Real Flat Television

29/34PT8845

User manual

IMPORTANT

Before you begin:

Make sure your package includes the following items:TV and mains cord,

remote control, user manual, antenna cable (optional) and Coaxial

cable (optional).

Attention:

1. Read your manual first – your Philips TV comes with a well-designed

remote control and onscreen display to ensure your TV is easy to

operate.

2. The tips provided in this manual will save you time and money as

charges for TV installation and adjustments of customer controls are

not covered under the warranty.

3. For information outside of this manual, such as sales locations and

other Philips products, please visit www.philips.com which will

automatically link you to your local Philips website.

4. Please refer to the ‘Tips’ page before calling for service.

5. In case you need to call for service, we recommend that you call from

your room where your TV set is and have your remote control,

warranty card,TV model and serial number on hand.

6 Do not throw away packaging materials:

• without thorough inspection for parts and accessories that may be

packed separately inside the carton.

• during the warranty period should you need to exchange the set.

Recycling:

The materials used in your set are either reusable or can be recycled.

To minimise environmental waste, specialist companies collect used

appliances and dismantle them after retrieving any materials that can be

used again (ask your dealer for further details).

Disclaimer: Graphics in this manual are for illustration purpose and may not represent the

actual product

Table of Contents

General

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . 2

Useful Tips . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

What’s Hot

Picture Scanning mode . . . . . . . . . . . . . . . . . . . . 3

YPbPr Digital High Deﬁnition input . . . . . . . . 3

Installation

Installing your television set . . . . . . . . . . . . . . . 4

The keys on the TV set . . .. . . . . . . . . . . . . . . . . 4

Remote control keys . . . . . . . . . . . . . . . . . . . . 5

Language . . . . .

.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Auto Store . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Manual Store. . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . 8

Sort . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Channel Edit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Operation

Picture settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Sound settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Features settings . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Child Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Active Ctrl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Demo.................................... 13

Autopicture Booster. . . . . . . . . . . . . . . . . . . . . . . .

Personal Zapping . . . . . . . . . . . . . . . . . . . . . 14

Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Peripherals

DVD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Video recorder . . . . . . . . . . . . . . . . . . . . . . 17

Other equipment ......................

Ampliﬁer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Sideconnections....................... 18

Practical information

Tips................................. 19

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Speciﬁcations ............................ . 21

Safety information

•Remove mains plug when :

– the indicator light below the TV screen is flashing continuously.

– a bright white line is displayed across the screen.

– there is a lightning storm.

– the set is left unattended for a prolonged period of time.

• cleaning the TV screen. Never use abrasive cleaning agents such as scouring powder.

Use a slightly damp chamois leather or soft cloth.

• No naked flame sources, such as lighted candles, should be placed on top of the TV or in

the vicinity.

• Do not place your TV set under direct sunlight or heat.

• Leave at least 10 cm around each side of TV set to allow for proper ventilation.

• Avoid placing your set (e.g. near the window) where it is likely to be exposed to rain

or water.

• No objects filled with liquids should be placed on top the TV so as to avoid dripping

or splashing on the set.

Useful information

• Do not leave your set on standby mode for a prolonged period of time. Switch off set

to allow it to be demagnetised. A demagnetised set supports good picture quality.

• Do not shift or move the set around when it is switched on. Unevenness in colour in

some parts of the screen may occur.

• Never try to repair a defective TV yourself. Always check with a skilled service personnel.

What’s Hot

Picture scanning

Your Philips TV has been built with scanning features to enhance your TV viewing.All you

need is to select your desired mode to enjoy sharper and clearer pictures.The description

below will help you make your choice.

Auto

If you are undecided of which mode to choose, select Auto and let your TV decide for you

automatically!

100 Hz Digital Scan (available only for PAL signal)

Working with three lines of picture information, the 3-line digital comb filter in the TV

virtually eliminates both horizontally and vertically hanging dots, as well as dot crawl.

Progressive Scan

Doubles the vertical resolution of the image to produce a noticeably sharper picture.

How to access

&Press the

éPress the

“Use the

‘Ë

key.

The Main Menu will be call up.

to select the Scan mode.

key to select Auto, 100 Hz or Prog Scan.

To quit the menus, press .

YPbPr Digital High Definition input

When you have a digital equipment with a 480p/576p/720p/1080p/1080i (PAL version) or

480p/720p/1080i/1080p (NTSC version) output (e.g. a digital set top box or Progressive

Scan DVD player), connect it to the HD 2Fh input.

How to access

&Connect the TV’s green, blue and red Y Pb Pr (HD in) jacks to the corresponding

COMPONENT VIDEO OUT jacks on the equipment.

éConnect the TV’s red and white (R and L) AUDIO IN jacks from AV2 IN to the

corresponding AUDIO OUT jacks on the player. Match the cable colour to the jacks’ colour.

The red jack is the Right audio channel and the white jack is the Left audio channel.

“Turn on the TV and the equipment. Set the TV to a channel displayed as YPbPr to playback.

Installing your television set

Positioning the television set Remote control

Place yourTV on a solid, stable surface,

leaving a space of at least 10 cm around the

appliance.

Connections

10 cm

10 cm 10 cm

• Insert the aerial plug into the socket

at the rear of the set.

If you are using an indoor aerial, reception

may be difficult in certain conditions. You

can improve reception by rotating the

aerial. If the reception remains poor, you

will need to use an external aerial.

• Insert the mains plug into a wall socket.

Insert the two AA-sized batteries (supplied)

making sure that they are the right way

round.

The batteries supplied with this appliance do

not contain mercury or nickel cadmium.

If you have access to a recycling facility, please do

not throw away your used batteries (if in doubt,

consult your dealer).

Switching on

To switch on the set, press the on/off key.

A red indicator means that the television is on

standby mode. Refer to the next page on ‘Remote

Control keys’ for the various keys that you can

use to switch on the set.An indicator light will

flash when it is receiving signal from the remote

control.

The keys on the TV set

The television set has 4 keys which are

located in front. On some models, the keys

are located at the top of the set.

The VOLUME – + keys are used to adjust the

sound louder or softer.The CHANNEL v ^

keys are used to change the channels.

To access or exit the main menu, press down

theVOLUME – + keys, simultaneously.

To select an item in the main menu, press the

CHANNEL v or ^ key.

To select an adjustment, press down the

VOLUME – or + key.

Remote control keys (Choose the right remote control that

came with your TV set)

Personal Zapping

You can surf up to 10 personal

channels for each key (p. 14)

Sleeptimer

Not applicable.

Add Personal Zapping list

Adds and stores channels into

Personal Zapping list (p. 14)

Smart Sound

Used to access a series of stored

settings:Theatre, Music,Voice or

Personal.

To call up or exit menus.

Cursor

These 4 keys are used to move

around the menus or provide direct

access to the different picture

formats

Volume

To adjust the sound level.

Digit keys

Direct access to the channels. For

a 2-digit channel, enter the 2nd

digit before the dash disappears.

Alternate channel

Switches between the current

and the previous channel.

A/C

POWER

Standby

Lets you place the TV set on standby.

To turn on the TV, press CH + or –,

, AV, A/CH or digit keys.

AV channel selection

Press several times to select AV1,

CVI,AV2,YPbPr or Side.

Delete Personal Zapping list

Deletes stored channels from

Personal Zapping list (p. 14)

Smart Picture

Used to access a series of stored

settings: Rich, Natural, Soft, DVD/

VCD or Personal.

Incredible Surround

To enable/disable the Incredible

Surround feature. In stereo, the

speaker sounds appear further apart.

In mono, a pseudo-spatial effect is

obtained.

During stereo transmission, to

switch from Stereo to Mono.

During dual sound transmission, to

switch betwen language or .

(For NTSC version: Select Mono,

Stereo, or SAP).

Channel selection

To access the next or previous

channel.The number and sound

modes are displayed for a few

moments whenever you select a

new channel.

Mute

To turn on or turn off sound.

On screen display

To display/clear the on screen

information. Hold down key for 3

seconds to activate permanent

display of channel number.This key

is also used to exit from the menu.

Remote control keys (Choose the right remote control that

came with your TV set)

Teletext /Personal Zapping

In teletext mode; the colour keys

allows direct access to an item or

corresponding pages (p 15-16)

In Personal Zapping mode; you can

surf up to 10 personal channels

for each key (p14)

Not applicable.

Add Personal Zapping list

Adds and stores channels into

Personal Zapping list (p. 14)

Not applicable.

Smart Sound

Used to access a series of stored

settings:Theatre, Music,Voice or

Personal.

To call up or exit menus.

Volume

To adjust the sound level.

Mute

To turn off or turn on sound.

Alternate channel

To switch between the current and

the previous channel.

During stereo transmission, to switch

from Stereo to Mono. During dual

sound transmission, to switch between

language and . (For NTSC version:

select Mono, Stereo, or SAP).

Digit keys

Direct access to the channels. For a

2-digit channel, enter the second

digit before the first digit disappears.

Sleeptimer

Not applicable.

Standby

Lets you place the TV set on standby.

To turn on the TV, press CH + or –,

, AV , A/CH or digit keys

Teletext keys (p. 15-16)

Delete Personal Zapping list

Deletes stored channels from

Personal Zapping list (p. 14)

Smart Picture

To access a series of stored

settings: Rich, Natural, Soft,

DVD/VCD or Personal.

Incredible Surround

To enable/disable the Incredible

Surround feature. In stereo, the

speaker sounds appear further

apart. In mono, a pseudo-spatial

effect is obtained.

Cursor

These 4 keys are used to move

around the menus or provide

direct access to the different

picture formats.

Channel selection

To access the next or previous

channel.The number and sound

modes are displayed for a few

moments whenever you select a

new channel.

Teletext key (p. 15-16)

On screen display

To display/clear the on-screen

information. Press the key for 5

seconds to activate permanent

display of channel number.This key

is also used to exit from the menu.

AV channel selection

Press several times to select

AV1, CVI, AV2, YpbPr, or Side.

Language

When there is no signal input to the TV, you

may encounter instability of the screen display.

In this instance, please use the

key to select

an AV channel.

(On screen display may differ from actual TV)

The Language feature is used to change the

display language for menus.

&Press the key.

éWith the cursor, select the Install menu

and followed by Language.

“Use the key to select a language of

your choice.

‘To quit the menus, press Ë.

(applicable to certain TV models only)

Auto Store

This menu is used to store all available &Press the key.

channels automatically. éWith the cursor, select the Install menu

and follow by the Auto Store.

“Use the key to start auto store.

All the available TV channels will be stored

automatically.

This operation takes a few minutes.The display

shows the progress of the search and the

number of channels found.

‘To quit the menus, press Ë.

If no channels are found, consult the possible

solutions on p.18.

Manual Store (applicable to certain TV models only)

This menu is used to store channels one at a

time.

&Press the key.

éWith the cursor, select the Install menu

and followed by the Manual.

“Colour Sys(tem): use the or

key to select the desired colour system;

Auto, PAL, NTSC 3.58, NTSC 4.43

and SECAM.

‘Sound Sys(tem): use the or

key to select the desired sound system;

Auto, BG, I, DK or M.

(Search: press . The search starts.

Once a channel is found, the scanning

stops. Go to the next step.

If no picture is found, consult the possible

solutions ('Tips' page).

§Channel: enter the required channel

with the , or digit keys.

Fine Tune: if the reception is not

satisfactory, adjust using the or

keys.

!Store: press .The channel is stored.

çRepeat steps “to ‘for each channel

you wish to store.

àTo quit the menus, press Ë.

Sort (applicable to certain TV models only)

This feature allows you to rearrange channels

according to your preference.

&Press the key.The Main menu is

displayed on the screen.

éWith the cursor, select the Install menu

followed by the Sort menu.

“Use the or key to select the

channel number you want to change

from (e.g. 001) and confirm selection with

the key.

‘Use the or key to select the

channel number you want to change to

(e.g. 004) and confirm selection with the

key.

The change is done. Channel 4 will move up to

channel 3 and channel 3 will move up to channel

(Repeat steps “ and ‘ for each

channel you wish to change.

§To quit the menus, press .

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Téléviseur LCD

Philips

Philips 26HFL4372D Manuel utilisateur

Philips

Philips 47PFL7403D Manuel utilisateur

Philips

Philips 42PFL5332D Manuel utilisateur

Philips

Philips 32RF82S Manuel utilisateur

Philips

Philips 32PFL7674H Manuel utilisateur

Philips

Philips 32HFL5662L/F7 Manuel utilisateur

Philips

Philips 22PFL3505D Manuel utilisateur

Philips

Philips 40PFL8605H Manuel utilisateur

Philips

Philips 42PFL7603H/10 Manuel utilisateur

Philips

Philips 32PFL6606M 37PFL6606M Manuel utilisateur

Philips

Philips 19PFL3504D/F7 Manuel utilisateur

Philips

Philips 52PFL5604H/12 Manuel utilisateur

Philips

Philips 40PFL5505D Manuel utilisateur

Philips

Philips 52PFL8605D/93 Manuel utilisateur

Philips

Philips 40PFL6636T Manuel utilisateur

Philips

Philips 55PFL5706 Manuel utilisateur

Philips

Philips 42PFL3603D Manuel utilisateur

Philips

Philips 19PFL3403 Manuel utilisateur

Philips

Philips 32PFL5237A/V7 Manuel utilisateur

Philips

Philips 32HFL4351D Manuel utilisateur

Philips

Philips BDL323I Manuel

Philips

Philips 26PFL3606H Manuel utilisateur

Philips

Philips 17-LCD HDTV MONITOR FLAT TV CRYSTAL CLEAR III... Manuel utilisateur

Philips

Philips 21PT5027C/79 Manuel utilisateur

Manuels Téléviseur LCD populaires d'autres marques

LG 32LC4R* Manuel utilisateur

ViewSonic

ViewSonic N4200w-1 VS10945-1M Manuel utilisateur

Salora

Salora 22LED1600 Manuel utilisateur

Samsung

Samsung LA32E420 Mode d’emploi

Dell

Dell W1900 19 Instructions d'utilisation

Samsung

Samsung LN40C670M1F Manuel utilisateur

Samsung

Samsung Series 4+ Manuel utilisateur

Samsung

Samsung 5 Series Manuel utilisateur

Grundig

Grundig 40 VLE 8230 BP Manuel utilisateur

Sony

Sony Bravia XBR-43X830C Manuel utilisateur

LG 32LS350 Manuel utilisateur

VIORE

VIORE LED32VF60 Manuel utilisateur

Toshiba

Toshiba Regza 42HL167 Manuel utilisateur

JVC

JVC LT-32A220 Manuel utilisateur

Sony

Sony Bravia KDL-V32XBR2 Manuel utilisateur

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Manuel utilisateur

Dynex

Dynex DX-40L261A12 Manuel utilisateur

JVC

JVC LT-23C50BU Manuel utilisateur
