Philips 8FF3WMI/05 Manuel utilisateur

Quick start guide

8FF3WMI

Connect

Setup

Enjoy

PhotoFrame

What you also need

What’s in the box

Philips Wireless Digital

PhotoFrame

AC power socket

Quick Start Guide

Quick start guide

8FF3WMI

Connect

Setup

Enjoy

PhotoFrame

Digital User Manual

(with Philips PhotoFrame Manager

software and user manual)

AC-DC power adaptor

USB cable

Memory card/USB

Stand

Wireless Router Computer

1Connect

Connect the power

Insert a memory card or a USB ﬂash drive.

• Compact Flash type I

• Secure Digital (SD)

• Secure Digital (SDHC)

• Multimedia Card

• xD card

• Memory Stick

• Memory Stick Pro

• Memory Stick Duo

• Memory Stick Pro Duo

• USB ﬂash drive

Install the stand

AInsert a storage device

1Insert the stand into the PhotoFrame.

1 Connect the power cord to the PhotoFrame.

Connect the power cord to a power supply

socket.

2 Turn the stand clockwise 45 degrees to

lock it to the PhotoFrame ﬁrmly.

Setup

Turn on the PhotoFrame

Set up wireless connection

Press and hold for more than 1 second.

For the ﬁrst time use

Language selection screen is displayed.

For any other time use

The main menu is displayed.

CCaution

We recommend not to connect Philips

Wireless PhotoFrame to an open public

network (instead of a secure home network)

to protect the content on the PhotoFrame

from possibly being explored, modiﬁed, or

deleted undesirably.

You can wirelessly connect the PhotoFrame to

a PC/Mac or the Internet to share photos in

one of the 3 methods:

• Manually

• Using WPS button (Suggested)

• Using a WindowsVista PC (For details, see

User Manual in the supplied CD-ROM.)

ENote

What you need:

• A wireless router

• Broadband Internet access

Control buttons

:Turn on/off the PhotoFrame

: Go back to the upper menu

3 / 4 / 1 / 2Navigation buttons:

Select the previous/next/right/left item

OK : confirm a selection

: Menu button

1Press the WPS button on the PhotoFrame.

2Within 2 minutes, press the WPS button on

the router.

If wireless network setup is complete, a

conﬁrmation message is displayed.

3Press OK to conﬁrm.

If wireless connection is set up, is

displayed on the top-right corner of the

PhotoFrame.

4Share PC photos for wireless display.

WPS

ENote

What you need:

• A wireless router that isWPS-enabled

• Broadband Internet access

Setup

Set up wireless connection manually

AOn the PC:

1Check the settings of the wireless network.

2Record the network name (SSID) and

security key for the network.

BOn the PhotoFrame:

1In the main menu, select [Settings], then

press OK to conﬁrm.

2Select [Installation] > [Network] >

[Wireless] > [Use manual

conﬁguration], then press OK to conﬁrm.

Set up wireless connection with WPS-

enabled router

3Select the SSID for the network, then press

OK to conﬁrm.

When the security key is complete, select

[Enter], then press OK to conﬁrm.

If wireless connection is set up, is

displayed on the top-right corner of the

PhotoFrame.

6 Share PC photos for wireless display.

4To enter the security key to connect to

the network, select an alphabet/number,

then press OK to conﬁrm.

Share PC photos for wireless

display with Windows Media

Player 11

5Click [Add].

6Select a photo folder to be added to

Windows Media Player 11, then click [OK]

to conﬁrm.

7Click [OK] again.

8Enable access to shared photos with

Windows Media Player 11.

BEnable access to shared photos

1Open Windows Media Player 11.

2Click [Library].

3Select [Media Sharing ...] from the

dropdown menu.

4Select [Share my media], then click [OK]

to conﬁrm.

5Click [Settings].

6Select [Pictures] under [Media tpyes:],

choose [All ratings] under [Parental

ratings], then click [OK] to conﬁrm.

7Select the PhotoFrame, then click [Allow].

Setup

The PhotoFrame only supports JPEG photos.

ENote

• Ensure that Windows Media Player 11 is set

up on your PC.

• Ensure that the PhotoFrame and the PC are

connected to the same network.

ASelect photos on PC to share

1Open Windows Media Player 11.

2Click [Library].

3Select [Add to Library ...] from the

drop-down menu.

4Select [My personal folders] under

[Select folders to the monitor], then click

[Advanced Options>>].

8Click [OK] to conﬁrm.

9On the PhotoFrame, display photos in the

shared folder on a PC on a home network.

ETip

For details on how to set a wireless sharing

center, see User Manual in the supplied

CD-ROM.

Setup

Load an RSS feed to the

PhotoFrame

The PhotoFrame only supports JPEG photos.

RSS feeds from normal blog do not work

properly on the PhotoFrame. You can

download RSS feeds from some popular

photo web sites, for example::

• www.smugmug.com

• www.ﬂickr.com

• picasaweb.google.com

ENote

• Ensure that Philips PhotoFrame Manager is

set up on your PC.

• Ensure that the PhotoFrame and the PC are

connected to the Internet.

• Ensure that Broadband Internet access is

available.

AOn the PC:

Search the RSS photos on the Internet with

a web browser.

2Click [Start] > [PhotoFrame Manger]

to start Philips PhotoFrame Manager.

2Click the +symbol on the [RSS Feed]

panel to add an RSS feed.

3Enter [Category] and [Name] of the RSS

feed.

4Drag and drop (or copy) the RSS icon

to the [Address] ﬁeld, then click [OK] to

conﬁrm.

5On the PhotoFrame, display RSS photos

posted online.

BOn Philips PhotoFrame Manager:

Click the [RSS Feed] panel.

1In the main menu, select [PhotoFrame],

then press OK to conﬁrm.

2Select a photo source, then press OK to

conﬁrm.

3Select an album, then press OK to conﬁrm.

ETip

Only JPEG photos can be displayed on the

PhotoFrame.

Display photos on the

PhotoFrame/storage device

Enjoy

1In the main menu, select [Shared], then

press OK to conﬁrm.

2Select [Network Servers], then press OK

to confirm.

3Select an access point, then press OK to

confirm.

4Select a shared photo folder from the list,

then press OK to confirm.

Display streaming photos on

shared folders on a home

network

1In the main menu, select [Online], then

press OK to conﬁrm.

2Select an RSS feed, then press OK to

conﬁrm.

3Select an album, then press OK to conﬁrm.

ETip

• The PhotoFrame only supports JPEG photos.

The RSS feed from normal blog does not

work properly on the PhotoFrame.

• An RSS feed refreshes frequently (usually at

an interval of an hour) online.

Display Internet photos with

the PhotoFrame

Enjoy

1In the main menu, select [Settings], then

press OK to conﬁrm.

2Select [Slideshow], then press OK to

conﬁrm.

3Select [Transition Effect], then press OK

to conﬁrm.

4Select [Collage], then press OK to conﬁrm.

5Select a collage format, then press OK to

conﬁrm.

• To stop collage display, select [Settings] >

[Slideshow] > [Transition Effect] > [No

effect], then press OK to conﬁrm.

Display collage photos on the

PhotoFrame

1In the main menu, select [PhotoFrame]

> a photo source, then press OK to

conﬁrm.

2 Select an album, then press 1 (Right) to

access the thumbnail mode.

3Select a photo, then press to access

Photo Options.

Then you can select an option from the list

to edit photos:

• Rotate

• Effect

• Rename

• Copy

• Move

• Delete

Edit Photos

You can display photos in the correct

orientation depending the horizontal/vertical

orientation of the PhotoFrame.

1In the main menu, select [Settings], then

press OK to conﬁrm.

2 Select [Installation], then press OK to

conﬁrm.

3Select [Auto Tilt], then press OK to

conﬁrm.

4Select [On], then press OK to conﬁrm.

Set auto orientation

Enjoy

You can adjust the brightness sensor for

the PhotoFrame to turn on or off the display

according to the brightness of environment.

1In the main menu, select [Settings], then

press OK to conﬁrm.

2Select [Installation], then press OK to

conﬁrm.

3Select [SmartPower Pro], then press OK

to conﬁrm.

4Select [Screen On-Sensor] / [Screen

Off-Sensor], then press 1 (Right).

Press 3 / 4 to adjust brightness sensor,

then press OK to conﬁrm.

Select [Auto Screen On/Off], then press

OK to conﬁrm.

7Select [Auto Sensor], then press OK to

conﬁrm.

Select display auto on/off by

brightness sensor

ETip

• When the ambient light reaches the set

auto on/off level and lasts 15 seconds, the

Auto Sensor function takes effect.

• If the auto-on brightness level is set too

close with the auto-off brightness level,

the display Auto on/off function may not

work.

With SmartPower function on the

PhotoFrame, you can conﬁgure the time for

the PhotoFrame to turn on or off the display

automatically.

1In the main menu, select [Settings], then

press OK to conﬁrm.

2Select [Installation], then press OK to

conﬁrm.

3Select [SmartPower Pro], then press OK

to conﬁrm.

4Select [Screen On-Timer] / [Screen

Off-Timer], then press 1 (Right).

5Press 3 / 4 / 1 / 2to set time, then press

OK to conﬁrm.

6Select [Auto Screen On/Off] and press

OK to conﬁrm.

7Select [Timer], then press OK to conﬁrm.

Select display auto on/off by

time

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Cadre photo numérique

Philips

Philips SPF3007 Manuel utilisateur

Philips

Philips SPF3400/G7 Manuel utilisateur

Philips

Philips SPF1027/05 Manuel utilisateur

Philips

Philips 7FF1CWO Manuel utilisateur

Philips

Philips SPF5010/12 Manuel utilisateur

Philips

Philips 7FFI Manuel utilisateur

Philips

Philips 6FF3FPB Manuel utilisateur

Philips

Philips 7FF2FPAS Manuel utilisateur

Philips

Philips SPF1207 Manuel utilisateur

Philips

Philips SPF2017/10 Manuel utilisateur

Philips

Philips SPF3480T Manuel utilisateur

Philips

Philips SPH8528/10 Manuel utilisateur

Philips

Philips SPF3473 Manuel utilisateur

Philips

Philips PhotoViewer SPV3000 Manuel utilisateur

Philips

Philips SPH8628/12 Manuel utilisateur

Philips

Philips SPF5008 Manuel utilisateur

Philips

Philips SPF2027/93 Manuel utilisateur

Philips

Philips SPF5208 Manuel utilisateur

Philips

Philips SPF4328/10 Manuel utilisateur

Philips

Philips 10FF2M4 Manuel utilisateur

Philips

Philips 10FF3CMI Manuel utilisateur

Philips

Philips 10FF2CMW/27 Manuel utilisateur

Philips

Philips 9FF2CME - annexe 2 Manuel utilisateur

Philips

Philips 10FF2CMW Manuel utilisateur

Manuels Cadre photo numérique populaires d'autres marques

LENCO

LENCO DF-830 Manuel utilisateur

NIX

NIX Advance X10G Manuel utilisateur

Nextar

Nextar N7S-100 Manuel utilisateur

Sungale

Sungale TD350A Manuel utilisateur

texet

texet DPF-830 Instructions de montage

Digital Spectrum

Digital Spectrum MemoryVue MV-1500 Manuel utilisateur

ViewSonic

ViewSonic VFM1042-52 Manuel utilisateur

YURAKU

YURAKU YUR.PHOTO 7B4C Manuel utilisateur

Denver

Denver PFF-710WHITE MK2 Manuel utilisateur

Pandigital

Pandigital PAN8000DWPCF1 Manuel utilisateur

Rekam

Rekam Deja View HD-850 Manuel utilisateur

Majestic

Majestic DF 918HD MP3 Manuel utilisateur

ViewSonic

ViewSonic DPF8-CAM Manuel utilisateur

Digital Foci

Digital Foci Image Moments IMT-063 Manuel utilisateur

Nokia

Nokia SU-4 Manuel utilisateur

Hama

Hama 118564 Manuel utilisateur

Sungale

Sungale CD352LD Manuel utilisateur

Kodak

Kodak W1020 - GUIA COMPLETO DO USUÁRIO FOR FIRMWARE VERSIONS EARLIER THAN... Manuel utilisateur
