Philips HTS6510/05 Manuel utilisateur

1Connect

Placement

Proper speakers system placement is important to

ensure optimum sound performance.

APlace the Ambisound speakers at the normal

listening ear level, equal distance from the TV and

face straight ahead towards the listening area.

BPlace the subwoofer on the floor, at least one

metre away from the TV.

2Set up

Connect the radio antennas

Keep the antennas away from the electronic devices to

prevent unwanted interference.

FM 75

FM/MW ANTENNA

HDMI OUT

MAINS

SUB-

WOOFER

FRONT

LEFT

FRONT

RIGHT

12 mm

AConnect the FM antenna to the FM socket. Extend

the wire and fix its end to the wall.

BUnfold the AM/MW loop antenna and fix the claw

into the slot.

CPush the tabs and insert the wires into the AM/MW

sockets.

Connect the Ambisound speakers

and subwoofer

Connect the left speaker to the FRONT LEFT socket,

right speaker to the FRONT RIGHT socket and the

subwoofer to the SUBWOOFER socket at the rear of

the DVD system.

FM 75

FM/MW ANTENNA

HDMI OUT

MAINS

SUB-

WOOFER

FRONT

LEFT

FRONT

RIGHT

SUB-

WOOFER

FRONT

LEFT

FRONT

RIGHT

DVD system (rear)

SUBWOOFER FRONT

RIGHT

FRONT

LEFT

Finding the viewing channel

APress STANDBY ON on the DVD system.

BPress SOURCE on the DVD system until “DISC”

appears on the display panel.

CTurn on the TV. Use the TV’s remote control to

select the correct viewing channel for the DVD

system.

You should see the blue DVD background on the

TV.

Note To search for the correct viewing channel,

press the Channel Down button on the TV’s remote

control repeatedly (or AV, SELECT, °button) until

you see the blue DVD background.

Setting up the Ambisound speakers

APress and hold SOUND on the remote control to

enter the Ambisound speaker settings mode.

BUse WXkeys to view the available settings (ROOM

ACOUSTICS, SPEAKER DISTANCE, LISTENING

POSITION) and press OK to select.

CUse WXkeys to select a most suitable predefined

setting and press OK to confirm.

ROOM ACOUSTICS

HARD - for concrete/glass walls.

SOFT - for wooden walls.

SPEAKER DISTANCE

NEAR - ‘X’ is less than 1 metre.

DEFAULT - ‘X’ is between 1~2.5 metres.

FAR - ‘X’ is more than 2.5 metres.

LISTENING POSITION

NEAR - ‘Z’ is less than 1.5 metre.

DEFAULT - ‘Z’ is between 1.5~2.5 metres.

FAR - ‘Z’ is more than 2.5 metres.

Note The underlined options are the default setting.

Connect the DVD system to TV

FM75

FM/MWANTENNA

HDMIOUT

MAINS

SUB-

WOOFER

FRONT

LEFT

FRONT

RIGHT

SCART IN

AUse the supplied scart cable to connect the SCART

socket on this DVD system to the SCART IN socket

on your TV.

BPlug in the power cable from the DVD system to an

AC power outlet.

Note It is important to connect the DVD system

directly to your TV. When watching the TV

programmes, you can press TV on the remote control

to get the sound output from the speakers system.

DVD System (rear)

Television ( rear)

Connect the audio from other

device to DVD system (optional)

Use the red and white audio cables (not supplied) to

connect the AUX IN (R/L) sockets on this DVD system

to the AUDIO output sockets on your Audio/Video

device (for example, DVD recorder, VCR).

FM75

FM/MWANTENNA

HDMIOUT

MAINS

SUB-

WOOFER

FRONT

LEFT

FRONT

RIGHT

AUDIO

OUT

AUDIOIN

AUDIO

OUT

AUDIO OUT

Note Press AUX/DI on the remote control to get

the sound output from the speakers system when

watching the TV programme.

DVD System (rear)

Television ( rear)

To off-air

antenna or

set-top box

DVD System (rear)

Ensure that this portion is

fully inserted in to the

socket.

3Enjoy DVD HOME THEATER SYSTEM HTS6510

Quick Start Guide

Connect

Set up

Enjoy

What’s in the box?

DVD system Remote Control

and 2 batteries

User Manual

Start disc playback

AInsert a disc into the disc slot with the disc label

facing up.

EJECT

BPlayback will start automatically.

CIf the disc menu appears, use TS keys to select an

option in the menu and press PLAY Xto start

playback.

zTo enjoy the powerful surround sound from the

Ambisound speakers, press SURROUND to turn

on the multi-channel surround mode.

DPress STOP xto stop playback.

EPress EJECT Zto remove the disc.

Note When you press PLAY button again,

the playback will resume from where it last

stopped. To start playback from the beginning,

you have to press STOP button two times to

cancel the resume mode, then press PLAY

button.

Playback from the USB

AInsert your USB device into the USB port and wait

for the message to appear on the screen.

BPress DISC/USB to access the contents on your

USB device.

CPress OK to start playback.

DTo stop playback, press DISC/USB again to switch

to ‘DISC’ mode. You can unplug your USB device

now.

Playback from the portable

audio/HDD player

AUse the supplied MP3 direct cable to connect the

headphone output socket on your portable audio/

HDD player to the MP3 DIRECT socket.

BPress MP3 DIRECT on the remote control.

CPress PLAY on your portable audio/HDD player to

start playback.

Note You can only control the playback features

using your portable audio/HDD player.

Troubleshooting

For more troubleshooting tips, see the user manual.

No picture.

• Press DISC/USB button on the remote control.

• Check the connection to the TV and ensure the plugs are rmly in place.

No sound.

• Check the speaker connections and settings.

• Check the audio connections and press SOURCE button to select the correct input source.

• Press SURROUND button to turn on the multi-channel surround output.

The DVD system does not work.

• Disconnect the power cord from the power outlet for a few minutes. Reconnect the power cord and try again.

2 Ambisound speakers

and subwoofer

FM wire antenna AM/MW loop

antenna

MP3 direct cable for

portable audio player

Micro bre

cleaning cloth

Need help?

User Manual

See the user manual that came with your Philips DVD System

Online

Go to www.philips.com/welcome 2007 CKoninklijke Philips N.V.

12 NC 3139 245 21782

www.philips.com

Scart cable
