Philips 420WN6 Manuel utilisateur

Manual

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/MANUAL.HTM2005-11-07 12:43:09 PM

Safety & Troubleshooting

Safety and Troubleshooting Information

Safety Precautions and Maintenance • FAQs • Troubleshooting • Regulatory Information •

Other Related Information

Safety precautions and maintenance

WARNING: Use of controls, adjustments or procedures other than those

specified in this documentation may result in exposure to shock, electrical

hazards and/or mechanical hazards.

Read and follow these instructions when connecting and using your computer monitor:

●Unplug the monitor if you are not going to use it for an extensive period of time.

●Unplug the monitor if you need to clean it with a slightly damp cloth. The screen many be

wiped with a dry cloth when the power is off. However, never use alcohol, solvents or

ammonia-based liquids.

●Consult a service technician if the monitor does not operate normally when you have

followed the instructions in this manual.

●The casing cover should be opened only by qualified service personnel.

●Keep the monitor out of direct sunlight and away from stoves or any other heat source.

●Remove any object that could fall into the vents or prevent proper cooling of the monitor’s

electronics.

●Do not block the ventilation holes on the cabinet.

●Keep the monitor dry. To avoid electric shock, do not expose it to rain or excessive moisture.

●If turning off the monitor by detaching power cable or DC power cord, wait for 6 seconds

before attach the power cable or DC power cord for normal operation.

●To avoid the risk of shock or permanent damage to the set do not expose the monitor to rain

or excessive moisture.

●When positioning the monitor, make sure the power plug and outlet are easily accessible.

●IMPORTANT: Always activate a screen saver program during your application. If a still

image in high contrast remains on the screen for an extended period of time, it may leave an

'after-image' or 'ghost image' on the front of the screen. This is a well-known phenomenon

that is caused by the shortcomings inherent in the LCD technology. In most cases the after-

image will disappear gradually over a period of time after the power has been switched off.

Be aware that the after-image symptom cannot be repaired and is not covered under

warranty.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAFETY.HTM (1 of 2)2005-11-07 12:44:07 PM

Safety & Troubleshooting

Consult a service technician if the monitor does not operate normally when the operating

instructions given in this manual have been followed.

RETURN TO TOP OF THE PAGE

Installation Locations

●Avoid exposure to heat and extreme cold

●Do not store or use the product in locations exposed to heat, direct sunlight or extreme cold.

●Avoid moving the product between locations with large temperature differences. Choose a

site that falls within the following temperature and humidity ranges.

❍Temperature: 0-35°C 32-95°F

❍Humidity: 20-80% RH

●Do not subject the product to severe vibration or high impact conditions. Do not place the

product inside a car boot.

●Take care not to mishandle this product by either knocking or dropping during operation or

transportation.

●Do not store or use the product in locations where there is a high level of humidity or in dusty

environments. Do not allow water or other liquids to spill on or into the product.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/SAFETY/SAFETY.HTM (2 of 2)2005-11-07 12:44:07 PM

About This Manual

About This Guide • Notational Descriptions

About This Guide

This electronic user's guide is intended for anyone who uses the Philips LCD Monitor TV. It

describes the features, setup, operation and other important information.

It includes the following sections:

●Safety and Troubleshooting Information provides tips and solutions for common problems as

well as other related information you may need.

●About This Electronic User's Manual gives an overview of information included, along with

notation icon descriptions and other documentation for your reference.

●Product Information gives an overview of the monitor's features as well as the technical

specifications for this monitor.

●Installing Your Monitor describes the initial setup process and gives an overview of how to

use the monitor.

●On-Screen Display provides information on adjusting the settings on your monitor.

●Remote Control provides information on adjusting the settings for your TV function.

●Customer Care and Warranty contains a list of worldwide Philips Consumer Information

Centres along with help desk phone numbers and information on the warranty applicable to

your product.

●Download and Print Option transfers this entire manual to your hard drive for easy reference.

RETURN TO TOP OF THE PAGE

Notational Descriptions

The following subsections describe notational conventions used in this document.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/ABOUT/ABOUT.HTM (1 of 2)2005-11-07 12:44:09 PM

About This Manual

Notes, Cautions and Warnings

Throughout this guide blocks of text may be accompanied by an icon and printed in bold or italic

type. These blocks contain notes, cautions or warnings. They are used as follows:

NOTE: This icon indicates important information and tips that help you make

better use of your computer system.

CAUTION: This icon indicates information that tells you how to avoid either

potential damage to hardware or loss of data.

WARNING: This icon indicates the potential for bodily harm and tells you how

to avoid the problem.

Some warnings may appear in alternate formats and may not be accompanied by an icon. In such

cases, the specific presentation of the warning is mandated by the relevant regulatory authority.

RETURN TO TOP OF THE PAGE

broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/ABOUT/ABOUT.HTM (2 of 2)2005-11-07 12:44:09 PM

Product Information

Product Features • Lead-free Product • Technical Specifications • Resolution & Preset

Modes • Philips Pixel Defect Policy • Automatic Power Saving • Physical Specification •

Pin Assignment • Product Views

Product Features

420WN6

●Less management effort for maximum productivity

❍Multiple displays form a daisy chain to show uniform

❍Monitor is network controllable for remote management

❍Input connectors: CVBS, S-video, SCART, YPbPr.

●Better front of screen experience

❍Motion adaptive deinterlacing for razor sharp images

❍3D comb filter separates color for a razor-sharp image

❍WXGA, wide format 1366 x 768 resolution for sharper display

❍Adaptive brightness intensifier technology

❍Ready to display SDTV, EDTV, and HDTV formats

●Great convenience

❍Zoom function to enable tiled matrix application

❍Support hight-bandwidth digital content protection decryption

❍Split screen for dual video/PC display

❍Picture in picture for public display

*RF(TV input) is only available for 420WN6QS.

RETURN TO TOP OF THE PAGE

Lead-free Product

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (1 of 10)2005-11-07 12:44:12 PM

Product Information

Philips eliminated toxic substances like lead from its displays. Lead-free display

helps protect your health and promotes environmentally sound recovery and

disposal of waste from electrical and electronic equipment.Philips complies with the

European Community stringent RoHS Directive mandating restrictions on

hazardous substances in electrical and electronic equipment. With Philips, you can

be confident that your display device does not harm the environment.

Technical Specifications*

LCD PANEL

• Type TFT LCD

• Screen size 42"

• Pixel Pitch 0.227 x 0.681 mm

• LCD Panel type 1366 x 768 pixels

R.G.B. vertical stripe

Hard coating surface, anti-glare polarizer

• Effective viewing area 930.25 x 523.01 mm

• Display Colors 8 bits interface (16.7M colors)

PC SCANNING

• Vertical refresh rate 47Hz-63Hz

• Horizontal frequency 45kHz-50kHz

PC VIDEO

• Video dot rate < 85 MHz

• Input impedance

- Video 75 ohm

- Sync 2.2K ohm

• Input signal levels 0.7 Vpp

• Sync input signal Separate sync

• Sync polarities Positive and negative

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (2 of 10)2005-11-07 12:44:12 PM

Product Information

• Input Frequency WXGA Hsync 48 kHz, Vsync 60 Hz (N.I.)

SVGA Hsync 38 kHz, Vsync 60 Hz (N.I.)

VGA/DVI-D Hsync 31 kHz, Vsync 60 Hz (N.I.)

• Video interface D-sub, S-Video, TV-RF, SCART composite, components

video, and DVI-D

AUDIO

• Input level for PC/SVHS/SCART 500 mV nominal

• Loudspeaker 10W Stereo Audio (200Hz~10kHz, 8 ohm, 10% THD)

OPTICAL CHARACTERISTICS

• Contrast ratio 1100:1 (with DCR on)

• Brightness 500 cd/m2(typ.)

• Peak contrast angle 6 o'clock

• White Chromaticity x: 0.283 y: 0.297 (at 9300°K)

x: 0.313 y: 0.329 (at 6500°K)

x: 0.328 y: 0.344 (at 5700°K)

• Viewing Angle (C/R >5)

Upper >89° (typ.)

Lower >89° (typ.)

Left >89° (typ.)

Right >89° (typ.)

• Response time (G to G) 8 ms(typ.) 12 ms(max.)

sRGB

sRGB is a standard for ensuring correct exchange of colors between different devices (e.g.

digital cameras, monitors, printers, scanners, etc.)

Using a standard unified color space, sRGB will help represent pictures taken by an sRGB

compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are

calibrated and you can rely on the correctness of the colors shown on your screen.

Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to a

predefined setting as well as the color gamut. Therefore it is important to select the sRGB

setting in the monitor's OSD.

To do so, at PC mode, open the OSD by pressing the MENU button of your monitor. Use the

down button to go to COLOR SETTINGS and press MENU again. Then move the down button

to go to NORMAL COLOR and press MENU again.

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (3 of 10)2005-11-07 12:44:12 PM

Product Information

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

Resolution & Preset Modes

• Recommended 1360 x 768 at 60Hz

10 factory preset modes:

Resolution Mode H. freq (kHz) V. freq (Hz)

640x350 VGA-1 31.469 70.086

640x480 VGA VESA 60 31.469 59.940

640x480 VGA VESA 75 37.500 75.000

720x400 IBM VGA 3H 31.468 70.087

800x600 SVGA VESA 56 35.156 56.250

800x600 SVGA VESA 60 37.879 60.317

800x600 SVGA VESA 75 46.875 75.000

1024x768 XGA VESA 60 48.363 60.004

1024x768 XGA VESA 75 60.023 75.029

1280x768 CVT 47.700 60.000

1280x720 CVT 44.772 59.855

1360x768 VESA 47.700 60.000

Video

720x480 480i 15.734 59.940

720x576 576i 15.625 50.000

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (4 of 10)2005-11-07 12:44:12 PM

Product Information

720x480 480p 31.470 60.000

720x576 576p 31.250 50.000

1280x720 720p 37.500 50.000

1280x720 720p 45.000 60.000

1920x1080 1080i 28.125 50.000

1920x1080 1080i 33.750 60.000

RETURN TO TOP OF THE PAGE

Automatic Power Saving

If you have VESA DPMS compliance display card or software installed in your PC, the monitor

can automatically reduce its power consumption when not in use. If an input from a keyboard,

mouse or other input device is detected, the monitor will then 'wake up' automatically. The

following table shows the power consumption and signaling of this automatic power saving

feature:

Power Management Definition

VESA Mode Video H-sync V-sync Power Used LED color

Active On Yes Yes 100 W (typ.) Blue

Sleep Off No No < 5 W Amber

Switch Off Off - - < 3 W Off

RETURN TO TOP OF THE PAGE

Physical Specifications

file:///D|/My%20Documents/dfu/420WN6/english/420wn6/PRODUCT/product.htm (5 of 10)2005-11-07 12:44:12 PM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Téléviseur LCD

Philips

Philips 23PF5320 Manuel utilisateur

Philips

Philips 23-LCD HDTV MONITOR FLAT TV DIGITAL CRYSTAL CLEAR... Manuel d'utilisation

Philips

Philips 19PFL5403/60 Manuel utilisateur

Philips

Philips 22HFL3381D/10 Manuel utilisateur

Philips

Philips 7900 Series Manuel utilisateur

Philips

Philips 42PFL3609/93 Manuel utilisateur

Philips

Philips 27-REAL FLAT SDTV 27PT9015D - Hook Up Guide Manuel utilisateur

Philips

Philips 32PF5321D/37 Manuel utilisateur

Philips

Philips 42PFL9803H/10 Manuel utilisateur

Philips

Philips 26HFL4373D Manuel utilisateur

Philips

Philips 15PF9936 - annexe 2 Manuel utilisateur

Philips

Philips 26PF9956 Manuel utilisateur

Philips

Philips 32PFL5306H/58 Manuel utilisateur

Philips

Philips 6700 SERIES Manuel utilisateur

Philips

Philips 19HFL2807D/10 Manuel utilisateur

Philips

Philips 29HT3312/93R Manuel utilisateur

Philips

Philips 21PT5618/01 Manuel utilisateur

Philips

Philips 39PFL4208/F8 Manuel utilisateur

Philips

Philips 29PT6566 Manuel utilisateur

Philips

Philips 26PFL3405H Manuel utilisateur

Philips

Philips 20PF1000/62 Manuel utilisateur

Philips

Philips 30HF9442 Manuel utilisateur

Philips

Philips 52PFL7932D Manuel utilisateur

Philips

Philips 32PFL1507 Manuel utilisateur

Manuels Téléviseur LCD populaires d'autres marques

LG 32LC4R* Manuel utilisateur

ViewSonic

ViewSonic N4200w-1 VS10945-1M Manuel utilisateur

Salora

Salora 22LED1600 Manuel utilisateur

Samsung

Samsung LA32E420 Mode d’emploi

Dell

Dell W1900 19 Instructions d'utilisation

Samsung

Samsung LN40C670M1F Manuel utilisateur

Samsung

Samsung Series 4+ Manuel utilisateur

Samsung

Samsung 5 Series Manuel utilisateur

Grundig

Grundig 40 VLE 8230 BP Manuel utilisateur

Sony

Sony Bravia XBR-43X830C Manuel utilisateur

LG 32LS350 Manuel utilisateur

VIORE

VIORE LED32VF60 Manuel utilisateur

Toshiba

Toshiba Regza 42HL167 Manuel utilisateur

JVC

JVC LT-32A220 Manuel utilisateur

Sony

Sony Bravia KDL-V32XBR2 Manuel utilisateur

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Manuel utilisateur

Dynex

Dynex DX-40L261A12 Manuel utilisateur

JVC

JVC LT-23C50BU Manuel utilisateur
