Philips GC4005/02 Manuel utilisateur

Azur GC4043, GC4040, GC4038, GC4035, GC4033, GC4030, GC4028,

GC4025, GC4023, GC4020, GC4018, GC4015, GC4013, GC4010,

GC4005

ENGLISH 4

DEUTSCH 12

FRANÇAIS 20

NEDERLANDS 28

ESPAÑOL 36

ITALIANO 44

PORTUGUÊS 52

TÜRKÇE 60

GC4043, GC4040, GC4038, GC4035, GC4033, GC4030, GC4028,

GC4025, GC4023, GC4020, GC4018, GC4015, GC4013, GC4010,

GC4005

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗Only connect the appliance to an earthed wall socket.

◗Do not use the appliance if the plug, the cord or the appliance

itself shows visible damage, or if the appliance has been dropped

or is leaking.

◗Check the cord regularly for possible damage.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

◗Never leave the appliance unattended when it is connected to the

mains.

◗Never immerse the iron and the stand, if provided, in water.

◗Keep the appliance out of the reach of children.

◗The soleplate of the iron can become extremely hot and may

cause burns if touched.

◗Do not allow the cord to come into contact with the soleplate

when it is hot.

◗When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave the

iron even for a short while: set the steam control to position O,

put the iron on its heel and remove the mains plug from the wall

socket.

◗Always place and use the iron and the stand, if provided, on a

stable, level and horizontal surface.

◗Do not put perfume, vinegar, starch, descaling agents, ironing aids

or other chemicals in the water tank.

◗This appliance is intended for household use only.

Before first use

1Check if the voltage rating on the typeplate corresponds to the

mains supply in your home.

C2Remove any sticker, protective foil or storage cover (Type

GC4043, GC4040, GC4028, GC4025 only) from the soleplate.

3Heat up the iron to maximum temperature and iron over a

piece of damp cloth for several minutes to remove any residue

on the soleplate.

The iron may give out some smoke when using it for the first time.

After a short while this will cease.

ENGLISH4

Filling the water tank

Do not immerse the iron in water.

1Remove the mains plug from the wall socket.

C2Set the steam control to position O (= no steam).

3Open the filling cap.

4Hold the iron in a tilted position.

C5Pour tap water from the filling jug into the water tank up to

the maximum level.

Do not fill the tank beyond the MAX indication.

If the tap water in your area is very hard, we advise you to mix it with

an equal portion of distilled water, or to use distilled water only.

Do not use vinegar, starch or chemically descaled water.

6Press to close the filling cap (click!).

Setting the temperature

C1(Type GC4043, GC4040, GC4028, GC4025 only). Remove the

protective storage cover.

Do not use the cover during ironing.

2Put the iron on its heel.

C3Set the temperature control to the required ironing

temperature by turning it to the position of the temperature

indicator.

- Check the garment label for the required ironing temperature.

-1Synthetic fabrics (e.g. acrylic, viscose, polyamide, polyester)

-1Silk

-2Wool

-3Cotton, linen

- When you do not know what kind of fabric(s) the article is made of,

try to iron on a spot which will be invisible when you wear it.

- Silk, woolen and synthetic materials: iron the reverse side of the

fabric to prevent shiny spots.To prevent stains, avoid using the spray

function.

- Start ironing the articles that require the lowest ironing temperature,

such as those made of synthetic fibers.

ENGLISH 5

4Put the mains plug in an earthed wall socket.

C5When the amber temperature pilot light has first gone out,

wait for a while before start ironing.

BThe amber pilot light will come on from time to time during ironing.

For Auto-shut-off versions (Type GC4043, GC4040, GC4038,

GC4035, GC4033, GC4030)

If the Auto-shut-off is activated (red pilot light blinks), move the iron

slightly to deactivate it (blinking stops).

Steam-ironing

Make sure that there is enough water in the water tank.

1Set the temperature control to the recommended position.

See section 'Setting the temperature'.

C2Set the steam control to the appropriate steam position.

- 1 - 3 for moderate steam (temperature settings 2to 3)

- 4 - 6 for maximum steam (temperature settings 3to MAX)

BSteaming will start as soon as the set temperature has been reached.

Ironing without steam

1Set the steam control to position O (= no steam).

2Set the temperature control to the recommended position.

See section 'Setting the temperature'.

Other features

Spraying

To remove stubborn creases at any temperature.

Make sure that there is enough water in the water tank.

C1Press the spray button a couple of times to moisten the

laundry.

ENGLISH6

7ENGLISH

Shot of Steam

A powerful "shot" of steam helps remove stubborn creases.

The Shot-of-Steam function can only be used at temperature settings

between 2and MAX.

C1Press and release the Shot-of-Steam button.

Drip Stop

This iron features a "Drip Stop" steam shut-off facility: the iron

automatically stops steaming at too low temperatures to prevent water

from dripping out of the soleplate.When this happens you may hear a

sound.

Vertical Shot of Steam (Type GC4043, GC4040, GC4038,

GC4035, GC4033, GC4030, GC4028, GC4025, GC4023,

GC4020, GC4018, GC4015, GC4013, GC4010)

C1The Shot of Steam function can also be used when you hold

the iron in vertical position.

Never direct the steam towards people.

Automatic Anti-Calc system (Type GC4043, GC4040,

GC4038, GC4035, GC4033, GC4030, GC4028, GC4025,

GC4023, GC4020, GC4018, GC4015)

C1The built-in Anti-Calc system automatically reduces deposit of

scale and ensures a longer life of the iron.

Auto-shut-off (Type GC4043, GC4040, GC4038, GC4035,

GC4033, GC4030)

C1An electronic safety device will automatically switch off the

iron if it has not been moved for a while.

◗To indicate that the iron has been switched off, the red auto-off

pilot light will start blinking.

To heat up the iron again:

- Pick up the iron or move it slightly.

- The red auto-off pilot light will go out.The amber temperature pilot

light may come on, depending on the soleplate temperature.

- If the amber pilot light comes on after the iron is moved, wait for it

to go out before start ironing.

- If the amber pilot light does not come on after the iron is moved, the

iron is ready for use.

Cleaning and maintenance

Calc-Clean

This is a Calc-Cleaning function which removes scale and impurities.

Use the Calc-Clean function once every two weeks. If the water in

your area is very hard (when flakes coming out from the soleplate

during ironing), the Calc-Clean function should be used more

frequently.

1Set the steam control to position O.

2Fill the water tank to the maximum level.

Do not use vinegar or other descaling agents.

C3Set the temperature control to MAX.

4Put the plug in the wall socket.

5Unplug the iron when the amber pilot light has gone out.

C6Hold the iron over the sink, press and hold the calc-clean

button and gently shake the iron.

BSteam and boiling water will come out of the soleplate. Impurities and

flakes (if any) will be flushed out.

7Release the Calc-Clean button as soon as all the water in the

tank has been used up.

ENGLISH

Repeat the calc-cleaning process if the iron still contains a lot of

impurities.

After calc-cleaning

- Plug in the iron to let the soleplate dry up.

- Unplug the iron when the amber pilot light has gone out.

- Move the hot iron gently over a piece of used cloth to remove any

water stains that may have formed on the soleplate.

- Let the iron cool down before you store it.

After ironing

1Remove the mains plug from the wall socket and let the iron

cool down.

2Wipe flakes and any other deposits off the soleplate with a

damp cloth and a non-abrasive (liquid) cleaner.

3Clean the upper part of the iron with a damp cloth.

C4Regularly rinse the water tank with water. Empty the water

tank after cleaning.

Storage

1Remove the mains plug from the wall socket and set the steam

control to position 0.

2Empty the water tank.

C3Type GC4038, GC4035, GC4033, GC4030, GC4023, GC4020,

GC4018, GC4015, GC4013, GC4010, GC4005.

a) Let the iron cool down.Wind the mains cord around the cord

storage facility and fix it with the cord clip.Type GC4040 comes with

a 3m cord.

b) Always store the emptied iron horizontally on a stable surface and

use a cloth to protect the soleplate.

C4Protective storage cover ( Type GC4043, GC4040, GC4028,

GC4025).

a) Put the protective storage cover on the iron.

Do not use the protective storage cover during ironing.

b) Wind the mains cord around the cord storage facility.

c) Store the iron with the protective storage cover horizontally on a

stable surface.

9ENGLISH

Environment

C◗Do not throw the appliance away with the normal household

waste at the end of its life, but hand it in at an official collection

point for recycling. By doing this you will help to preserve the

environment.

Guarantee & service

If you need information or if you have a problem, please visit the Philips

Web site at www.philips.com or contact the Philips Customer Care

Centre in your country (you will find its phone number in the

worldwide guarantee leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and Personal Care BV.

ENGLISH

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Philips Fer

Philips

Philips GC9040/02 Manuel utilisateur

Philips

Philips HI 205 Manuel utilisateur

Philips

Philips GC5000 series Manuel utilisateur

Philips

Philips Perfective AQUARIUS HV-SOLG-FU Manuel utilisateur

Philips

Philips GC9614 Manuel utilisateur

Philips

Philips Insta Press GC9500 Manuel utilisateur

Philips

Philips Premium GC4444 Manuel utilisateur

Philips

Philips Mistral GC2225 Manuel utilisateur

Philips

Philips Mistral GC2225 Manuel utilisateur

Philips

Philips GC3593 Manuel utilisateur

Philips

Philips GC3388 Manuel utilisateur

Philips

Philips PerfectCare Elite Plus GC9690/80 Manuel utilisateur

Philips

Philips EcoCare GC3740/32 Manuel utilisateur

Philips

Philips Diva GC120 Series Manuel utilisateur

Philips

Philips GC4800 series Manuel utilisateur

Philips

Philips GC4500 series Manuel utilisateur

Philips

Philips GC 6005 Manuel utilisateur

Philips

Philips GC8030/28 Manuel utilisateur

Philips

Philips GC4038/02 Manuel utilisateur

Philips

Philips Azur GC4250 Manuel utilisateur

Philips

Philips PerfectCare Pure GC7600 series Manuel utilisateur

Philips

Philips GC7900 Series Manuel utilisateur

Philips

Philips GC4880 series Manuel utilisateur

Philips

Philips HI835/22 Manuel utilisateur

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

dyras

dyras ESI-2400AC Manuel utilisateur

GE 169061 Manuel utilisateur

Gorenje

Gorenje SIH 2200 GC Manuel utilisateur

AEG

AEG DBS 5591 Manuel utilisateur
