Philips DVP520/00 Manuel utilisateur

. Technical Specifications…………………………………….………1-2

. Safety Instructions, Warnings, Notes...……………………...……1-3

. Mechanical and Dismantling Instructions…………………....……2-1

. Software Version& Upgrades…........................……………...…...3-1

. Trouble Shooting Chart…………………………………..…….……4-1

. Block and Wiring Diagram…………………………………….…….5-1

. Electrical Diagrams and Print-layouts

Front Board……………………………...…………………………..6-1

Power Board………………………………………………………...7-1

Main Board………………..………………………….…….….…….8-1

. Set Mechanical Exploded view& Parts List………………………..9-1

. Revision List……………….……………………………………......10-1

DVD Player DVP520/00/02/05

Service

TABLEOFCONTENTS

Page

3139 785 30530

Version 1.0

Service Manual

PHILIPS

transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise

without the prior permission of Philips.

CLASS 1

LASER PRODUCT

Published by TCL-KC 0412 Service Audio Printed in The Netherlands Subject to modification

Technical Specifications

TV standard (PAL/50Hz) (NTSC/60Hz)

Number of lines 625 525

Playback Multi standard (PAL/NTSC)

Video performance

Video output 1Vpp into 75ohm

S-video output Y: 1Vpp into 75ohm

C: 0.3Vpp into 75ohm

RGB(SCART) output

Y:0.7Vppinto75ohm

Audio format

Digital MPEG CompressedDigital

Dolby Digital 16, 20, 24bits

PCM fs,44.1,48,96kHz

MP3(ISO 9660) 96,112,128,256kbps

& variable bit rate fs,32,

44.1,48 kHz

Analogue Sound Stereo

Dolby surround-compatible downmix from Dolby Digital multi-channel

sound

Audio performance

DA converter 24bits

DVD fs 96kHz 4Hz----44kHz

fs 48kHz 4Hz----22kHz

SVCD fs 48kHz 4Hz----22kHz

fs 44.1kHz 4Hz----20kHz

CD/VCD fs 44.1kHz 4Hz----20kHz

Signal-Noise (1kHz) >90dB

Dynamic Range (1kHz) >80dB

Cross talk (1kHz) >80dB

Distortion/Noise (1kHz) >80dB

MPEG MP3 MPEG Audio L3

Audio L+R output: 1.0~2.0 Vpp into 10K ohm

Connections

Scart Output Euroconnector

S-video output Mini DIN, 4pins

Video output Cinch( yellow)

Audio L+R output Cinch (white/red)

Digitaloutput 1coaxial

IEC60958 for CDDA/LPCM

IEC61937 for MPEG1/2,

Dobly Digital

Cabinet

Dimensions (w X h X d) 360 X 43 X 285mm

Weight Approximately2.0kg

Power consumption

Power supply 230V for/00/02/05

Powerconsumption <12W

Power consumption in Standby mode <1W

*Typical playing time for movie with 2 spoken languages and

3 subtitle languages.

Specifications subjects to change without prior notice.

1-2

Safety instructions

1. General safety

Safety regulations require that during a repair:

. Connect the unit to the mains via an isolation transformer.

. Replace safety components indicated by the symbol ,

only by components identical to the original ones. Any other

component substitution (other than original type) may

increase risk of fire or electrical shock hazard.

Safety regulations require that after a repair, you must return

the unit in its original condition. Pay, in particular, attention to

the following points:

. Route the wires/cables correctly, and fix them with the

mounted cable clamps.

. Check the insulation of the mains lead for external

damage.

. Check the electrical DC resistance between the mains plug

and the secondary side:

1) Unplug the mains cord, and connect a wire between

the two pins of the mains plug.

2) Set the mains switch the “on” position (keep the

mains cord unplug).

3) Measure the resistance value between the mains

plug and the front panel, controls, and chassis

bottom.

4) Repair or correct unit when the resistance

measurement is less than 1M .

5) Verify this, before you return the unit to the

customer/user (ref. UL-standard no. 1492).

6) Switch the unit “off”, and remove the wire between

the two pins of the mains plug.

2.Laser safety

This unit employs a laser. Only qualified service personnel

may remove the cover, or attempt to service this device (due

to possible eye injury).

Laser device unit

Type : Semiconductor laser GaAlAs

Wavelength : 650nm (DVD)

: 780nm (VCD/CD)

Output power : 7mW (DVD)

:10mW(DVD/CD)

Beam divergence: 60 degree

Note: Use of controls or adjustments or performance of

procedure other than those specified herein, may result in

hazardous radiation exposure. Avoid direct exposure to

beam.

Safet

instructions, Warnin

s, Notes

1-3

Warnings

1.General

. All ICs and many other semiconductors are susceptible to

electrostatic discharges (ESD). Careless handing during

repair can reduce life drastically. Make sure that, during

repair, you are at the same potential as the mass of the set

by a wristband with resistance. Keep components and tools

at this same potential. Available ESD protection equipment:

1) Complete kit ESD3 (small tablemat, wristband,

connection box, extension cable and earth cable) 4822

310 10671.

2) Wristband tester 4822 344 13999.

. Be careful during measurements in the live voltage section.

The primary side of the power supply , including the heat

sink, carries live mains voltage when you connect the player

to the mains (even when the player is “off”!). It is possible to

touch copper tracks and/or components in this unshielded

primary area, when you service the player. Service

personnel must take precautions to prevent touching this

area or components in this area. A “lighting stroke” and a

stripe-marked printing on the printed wiring board, indicate

the primary side of the power supply.

. Never replace modules, or components, while the unit is

“on”.

2. Laser

. The use of optical instruments with this product, will

increase eye hazard.

. Only qualified service personnel may remove the cover or

attempt to service this device, due to possible eye injury.

. Repair handing should take place as much as possible with

a disc loaded inside the player.

. Text below is placed inside the unit, on the laser cover

shield:

Notes: Manufactured under licence from Dolby Laboratories.

The double-D symbol is trademarks of Dolby Laboratories,

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION

WHEN OPEN, AVOID EXPOSURE TO BEAM.

1-4

Mechanical and Dismantling Instructions

Dismantling Instruction

The following guidelines show how to dismantle the player.

Step1: Remove 5 screws around the Top Cover. And remove

it (Figure 1)

Step2: If it is necessary to dismantle Loader or Front Panel,

It should be remove the front door assembly first. (Figure 2)

If the trace can’t open in normal way, you can make it by push

the gear wheel manually using the slot below the bottom

chassis with a tool.. (Figure 3)

Note: Make sure to operate gently otherwise the gear wheel

would be damaged.

2-1

Figure 2

Figure 1

Figure 3

Push the gear gentl

until the trace out.

Make sure operate

gentlyto avoid the gea

wheel dama

ed.

Mechanical and Dismantling Instructions

Step3: Dismantling Loader, First, disconnect the 3 connectors

aiming in the figure, and then remove the 4 screws at both

sides of the loader,(Figure 4)

Step4:Dismantling Front Panel: disconnect the 2 connectors

aiming in the figure then Release the snaps on the both sides

of Front Panel and gently pull the Panel out from the set.

Figure4

Figure 5Figure 6

Snap1 Snap2

CON 1

CON 2

CON 3

CON 4

CON 5

2-2

(Figure5& 6)

Mechanical and Dismantling Instructions

Step5: Dismantling Main Board, first disconnect the

connector,and then remove the relative screws, (Figure 7)

Step6: Removethe 3 screwson power board to dismantle

the power board. (Figure 8)

Figure 6

Figure 8

CON 6

2-3

Figure 7

Mechanical and Dismantling Instructions

ATTENTION OF REPAIRING

Make sure adding silicon glue to fix the capacitor C203 after repairing, ( Avoid the hazard of C203 touching the Top

Cover.)

Figure 9

dd Silicon glue or Heat glue to fix

C203 to keep this status

2-4

Software upgrade

A. Preparation to upgrade software

1) Start the CD Burning software and create a new CD

project (Data Disc) with the following setting:

Label: DVP5XX

File System: DVP530.BIN

Note: It is required capital letter for the Label name &

the File System name.

2) Burn the data onto a blank CDR

B. Procedure for software upgrade:

1) Power up the set and insert the prepared Upgrade

CDR.

2) The set will starts reading disc & response with the

following display TV screen:

Upgrade File DETECTED

Upgrade?

Press Play TO START

3) Press <Play>button to confirm, then screen will display :

Files coping…

UPGRADING…

3) The upgraded disc will automatically out when files

coping complete, then take out the disc.

4) About 1 minute later, the trace will automatically close

when upgrading complete.

C. Read out the software versions to confirm upgrading

1) Power up the set and press <system menu> button on

the remote control.

2) Press <1><3><7><9> button.

The software version and other information are display

on the TV screen as follows:

Version XX.XX.XX.XX (Main version)

SUB-VER XX.XX.XX.XX ( software version of

application software)

8032 XX.XX.XX.XX

Servo XX.XX.XX.XX (software version of Servo)

RISC XX.XX.XX.XX

DSP XX.XX.XX.XX

Region Code X

3-1

Caution: The set must not be power off during

upgrading, in that case the decoder board will

be damaged entirely.

4-1

Spindle motor does not rotate

Yes

Check whether “AVCC”

(+5V) voltage is normal.

Fix connection

Check the AVCC powe

supply

Check/Replace Q5 Q6.

Check/ Replace U1.

Check whether the

pich-up doesn't focus

1.Check there is signal from pin 12

and pin 13 of U3 to pin 1 and pin 26

of U2,

2.Check whether there are F+, F-,

T+ and T- signals from U2.

Check/Replace the loader

Yes

Check whether laser voltage

(2V for VCD & 2.2V for DVD)

on Collector of Q5 and Q6

Check the FFC connection

between 24P and the loader.

1.Whether voltage on pin 52 of U1

varies between 0 and 3.3V (3.3V fo

VCD and 0V for DVD),

2.Whether peripheral components

are eroded or badly soldered.

Trouble shooting chart

Motor does not rotate

Autres manuels pour DVP520/00

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Lecteur DVD

Philips

Philips DVD Video Player ProDVD Wired Controller Manuel utilisateur

Philips

Philips DVP3260/05 Manuel utilisateur

Philips

Philips LX3750 Manuel utilisateur

Philips

Philips DVP3254K Manuel utilisateur

Philips

Philips DVP 1013 Manuel utilisateur

Philips

Philips DVP3880K/F8 Manuel utilisateur

Philips

Philips DVP 3015K Manuel utilisateur

Philips

Philips DVP2850MK2 Manuel utilisateur

Philips

Philips DVP 720 SA Manuel utilisateur

Philips

Philips DVP3252 Manuel utilisateur

Philips

Philips DVP3850K/96/98 Manuel utilisateur

Philips

Philips DVD590M Manuel utilisateur

Philips

Philips MATCHLINE DVD 955 Manuel utilisateur

Philips

Philips DVP3516 Manuel utilisateur

Philips

Philips GoGear SA3085/02 Manuel utilisateur

Philips

Philips DVDQ50 Manuel utilisateur

Philips

Philips PD7012 Manuel utilisateur

Philips

Philips DVD702 Manuel utilisateur

Philips

Philips DVD-712 Manuel utilisateur

Philips

Philips DVP3166K Manuel utilisateur

Philips

Philips MMS 430 Manuel utilisateur

Philips

Philips DVD616K/P01 Manuel utilisateur

Philips

Philips DVDR3320V Series Guide de démarrage rapide

Philips

Philips DVP3005/00 Manuel utilisateur

Manuels Lecteur DVD populaires d'autres marques

Sony

Sony DVP-F11 Manuel utilisateur

LENCO

LENCO DVP-740 X2 Manuel utilisateur

JVC

JVC XV-N650BEU Manuel utilisateur

Aiwa

Aiwa XD-DV370 Manuel utilisateur

MedeaWiz

MedeaWiz Sprite 4K DV-S4 Manuel utilisateur

Denon

Denon DVM-1805 - DVD Changer Manuel utilisateur

Toshiba

Toshiba SD-3815 Manuel utilisateur

Tevion

Tevion 44330 Manuel utilisateur

Samsung

Samsung DVD-HD860 Manuel utilisateur

Sylvania

Sylvania DP170SL8 Manuel utilisateur

Toshiba

Toshiba SD-P1200 Manuel utilisateur

JVC

JVC XV-D9000E Manuel utilisateur

Dolby Laboratories

Dolby Laboratories CP650 Manuel utilisateur

Denon

Denon DVD-5900 Manuel utilisateur

Sony

Sony DVP-SR201P Manuel utilisateur

Toshiba

Toshiba SD-V394SU Manuel utilisateur

Toshiba

Toshiba SD5300KC Manuel utilisateur

Impecca

Impecca DVHP-9109 Manuel utilisateur
