Safety & Troubleshooting

Safety and Troubleshooting Information

Safety Precautions and Maintenance • FAQs • Troubleshooting • Regulatory Information•

Other Related Information

Safety precautions and maintenance

WARNING: Use of controls, adjustments or procedures other than those

specified in this documentation may result in exposure to shock, electrical

hazards and/or mechanical hazards.

Read and follow these instructions when connecting and using your computer monitor:

Operation:

●Keep the monitor out of direct sunlight and away from stoves or any other heat source.

●Remove any object that could fall into ventilation holes or prevent proper cooling of the

monitor’s electronics.

●Do not block the ventilation holes on the cabinet.

●When positioning the monitor, make sure the power plug and outlet are easily accessible.

●If turning off the monitor by detaching the power cable or DC power cord, wait for 6 seconds

before attaching the power cable or DC power cord for normal operation.

●Please use approved power cord provided by Philips all the time. If your power cord is

missing, please contact with your local service center. (Please refer to Customer Care

Consumer Information Center)

●Do not subject the LCD monitor to severe vibration or high impact conditions during

operation.

●Do not knock or drop the monitor during operation or transportation.

Maintenance:

●To protect your display from possible damage, do not put excessive pressure on the LCD

panel. When moving your monitor, grasp the frame to lift; do not lift the monitor by placing

your hand or fingers on the LCD panel.

●Unplug the monitor if you are not going to use it for an extensive period of time.

●Unplug the monitor if you need to clean it with a slightly damp cloth. The screen may be

wiped with a dry cloth when the power is off. However, never use organic solvent, such as,

alcohol, or ammonia-based liquids to clean your monitor.

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/SAFETY/SAFETY.HTM (1 of 2)2005-07-08 5:42:10 PM

Safety & Troubleshooting

●To avoid the risk of shock or permanent damage to the set, do not expose the monitor to

dust, rain, water, or excessive moisture environment.

●If your monitor gets wet, wipe it with dry cloth as soon as possible.

●If foreign substance or water gets in your monitor, please turn the power off immediately and

disconnect the power cord. Then, remove the foreign substance or water, and send it to the

maintenance center.

●Do not store or use the LCD monitor in locations exposed to heat, direct sunlight or extreme

cold.

●In order to maintain the best performance of your monitor and use it for a longer ligetime,

please use the monitor in a location that falls within the following temperature and humidity

ranges.

❍Temperature: 5-40°C 41-104°F

❍Humidity: 20-80% RH

Service:

●The casing cover should be opened only by qualified service personnel.

●If there is any need for any document for repair or integration, please contact with your local

service center. (please refer to the chapter of "Consumer Information Center")

●For transportation information, please refer to "Physical Specifications".

●Do not leave your monitor in a car/trunk under direct sun light.

Consult a service technician if the monitor does not operate normally, or you are not

sure what procedure to take when the operating instructions given in this manual have

been followed.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/SAFETY/SAFETY.HTM (2 of 2)2005-07-08 5:42:10 PM

About This Manual

About This Guide • Notational Descriptions

About This Guide

This electronic user's guide is intended for anyone who uses the Philips LCD Monitor TV. It

describes the features, setup, operation and other important information.

It includes the following sections:

●Safety and Troubleshooting Information provides tips and solutions for common problems as

well as other related information you may need.

●About This Electronic User's Manual gives an overview of information included, along with

notation icon descriptions and other documentation for your reference.

●Product Information gives an overview of the monitor's features as well as the technical

specifications for this monitor.

●Installing Your Monitor describes the initial setup process and gives an overview of how to

use the monitor.

●On-Screen Display provides information on adjusting the settings on your monitor.

●Remote Control provides information on adjusting the settings for your TV function.

●Customer Care and Warranty contains a list of worldwide Philips Consumer Information

Centres along with help desk phone numbers and information on the warranty applicable to

your product.

●Download and Print Option transfers this entire manual to your hard drive for easy reference.

RETURN TO TOP OF THE PAGE

Notational Descriptions

The following subsections describe notational conventions used in this document.

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/ABOUT/ABOUT.HTM (1 of 2)2005-07-08 5:42:12 PM

About This Manual

Notes, Cautions and Warnings

Throughout this guide blocks of text may be accompanied by an icon and printed in bold or italic

type. These blocks contain notes, cautions or warnings. They are used as follows:

NOTE: This icon indicates important information and tips that help you make

better use of your computer system.

CAUTION: This icon indicates information that tells you how to avoid either

potential damage to hardware or loss of data.

WARNING: This icon indicates the potential for bodily harm and tells you how

to avoid the problem.

Some warnings may appear in alternate formats and may not be accompanied by an icon. In such

cases, the specific presentation of the warning is mandated by the relevant regulatory authority.

RETURN TO TOP OF THE PAGE

broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V.

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/ABOUT/ABOUT.HTM (2 of 2)2005-07-08 5:42:12 PM

Product Information

Product Features • Technical Specifications • Resolution & Preset Modes • Philips Pixel

Defect Policy • Automatic Power Saving • Physical Specification • Pin Assignment •

Product Views

Product Features

BDL3221V

●Less management effort for maximum productivity

❍Multiple displays form a daisy chain to show uniform

❍Monitor is network controllable for remote management

❍Input connectors: CVBS, S-video, SCART, YPbPr, and RF (TV input)

●Better front of screen experience

❍Montion adaptive deinterlacing for razor sharp images

❍3D comb filter separates color for a razor-sharp image

❍WXGA, wide format 1366 x 768 resolution for sharper display

❍Adaptive brightness intensifier technology

❍Ready to display SDTV, EDTV, and HDTV formats

●Great convenience

❍Zoom function to enable tiled matrix application

❍Support hight-bandwidth digital content protection decryption

❍Split screen for dual video/PC display

❍Picture in picture for public display

* RF(TV input) is only available for 320WN6QS

RETURN TO TOP OF THE PAGE

Technical Specifications*

LCD PANEL

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/PRODUCT/PRODUCT.HTM (1 of 9)2005-07-08 5:42:15 PM

Product Information

• Type TFT LCD

• Screen size 31.51inch

• Pixel Pitch 0.17 x 0.511 mm

• LCD Panel type 1366 x 768 pixels

R.G.B. vertical stripe

Hard coating surface, anti-glare polarizer

• Effective viewing area 697.7 x 392.2 mm

• Display Colors 8 bits interface (16.7M colors)

PC SCANNING

• Vertical refresh rate 56Hz-75Hz

• Horizontal frequency 30kHz-63kHz

PC VIDEO

• Video dot rate < 85 MHz

• Input impedance

- Video 75 ohm

- Sync 2.2K ohm

• Input signal levels 0.7 Vpp

• Sync input signal Separate sync

• Sync polarities Positive and negative

• Input Frequency WXGA Hsync 48 kHz, Vsync 60 Hz (N.I.)

SVGA Hsync 38 kHz, Vsync 60 Hz (N.I.)

VGA/DVI-D Hsync 31 kHz, Vsync 60 Hz (N.I.)

• Video interface D-sub, S-Video, TV-RF, SCART composite, components

video, and DVI

AUDIO

• Input level for PC/SVHS/SCART 500 mV nominal

• Loudspeaker 10W Stereo Audio (10W/channel RMS x2, 200Hz~10kHz, 8

ohm, 10% THD)

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/PRODUCT/PRODUCT.HTM (2 of 9)2005-07-08 5:42:15 PM

Product Information

OPTICAL CHARACTERISTICS

• Contrast ratio 1200:1(with DCR on)

• Brightness 500 cd/m2(typ.)

• Peak contrast angle 6 o'clock

• White Chromaticity x: 0.283 y: 0.297 (at 9300°K)

x: 0.313 y: 0.329 (at 6500°K)

x: 0.328 y: 0.344 (at 5700°K)

• Viewing Angle (C/R >5)

Upper >89° (typ.)

Lower >89° (typ.)

Left >89° (typ.)

Right >89° (typ.)

• Response time (G to G) 8ms(typ.) 12ms(max.)

sRGB

sRGB is a standard for ensuring correct exchange of colors between different devices (e.g.

digital cameras, monitors, printers, scanners, etc.)

Using a standard unified color space, sRGB will help represent pictures taken by an sRGB

compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are

calibrated and you can rely on the correctness of the colors shown on your screen.

Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to a

predefined setting as well as the color gamut. Therefore it is important to select the sRGB

setting in the monitor's OSD.

To do so, at PC mode, open the OSD by pressing the MENU button of your monitor. Use the

down button to go to COLOR SETTINGS and press MENU again. Then move the down button

to go to NORMAL COLOR and press MENU again.

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/PRODUCT/PRODUCT.HTM (3 of 9)2005-07-08 5:42:15 PM

Product Information

Resolution & Preset Modes

• Recommended 1366 x 768 at 60Hz

10 factory preset modes:

Resolution Mode H. freq (kHz) V. freq (Hz)

640x350 VGA-1 31.469 70.086

640x480 VGA VESA 60 31.469 59.940

640x480 VGA VESA 75 37.500 75.000

720x400 IBM VGA 3H 31.468 70.087

800x600 SVGA VESA 56 35.156 56.250

800x600 SVGA VESA 60 37.879 60.317

800x600 SVGA VESA 75 46.875 75.000

1280x1024 XGA VESA 60 48.363 60.004

1280x1024 XGA VESA 75 60.023 75.029

1280x768 GTF 60 47.700 60.000

1280x768 Wincomm 45.113 56.260

1360x768 VESA 47.700 60.000

Video

720x480 480i 15.734 59.940

720x576 576i 15.625 50.000

720x480 480p 31.470 60.000

720x576 576p 31.250 50.000

1280x720 720p 28.200 50.000

1280x720 720p 33.750 60.000

1920x1080 1080i 37.500 50.000

1920x1080 1080i 45.000 60.000

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/PRODUCT/PRODUCT.HTM (4 of 9)2005-07-08 5:42:15 PM

Product Information

RETURN TO TOP OF THE PAGE

Automatic Power Saving

If you have VESA DPMS compliance display card or software installed in your PC, the monitor

can automatically reduce its power consumption when not in use. If an input from a keyboard,

mouse or other input device is detected, the monitor will then 'wake up' automatically. The

following table shows the power consumption and signaling of this automatic power saving

feature:

Power Management Definition

VESA Mode Video H-sync V-sync Power Used LED color

Active On Yes Yes 100 W (typ.) Blue

Sleep Off No No < 5 W Amber

Switch Off Off - - < 3 W Off

RETURN TO TOP OF THE PAGE

Physical Specifications

• Dimension (WxHxD) * 1014mm x 517mm x 244mm (incl. Pedestal, Speakers)

794mm x 490mm x 130mm (w/o Pedestal, Speakers)

• Weight 19.2 kg (incl. Pedestal, Speakers)

• Power supply 100 — 240 VAC, 60 — 50 Hz

• Power consumption PC Mode: 100 W (typ.)

TV Mode: 130 W (typ.)

• Temperature (operating) 5° C to 35° C

• Relative humidity 20% to 80%

file:///D|/My%20Documents/dfu/320WN6/english/320wn6/PRODUCT/PRODUCT.HTM (5 of 9)2005-07-08 5:42:15 PM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Téléviseur LCD

Philips

Philips 42TA2000/93 Manuel utilisateur

Philips

Philips 55PFL5705D/F7 Manuel utilisateur

Philips

Philips 21PT5547/94 Manuel utilisateur

Philips

Philips 39PHT4002S/70 Manuel utilisateur

Philips

Philips PFL43x8 Manuel utilisateur

Philips

Philips 22HFL3350D Manuel utilisateur

Philips

Philips 32PF7321D/37 Manuel utilisateur

Philips

Philips Aurea 40HFL9561A Manuel utilisateur

Philips

Philips EasySuite 22HFL3233D Manuel utilisateur

Philips

Philips 52PFL7203H Manuel utilisateur

Philips

Philips 46PFL9605D Manuel utilisateur

Philips

Philips T260XW02V4 Manuel utilisateur

Philips

Philips Cineos 42PF9531/93 Manuel utilisateur

Philips

Philips 47HFL4381D Manuel utilisateur

Philips

Philips 29PT5642/55 Manuel utilisateur

Philips

Philips 32PFL3518/77 Manuel utilisateur

Philips

Philips 19PFL4505D Manuel utilisateur

Philips

Philips 58PFL6940 Manuel utilisateur

Philips

Philips 47PFL3704D Manuel utilisateur

Philips

Philips 47PFL5604H - annexe 2 Manuel utilisateur

Philips

Philips 20HF4003F/10 Manuel utilisateur

Philips

Philips 55PFL6606H/60 Manuel utilisateur

Philips

Philips 32PFL6506/V7 Manuel utilisateur

Philips

Philips 42HFL7406D Manuel utilisateur

Manuels Téléviseur LCD populaires d'autres marques

LG 32LC4R* Manuel utilisateur

ViewSonic

ViewSonic N4200w-1 VS10945-1M Manuel utilisateur

Salora

Salora 22LED1600 Manuel utilisateur

Samsung

Samsung LA32E420 Mode d’emploi

Dell

Dell W1900 19 Instructions d'utilisation

Samsung

Samsung LN40C670M1F Manuel utilisateur

Samsung

Samsung Series 4+ Manuel utilisateur

Samsung

Samsung 5 Series Manuel utilisateur

Grundig

Grundig 40 VLE 8230 BP Manuel utilisateur

Sony

Sony Bravia XBR-43X830C Manuel utilisateur

LG 32LS350 Manuel utilisateur

VIORE

VIORE LED32VF60 Manuel utilisateur

Toshiba

Toshiba Regza 42HL167 Manuel utilisateur

JVC

JVC LT-32A220 Manuel utilisateur

Sony

Sony Bravia KDL-V32XBR2 Manuel utilisateur

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Manuel utilisateur

Dynex

Dynex DX-40L261A12 Manuel utilisateur

JVC

JVC LT-23C50BU Manuel utilisateur
