Philips HP4880/08 Manuel utilisateur
JetSet Control
HP4881, HP4880
2
3
D
G
A
F
B
C
4
ENGLISH 6
DEUTSCH 12
FRANÇAIS 18
NEDERLANDS 24
ESPAÑOL 31
ITALIANO 37
PORTUGUÊS 43
NORSK 49
SVENSKA 55
SUOMI 61
DANSK 67
73
TÜRKÇE 80
HP4881, HP4880
Introduction
The Philips JetSet Control has been specially designed to meet your
personal needs, giving you frizz-free, beautiful and shiny hair.
This hairdryer offers you a variety of heat and speed settings. In
addition, this hairdryer has a Jet position for an ultra-strong airflow and
a Set position for a cool shot.This gives you optimal styling freedom
and optimal control over your hairstyle.
You can visit our website at www.philips.com/beauty for more
information about this product or any other Philips beauty product.
General description (fig. 1)
AAir inlet grille
BTemperature slide switch
- 6= Quick-Dry setting
- 5= Caring setting
- 4= Fixation setting
CAirflow slide switch
- O = off
- I = low airflow especially intended for styling
- II = strong airflow for quick drying
DJetSET switch
- Jet = position for extra-powerful airflow
- 4= off
- SET = position for fixation by means of cool airflow
EHanging loop
FVolume diffuser (HP4881 only)
GConcentrator
Important
Read these instructions for use carefully before using the appliance and
save them for future reference.
◗Check if the voltage indicated on the appliance corresponds to
the local mains voltage before you connect the appliance.
ENGLISH6
◗Check the condition of the mains cord regularly. Do not use the
appliance if the plug, the cord or the appliance itself is damaged.
◗If the mains cord is damaged, it must be replaced by Philips, a
service centre authorised by Philips or similarly qualified persons
in order to avoid a hazard.
◗Keep this appliance away from water! Do not use this product
near or over water contained in baths, washbasins, sinks etc.
When used in a bathroom, unplug the appliance after use since
the proximity of water presents a risk, even when the hairdryer is
switched off.
◗For additional protection, we advise you to install a residual
current device (RCD) with a rated residual operating current not
exceeding 30mA in the electrical circuit supplying the bathroom.
Ask your installer for advice.
◗Keep the appliance out of the reach of children.
◗Never block the air grilles.
◗If the appliance overheats, it will switch off automatically. Unplug
the appliance and let it cool down for a few minutes. Before you
switch the appliance on again, check the grilles to make sure they
are not blocked by fluff, hair, etc.
◗Always switch the appliance off before putting it down, even if it
is only for a moment.
◗Always unplug the appliance after use.
◗Do not wind the mains cord round the appliance.
◗You may notice a characteristic odour when using this hairdryer.
This is caused by the ions that are generated and it is not harmful
to the human body.
◗Do not probe the ion generator with metal objects.
Using the appliance
Drying
1Put the plug in the wall socket.
2Switch the appliance on by selecting the desired airflow setting:
- Set the slide switch to airflow setting II for ultra-quick drying.
ENGLISH 7
- Set the slide switch to airflow setting I for drying short hair or
styling your hair.
◗You can also use the Jet position of the JetSet switch for an extra-
powerful airflow (fig. 2).
3Set the temperature slide switch to the Quick-Dry, Caring or
Fixation setting.
The Quick-Dry setting 6
◗The Quick-Dry setting enables you to dry shower-wet hair very
quickly (fig. 3).
It is recommended to use the Quick-Dry setting only on shower-wet
hair and to select the Caring setting when the hair is almost dry in
order to reduce the risk of overdrying.
The Caring setting 5
◗The Caring setting gently dries the hair at a caring temperature
(fig. 4).
The Fixation setting 4
◗The Fixation setting fixes the style you have created (fig. 5).
For long-lasting styling results, set the switch to the Fixation setting and
direct the cool airflow at your hair to fix your style.
◗You can also use the Set position of the JetSet switch to fix your
style (fig. 6).
4Dry your hair by making brushing movements with the hairdryer
at a small distance from the hair (fig. 7).
Attachments
Concentrator
The concentrator enables you to direct the airflow straight at the brush
or comb with which you are styling your hair.
1Connect the concentrator by simply snapping it onto the
appliance. Disconnect it by pulling it off (fig. 8).
ENGLISH8
2Switch the appliance on by setting the airflow slide to position I
or II.
3While you are drying your hair with the concentrator, you can
use a brush or comb to style your hair (fig. 9).
Volume diffuser (HP4881 only)
The volume diffuser has been specially developed to gently dry both
straight and curly or wavy hair.
◗The volume diffuser emits a gentle airflow and allows you to give
your style volume and bounce (fig. 10).
1Connect the diffuser by simply snapping it onto the appliance and
align the arrows on the diffuser and the barrel. Disconnect it by
pulling it off (fig. 11).
◗To add volume at the roots, insert the pins into your hair in such
a way that they touch your scalp (fig. 12).
2Make rotating movements with the appliance to distribute the
warm air evenly through your hair (fig. 13).
Curly or wavy hair
◗When you are styling curly or wavy hair, hold the diffuser at a
distance of 10-15 cm from your head to let the hair dry gradually
(fig. 14).
- In the meantime you can style your hair with your free hand or
with a comb.
- You can also scrunch locks of hair in your hand to model the curls
and waves while drying.This will prevent the curls from sagging or
becoming frizzy.
Long hair
◗To dry long hair, you can spread out locks of hair on top of the
diffuser (fig. 15).
◗Alternatively, you can comb the hair downwards with the pins of
the diffuser while drying (fig. 16).
ENGLISH 9
Cleaning
Always unplug the appliance before cleaning it.
Never rinse the appliance with water.
◗Open the inlet grille to remove hairs and dust.
◗Clean the appliance with a dry cloth.
◗Clean the attachments with a moist cloth or by rinsing them
under the tap.
Remove the attachments from the appliance before cleaning them.
Storage
Always unplug the appliance before storing it.
◗Put the appliance in a safe place and let it cool down.
◗Do not wind the mains cord round the appliance.
◗The appliance can be stored by hanging it from its hanging loop.
Guarantee & service
If you need information or if you have a problem, please visit the Philips
website at www.philips.com or contact the Philips Customer Care
Centre in your country (you will find its phone number in the
worldwide guarantee leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and Personal Care BV.
ENGLISH10
