Philips GC4900 Manuel utilisateur

User manual

www.philips.com/welcome

GC4900 series

ENGLISH 6

DEUTSCH 14

FRANÇAIS 23

NEDERLANDS 31

Introduction

Congratulations on your purchase and welcome to Philips! To fully benet

from the support that Philips offers, register your product at www.philips.

com/welcome.

The new Philips PerfectCare Azur steam iron offers you an innovative

way to iron garments.We all know the fuss with traditional irons: choosing

the right temperature for tough and delicate fabrics, waiting for the iron

to warm up and cool down to avoid the risk of damaging clothes with

a too hot iron.Those hassles are things of the past with the new Philips

PerfectCare Azur steam iron.

Historically, wrinkle removal was done with a very hot soleplate, then

steam was added to enhance heat transfer and we could iron much faster.

Our research conrmed that the best way to remove wrinkles

effectively is a perfect combination of intense steam and

optimal soleplate temperature. The key to effective wrinkle

removal is the steam, not the soleplate temperature. To get

optimal steam, the soleplate temperature needs to be just

above the steam temperature.

In the past, a large amount of steam at this optimal temperature would

have led to water leakage.We have developed a unique steam chamber

that generates a consistent output of moisture-rich steam that penetrates

deep into the fabric for fast ironing with no risk of water leakage.

- Ironing is now really simple: no temperature adjustment, no scorching,

no waiting for the iron to heat up or cool down. Ironing takes less

time, no matter who does it.With this OptimalTEMP technology, every

single garment can be ironed effectively and safely.

This iron has been approved byThe Woolmark Company Pty Ltd for the

ironing of wool-only products, provided that the garments are ironed

according to the instructions on the garment label and those issued by the

manufacturer of this iron, R1101. In the United Kingdom, Eire, Hong Kong

and India, the Woolmark trademark is a certication trademark.

General description (Fig. 2)

1 Water tank lid

2 Spray button

3 Steam slider

4 Steam boost trigger

5 Mains cord

6 Cord winding area

7 Calc-Clean button

8 SmartLight/Calc-Clean reminder light

9 Soleplate

10 Spray nozzle

ENGLISH

Preparing for use

Filling the water tank

1 Flipopenthewatertanklid,thenllthewatertankuptotheMAX

indication.

Type of water to be used

This appliance has been designed to be used with tap water. If you live

in an area with hard water, fast scale build-up may occur.Therefore, it is

recommended to use distilled or de-mineralized water to prolong the

lifetime of the appliance.

Note: Do not put perfume, vinegar, starch, descaling agents, ironing aids or

other chemicals in the water tank, as your appliance is not designed to work

with these chemicals.

Heating up

1 Insert the plug into an earthed wall socket.The SmartLight starts

ashingbluetoindicatethattheironisheatingup.

2 TheSmartLightlightsupbluesteadilywhentheironisreadyforuse.

Note: If the colour of the SmartLight is amber instead of blue, this is a

reminder that you should perform Calc-Clean function. See chapter

‘Cleaning and maintenance, section ‘Using the Calc-Clean function’.

OptimalTemp technology

The OptimalTemp technology enables you to iron all types of ironable

fabrics, in any order, without the need to adjust any temperature setting.

- Fabrics with these symbols are ironable, for example linen, cotton,

polyester, silk, wool, viscose and rayon.

- Fabrics with this symbol are not ironable.These fabrics include synthetic

fabrics such as Spandex or elastane, Spandex-mixed fabrics and

polyolens (e.g. polypropylene), but also prints on garments.

- Do not iron non-ironable fabrics.

ENGLISH 7

Steam settings

You can set different steam settings with the steam slider:

- No steam: to stop steam output when the iron is not in use.

During ironing, always choose ECO or MAX setting.

- ECO: (specic types only) to save energy, reduce the steam output,

and still have sufcient steam to iron your garments.

- MAX: to set the maximum steam output, perfect combination with

OptimalTemp setting.

For the best results and shortest ironing time, we strongly recommend that

you iron all ironable fabrics at the setting for maximum steam output.

1 Makesurethereisenoughwaterinthewatertank.

2 Push the steam slider to the desired steam setting.

Note:The iron starts to produce steam when the SmartLight lights up

blue steadily.

Using the appliance

Ironing

With the OptimalTemp technology, you can iron every single garment

effectively and safely, even delicate fabrics like silk without having to worry

about temperature settings.

1 YoucanstartironingwhentheSmartLightstopsashingandlightsup

bluesteadily.(Seechapter‘Preparingforuse’,section‘Heatingup’).

Features

Spray function

You can use the spray function to moisten the garment to be ironed.This

helps to remove stubborn creases.

1 Makesurethereisenoughwaterinthewatertank.

2 Pressthespraybuttonseveraltimestomoistenthegarmenttobe

ironed.

Steam boost function

A steam boost from the soleplate helps removing stubborn creases.The

steam boost enhances the distribution of steam into every part of the

garment.

ENGLISH8

1 Pressandreleasethesteamboosttrigger.

For optimal steam boost performance, it is recommend to press the steam

boost trigger at intervals of 5 seconds.

Ironing with extra steam

1 Forextrasteamduringironing,pressandholdthesteamboost

trigger.

Vertical steam boost

You can also use the steam boost function when you hold the iron in

vertical position.

1 Holdtheironinverticalposition,pressandreleasethesteamtrigger

and touch the garment lightly with the soleplate.

Tip: Pull the garment with one hand to stretch it for more effective wrinkle

removal.

Hotsteamcomesoutoftheiron.Donotremovewrinklesfroma

garmentwhileyouarewearingitorsomebodyelseiswearingit.To

preventburns,donotdirectthesteamatpeople.

Safety Auto off

To save energy, the appliance switches off automatically when it has not

been moved for 2 minutes in horizontal position, or 3 minutes when is

standing on its heel.

1 TheSmartLightstartspulsatingslowlywhenSafetyAutooffmode

hasbeenactivated.

2 Toreactivatetheiron,simplymoveit.TheSmartLightashesblueto

indicate that the iron is heating up, and it lights up steadily when the

ironisreadyforuse.

Note:The steam iron is not switched off completely when it is in Safety Auto off

mode. Unplug the iron to switch it off.

ENGLISH 9

Ironing tips

Minimising wrinkles while drying

Start wrinkle removal early in the drying process by spreading out the

laundry properly after washing. Put the garments on hangers to make them

dry naturally with less wrinkles.

Shirt ironing

Start with the time-consuming parts such as collar, cuff links and sleeves.

Next, iron the bigger parts like front and back. By doing this, you prevent

wrinkling the bigger parts when you are busy ironing the time-consuming

ones.

Collar:When you iron a collar, start on its underside and iron from the

outside (the pointy end) inwards. Turn over and repeat. Fold down the

collar and press the edge for a crisp nish.

Buttons: Iron on the reverse side of the buttons for more effective and

faster ironing.

Cleaning and maintenance

Cleaning

1 Setthesteamslidertothe‘nosteam’position,removetheplugfrom

the wall socket and let the iron cool down.

2 Wipeakesandanyotherdepositsoffthesoleplatewithadamp

clothandanon-abrasive(liquid)cleaningagent.

Tokeepthesoleplatesmooth,avoidhardcontactwithmetalobjects.

Neveruseascouringpad,vinegarorotherchemicalstocleanthe

soleplate.

3 Cleantheupperpartoftheironwithadampcloth.

4 Regularly rinse the water tank with water. Empty the water tank

afteryouhaverinsedit.

ENGLISH10
