Philips

widescreen flat TV with

Pixel Plus

37"

LCD HD Ready

37PF7320

Turn up your viewing experience

with Pixel Plus

Experience the superior picture quality of this excellent Flat TV with the latest LCD

technology and Pixel Plus. It's packed into a stunning design that will complement your

interior.

Breathtaking natural pictures

• HD LCD WXGA display, with a 1366 x 768p resolution

• HD Ready for the highest quality display of HD signals

• Pixel Plus for detail, depth and clarity

• Progressive Scan component video for optimized image quality

• Active Control with Light Sensor optimizes picture quality

Superb sound reproduction

• Virtual Dolby Surround for a cinema-like audio experience

Slim, stylish design to complement your interior

• Matching stand with elegant design included

Leading interface for digital quality audio/video

• DVI-I provides the best picture and flexible connectivity

One touch convenience

• View PC content in a second window on your TV

37PF7320/10

Highlights

Widescreen flat TV with Pixel Plus

37" LCD HD Ready

LCD WXGA display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

HD Ready

Enjoy the exceptional picture quality of High

Definition pictures and be fully prepared for

HD sources like HDTV settop box or Blu-ray

disc. HD Ready is a protected label that offers

picture quality beyond that of progressive scan.

It conforms to strict standards laid out by

EICTA to offer a HD screen that displays the

benefits of resolution and picture quality of a

High Definition signal. It has a universal

connection for both analog YPbPr and

uncompressed Digital connection of DVI or

HDMI, supporting HDCP. It can display 720p,

and 1080i signals at 50 and 60Hz.

Pixel Plus

Pixel Plus is a digital picture processing

technology that increases the number of lines

and the number of pixels. The result is razor

sharp pictures with incredible detail and depth,

every time from any source.

Progressive Scan

Progressive Scan doubles the vertical

resolution of the image resulting in a noticeably

sharper picture. Instead of sending a field

comprising the odd lines to the screen first,

followed by the field with the even lines, both

fields are written at one time. A full image is

created instantaneously, using the maximum

resolution. At such a speed, your eye perceives

a sharper picture with no line structure.

Active Control + Light Sensor

Active Control is a unique and intelligent way

of optimizing picture quality by measuring and

analyzing the incoming signal to automatically

adjust picture quality settings. Active Control

with Light Sensor uses a sensor to adjust the

picture brightness depending on the room light

conditions.

Virtual Dolby Surround

Virtual Dolby Surround is a processing

technology for enhancing surround sound

effects. It will create the sensation of Dolby

Pro Logic without the necessity of additional

rear speakers. You become totally immersed

in your television experience.

Bypacked tabletop stand

A table-top stand with matching design is

packed with the set.

DVI-I Input

A DVI-I input connects the non-compressed

high-bandwidth digital RGB signal from source

to screen. By eliminating the conversion of the

digital signals to analog, it delivers an

unblemished and noisefree image, that is clear

and flickerfree. The DVI input supports HDCP

copy protection that allows viewing of copy

protected programs from Digital Settop boxes,

DVD players and HD recorders. DVI-I is

future proof as it can be be connected to all

HDMI devices (a converter cable is required).

The DVI-I input also supports analog PC-VGA

signals.

Picture in Graphics

Picture-in-Graphics is a small window in the

main picture, allowing to watch data/graphics

in your main TV screen. It provides the ability

to simultaneously watch data/graphics and the

TV.

37PF7320/10

Specifications

Widescreen flat TV with Pixel Plus

37" LCD HD Ready

Picture/Display

• Aspect ratio: 16:9

• Brightness: 550 cd/m²

• Diagonal screen size: 37 inch / 94 cm

• Display screen type: LCD WXGA Active Matrix

TFT

• Picture enhancement: Pixel Plus, Progressive Scan,

Active Control + Light sensor, 3/2 - 2/2 motion

pull down, Contrast Plus, Digital Noise Reduction,

Dynamic contrast, 3D Combfilter, Jagged Line

Suppression

• Screen enhancement: Anti-Reflection coated

screen

• Panel resolution: 1366 x 768p

• Response time (typical): 8 ms

• Viewing angle: 176º (H) / 176º (V)

• Contrast ratio (typical): 800:1

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60, 67, 72, 75Hz

800 x 600 56, 60, 72, 75Hz

1024 x 768 60, 70, 75Hz

1280 x 1024 60Hz

•Video Formats

Resolution Refresh rate

640 x 480i 1Fh

640 x 480p 2Fh

720 x 576i 1Fh

720 x 576p 2Fh

1280 x 720p 3Fh

1920 x 1080i 2Fh

Sound

• Sound Enhancement: Dynamic Bass Enhancement

• Sound System: Virtual Dolby Surround

• Output power (RMS): 2 x 15W

• Equalizer: 5-bands

Loudspeakers

• Built-in speakers: 2

Convenience

• Ease of Installation: Autostore, Plug & Play, Auto

Program Naming, Automatic Channel Install(ACI),

Automatic Tuning System (ATS), Fine Tuning,

Program Name, Sorting

• Ease of Use: Side Control, Smart Picture, Smart

Sound, Auto Volume Leveller (AVL), Program List

• Remote control type: RCFE05SPS00

• Teletext: Smart Text

• Picture in Picture: Picture in graphics, Twin page

text

• Remote Control: Amp, DVD, Multi-functional, TV

• Screen Format Adjustments: Auto Format, 4:3,

Subtitle Zoom, Super Zoom, Widescreen, Zoom

14:9, Zoom 16:9, Subtitle and Heading Shift

• Clock: Sleep Timer

Tuner/Reception/Transmission

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• TV system: PAL, SECAM

• Video Playback: NTSC, PAL, SECAM

• Aerial Input: 75 ohm coaxial (IEC75)

•TunerDisplay:PLL

• Number of Preset Channels: 100

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in/out, RGB

• Ext 2 Scart: Audio L/R, CVBS in/out, S-video in

• AV 3: DVI-I with HDCP, Audio-in mini jack 3.5mm

•Front/Sideconnections:Audio L/R in, CVBS in,

Headphone out, S-video in

Power

• Power consumption: 185 W

• Standby power consumption: < 2 W

• Mains power: AC 220 - 240 V +/- 10%

• Ambient temperature: 5 °C to 40 °C

Dimensions

• Product weight: 24 kg

• Weight incl. Packaging: 32 kg

• Set dimensions (W x H x D): 1105 x 610 x 97 mm

• Color cabinet: Bicolour High Gloss Black and Silver

Frost

• VESA wall mount compatible: 800 x 400 mm

• Stand dimensions (W x H x D):

820x 40 x 240 mm

Accessories

• Included Accessories: Table top stand, Power

cord, Quick start guide, Registration card, Remote

Control, RF antenna cable, User Manual, Warranty

certificate, DVI-I to YPbPr cable

• Optional accessories: Floor stand

•

Issue date 2009-03-30

Version: 28.0.30

12 NC: 8670 000 21621

EAN: 87 10895 88587 4

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com
