Ideal for roadway lighting, bridge

and tunnel lighting, security lighting,

area floodlighting, railway crossing

lighting and airport lighting

◗Excellent Energy Efficiency

Up to 180 lumens per watt

◗Long Life

18,000 hours rated a erage life

◗Vibration Resistant

Rough ser ice arc tube support system pro ides

protection against shock and ibration

Low Pressure Sodium Lamps (SOX-E, SOX)

High energy efficiency low pressure sodium lamps

for indoor and outdoor applications

180º 150º 150º180º210º

30º0º330º

120º 240º

270º

300º

120º

90º

60º

90º

60º

30º0º

A-A

50 cd 50 cd 50 cd

100 cd 100 cd 100 cd

Candlepower Distribution Curves (cd/1000 lm—candelas per 1000 lumens)

Percent

0 2 4 6 8 10 12 14 16 95 100 105 110

Percent of Nominal

220

200

180

160

140

120

100

Minutes – Warm-up Time Percent of Line Volts

150

140

130

120

110

100

LOW PRESSURE SODIUM LAMPS (SOX-E AND SOX)

Warm-Up Characteristics Effects of Input Voltage Variations

Lamp Volts

Lamp Current

Lamp Watts

Light Output

Lamp Volts

Lamp Current

Lamp Watts

Light Output

Ordering

Code Bulb

SOX-E 18 T-17

SOX 35 T-17

SOX 55 T-17

SOX 90 T-21

SOX 135 T-21

SOX 180 T-21

Max. Diameter (B)

In. mm

2 1⁄854

2 11⁄16 68

MOL1(A)

In. mm

8 1⁄2216

12 3⁄16 310

16 3⁄4425

20 3⁄4528

30 1⁄2775

44 1⁄81120

Physical Dimensions—SOX-E and SOX Lamps

Low Pressure Sodium Lamp Construction

LCL2(C)

In. mm

5 1⁄2141

7 1⁄4184

9 1⁄2243

11 1⁄2292

16 3⁄8416

23 584

Light Length (D)

In. mm

3 5⁄892

7 1⁄2192

12 305

5 7⁄8403

25 7⁄16 646

38 965

1. MOL = Maximum Overall Length

2. LCL = Light Center Length

Base: Double Contact Bayonet-Medium (BY-22d)

1725

1. Non-Metallic- ayonet ase will not corrode or stick in lamp

socket, providing quick,safe relamping. Locking pins on lamp base

assure the lamp locks in socket and cannot vibrate loose. SOX-E

lamps are distinguished by the use of the black bases compared

to the tan bases used on SOX lamps.

2. Sodium Retaining Reservoirs provide even distribution of

sodium for 100% lumen maintenance, long lamp life and lamp

wattage control.

3. U- end Insulation Feature controls lamp wattage rise and

helps provide more consistent lamp life.

4. Rough Service Arc Tube Support System eliminates arc

tube movement along lamp axis yet allows radial arc tube flex.

It provides highest protection from shock and vibration.

5. Uniform Indium Oxide Heat Reflecting Coating creates

highest luminous efficacy of all light sources and contributes to 100%

lumen maintenance by keeping arc tube at the optimum temperature.

6. arium Getter absorbs trace gases to properly maintain correct

arc tube temperature and maximize light output.

7.Triple Coil Electrode with full tungsten support holds more

emission paste for superior life.Tungsten supports prevent

electrode vibration keeping emissive paste on the electrode.

8. Fuse Coil in lamp base provides additional protection to ballast.

By preventing D.C. currents that may occur at end of lamp life,

ballast currents are lower, ballast temperatures are lower and

ballast life is longer.

110º

0º

20º

Product ANSI Nominal Nominal Nominal Nominal Max. Rated Run Up

Number Ordering Ballast Operating on Lamp System Lamp Lamp Starting A erage Time

046677- Code Code Ballast For Watts Watts Lumens Volts Current Current Life (Hrs.) (Minutes)

23404-7 SOX-E 18 L69 SOX 18 18 1800 55 0.36 0.42 18000 15

32781-7 SOX 35 L70 SOX 35 35 60 4550 70 0.6 0.60 18000 7

32151-3 SOX 55 L71 SOX 55 55 80 7800 109 0.59 0.59 18000 7

32152-1 SOX 90 L72 SOX 90 90 125 14300 112 0.91 0.94 18000 9

32153-9 SOX 135 L73 SOX 135 135 178 22600 164 0.95 0.95 18000 9

32799-9 SOX 180 L74 SOX 180 180 220 32000 240 0.91 0.91 18000 9

Light Output Over Life 100%

BaseTemperature Limit 150º C

BulbTemperature Limit 150º C

Lamp Brightness (SOX) 10 cd/cm2

SOX-E 18

SOX 35

SOX 55

SOX 90

SOX 135

SOX 180

Philips Lighting Company

200 Franklin Square Drive ■P.O. ox 6800

Somerset, NJ 08875-6800

1-800-555-0050

www.lighting.philips.com/nam

A Di ision of Philips Electronics North America Corporation

Printed in USA 4/03 P-1785-C

Philips Lighting

281 Hillmount Road

Markham, Ontario

Canada L6C 2S3

1-800-555-0050

www.lighting.philips.com/nam

A Di ision of Philips Electronics Ltd.

Electrical,Technical and Ordering Data (Subject to change without notice)

Operating Positions

Low Pressure Sodium Lamps (SOX-E and SOX)
