are subject to change without notice

Philips and the Philips Shield Emblem are registered trade marks of

Koninklijke Philips Electronics N.V. and are used under license

from Koninklijke Philips Electronics N.V.

Specifications are subject to change without notice.
