3Enjoy DVD HOME THEATRE SYSTEM

Quick Start Guide

Connect

Set up

Enjoy

What’s in the box?

Start disc playback

APress OPEN/CLOSE çto open the disc tray.

BPlace a disc with the disc label facing up.

CPress OPEN/CLOSE çto close the disc tray.

DPlayback starts automatically.

EIf the disc menu appears on the TV, use  

keys or numeric keypad to select an option in the

menu and press OK to start playback.

zTo enjoy the powerful surround sound from the

speakers, press SURROUND on the remote

control to turn on the multi-channel surround

mode.

FPress to stop playback.

Note When you press ubutton, playback

resumes from where it last stopped. To start playback

from the beginning, you have to press .

Listen to radio

APress RADIO.

The display panel shows ‘AUTO INSTALL PRESS

PLAY’.

BPress

All the available radio stations with strong reception

signal will be stored automatically.

COnce complete, use í/ ëkeys to select a preset

radio station.

Troubleshooting

For more troubleshooting tips, see the user manual.

No picture.

• Press DISC on the remote control.

• Check the connection to the TV and ensure the plugs are rmly in place.

No sound.

• Check the speaker connections and settings.

• Check the audio connections and press SOURCE to select the correct input source.

• Press SURROUND to turn on the multi-channel surround output.

The main unit does not work.

• Disconnect the power cord from the power outlet for a few minutes. Reconnect the power cord and try again.

HTS3000

Main Unit Remote Control

and 2 batteries

User

Manual

1 centre, 2 front, 2 rear speakers

and subwoofer

FM wire

antenna

AM/MW

loop antenna

Need help?

User Manual

See the user manual that came with your Philips DVD Home Theatre System.

Online

Go to www.philips.com/welcome 2007 CKoninklijke Philips N.V.

www.philips.com

Composite

video cable

Power cable

1Connect

Placement

Proper speakers system placement is important to

ensure optimum sound performance.

FRONT

RIGHT

FRONT

LEFT

CENTER

REAR

RIGHT

REAR

LEFT

SUBWOOFER

APlace the centre speaker above or close to the TV.

BPlace the subwoofer on the floor, at least one metre

away from the TV.

CPlace the front speakers at equal distances from the

TV.

DPlace the rear speakers at normal listening ear level.

Connect the main unit to TV

SPEAKERS

AM/

VIDEO OUT

Pr Y

VIDEOIN

(CVBS)

VIDEO IN

(CVBS)

zConnect a composite video cable (supplied) from the

CVBS socket on the main unit to the VIDEO IN

socket on your TV.

Note It is important to connect the main unit

directly to your TV.

2Set up

Connect the speakers and

subwoofer

Connect the various coloured plugs from the speakers

and subwoofer to the same coloured sockets at the rear

of the main unit.

SPEAKERS

AM/

Main Unit (rear)

Finding the viewing channel

APress 2(STANDBY ON) on the main unit to turn

it on.

BTurn on the TV. Use the TVs remote control to

select the correct viewing channel.

STANDBY-ON

Note To search for the correct viewing channel,

press the Channel Down button on the TVs remote

control repeatedly (or AV, SELECT, °button) until

you see the Video In channel.

Select the display language on the

screen

APress SETUP.

The { General Setup Page } appears.

General Setup Page

Disc Lock

Display Dim

Program

OSD Language

Screen Saver

Sleep

DivX(R) VOD Code

English

Melayu

Русский

BPress to select { OSD Language } and press .

CUse  keys to select a language option in the

menu and press OK to confirm.

DPress SETUP to exit.

Note The language set here is only for the menus

that are shown on the TV while operating this Home

Theatre system, not for the DVD disc menu.

There are various setup options (Audio Setup, Video

Setup, Preference Setup) available on this Home Theatre

System. Refer to the user manual for more information.

Connect the radio antennas

Keep the antennas away from the electronic devices to

prevent unwanted interference.

SPEAKERS

AM/

AConnect the FM antenna to the inner pin of the

FM 75 socket. For optimum reception, extend the

wire and fix its end to the wall.

BUnfold the AM/MW loop antenna and fix the claw

into the slot. Push the tabs and insert the wires into

the AM/MW sockets.

CConnect in the power cable from the main unit to

the AC power outlet.

Connect audio output from TV

(optional)

To hear the TV audio through this home theatre system,

use a red and white audio cables (not supplied) to

connect the AUDIO IN-TV sockets on the main unit to

the AUDIO OUT sockets on your TV.

SPEAKERS

AM/

AUDIO

OUT

AUDIOIN

AUDIO

OUT

AUDIOOUT

Note When watching the TV programmes, you can

press TV on the remote control to get the sound

output from the speakers.

Main Unit (rear)

Television

(rear)

Main Unit (rear)

FM antenna

AM/MW antenna

SUBWOOFER

FRONT

RIGHT FRONT

LEFT REAR

RIGHT REAR

LEFT

FRONT CENTRE

SETUP

Television

(rear)
