3Enjoy

What’s in the box?

Start disc playback

APress çto open the disc tray.

BPlace a disc with the disc label facing up.

CPress çto close the disc tray.

DPlayback starts automatically.

EIf the disc menu appears on the TV, use  

keys or the numeric keypad to select an option in

the menu and press OK to start playback.

zTo enjoy the powerful surround sound

from the speakers, press SURROUND

on the remote control to turn on the

multi-channel surround mode.

FPress to stop playback.

Note When you press ubutton,

playback resumes from where it last stopped.

To start playback from the beginning, you

have to press .

Playback other supported

devices

USB device

AInsert your USB device to the USB socket.

BPress USB to switch to ‘USB’ mode.

CPress uto start playback.

DTo stop playback, press DISC to switch to ‘DISC’

mode. You can unplug your USB device now.

Other portable audio player

AUse a 3.5mm stereo audio cable (not supplied) to

connect the headphone output socket on your

portable audio player to MP3 LINK socket.

BPress PLAY on your portable audio player.

CPress AUX (MP3 LINK) repeatedly until

‘MP3 LINK’ is displayed to listen to the playback.

Main Unit Remote Control

and 2 batteries

User

Manual

1 centre, 2 front, 2 rear speakers

and subwoofer

Need help?

User Manual

See the user manual that came with your Philips DVD Home Theatre System.

2008 CKoninklijke Philips N.V.

www.philips.com

sgpjy_828/12_14_eng

Scart Cable

www.philips.com/welcome

Quick Start Guide

Connect

Set up

Enjoy

HTS3568

4 Screws

(for connecting

the tallboy speakers)

FM wire antenna

Speaker cables

hts3568_12_qsg_eng1_final.indd 1hts3568_12_qsg_eng1_final.indd 1 2008-07-03 1:06:27 PM2008-07-03 1:06:27 PM

1Connect

Placement

Proper speakers system placement is important to

ensure optimum sound performance.

SUBWOOFER

FRONT

RIGHT

FRONT

LEFT

CENTER

REAR

RIGHT

REAR

LEFT

APlace the centre speaker above or close to the TV.

BPlace the subwoofer on the floor, at least one metre

away from the TV.

CPlace the front speakers at equal distances from the

TV.

DPlace the rear speakers at the back or beside the

listening position.

Connect the main unit to TV

SCART IN

zConnect a scart cable (supplied) from the

SCART TO TV socket on the main unit to the

SCART IN socket on your TV.

Notes

– When watching the TV programmes, press

AUX (MP3 LINK) repeatedly until ‘SCART IN’ is

displayed, to get the sound output.

– If your TV supports HDMI, connect this unit to your

TV using HDMI connection for better picture quality.

See the accompanying user manual for more

information.

2Set up

Assemble the tallboy speakers

AConnect the speaker cables to the matching colour

sockets on the speakers (or speaker stands).

BPlace the stands upright and lock the speakers down

into position.

CSecure the position with screws (supplied).

Connect the speakers and subwoofer

Connect the various coloured plugs from the speakers

and subwoofer to the same coloured sockets at the rear

of the main unit.

Finding the viewing channel

APress 2(Standby-On) on the main unit to turn it

on.

BTurn on the TV. Use the TVs remote control to

select the correct viewing channel.

Note To search for the correct viewing channel,

press the Channel Down button on the TVs remote

control repeatedly (or AV, SELECT, °button) until

you see the Video In channel.

Select the display language on the

screen

APress OPTIONS.

The { General Setup } appears.

BPress

.

Press OPTIONS to exit menu

General Setup

Disc Lock

Display Dim

OSD Language

Screen Saver

DivX(R) VOD Code

Sleep

Dansk

Suomi

Français

Deutsch

Italiano

English

Auto

Nederlands

CUse  keys to select { OSD Language } and press

.

DUse  keys to select a language option in the

menu and press OK to confirm.

EPress OPTIONS to exit.

Note The language set here is only for the menus

that are shown on the TV while operating this Home

Theatre system, not for the DVD disc menu.

There are various setup options (Audio Setup, Video

Setup, Preferences) available on this Home Theatre

System. Refer to the user manual for more information.

Connect the radio antenna and

power cable

Keep the antennas away from the electronic devices to

prevent unwanted interference.

AConnect the FM antenna (supplied) to the inner pin

of the FM 75 socket. (For some models, it has

been connected in the factory.) Extend the wire for

optimum reception.

BConnect the power cable from the main unit to the

AC power outlet.

Connect audio output from other

device (optional)

Use a red and white audio cables (not supplied) to

connect the AUDIO IN-AUX sockets on the main unit

to the AUDIO OUT sockets on the connected device

(for example, DVD recorder, VCR, Cable/Satellite Box).

AUDIO

OUT

AUDIO OUT

AUDIO IN

AUX

AUDIO

OUT

Note Press AUX (MP3 LINK) repeatedly on the

remote control until ‘AUX’ is displayed as the source

you want to listen to.

Main Unit (rear)

DVD recorder/ VCR/

Cable/ Satellite Box

FM antenna

SUBWOOFER

FRONT

RIGHT

FRONT

LEFT REAR

RIGHT

REAR

LEFT

FRONT CENTER

Main Unit (rear)

Main Unit (Front)

Standby button

Main Unit (rear)

Television (rear)

hts3568_12_qsg_eng1_final.indd 2hts3568_12_qsg_eng1_final.indd 2 2008-07-03 1:06:31 PM2008-07-03 1:06:31 PM
