Philips MCD 289/55 Manuel utilisateur

SLOW

ANGLE

DISPLAY

MUTE

STANDBY-ON

MCD 289

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

Quick Start Guide

A/V cord (R/W/Y) Remote control with two AAA

batteries

FM wire antenna

AC power cord

(for subwoofer)

Stand

User manual

Quick start guide

Power adapter

(for main set)

MCD289 QUG_Eng-61 2008.1.11, 17:301

AUDIO

S-VIDEO

VIDEOIN

TVIN

AUDIO

S-VIDEO

VIDEO IN

TV IN

Tips

–See the User Manual for other TV

connection options.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

– In case of wireless connection failure

between the main set and subwoofer, see

the User Manual for manual pairing.

Connect the speaker cables.

Connect the FM antenna.

Connect the A/V cord to a TV.

Connect the power cords of the system and TV.

Setting up the TV

Press SOURCE (DISC on the remote control) to select disc source.

Turn on the TV and set it to the correct Video In channel.

SLOW

ANGLE

DISPLAY

MUTE

STANDBY-ON

Power on both the main set and subwoofer.

➜Wireless connection will set up automatically.

AC power

Speaker

(right)

Speaker

(left)

FM antenna

AC power

Red

White

MCD289 QUG_Eng-61 2008.1.11, 17:302

In standby mode, press and hold CLOCK on the remote control.

When the hour digits flash, press VOLUME-/+ (VOL+/- on the remote control) to set the

hours.

Press CLOCK again and the minute digits flash.Then press VOLUME-/+ (VOL+/- on the

remote) to set the minutes.

Press CLOCK again to confirm the time setting.

IMPORTANT!

– To set clock in the Eco Power mode, press and hold STANDBY-ON/ECO POWER

on the set for

3 seconds or more to switch to normal standby mode first before proceeding with the procedures

below.

Setting the clock

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support progressive

signals or the cables are not connected accordingly, see the user manual for proper progressive

scan setup or deactivate the progressive scan feature as below:

1)Turn off your TV progressive scan mode or turn on to interlaced mode.

2) Press SYSTEM MENU on the remote to exit the system menu and then DISC and “1” to exit

progressive scan.

Tip

See chapters "Preparations" and "System

Menu Options" in the User Manual for

detailed descriptions.

SLOW

ANGLE

RDS

DISPLAY

MUTE

STANDBY-ON

DIVX (R) VOD

DIGITAL AUDIO SETUP

ANALOG AUDIO SETUP

PICTURE SETTING

MCD289 QUG_Eng-61 2008.1.11, 17:303

Playing a disc

Insert a disc into the slot loader.

➜Make sure the label side is facing you.

➜Make sure you have removed any other disc from the slot loader.

Playback will start automatically. If not pressÉÅ.

To stop playback, press 9.

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote control) to select tuner source.

Press PROGRAM for more than two seconds to program all available stations in order of waveband.

Press PRESET ¡/ ™until the desired preset station is displayed.

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more to select USB (or USB on the remote control).

Play the USB’s audio files as you do with the albums/tracks on a CD,

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

IMPORTANT!

Slide down to

expose some

buttons and jacks on

the front panel!

Tip

Detailed playback features and additional functions are

described in the accompany owner's manual.

PDCC-JS/JW-0802

MCD289 QUG_Eng-61 2008.1.11, 17:304
