Philips 20HF8432/98 Manuel utilisateur

20HF

23HF

30HF

42HF

Instruction for Use

Care of the screen

Do not touch, push, rub or strike the screen with anything hard as this may scratch or damage the screen

permanently. Do not rub with chemically treated cloth. Do not touch the surface with bare hands or greasy

cloth. Unplug the TV before cleaning the screen. When the surface becomes dusty, please wipe gently with

absorbent cotton or other soft materials like chamois. Do not use acetone, toluene and alcohol because

they cause chemical damage.

Do not use liquid cleaners or aerosol cleaners. Wipe off saliva or water drops from the screen as soon as

possible as their long time contact with the screen may cause deformations and colour fading over time.

Warning concerning stationary images on the TV screen (For Plasma TV only)

characteristic of Plasma Display Panels is that displaying the same image for a long time can cause a

permanent after-image to remain on the screen. This is called phosphor burn in. Normal use of the Plasma

TV should involve the showing of pictures that contain constantly moving and changing images that fill the

screen.

Warning concerning VGA/DVI display mode

s this product processes in VGA/DVI mode, some diagonal lines may be seen due to environmental

interference. This will not affect the computer signal performance that displays in VGA/DVI mode.

Environmental

• Your television contains material that can be recycled and reused by specialized companies. Please

find out about local regulations on the disposal of your old television set. Pay particular attention

to the disposal of exhausted batteries.

• Your television consumes energy in the stand-by mode. Energy consumption contributes to air

and water pollution. We advise you to switch off your television overnight instead of leaving it in

stand-by mode.

Wall mounting instructions/Table stand

According to the type of TV you’ve purchased a wall mount bracket and/or stand may be supplied.

To mount the supplied stand and/or wall mount bracket, please refer to attached separate

instructions. Make sure that the wall mount is fixed securely so that it meets safety standards.

- 2 -

Make sure that air can circulate freely through the ventilation slots

o prevent any unsafe situations, no naked

flame sources, such as lighted candles, should

be placed on or in the vicinity. Avoid heat,

direct sunlight and exposure to rain or water.

The equipment should not be exposed to

dripp

ng or splashing and no objects filled with

liquids, such as vases, should be placed on it.

Insert the aerial plug firmly into the aerial

socket at the bottom rear of the TV.

Connecting the Mains

Insert the mains plug into the wall socket and switch on. Please refer to the label on the back of the

television for the correct operating voltage.

Installing the remote control

•

Remove the cover at the back of the

remote control.

• Insert the correct battery type and size

into the compartment making sure that

the polarity orientation is correct.

• You can secure your batteries by

fastening an appropriate screw into the

hole of the battery cover.

Switch the TV on:

Press the power switch on the TV. An indicator on the front of the TV lights up and the screen

comes on. If the TV is in standby mode (red indicator), press the - TV+ keys or the key on the

remote control to switch on the TV.

- 3 -

Accessing the Set-up Menu

When the set is in the High Security Mode, the Setup menu can be accessed only by the Institutional

Set-up Remote Control (RG4172BK or RC2573) by pressing the M key. The Institutional Set-Up

Remote Control is available as an option.

When the set is in the Standard Security Mode the Set-up Menu may be accessed with the standard

guest remote control (RC2886) by a sequence of commands (3 1 9 7 5 3 MUTE).

RC2886 RG4172BK RC 2573

(Optional) (Optional)

- 4 -

Navigation

The current menu item can be selected by means of the Up/Down keys.

Submenus can be accessed from menu items indicated with a “>” symbol by pressing the Right key.

•

To exit any menu press

“Menu” button

• Select “YES” to

activate/enable a setting,

“NO” to deactivate/disable.

• TELEVISION up/down,

INFO up/down, PAY-TV

up/down and RADIO

up/down are active in Setup

menu mode and the television

reacts the same way as in TV

mode.

- 5 -

• Language: Select the language of the installation menu. Options are "ENGLISH" and

"MELAYU".

• Communication: The Communication option is for enabling interactive applications. For

more information consult the application notes. For stand-alone applications select “OFF”

option under the Communication sub menu.

Important!

Do not select

Iconn1

mode unless application is with Iconn 1 box. Once the T

is set in Iconn1 mode, it will not respond to RC commands anymore. To regain control over

the TV, press any key (except the Power key) on the Set-Up remote for about 4 seconds and

while continuing to hold the key, press any key (except the Power key) on the local keyboard.

message “IR Loopback” will appear momentarily to indicate that the set has been released

from

Iconn1

mode.

• No. of Channels: This sub menu allows setting the number of TV, PAY-TV, Radio and

Info channels.

• Channel Install: In the Channel Install sub-menu, various channel settings can be set. Please

refer to the section on Channel Installation for further details.

• Configuration: In the Configuration menu, various settings and features of the TV can be

adjusted. Please refer to the section on Configuration for further details.

- 6 -

In the Channel Installation sub-menu, channel settings can be set. When this menu is open, all the

protections are inactive.

•

Channel: The Channel type

can be selected with the cursor

Left/Right key. The available

options are: "TV", "INFO",

"PAYTV" and "RADIO".

Note:

Use the numeric keys to enter the

program number. For program

number below 10, enter the first digit

as “0” followed by the program

number. Eg “01” for TV 1.

Alternatively, enter the program

number followed by Up/Down key.

Program number “0” or “00” are

not allowed.

• Input: The "Input" menu item selects the desired input source that will be assigned to the

program. Possible values are Tuner, AV1, AV2, S-Video, CVI, RADIO, VGA, DVI, HD-A and

HD-D. Note that some input sources may not be available on certain models.

• System: NTSC 3.58 BG/I/DK/M, NTSC 4.43 BG/I/DK, PAL 4.43 BG/I/DK, SECAM 4.43

BG/I/DK, and AUTO.

• Frequency: Digits can be entered for a frequency in MHz. Press the Right key to start the auto

search; during frequency entry the digits not yet entered are displayed as dashes "-". Enter first

digit as “0” for frequencies below 100 MHz.

• Label: This menu item will be used to add a label/name for each program.

o Press the Left/Right key to select the label digit; press the Up/Down key to insert

alphanumeric characters.

o Press the Menu button to exit the Label menu item.

• Store: The Channel information is stored after pressing the Left/Right key. Press the Menu key

to exit without storing.

• Fine Tune: Press the Left/Right key for fine-tuning.

• Mute: This item enables/disables picture and sound for the particular channel.

o NONE: normal picture and sound enabled

o VIDEO: picture is blanked for this channel (e.g. radio channel)

o AUDIO: sound is muted for this channel (e.g. information channel)

• Auto Install TV: This sub menu allows the TV channels to be scanned and set automatically.

• Protection: This function is to protect a selected program for Pay TV purpose. Press the

Left/Right key to toggle the protection between "YES" and "NO".

- 7 -

In the Configuration menu, various settings and features of the TV can be adjusted.

•

Switch On/OSD: In this sub-

menu the Switch On characteristics

and On Screen Display settings of

the TV upon switched On can be

configured.

• Picture/Sound: In this sub-menu,

the Picture and Sound settings of

the TV can be set.

• Security: In this sub-menu, the

Security settings of the TV can be

configured.

• Control: In this sub-menu, the

Control settings of the TV can be

configured.

In this sub menu the behavior of the TV after switching on and the behavior of the On Screen

Display can be selected.

•

Welcome Message: Press Cursor

Left/Right to display Welcome

message entry menu:

o Welcome Message

o Display Yes/No

o Line 1

o Line 2

o Clear

With the Up/Down key you can

set the message characters.

• Switch On Channel: This item

sets the television’s channel at

switch on.

• Switch On Volume: This item

sets the television’s volume at

switch on. Use the Right/Left key

to adjust.

- 8 -

• Switch On Pic Fmt: This item sets the television’s Picture Format at switch on. Use the

Right/Left key to select the desired format.

• Power On: The Power On menu function defines the behavior of the television whenever

AC Power is applied. The available options are "FORCED ON", "LAST STATUS" and

“STANDBY”.

o FORCED ON: TV will be automatically switched to ON mode whenever the

mains power is turned ON or resumed after a power interruption. Note that the

remote control STANDBY key will no longer function when TV is set in this

mode. TV can only be switched OFF by means of the main switch or a set-up

remote control or by ESP function (Energy Saving Programmability controls the

maximum continuous viewing time allowed).

o LAST STATUS: TV will be automatically switched to the last status (either

STANDBY or ON) whenever the mains power is turned ON or resumed after a

power interruption.

o STANDBY: TV will be automatically switched to STANDBY mode (even if the

last status was ON) whenever the mains power is turned ON or resumed after a

power interruption.

• Volume Indicator: To display volume indicator when adjusting volume, select "YES".

Select “NO” to hide the volume indicator.

• Channel Display: Channel Display values can be: Number, Label, All, None.

• Digit Timeout: This is the time-out to enter the second digit of program number, eg for

program number 10 and above.

In this sub menu, the Picture and Sound settings of the TV can be selected.

•

Brightness: This changes picture

brilliance.

• Colour: This changes the intensity

of the colour.

• Contrast: This changes the

difference between the light and

dark tones.

• Sharpness: This changes the

picture definition.

• Tint: This allows adjustment of

colour hue to obtain natural skin

tones.

• Active Control (* menu option

only available in certain models):

Active Control function optimises

the quality of the picture according

to the quality of reception

- 9 -

• Treble/Bass: This adjusts the level of treble and bass effects on the TV’s sound output.

• Balance: This balances the sound on the left and right speakers.

• AVL (Automatic Volume Leveller): This option is used to limit the increase in sound level

eciall

durin

ramme chan

e or advertisin

slots.

In this sub menu, the Security settings of the TV can be configured.

• Security Level: The “SECURITY” function allows the user to select one of two states -

“HIGH” or “STANDARD”. The default is “STANDARD”.

o When the set is in the Security High Mode the setup menu can only be accessed by a

Institutional Set-up Remote Control.

o When the set is in the Security Standard Mode, the Set-up Menu can be accessed with a

guest remote control by a sequence of commands (3 1 9 7 5 3 MUTE).

• Keyboard Lock: The Keyboard Lockout function disables the television’s local keyboard for

volume and program control.

• Video Out Mute (* menu option only available for 30” and 42” models) : This option

allows the user to mute the AV output, to prevent unauthorized copying of AV content.

- 10 -

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Téléviseur LCD

Philips

Philips 55PFL5240/T3 Manuel utilisateur

Philips

Philips 32PFL3505D Manuel utilisateur

Philips

Philips 42PF7421D Manuel utilisateur

Philips

Philips 26HFL4372D Manuel utilisateur

Philips

Philips 20PF5120/28 Manuel utilisateur

Philips

Philips 42PF7421D Manuel utilisateur

Philips

Philips 20TA1000/93 Manuel utilisateur

Philips

Philips 32PFL2507 Manuel utilisateur

Philips

Philips 50PFL5806/F7 Manuel utilisateur

Philips

Philips 42PFL3403D - annexe 1 Manuel utilisateur

Philips

Philips 39PFL3708 Manuel utilisateur

Philips

Philips 19PFL4505D Manuel utilisateur

Philips

Philips 42PFL4606H Manuel utilisateur

Philips

Philips 28PW8720 Manuel utilisateur

Philips

Philips Cineos 47PFL9632D/10 Manuel utilisateur

Philips

Philips 32PF7321D/37 Manuel utilisateur

Philips

Philips 42PFL8803D/30 Manuel utilisateur

Philips

Philips 55PFL3907/F7 Manuel utilisateur

Philips

Philips HFL5010T Series Manuel utilisateur

Philips

Philips 43PUS7956 Manuel utilisateur

Philips

Philips 37PFL5604H Manuel utilisateur

Philips

Philips 32PF3320 Manuel utilisateur

Philips

Philips 32PFL5203S/98 Manuel utilisateur

Philips

Philips 32PFL56*5H/12 Manuel utilisateur

Manuels Téléviseur LCD populaires d'autres marques

LG 32LC4R* Manuel utilisateur

ViewSonic

ViewSonic N4200w-1 VS10945-1M Manuel utilisateur

Salora

Salora 22LED1600 Manuel utilisateur

Samsung

Samsung LA32E420 Mode d’emploi

Dell

Dell W1900 19 Instructions d'utilisation

Samsung

Samsung LN40C670M1F Manuel utilisateur

Samsung

Samsung Series 4+ Manuel utilisateur

Samsung

Samsung 5 Series Manuel utilisateur

Grundig

Grundig 40 VLE 8230 BP Manuel utilisateur

Sony

Sony Bravia XBR-43X830C Manuel utilisateur

LG 32LS350 Manuel utilisateur

VIORE

VIORE LED32VF60 Manuel utilisateur

Toshiba

Toshiba Regza 42HL167 Manuel utilisateur

JVC

JVC LT-32A220 Manuel utilisateur

Sony

Sony Bravia KDL-V32XBR2 Manuel utilisateur

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Manuel utilisateur

Dynex

Dynex DX-40L261A12 Manuel utilisateur

JVC

JVC LT-23C50BU Manuel utilisateur
