Philips DECT515 Manuel utilisateur
GB
IRL
3111 285 21872
User manual
Charge the handset(s) 24 hours
before use.
Quick start guide 1
http://www.philips.com/faqs/dect
Quick start guide
Answer/end a call
Make a call
Redial a number
Call from phonebook
Add a name in the phonebook
Adjust the earpiece volume during a call
Adjust the handset loudspeaker volume
Mute and unmute the microphone
Read Call log
Read an event
Set the date and time
Set the handset external ring tone
Activate/deactivate the answer machine
Transfer a call/Intercom (if there are
at least 2 handsets)
Predial number & or and dial number
up and browse and
down,browse through the list and
Predial number and select scroll to Store
and select ,enter the name and press OK
Scroll up to increase the volume, scroll down
to decrease the volume
During a handsfree call,up to increase, down to
decrease
During a call press Options,press Mute
press End mute
Press to enter the carousel,scroll to Sounds
and select. ,press to select Handset ring tones.
Press to select External ring tone
Browse through the list to hear the ring tones and select
your ring tone
Press to enter the carousel,scroll to Handset
and select. ,scroll to Date and time and select
Press to select Set date and enter the current date,
press OK.Scroll to Set time and enter the current time,
press OK
Press View
up and browse
Press + number phone
Press on the base station to switch the answer
machine ON or OFF
The pilot key allows you to browse the menus.Up to go left in the menus and down to go
right in the menus & options.
Press to select a menu or an option and validate a setting.It is also used as shortcut to menus
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 1
DECT 511/DECT 515 handset
2http://www.philips.com/faqs/dect
Pilot key
Press to enter the carousel or
select a menu or an option
Scroll to move through the
menus & options
Move the cursor left/right
Scroll up to access the Call
Log from idle mode
Scroll down to access the
Phonebook from idle mode
A long press to unlock the keypad
Loudspeaker*
- Short press to take the line or to
activate the handset loudspeaker
during a call
Keypad lock & Editing
- Short press to insert *
- Long press to lock/unlock the
keypad in idle mode
- Long press to insert R (in
between-digit pause) when dialling
- Long press to enter multitap
system or Eatoni®editor when
entering text
-A short press to change the
letter when editing in Eatoni®.
SMS key
- Short press to directly access
Send new SMS from idle mode
- Short press from the Phonebook
or the Call log menu to edit an SMS
Alarm clock
-A short press to dial 0
-A long press to activate/deactivate
the alarm clock
Do not disturb & case mode
- Short press to insert # when
dialling
- Long press to activate/deactivate
the“Do Not Disturb” mode
- Long press to insert a pause (P)
when dialling
- Press to switch case mode when
editing
Clear/Recall
-To correct a digit when predialling
or a character when editing
- Short press to go back one menu
when navigating
- Long press to return to idle
mode when navigating
-To insert R for operator services
when on line
Talk
- Press to take the line,answer a
call or hang up.
Earpiece
Microphone
Call transfer/Intercom
- Short press to initiate or cancel
internal call
- Short press during internal call to
transfer the call or switch between
internal call and External call
- Short press to answer an internal
call or to release an internal call
DECT 511/DECT 515
Handset
*Warning : Handsfree activation could suddenly increase the volume in the earpiece to a very
high level.Make sure the handset is not too close to your ear.
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 2
Icons on the handset display 3
http://www.philips.com/faqs/dect
Icons on the handset display
The display gives information about the operation of your telephone
The answer machine is activated (DECT 515).When blinking,this symbol
indicates that there is a new message on the answer machine or on the
operator voice mailbox.When fast blinking it shows that the answer
machine is full.
When charging,the battery bars scroll from empty to full status.
When the handset discharges,the battery shows the status :
Full ,2/3 , 1/3 and empty .
An internal call is in progress.When blinking, this symbol indicates that there
is an internal incoming call.
The handset loudspeaker is activated.When blinking,this symbol shows that
the base loudspeaker is activated (only for DECT 515).
The ring tone is deactivated.
The SMS function is activated.When blinking,this symbol indicates that a
new SMS has been received.When fast blinking,it indicates that the SMS
memory is full.
The handset is registered and in range of the base.When blinking,this symbol
indicates that the handset is not registered to the base.
An external call is in progress.When blinking,this symbol indicates that
there is an incoming external call in progress or that the line is already busy.
On first use, it is sometimes necessary to wait for a few minutes of charge before seeing icons
on the display.
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 1
DECT 511/DECT515 base stations
4
http://www.philips.com/faqs/dect
Paging key
The paging key enables you to locate a missing handset.Press the key until the handset starts
to ring.Once retrieved,press any key on the handset to end paging.
Delete key
Short press to delete current
message
Long press to delete all the
messages (except unread ones)
ON/OFF key
Press to switch the answer
machine ON or OFF
Play/Stop key
Short press to play new
message
Short press to stop a message
while listening to it
Skip/Fast forward key
Short press to go to the next
message while listening
Long press to fast forward the
current message while listening
Paging key
Press to locate all handsets
New message
indicator
When blinking,it indicates
that there is a new message.
When fast blinking,it indicates
that the answer machine
memory is full.
base station
base station
Loudspeaker
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 2
Table of contents 5
http://www.philips.com/faqs/dect
Quick start guide 1
DECT 511 / DECT 515 handset 2
Icons on the handset display 3
DECT 511 / DECT 515 base stations 4
Table of Contents 5-6
Menu structure 7-11
Conformity, Environment and Safety 12
Declaration of conformity
Using GAP standard compliance 13
Installing the DECT 511/515
Unpacking your DECT 511 14
Unpacking your DECT 515 14
Installing the base station 15
Installing and replacing the batteries in the handset 15
Battery life and range 15
Introduction
Philips screen saver 16
Idle mode 16
Understanding the menu system 16
How to navigate in the menus 16
Basic principles 17
In-call features 18
Editing systems 19-20
SMS
Send new SMS 21
Read SMS 22
SMS settings 25
Handset
Babysit mode 28
Registration 28
Rename handset 29
Date & time 29
Display contrast 30
Backlight 30
Screen saver 30
Table of contents
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 3
Table of contents
6
http://www.philips.com/faqs/dect
Answer machine
Saved messages 31
Outgoing messages 33
Answerphone settings 33
Record and listen to a memo 37
Intercom
Internal call 38
Call transfer 38
Conference call 39
Babysit mode 39
Phonebook
Add new 40
View 40
Call log
View 43
Delete all 45
Call log settings 45
Operator services 46
Extra
Call duration 47
Alarm clock 47
“Do Not Disturb” mode 48
Sounds
Handset ring tones 49
Base ring tones 50
Group ring tones 50
Handset ring tone volume 50
Base ring tone volume 50
My ring tones 51
Record personal melody 51
Settings 52
Base
Enable registration 54
Line settings 54
Service code settings 56
FAQ 57-58
Troubleshooting 59-60
Index
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 4
Menu structure 7
http://www.philips.com/faqs/dect
SMS Send new SMS Choose SMS box* Send SMS to phone
View number
Reply
Forward
Send again
Delete SMS
Copy to phonebook
Call
Read SMS
Read SMS
SMS Settings
Choose SMS box*
Mode
SMS boxes*
SMS centre
Handset Babysit mode
Registration
Rename handset
Date & time
Display contrast
Backlight
Screensaver
Register handset
On or Off
Enter name
Set date
Levels (1 to 5)
Off / 10s / 20s
Set time
Enter RC code
On or Off
Un-register handset
Menu structure
Menu
By using the“Pilot key” on the side of the handset,you can scroll through the menus.
* only available in the UK
Base selection
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 5
Menu structure
8http://www.philips.com/faqs/dect
Call all
Handset list
Intercom
Change code
Answerphone settings Mode On or Off
Toll saver / 3 / 5 / 7
Rings before answer
Voice language Off/Low/Medium/
High/Boost
Call screening
Recording quality
Answer and record
with personalised OGM
Answer only with
personalised OGM
Answer and record
with predefined OGM
Answer only with
predefined OGM
High / Standard
Mode (On or Off)
Remote control
Play
Next
Previous
Call
Delete
Store
Send SMS
Answer machine Saved messages
Record a memo
Outgoing messages Answ.machine mode
Record outgg msg Standard OGM for
answ.& record mode
Standard OGM for
answer mode only
Group A Play/Record new
Delete
Group B
Group C
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 6
Menu structure 9
http://www.philips.com/faqs/dect
Operator services Call forward
Cancel call forward
Call forward when
line busy
Call forward when
unanswered
Voice mail
Cancel call back
Withhold identity
Cancel call forward
when line busy
Cancel call forward
when unanswered
All calls
No call
Call log View
Delete all
Call log settings Incoming calls
Outgoing calls
All calls
Unanswered calls only
Calls with answer
machine message only
View
Add new
Phonebook Call
Change number
Change name
Define the group A / B / C
Change SMS box*
Delete
Send SMS
Play
Call
View number
Store
Delete
Send SMS
* only available in the UK
DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 7
Ce manuel convient aux modèles suivants
6
Table des matières
Autres manuels Philips Téléphone sans fil
Philips
Philips CD4953B Manuel utilisateur
Philips
Philips D705 Manuel de l'opérateur
Philips
Philips D450 Manuel de l'opérateur
Philips
Philips DECT7272S Manuel utilisateur
Philips
Philips Kala 300 Quattro Manuel utilisateur
Philips
Philips Kala Plus 200 Manuel utilisateur
Philips
Philips VOIP3212S Manuel utilisateur
Philips
Philips CD4401B/51 Manuel utilisateur
Philips
Philips B155 Manuel de l'opérateur
Philips
Philips BeNear CD4851B Manuel utilisateur
Philips
Philips XL3401B/05 Manuel utilisateur
Philips
Philips CD280 Manuel utilisateur
Philips
Philips D135 Fiche d'information produit
Philips
Philips CD4453B Manuel utilisateur
Philips
Philips XL490 Manuel utilisateur
Philips
Philips ID9370B/37 Manuel utilisateur
Philips
Philips SE245 Manuel utilisateur
Philips
Philips M8881W Fiche d'information produit
Philips
Philips 2000 series Manuel utilisateur
Philips
Philips DECT5211S Manuel utilisateur
