Philips Azur GC4243 Manuel utilisateur

Azur

GC4243, GC4238, GC4233, GC4223, GC4218

ENGLISH 4

DEUTSCH 12

FRANÇAIS 21

NEDERLANDS 29

ITALIANO 38

GC4243, GC4238, GC4233, GC4223, GC4218

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗Only connect the appliance to an earthed wall socket.

◗Do not use the appliance if the plug, the cord or the appliance

itself shows visible damage, or if the appliance has been dropped

or is leaking.

◗Check the cord regularly for possible damage.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

◗Never leave the appliance unattended when it is connected to the

mains.

◗Never immerse the iron and the stand, if provided, in water.

◗Keep the appliance out of the reach of children.

◗The soleplate of the iron can become extremely hot and may

cause burns if touched.

◗Do not allow the cord to come into contact with the soleplate

when it is hot.

◗When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave

the iron even for a short while: set the steam control to position

O, put the iron on its heel and remove the mains plug from the

wall socket.

◗Always place and use the iron and the stand, if provided, on a

stable, level and horizontal surface.

◗Do not put perfume, vinegar, starch, descaling agents, ironing aids

or other chemicals in the water tank.

◗This appliance is intended for household use only.

Before first use

1Check if the voltage indicated on the appliance corresponds to

the local mains voltage before you connect the appliance.

C2Remove the protective heat cover from the soleplate (type

GC4243 only). Remove any sticker or protective foil from the

soleplate.

3Let the iron heat up to maximum temperature and pass the

iron over a piece of damp cloth for several minutes to remove

any residues from the soleplate.

BThe iron may give off some smoke when you use it for the first time.This

will cease after a short while.

ENGLISH4

Preparing for use

Filling the water tank

Never immerse the iron in water.

1Remove the mains plug from the wall socket.

C2Set the steam control to position O (= no steam).

3Open the cap of the filling opening.

4Tilt the iron backwards.

C5Fill the water tank with tap water up to the maximum level by

means of the filling cup.

Do not fill the tank beyond the MAX indication.

◗If the tap water in your area is very hard, we advise you to mix it

with an equal amount of distilled water or to use distilled water

only.

Do not put additives, vinegar, starch or chemically descaled water in the

water tank.

C6Close the cap of the filling opening.You will hear a click.

Setting the temperature

C1Type GC4243 only: remove the protective heat cover.

Do not leave the protective heat cover on the soleplate during ironing.

2Put the iron on its heel.

C3Set the temperature dial to the required ironing temperature

by turning it to the appropriate position.

- Check the garment label for the required ironing temperature.

-1Synthetic fabrics (e.g. acrylic, nylon, polyamide, polyester)

-1Silk

-2Wool

-3Cotton, linen

ENGLISH 5

6ENGLISH

- If you do not know what kind(s) of fabric(s) an article is made of,

determine the right ironing temperature by ironing a part that will

not be visible when you wear or use the article.- Silk, woollen

and synthetic materials: iron the reverse side of the fabric to prevent

shiny patches. Avoid using the spray function to prevent stains.

- Start ironing the articles that require the lowest ironing temperature,

such as those made of synthetic fibres.

4Put the mains plug in an earthed wall socket.

C5When the amber temperature pilot light has gone out, wait a

while before you start ironing.

The amber pilot light will go on from time to time during ironing.

Using the appliance

Steam ironing

1Make sure that there is enough water in the water tank.

C1Select the appropriate steam setting. Make sure that the steam

setting you select is suitable for the ironing temperature

selected:

- 1 - 3 for moderate steam (temperature settings 2to 3)

- 4 - 6 for maximum steam (temperature settings 3to MAX)

See 'Setting the temperature'.

BThe iron will start producing steam as soon as the set temperature has

been reached.

Ironing without steam

C1Set the steam control to position O (= no steam).

2Select the recommended ironing temperature.

See 'Setting the temperature'.

Features

Spraying

You can use the spray function to remove stubborn creases at any

temperature.

Make sure that there is enough water in the water tank.

C1Press the spray button several times to moisten the article to

be ironed.

Shot of steam

A powerful 'shot' of steam helps remove stubborn creases.

The shot-of-steam function can only be used at temperature settings

between 2and MAX.

C1Press and release the shot-of-steam button.

Drip stop

This iron is equipped with a drip-stop function: the iron automatically

stops producing steam when the temperature is too low to prevent

water from dripping out of the soleplate.When this happens you may

hear a sound.

Vertical shot of steam

C1The shot-of-steam function can also be used when you hold

the iron in vertical position.

Never direct the steam at people.

ENGLISH

Automatic anti-calc function

C1The built-in anti-calc system reduces the build-up of scale and

guarantees a longer life for the iron.

Electronic safety shut-off function (Types GC4243, GC4238,

GC4233 only)

C1The electronic safety shut-off function automatically switches

off the iron if it has not been moved for a while.

◗The red auto-off pilot light starts blinking to indicate that the iron

has been switched off by the safety shut-off function.

To let the iron heat up again:

- Pick up the iron or move it slightly.

- The red auto-off pilot light goes out. If the temperature of the

soleplate has dropped below the set ironing temperature, the amber

temperature pilot light goes on.

- If the amber pilot light goes on after you have moved the iron, wait

for it to go out before you start ironing.

- If the amber pilot light does not go on after you move the iron, the

soleplate still has the right temperature and the iron is ready for use.

Alert light

C◗Types GC4243 and GC4238 only:

- The iron is equipped with a blue alert pilot light.

- The blue alert light burns as long as the iron is plugged in, even if the

iron has been switched off by the safety shut-off function.

ENGLISH

Cleaning and maintenance

Using the calc-clean function

You can use the calc-clean function to remove scale and impurities.

◗Use the calc-clean function once every two weeks. If the water in

your area is very hard (i.e. when flakes come out from the

soleplate during ironing), the calc-clean function should be used

more frequently.

1Set the steam control to position O.

2Fill the water tank to the maximum level.

Do not put vinegar or other descaling agents in the water tank.

C3Select the maximum ironing temperature.

4Put the plug in the wall socket.

5Unplug the iron when the amber temperature pilot light has

gone out.

C6Hold the iron over the sink, press and hold the calc-clean

button and gently shake the iron to and fro.

BSteam and boiling water will come out of the soleplate. Impurities and

flakes (if any) will be flushed out.

7Release the calc-clean button as soon as all the water in the

tank has been used up.

Repeat the calc-clean process if the iron still contains a lot of impurities.

After the calc-clean process

- Put the plug in the wall socket and let the iron heat up to allow the

soleplate to dry.

- Unplug the iron when it has reached the set ironing temperature.

- Move the hot iron gently over a piece of used cloth to remove any

water stains that may have formed on the soleplate.

- Let the iron cool down before you store it.

After ironing

1Remove the mains plug from the wall socket and let the iron

cool down.

2Wipe flakes and any other deposits off the soleplate with a

damp cloth and a non-abrasive (liquid) cleaning agent.

ENGLISH

3Clean the upper part of the iron with a damp cloth.

C4Regularly rinse the water tank with water. Empty the water

tank after cleaning.

Storage

1Remove the mains plug from the wall socket and set the steam

control to position O.

2Empty the water tank.

C3a) Let the iron cool down.Wind the mains cord around the

cord storage facility and fix it with the cord clip.

b) Always store the emptied iron horizontally on a stable surface and

use a cloth to protect the soleplate.

C4Protective heat cover (type GC4243 only)

a) Put the iron on the protective heat cover.

Do not use the protective heat cover during ironing.

b) Wind the mains cord around the cord storage facility.

c) Store the iron with the protective heat cover horizontally on a stable

surface.

Environment

C◗Do not throw the appliance away with the normal household

waste at the end of its life, but hand it in at an official collection

point for recycling. By doing this you will help to preserve the

environment.

ENGLISH
