Philips MCD288E Manuel utilisateur

AUDIO

S-VIDEO

VIDEOIN

TVIN

AUDIO

S-VIDEO

VIDEO IN

TV IN

1 1

Tips

–See the User Manual for other TV

connection options.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

–Never connect the AC power cord

before connection of the DIN cable to

avoid causing any damage to the set.

Connect the speaker (subwoofer) cables.

Connect the FM antenna.

Connect the A/V cord to a TV.

Connect the power cords of the system and TV.

AC power

FM antenna

Speaker

(right)

Speaker

(left)

AC power

Setting up the TV

Press SOURCE (DISC on the remote control) to select disc source.

Turn on the TV and set it to the correct Video In channel.

USB/AUX

DIM

MCD288E QUG_Eng-BK 2008.1.7, 15:462

In standby mode, press and hold CLOCK on the system.

When the hour digits flash, press VOLUME-/+ (VOL+/- on the remote control) to set the

hours.

Press CLOCK again and the minute digits flash.Then press VOLUME-/+ (VOL+/- on the

remote) to set the minutes.

Press CLOCK again to confirm the time setting.

IMPORTANT!

– To set clock in the Eco Power mode, press and hold STANDBY-ON/ECO POWER

on the set for

3 seconds or more to switch to normal standby mode first before proceeding with the procedures

below.

Setting the clock

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support progressive

signals or the cables are not connected accordingly, see the user manual for proper progressive

scan setup or deactivate the progressive scan feature as below:

1)Turn off your TV progressive scan mode or turn on to interlaced mode.

2) Press SYSTEM MENU on the remote to exit the system menu and then DISC and “1” to exit

progressive scan.

Tip

See chapters "Preparations" and "System

Menu Options" in the User Manual for

detailed descriptions.

USB/AUX

DIM

DIVX (R) VOD

DIGITAL AUDIO SETUP

ANALOG AUDIO SETUP

PICTURE SETTING

HDMI SETUP

MCD288E QUG_Eng-BK 2008.1.7, 15:463

Playing a disc

Insert a disc into the slot loader.

➜Make sure the label side is facing you.

➜Make sure you have removed any other disc from the slot loader.

Playback will start automatically. If not pressÉÅ.

To stop playback, press 9.

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote control) to select tuner source.

Press PROGRAM on the remote control for more than two seconds to program all available stations in order of

waveband.

Press PRESET ¡/ ™until the desired preset station is displayed.

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more to select USB (or USB/AUX on the remote control).

Play the USB’s audio files as you do with the albums/tracks on a CD,

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

IMPORTANT!

Slide down to

expose some

buttons and jacks on

the front panel!

MCD288E QUG_Eng-BK 2008.1.7, 15:464
