Philips GC9630/20 Manuel utilisateur
GC9600
1
2
4
12
11
10
13
16
17
14
9
8
5
18
6 7
3
15
3
EN IMPORTANT: Perform descaling regularly for great steam
and prolonged life.
DE WICHTIG: Entkalken Sie regelmäßig, um eine gute
Dampeistung und eine lange Nutzungsdauer zu gewährleisten.
FI TÄRKEÄÄ: voit pidentää käyttöikää ja parantaa höyryntuottoa
suorittamalla kalkinpoiston säännöllisesti
FR IMPORTANT : effectuez régulièrement un détartrage pour
une vapeur de qualité et une durée de vie prolongée.
IT IMPORTANTE: eseguite regolarmente la procedura di
decalcicazione per avere maggiore vapore e maggiore durata
del ferro.
NL BELANGRIJK: regelmatig ontkalken zorgt voor goede stoom
en een langere levensduur.
SV VIKTIGT: Utför avkalkning regelbundet för bra ånga
och förlängd drifttid.
DA VIGTIGT: Udfør afkalkningsprocessen jævnligt for at opnå god
damp og forlænge apparatets levetid.
NO VIKTIG: Utfør avkalking regelmessig for ott damp og lang
levetid.
DE
CALC
6
Introduction
This iron has been approved by The Woolmark Company Pty Ltd for
the ironing of wool only products provided that the garments are ironed
according to the instructions on the garment label and those issued by the
manufacturer of this iron. R1501. In United Kingdom, Eire, HongKong and
India, the Woolmark trademark is a Certication trademark.
Product overview (Fig. 3)
1 Steam supply hose
2 Iron platform
3 First supply hose storage compartment
4 Mains cord with plug
5 ECO button with light
6 On/off button with safety auto off light and TURBO setting
7 ’Water tank empty’ light
8 EASY DE-CALC light
9 EASY DE-CALC knob
10 Cord storage compartment
11 Second supply hose storage compartment
12 Detachable water tank
13 Carry lock
14 Carry lock release button
15 Soleplate
16 Steam trigger
17 ‘Iron ready’ light
18 Filling hole
Important
Read the separate important information leaet and the user manual
carefully before you use the appliance. Save both documents for future
reference.
Using your appliance
Filling the water tank
Fill the water tank before every use and when the ‘water tank empty’
light ashes.
Do not add perfume, water from the tumble dryer, vinegar, starch,
descaling agents, ironing aids, chemically descaled water or other
chemicals, as they may cause water spitting, brown staining or damage to
your appliance.
ENGLISH
1 Removethewatertankfromtheapplianceandllitwithtapwater
up to the MAX indication.
Tip:Your appliance has been designed for use with tap water. If you live
in an area with very hard water, scale builds up quickly. In this case it is
recommended to use distilled water to prolong the life of your appliance.
2 Put the water tank back into the appliance by sliding in the bottom
partrst.Thenpushthetoppartuntilitlocksintoplace.
’Water tank empty’ light
When the water tank is almost empty, the ‘water tank empty’ light goes on.
Fill the water tank and press the steam trigger to let the appliance heat up
again. When the ‘iron ready’ light lights up continuously, you can continue
steam ironing.
OptimalTempTechnology
The Optimal Temp Technology enables you to iron all types of ironable
fabrics, in any order, without adjusting the iron temperature setting.
Fabrics with these symbols are ironable, for example linen, cotton, polyester,
silk, wool, viscose and rayon.
Fabrics with this symbol are not ironable. These fabrics include synthetic
fabrics such as Spandex or elastane, Spandex-mixed fabrics and polyolens
(e.g. polypropylene), but also prints on garments.
ENGLISH 7
Ironing
1 Place the steam generator on a stable and even surface.
2 Make sure that there is enough water in the water tank
(see section ‘Filling the water tank’).
3 Put the mains plug in an earthed wall socket and press the on/off
buttontoswitchonthesteamgenerator.Thebluepower-onlighton
theapplianceandthe‘ironready’lightstarttoashtoindicatethat
the appliance is heating up (this takes approx. 2 minutes).
,When the appliance is ready for use, the ‘iron ready light’ and the
power-onlightstopashingandlightupcontinuously.Additionally
you hear a short beep.
4 Press the carry lock release button to unlock the iron from the iron
platform.
5 Press and hold the steam trigger to start ironing.
Never direct steam at people.
Steam boost function
The steam boost function is designed to help tackle difcult creases.
- Double press the steam trigger for a continuous shot of steam.
It is not necessary to press and hold the steam trigger continuously
when the steam boost function is activated. To stop the steam boost
function, press the steam trigger once.
2x
ENGLISH8
Vertical ironing
Hot steam is emitted from the iron. Never attempt to remove creases
from a garment that someone is wearing. Do not apply steam near your
or someone else’s hand.
You can use the iron in vertical position to remove wrinkles from hanging
fabrics.
1 Hold the iron in vertical position, press the steam trigger and touch
the garment slightly with the soleplate.
Putting down the iron during ironing
- During ironing, you can place the iron either on the iron platform
or horizontally on the ironing board. Thanks to the OptimalTemp
technology, the soleplate will not damage the ironing board cover.
Energy saving
ECO mode
-
By using the ECO mode (reduced amount of steam), you can save
energy without compromising on the ironing result. The green light is on.
- You can deactivate the ECO mode by pressing the ECO button.
The green light goes off.
Safety auto-off mode
- To save energy, the appliance switches off automatically when it has not
been used for 10 minutes. The auto-off light in the on/off button starts
to ash.
- To activate the appliance again, press the on/off button. The appliance
then starts to heat up again.
Note:The appliance is not switched off completely when it is in safety auto-off
mode.To switch off the appliance, press the on/off button.
ENGLISH 9
Turbo steam
For faster ironing and a higher amount of steam, you can use Turbo steam.
1 Press and hold the on/off button for 2 seconds until the light turns
white.
2 TodeactivateTurbosteam,pressandholdtheon/offbuttonagainfor
2 seconds until the white light turns blue
Ironing tips
Minimising wrinkles while drying
Start wrinkle removal early in the drying process by spreading out your
laundry properly after washing and by putting garments on hangers to
make them dry naturally with fewer wrinkles.
Best practice shirt ironing
Start with the time-consuming parts like collar, cuff links and sleeves.
Next, iron the bigger parts like front and back to prevent wrinkling the
bigger parts when you are busy ironing the time-consuming parts.
Collar: When you iron a collar, start on its underside and work from the
outside (the pointy end) inwards. Turn over and repeat. Fold down the
collar and press the edge for a more crisp nish.
Buttons: Iron on the reverse side of the buttons for more effective and
faster ironing.
Cleaning and maintenance
To properly maintain your appliance, clean the iron and the appliance
regularly.
1 Cleantheappliancewithamoistcloth.Toremovestubbornstains,
youcanuseasmallamountofwashing-upliquid.
2 Toeasilyandeffectivelyremovestainsfromthesoleplate,switchon
the appliance and let it heat up.When the appliance has heated up,
move the iron over a moist cloth while you press the steam trigger.
Tip: Clean the soleplate regularly to ensure smooth gliding.
2 sec.
