Philips PVD1075 Guide d'installation

Theo Heijnen

Euroservice, Support&Training

Training PVD1075

December, 2007

PVD1075: 10,2” LCD TV

Euroservice, Support&Training, Theo Heijnen, December, 2007

Program PVD1075 training

Introduction set

Block Diagram

Mechanical instructions

Service SW Upgrade.

Euroservice, Support&Training, Theo Heijnen, December, 2007

Introduction.

PVD series are the additional features in the DVD portable products

with Digital and Analogue TV functions. With the growing popularity &

adoption of mobile TV experience, the market is ready to accept dedicated

personal & portable TV devices at affordable prices.

PVD1075 – 10.2” portable TV with Digital tuner (DVBT) *)

PVD1078 – 10.2” portable Analog TV tuner *)

PVD1079 – 10.2” portable TV with Digital/Analog turner (DVBT) *)

PVD775 – 7” portable TV with Digital tuner (DVBT) *)

PVD875 – 8.5” portable TV with Digital tuner (DVBT) *)

PVD375 – 3.5” portable TV with Digital tuner (DVBT) *)

*) Introduction not in all countries.

Euroservice, Support&Training, Theo Heijnen, December, 2007

Key Specifications.

30 msResponse time (typical)

200:1Contrast ratio (typical)

Typical 200 cd/m2Brightness

800x600x3 (RGB)Resolution

10.2” LCDSize

Display

n/aDynamic Bass boost

Digital up/down (on main

unit & remote control)

Volume control type

2x1WSpeakers

Sound

/12Stroke version

PVD1075 – Digital TVType Number

Euroservice, Support&Training, Theo Heijnen, December, 2007

4:3 and 16:9Picture Aspect Ratio

MPEG II Chipset

decoder

Video Decoding

PAL/NTSCOutput signal

Full 48~862 MHz

Frequency Range for

VHF and UHF

Input Frequency Band

Active & Passive,

Support auto-scan &

manual-scan

Antenna Model

DVB-TTuner

TV tuner

/12Stroke verion

PVD1075 – Digital TVType Number

Europe + AustraliaSuitable country

1/2,2/3,3/4,5/6,7/8Code Rate

1/4,1/8,1/16,1/32Guard Interval

YES/YESEPG & Teletext

2K/8K FFT for

SFN

Carrier Type

QPSK,16QAM or

64 QAM

Constellations

Modulation

6,7,8 MHzChannel

Bandwidth

MPEG Layer 1

and Layer 2

Audio Decoding

Euroservice, Support&Training, Theo Heijnen, December, 2007

1 headphones out, 3.5mm

(Cut the speaker output when

headphone detected)

Headphone

YesDC-in

n/aS-video

n/aAV out

YesAV in

Connections

The TV does not support

Hard Disk storage or Media

Transfer Protocol (MTP)

format.

USB

Audio: MP3/WMA

Picture: JPEG

Video: DivX

File playback

Yes, support SD standard

SD card slot

/12Stroke verion

PVD1075 – Digital TVType Number

Euroservice, Support&Training, Theo Heijnen, December, 2007

z500 time charging

/ discharging cycle

with not less than

80%

z4 hrs fully charged

Battery

Power: Green

Charging: Red

IR: Green; flashing

when response to

remote signal

LED indication

TV, Card and AV-

Source select

General

/12Stroke verion

PVD1075 –

Digital TV

Type Number

Mains & batteryPower supply

Support 3 hrs

playback

(measure by

power saving and

1/3 max volume)

Charging during

playback

Battery life

Euroservice, Support&Training, Theo Heijnen, December, 2007

Connections

9. SD Card Slot

10. Antenna input

5. USB connection

6. AV in

7. Headphone Jack

8. DC in

Euroservice, Support&Training, Theo Heijnen, December, 2007

Block Diagram

Euroservice, Support&Training, Theo Heijnen, December, 2007

Mechanical.
