Philips AJ7034D Manuel utilisateur

AJ7034D

www.philips.com/welcome

EN User manual

3EN

Contents

1 Important 4

Safety 4

2 Your Docking Entertainment System 5

Introduction 5

What's in the box 5

Overview of the main unit 6

3 Get started 7

Install battery 7

Connect power 7

Turn on 7

Set time and date 8

4 Play 8

Play from iPod/iPhone 8

Listen to radio 11

Play from an external device 11

Adjust volume 11

5 Other features 12

Set alarm timer 12

Set sleep timer 12

Adjust display brightness 12

6 Product information 13

Specications 13

7 Troubleshooting 14

8 Notice 14

4EN

1 Important

Safety

• Heed all warnings.

• Follow all instructions.

• Do not use the device near water.

• Clean only with dry cloth.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or other

devices(includingampliers)thatproduce

heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the device.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Unplug the device during lightning storms

or when unused for long periods of time.

• Referallservicingtoqualiedservice

personnel. Servicing is required when the

device has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the device, the device has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

device:

• Install the battery correctly, + and - as

marked on the device.

• Remove battery when the device is

not used for a long time.

• The device shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on

thedevice(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this clock radio.

•Never place this clock radio on other electrical

equipment.

•Keep this clock radio away from direct sunlight, naked

amesorheat.

•Toreducetheriskofreorelectricshock,donot

expose this apparatus to rain or moisture.

•Ensure that you always have easy access to the power

cord, plug or adapter to disconnect this clock radio

from the power.

5EN

2 Your Docking

Entertainment

System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Introduction

With this clock radio, you can

• listen to FM radio;

• enjoy audio from iPod/iPhone or an

external device;

• set alarms to ring at different time;

• choose buzzer, radio, or audio in iPod/

iPhone as your alarm source;

• experience various features brought by

HomeStudio app.

What's in the box

Check and identify the contents of your

package:

• Mainunit(withbattery)

• Quick start guide

6EN

Overview of the main unit

a AL1/AL2

• Set alarm.

• View alarm settings.

• Activate/deactivate alarm timer.

b SNOOZE/BRIGHTNESS

• Snooze alarm.

• Adjust display brightness.

c DOCK

• Dock for iPod/iPhone.

d Volume knob

• Rotate to adjust volume or time.

• Presstoconrmaselection.

• Turn on/off the device.

f SLEEP

• Set sleep timer.

g SOURCE

• Select source.

h Battery tray

i Power cord

j /

• Tune or scan to an FM radio station.

k SET TIME

• Set the time.

l MP3 LINK

• Connect an external audio device.

m FM ANTENNA

• Improve FM reception.

7EN

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Install battery

Caution

•Risk of explosion! Keep batteries away from heat,

sunshine,orre.Neverdiscardbatteriesinre.

•Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

•The battery contains chemical substances, so it should

be disposed of properly.

•Keep children away from the battery.

•Perchlorate Material - special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate.

Note

•You can only use AC power as power supply.The pre-

installed lithium CR2032 battery can only back up time

and alarm.

For rst-time use:

Remove the protective tab to activate the

battery.

To replace the battery:

CR2032

Connect power

Caution

•Risk of product damage! Make sure that the power

voltage corresponds to the voltage printed on the back

or underside of the unit.

•Risk of electric shock! When you unplug the power

adapter, always pull the plug from the socket. Never

pull the cord.

•Before connecting the power adapter, make sure that

you have completed all other connections.

•Use the supplied power adapter only.

Insert the power plug into the wall outlet.

» The clock radio switches to the last

selected source.

Turn on

Press .

» The clock radio switches to the last

selected source.

Switch to standby mode

Press to switch the clock radio to standby

mode.

» Theclock(ifset)isdisplayed.

8EN

Set time and date

1 Press and hold SET TIME on the back

of your clock radio for more than two

seconds.

» [12H] or [24H] begins to blink.

2 Rotate the knob to select 12/24 hour

format.

3 Presstheknobtoconrm.

» The hour digits begin to blink.

4 Repeat steps 2-3 to set hour and minute.

Note

•If clock is not manually set, when iPod/iPhone is

connected, the unit synchronizes time from the iPod/

iPhone automatically.

Tip

•The accuracy of the transmitted time depends on the

docked iPod/iPhone that transmits the time signal.

4 Play

Play from iPod/iPhone

You can enjoy audio from iPod/iPhone through

this device.

Compatible iPod/iPhone

This device supports the following iPod, iPhone

models:

Made for.

• iPod touch (1st, 2nd, 3rd, and 4th

generation)

• iPod nano (1st, 2nd, 3rd, 4th, 5th, and 6th

generation)

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

Install HomeStudio App

Philips HomeStudio app brings a suite of new

features to your clock radio, including FM radio

programming and a multi-function alarm clock.

To enjoy more features, you are recommended

to install this free HomeStudio app.

Note

•Make sure that your iPod/iPhone is connected to the

Internet.

1 Press SOURCE to select the DOCK mode.

2 Insert your iPod/iPhone into the dock.

3 Fortherst-timeuse,youwillbeasked

to install HomeStudio app on your iPod/

iPhone.

4 Tap [Yes] (yes)toaccepttheinstallation

request.

5 Follow the on-screen instructions to

complete the installation.

9EN

Philips HomeStudio app only can be installed in

the following iPod, iPhone models:

• iPod touch (1st, 2nd, 3rd, and 4th

generation)

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

Play music in the iPod/iPhone

Note

•Make sure that you have installed the HomeStudio app

on your iPod/iPhone.

1 Tap HomeStudio icon on your iPod/

iPhone.

» The clock/alarm setting screen appears.

2 Slide left to display the following screen.

3 Select a track from the playlist, and then

press .

» Music streams from your iPod/iPhone

to the clock radio.

Use more features with "HomeStudio

App"

Note

•Make sure that your iPod/iPhone is inserted into the

clock radio.

Set clock, alarm, and sleep timer:

1 Launch the HomeStudio app.

2 On the screen below, tap the setting icon .

» You can set clock, sleep timer, and

alarm for your clock radio.

10 EN

Note

•The alarms set with your clock radio will appear under

[Dock Alarm] (dockalarm)category.

•You can also set more alarms by tapping on the top

right of the alarm setting screen.

Store FM radio stations manually:

1 Slide right to display the screen as below.

2 Press to tune to a radio station.

3 Press [SAVE] (save),andthenpressa

preset number.

» [SAVE] (save)andtheselected

number turns blue.

» The radio station is saved successfully.

4 If [SAVE](save)isactivated,youcantune

to other stations, and press a number to

save stations directly.

Tip

•If you need not preset more stations, press [SAVE]

(save)againtodeactivateit(ingray).

Use more features:

Slide right to the next screen.You can:

• set the theme;

• share the information;

• set the location for weather report;

• choose temperature unit;

• select month/day display mode;

• store radio stations automatically by

tapping [Radio Auto Program] (radio auto

program).

» [Searching] (searching)isdisplayed.

» All available stations are stored.

» Therststoredradiostationis

broadcast automatically.

11EN

Charge the iPod/iPhone

When your clock radio is connected to power,

the docked iPod/iPhone begins to charge

automatically.

Remove the iPod/iPhone

Pull the iPod/iPhone out of the dock.

Listen to radio

Note

•Keep the unit away from other electronic devices to

avoid radio interference.

•For better reception, do not place iPod/iPhone into

the dock when you listen to the radio. Fully extend and

adjust the position of the FM antenna.

Tune to FM radio stations

You also can tune to radio stations from your

clock radio.

1 Press SOURCE repeatedly to select FM

tuner.

2 Press and hold / on the back

of your clock radio for more than two

seconds.

» The radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more stations.

To tune to a station manually:

Press / repeatedlyuntilyoundoptimal

reception.

Play from an external device

You can also listen to an external audio device

through this clock radio.

1 Press SOURCE to select the AUX source.

2 ConnecttheMP3linkcable(notsupplied)

to:

• the MP3-LINKsocket(3 5mm)atthe

back of your clock radio.

• the headphone socket of an external

device.

3 Start to play the device (see the user

manualofthedevice).

Adjust volume

During play, you can rotate the knob to adjust

volume.

Autres manuels pour AJ7034D

Table des matières

Autres manuels Philips Station d'accueil

Philips

Philips AS 141 - Manuel utilisateur

Philips

Philips DS1600/93 Manuel utilisateur

Philips

Philips DC200 Manuel utilisateur

Philips

Philips DC315/37 Manuel utilisateur

Philips

Philips DC912 Manuel utilisateur

Philips

Philips AD712/12 Manuel utilisateur

Philips

Philips DCP750 Manuel utilisateur

Philips

Philips SpeechMike ACC4000 Manuel utilisateur

Philips

Philips DC177/37B Manuel utilisateur

Philips

Philips DCP746/37 Manuel utilisateur

Philips

Philips DC350/79 Manuel utilisateur

Philips

Philips AD-700 Manuel utilisateur

Philips

Philips AJB7038D Manuel utilisateur

Philips

Philips DC290B/37 Manuel utilisateur

Philips

Philips Streamium DC1050/12 Manuel utilisateur

Philips

Philips DS8900 Fiche d'information produit

Philips

Philips DC200/79 Manuel utilisateur

Philips

Philips AJ5305D/05 Manuel utilisateur

Philips

Philips DCM850 Manuel utilisateur

Philips

Philips AZ1330D/37B Manuel utilisateur

Philips

Philips DCB146/05 Manuel utilisateur

Philips

Philips DCP852/37B Manuel utilisateur

Philips

Philips DCB-291 Manuel utilisateur

Philips

Philips AZD1755 Manuel utilisateur

Manuels Station d'accueil populaires d'autres marques

Sony

Sony Dream Machine XDR-DS12iP Manuel utilisateur

Acer

Acer USB Type-C Dock II Manuel utilisateur

ATEN

ATEN UC-2000 Manuel utilisateur

Xcellon

Xcellon HDD-202 Manuel utilisateur

Dok

Dok CR09 Manuel utilisateur

IOGear

IOGear Travel Pro GUD3C09 Manuel utilisateur

RKI

RKI SDM-E2 Manuel utilisateur

iHome

iHome iP15 Manuel utilisateur

VITURE ONE

VITURE ONE MOBILE DOCK Manuel utilisateur

Lindy

Lindy 42984 Manuel utilisateur

CipherLab

CipherLab 8001 Manuel utilisateur

Pyle

Pyle PIPDSP2 Manuel utilisateur

Avol

Avol AS2350 Manuel utilisateur

Datalogic

Datalogic JoyaTouch Manuel utilisateur

Targus

Targus DOCK315EUZ Manuel utilisateur

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manuel utilisateur

Sirius Satellite Radio

Sirius Satellite Radio SUBX2082808a Manuel utilisateur

OWC

OWC Thunderbolt Dock Manuel utilisateur
