Philips 3000 series

LCD TV with Digital

Crystal Clear

19" class

digital TV

19PFL3504D

Clearly the smart choice

Designed for ease of use, this Flat TV features modern design, 2 HDMI connections, a

powerful 720p, 60Hz display and brilliant Digital Crystal Clear engine. Making the smart

choice in total picture quality has never been easier.

See brilliant picture quality

• Digital Crystal Clear for detail depth and clarity

• HD LCD display, with a 1366 x 768p resolution

• Up to 5ms response time for clear, fast moving action

• Dynamic contrast for incredible rich black details

Hear crisp and clear sound

• 2x3W RMS audio power

Easy to connect and enjoy

• Settings assistant for effortless personalized TV settings

• PC-input allows you to use your TV as a PC monitor

• 2 HDMI inputs with Easylink for HD connection

Ready for digital

• ATSC & QAM tuner receives over the air and unscrambled cable

19PFL3504D/F7

Highlights

LCD TV with Digital Crystal Clear

19" class digital TV

Digital Crystal Clear

Digital Crystal Clear is a package of picture

innovations that digitally adjusts and optimizes

picture quality to optimal contrast, color and

sharpness levels. It's like watching vivid cinema-

like images.

LCD display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

5ms response time

Response time measures signal reaction speed in

milliseconds. Faster response time is better as it

eliminates visible image artifacts that could

dampen your experience when viewing fast

moving images or objects. In this case, this LCD

panel gives you 5ms response time so that you

can watch your LCD TV with a clear, fast

moving action.

Dynamic contrast

You want the LCD flat display with the highest

contrast and most vibrant images. Philips

advanced video processing combined with

unique extreme dimming and backlight boosting

technology results in vibrant images. Dynamic

contrast will increase the contrast with

excellent blacklevel and accurate rendition of

dark shades and colors. It gives a bright, lifelike

picture with high contrast and vibrant colors.

Settings assistant

Settings assistant for effortless personalized TV

settings. The new settings assistant

personalisation wizard guides you to

personalised settings with unparalleled ease. It

includes not only picture, but the complete

viewing experience, including sound and

Ambilight settings. The wizard shows a few

screens with easy to choose options to select

the essential settings. The TV performance is set

to the your personal preference without difficult

terms or settings, and this very quickly.

2 HDMI inputs with EasyLink

EasyLink uses the HDMI CEC industry standard

protocol to share functionality between

connected devices and the TV. With Easylink

only one remote control is needed to operate

main functionalities on your TV and connected

devices. HDMI makes an uncompressed digital

RGB connection from the source to the screen

for the ultimate picture quality. HDMI uses

HDCP copy protection. With 1 HDMI input on

the back and 1 HDMI on the side of the TV you

can connect multiple HD sources, for instance

an HD settop box, a Blu-ray player, and Game

Console or Digital Camcorder.

PC input (VGA)

With PC input you can connect your TV to a

computer by a VGA cable and use the TV as a

PC monitor.

Built-in ATSC & QAM tuner

Built-in ATSC & QAM tuner for reception of

over-the-air and unscrambled HD cable

programs

19PFL3504D/F7

Specifications

LCD TV with Digital Crystal Clear

19" class digital TV

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 300 cd/m²

• Contrast ratio (typical): 1000:1

• Viewing angle: 170º (H) / 160º (V)

• Dynamic screen contrast: 4000:1

• Response time (typical): 5 ms

• Diagonal screen size: 19 inch / 48.1 cm

• Panel resolution: 1366 x 768p

• Picture enhancement: Digital Crystal Clear, 3D

Combfilter, Digital Noise Reduction, Dynamic

contrast enhancement, Progressive scan

• Visible screen diagonal (inch): 18.5 inch

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60Hz

720 x 480 60Hz

800 x 600 60Hz

1024 x 768 60Hz

1280 x 768 60Hz

1360 x 768 60Hz

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

720p 60Hz

1080i 60Hz

Sound

• Equalizer: 5-bands

• Output power (RMS): 2 x 3W

• Sound System: Dolby Digital (AC-3), Stereo, SAP

Loudspeakers

• Built-in speakers: 2

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Ease of Installation: Autostore, PLL Digital Tuning

• Ease of Use: Auto Volume Leveller (AVL),

AutoPicture, AutoSound, Settings assistant Wizard,

Side Control

• Remote Control: TV

• Screen Format Adjustments: 4:3, Movie expand 16:9,

Widescreen

Tuner/Reception/Transmission

• Aerial Input: 75 ohm F-type

• TV system: ATSC, NTSC

• Video Playback: NTSC

• Cable: Unscrambled Digital Cable -QAM

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• AV 1: Audio L/R in, YPbPr

• HDMI 1: HDMI v1.3, Analog audio L/R in

• Audio Output - Digital: Coaxial (cinch)

• Other connections: PC Audio in, PC-In VGA

•Front/Sideconnections:HDMI v1.3, S-video in,

CVBS in, Audio L/R in, Headphone out, USB

• EasyLink (HDMI-CEC): One touch play, Power

status, System info (menu language), System audio

control, System standby

Power

• Ambient temperature: 5 °C to 35 °C

• Mains power: 120V/60Hz

• Power consumption: 55 W

• Standby power consumption: < 0.5 W

Dimensions

• Set dimensions in inch (W x H x D):

19.0 x 13.2 x 3.1 inch

• VESA wall mount compatible: 100 x 100 mm

• Set dimensions with stand in inch (W x H x D):

19.0 x 14.7 x 7.1 inch

• Weight incl. Packaging (lb): 11.5

• Product weight (lb): 8.2

• Product weight (+stand) (lb): 9.1 lb

• Box dimensions in inch (W x H x D):

22.3 x 16.7 x 7.0 inch

Accessories

• Included accessories: Table top stand, Power cord,

Quick start guide, User Manual, Registration card,

Remote Control, Batteries for remote control

•

Issue date 2010-08-02

Version: 1.11.3

12 NC: 8670 000 48326

UPC: 6 09585 16380 5

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com
