About This Electronic User's Manual

About This Guide • Other Documents You May Need • Notational Descriptions

About This Guide

This electronic user's guide is intended for anyone who uses the Philips 109B Color Monitor. It

describes the monitor's features, setup, operation and all other information, which is the same exact

information described in our printed version.

The sections are as follows:

●Safety and Troubleshooting Information provides tips and solutions for common problems,

and other related information you may need.

●About This Electronic User's Manual gives overview of what information are included as well

as notation icon descriptions and other documentation you can refer to.

●Product Information gives an overview of the monitor's features and as well as the technical

specifications for this monitor.

●Installing Your Monitor describes the initial setup process and gives an overview of how to

use the monitor.

●On Screen Display provides information on adjusting the settings on your monitor.

●Customer Care and Warranty is a list of worldwide Philips consumer information centers

along with the help desk phone numbers and information on the applicable warranty of your

product..

●Glossary provides more information for technical terms.

●Download Option allows you to consumer keep a copy of the entire manual in your hard drive.

RETURN TO TOP OF THE PAGE

Other Documents You May Need

In addition to this Electronic User's Guide, you may need to refer to the following documentation:

file:///E|/manual/english/109B/about/about.htm (1 of 3)2004-10-19 下午 01:44:07

About This Electronic User's Manual

●Philips Color Monitor Quick Start Guide which summarizes the steps for setting up the

monitor. This is included with this product.

RETURN TO TOP OF THE PAGE

Notational Descriptions

The following subsections describe notational conventions used in this document.

Notes, Cautions, and Warnings

Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in

italic type. These blocks are notes, cautions, and warnings, and they are used as follows:

NOTE: This icon indicates important information and tips that help you make

better use of your computer system.

CAUTION: This icon indicates information that tells you how to avoid either

potential damage to hardware or loss of data.

WARNING: This icon indicates the potential for bodily harm and tells you how

to avoid the problem.

SMART HELP: This icon indicates helpful information when adjusting the On

Screen Display of your monitor.

Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such

cases, the specific presentation of the warning is mandated by regulatory authority.

RETURN TO TOP OF THE PAGE

file:///E|/manual/english/109B/about/about.htm (2 of 3)2004-10-19 下午 01:44:09

About This Electronic User's Manual

broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V.

file:///E|/manual/english/109B/about/about.htm (3 of 3)2004-10-19 下午 01:44:09

Safety & Troubleshooting

Safety and Troubleshooting Information

Safety Precautions and Maintenance • Troubleshooting • Regulatory Information • Other

Related Information

Safety precautions and maintenance

WARNING: Use of controls, adjustments, or procedures other than those

specified in this documentation may result in exposure to shock, electrical

hazards, and/or mechanical hazards.

Read and follow these instructions when connecting and using your computer monitor:

●Disconnect the monitor from the power supply if the monitor is not to be used for an

extended period of time.

●Do not attempt to remove the back cover, as you will be exposed to a shock hazard. The

back cover should only be removed by qualified service personnel.

●Do not place objects on top of the monitor cabinet, objects could fall into vents or cover them

and prevent proper cooling of the monitor's electronic devices.

●To avoid the risk of shock or permanent damage to the set, do not expose the monitor to rain

or excessive moisture.

●Do not use alcohol or ammonia-based liquid to clean the monitor. If necessary, clean with a

slightly damp cloth. Disconnect the monitor from the power supply before cleaning.

Consult a service technician if the monitor does not operate normally when operating instructions of

this manual are followed.

RETURN TO TOP OF THE PAGE

file:///E|/manual/english/109B/safety/safety.htm2004-10-19 下午 01:44:15

109B Product Information

Product Information

Product Features • Technical Specifications • Automatic Power Saving • Physical

Specification • Pin Assignment • Product Views

Product Features

109B10:

●19-inch (18.0" VIS) color monitor with excellent front of screen performance for use with

MACs and PCs

●Autoscan covers horizontal frequencies up to 96 kHz offering a maximum resolution of 1920

x 1440 with flicker free display of 1280 x 1024 at up to 90 Hz

●Flat square High Contrast CRT with high-resolution 0.25 mm dot pitch (0.21 hdp)

●XSD-Xtra Space Design for large screen display in a small footprint: World's shortest 19"

monitor with maximum depth of only 396 mm/15.6" that matches most of today's 15-inch

monitors

●Outstanding ease of use thanks to CustoMax® monitor control software via USB

●Multimedia Base and USB Hub option

●TCO99, E2000, NUTEK, EPA, FCC, CE and ISO9241 certified

RETURN TO TOP OF THE PAGE

Technical Specifications*

CRT

• Size and deflection 19 inch / 46 cm ; 100° deflection angle

• Dot pitch / Grille pitch 0.25 mm

• Horizontal pitch 0.21 mm

• Tube type Shadow mask, flat square, high contrast, anti-glare, anti-

static, anti reflection, light transmission 46%

• Phosphor P22

• Recommended display area 14.0" x 10.4" / 355 x 265 mm

• Maximum display area 14.4" x 10.8" / 365 x 274 mm

file:///E|/manual/english/109B/product/product.htm (1 of 5)2004-10-19 下午 01:44:16

109B Product Information

SCANNING

• Horizontal scanning 30 - 96 KHz

• Vertical scanning 50 - 160 KHz

VIDEO

• Video dot rate 234 MHz

• Input impedance

- Video 75 ohm

- Sync 2.2 kOhm

• Input signal levels 0.7 Vpp

• Sync input signal

Separate sync

Composite sync

• Sync polarities Positive and negative

WHITE COLOR TEMPERATURE

Chromaticity CIE coordinates:

• at 9300 K degrees x = 0.283 / y = 0.297

• at 6500 K degrees x = 0.313 / y = 0.329

• at 5500 K degrees x = 0.332 / y = 0.347

* These information are subject to change without notice.

RETURN TO TOP OF THE PAGE

Automatic Power Saving

If you have VESA's DPMS compliance display card or software installed in your PC, the monitor

file:///E|/manual/english/109B/product/product.htm (2 of 5)2004-10-19 下午 01:44:16

109B Product Information

can automatically reduce its power consumption when not in use. And if an input from a keyboard,

mouse or other input device is detected, the monitor will automatically "wake up". The following

table shows the power consumption and signaling of this automatic power saving features:

Power Management Definition

VESA's Mode Video H-sync V-sync Power Used Power

Saving (%) LED color

ON Active Yes Yes < 95W 0 % Green

Stand-by Blanked No Yes < 10W 89% Yellow

Suspend Blanked Yes No < 10W 89% Yellow

OFF Blanked No No < 3W 97% Amber

This monitor is ENERGY STAR®compliant. As an ENERGY STAR®Partner, PHILIPS has

determined that this product meets the ENERGY STAR®guidelines for energy efficiency.

RETURN TO TOP OF THE PAGE

Physical Specifications

• Dimensions

17.3" x 17.6" x 15.6" / 440 x 447 x 396 mm (including base)

17.3" x 15.7" x 15.6" / 440 x 399 x 396 mm (excluding base)

• Weight 20.0 kg

• Power supply 90 - 264 VAC, 50/60Hz

• Temperature (operating) 0° to 35°C / 32° to 95°F

• Temperature (storage) -25° to +65°C / -13° to -149°F

• Relative humidity 5% to 95%

* Resolution 1280 x 1024, standard size, contrast max., brightness 50%, 9300°, full white pattern.

file:///E|/manual/english/109B/product/product.htm (3 of 5)2004-10-19 下午 01:44:16

109B Product Information

* These information are subject to change without notice.

RETURN TO TOP OF THE PAGE

Pin Assignment

The 15-pin D-sub connector (male) of the signal cable (IBM systems):

No. Assignment

1 Red video input 9 No pin

2 Green video input 10 Logic ground

3 Blue video input 11 Identical output -

connected to pin 10

4Identical output -

connected to pin 10 12 Serial data line (SDA)

5 Ground 13 H. Sync / H+V

6 Red video ground 14 V. Sync (VCLK for DDC)

7 Green video ground 15 Data clock line (SCL)

8 Blue video ground

RETURN TO TOP OF THE PAGE

file:///E|/manual/english/109B/product/product.htm (4 of 5)2004-10-19 下午 01:44:16

109B Product Information

Views

Follow the links to see various views of the monitor and its components.

Front View

Rear View

RETURN TO TOP OF THE PAGE

file:///E|/manual/english/109B/product/product.htm (5 of 5)2004-10-19 下午 01:44:16

Installing your Monitor

Front View • Rear View • 6G3B10 Multimedia Base (option) • PCUH411 USB Hub (option)

Front View

Power button switches your monitor on.

OK button which when pressed will take you to the OSD controls

Contrast hotkey. When the UP arrow is pressed, the adjustment

controls for the CONTRAST will show up.

file:///E|/manual/english/109B/install/install.htm (1 of 4)2004-10-19 下午 01:44:17
