Philips MCD700/93 Manuel utilisateur

MCD 700

MCL 707

Quick start guide

MCL707

MCD700

What’s in the Box?

You should find these items upon opening the box.

User Manual

Quick Start Guide

CompositeVideo Cable FM and MW antenna Remote Control

Quick Start Guide

User Manual

Control Cable

MCD700 QUG_Eng-93 2005.5.18, 2:56 PM1

Connect the speakers to the SPEAKERS (8ohm) terminals with two speaker cables. Right speaker to "R" and

left speaker to "L", red wire to "+" and silver wire to "–".

For radio reception, connect the supplied MW loop antenna wires to the AM AERIAL jack.

Connect the serial port marked CONTROL CABLE at the rear of the DVD player to the same port at the

rear of the power amplifier with the supplied control cable.

Connect the VIDEO OUTPUT jack at the rear of the DVD player to the video input jack on the TV using the

supplied video cable (yellow).

Connect the power cord of the DVD system to the AC power outlet.

Tip

See the User Manual for otherTV connection options.

AC power cord

Speaker

(Right)

Speaker

(Left)

FM antenna MW antenna

Speaker connection for MCL707

Tip

It is unnecessary to connect the FM pigtail antenna since it

is fixed to the main unit.

MCD700 QUG_Eng-93 2005.5.18, 2:56 PM2

Setting up the TV

Press STANDBY ONBon the front panel of the DVD player or B on the remote to switch the DVD system

on and then select the disc source.

Switch on the TV set and set to the correct video-in channel until the blue Philips DVD background screen

appears on the TV.

Tip

See your TV manual for more details.

Setting TV type and preferences

Press SYSTEM on the remote to enter the system menu.

Press 1 2 on the remote to enter the 'Preference Page'.Then, select the color

system matching your TV and the preferred audio, subtitle and disc menu languages

using 1 2 3 4 and OK on the remote.

Press 1 2 on the remote to enter the 'General Setup Page' and select the

preferred OSD language using 1 2 3 4 and OK on the remote.

IR SENSOR

MCD700 DVD/RECEIVER/POWER AMPLIFIER

STANDBY-ON

STANDBY-ON

Tip

You can enter the 'Preference Page' in full stop mode only.

MCD700 QUG_Eng-93 2005.5.18, 2:56 PM3

Loading a disc

Select the disc source, then press OPEN•CLOSE at the top of the DVD player or 0on the remote.

Load in a DVD disc with the label side facing up.

A disc menu pops up.

Playback

Use 1 2 3 4 and OK or Numeric Keypad (0-9) on the remote to select a playback feature or item.

Press PRESET/ÉÅ (orÉÅ on the remote) to start playback.

Types of Discs used

on this DVD System

Tip

Refer to the User Manual for playback of other types of discs.

Type

DVD VIDEO

AUDIO CD

VIDEO CD

MP3-CD

WMA

Record Playback Edit

DVD+RW

Super VCD

VIDEO CD

2005 © Koninklijie Philips Electronics N.V.

www.philips.com

MCD700 QUG_Eng-93 2005.5.18, 2:56 PM4
