Philips CD181 Manuel utilisateur

Quick start guide

CD181/CD186

Important safety instructions

• Use only the power supply listed in the technical data.

• Do not allow the product to come into contact with liquids.

• Risk of explosion if battery is replaced by an incorrect type.

• Dispose of used batteries according to the instructions. (Refer to the user manual online)

Overview

CD186

CD181

Loudspeaker

• Find handsets.

• Register additional

handsets.

Adjust the speaker volume.

• Play the previous message.

• Replay the current message.

Turn the answering machine on/off.

Skip to next message.

• Delete the currrent messages.

• Delete all messages (press and hold).

Start/stop listening to the recorded messages.

In call In idle mode In menu

MENU/OK Enter the option

Enter the option

Conrmselection

REDIAL/C Enter the redial list Enter the redial list Cancel operation

Increase the volume Enter the

phonebook

Scroll up

Decrease the

volume

Enter the call log Scroll down

Recall key*

*network dependent

Make and receive

calls

End calls Turn handset on/off

(press and hold)

Exit menu/operation

Mute/unmute the

microphone

Turn the speaker

on/off

Make and receive

calls

Speaker

Earpiece

Microphone

It displays the connection between

the handset and the base.The more

the bars are shown, the better the

connection is.

It indicates a received call in the call log.

It indicates an outgoing call in the

redial list.

Itasheswhenthereisanewmissed

call.

It remains steadily on when browsing

the missed calls in call log.

Itasheswhenreceivingincomingcall.

It remains steadily on during a call.

The speaker is on.

The ringer is off.

Answeringmachine:itasheswhen

there is a new message. It remains

steadily on when the telephone

answering machine is turned on.

If you are using a voice mailbox from

yourprovider,thisiconasheswhen

there is a new message.

It remains steadily on when the voice

messages are already viewed in the

call log.

The icon is not shown when there is

no voice message.

* This is network dependent

It displays when you scroll up/down

a list or increase and decrease the

volume.

There are more digits on the right.

Press REDIAL/C to read.

Connect the base station

Telephone

socket

Power

socket

Power

adapter

Power

socket

Extra

handset

charger

Telephone

base station

2 1 3

1 Connect each end of the power adapter to:

• the DC input jack at the bottom of the base station;

• the power socket on the wall.

2 Connect each end of the line cord to:

• the telephone socket at the bottom of the base station;

• the telephone socket on the wall.

For multi-handset version only:

3 Connect each end of the power adapter to:

• the DC input jack at the bottom of the extra handset charger.

• the power socket on the wall.

1Connect

2Get started

Congure your phone

1 The batteries are pre-installed in the handset. Pull the battery tape off

from the battery door before charging.

2 Whenusingyourphoneforthersttime,youseeawelcome

message (country dependent).

After the welcome message, press MENU/OK.

3 Please set the country and language if prompted.

4 Set the date and time.

• If the time is in 12-hour format, press / key to select [AM] or

[PM].

Charge your phone

Charge 8 hours

Place the handset on the base station to charge the handset.When

the handset is placed correctly on the base station, you hear a docking

sound.

»The handset starts charging.

NoteChargethebatteriesfor8hoursbeforerstuse.

Check the battery level

When the handset is off the base station/charger, the bars

indicate the battery level (full, medium and low).

When the handset is on the base station/charger, the bars

ashuntilchargingcompletes.

Theemptybatteryiconashesandyouhearanalerttone.

The battery is low and needs recharging.

3Enjoy

Call

• To make a call, press and dial the

phone number.

• To answer a call, press when the

phone rings.

• To end a call, press .

Earpiece volume

Press or to adjust the volume

during a call.

Phonebook

Add record

1 Press MENU/OK, then select

[PHONEBOOK] > [ADD NEW],

then press MENU/OKtoconrm.

2 Enter the name, then press

MENU/OKtoconrm.

3 Enter the number, then press

MENU/OKtoconrm.

Call from the phonebook

1 Press or, press MENU/OK >

[PHONEBOOK] > [VIEW] to

access the phonebook list.

2 Select a contact.

3 Press to make the call.

Direct access memory

You have 2 direct access memories

(Keys 1 and 2).To dial the saved phone

number automatically, press and hold

on the keys in idle mode.

Depending on your country, Keys 1

and 2 are preset to [1_VOICEMAIL]

(voice mail number) and [2_INFO

SVC] (information service number)

of your network operator respectively

(network dependent).

Call log

1 Press and select a record.

To make a call

2 Press .

To view more details

2 Press MENU/OK.

3 Select [VIEW].

To save a call record to the

phonebook

2 Press MENU/OK.

3 Select [SAVE NUMBER].

4 Press MENU/OKtoconrm.

5 Enter the name.

6 Press MENU/OKtoconrm.

7 Press MENU/OK to save.

To delete a call record

2 Press MENU/OK.

Select

[DELETE]

[DELETE ALL]

4 Press MENU/OKtoconrm.

Redial list

1 Press REDIAL/C and select a record.

To make a call

2 Press .

To save a call record to the

phonebook

2 Press MENU/OK.

3 Select [SAVE NUMBER].

4 Press MENU/OKtoconrm.

5 Enter the name.

6 Press MENU/OKtoconrm.

7 Press MENU/OK to save.

To delete a call record

2 Press MENU/OK.

3 Select [DELETE] or [DELETE

ALL].

4 Press MENU/OKtoconrm.

Record an

announcement

(for CD186 only)

1 Press MENU/OK > [ANSW

MACHINE] >

[ANNOUNCEMENT], then press

MENU/OKtoconrm.

2 Select [ANSWER ONLY] or

[RECORD ALSO], then press

MENU/OKtoconrm.

3 Select [RECORD NEW], then press

MENU/OKtoconrm.

4 Start recording close to the

microphone after the beep.

5 Press MENU/OK to stop recording.

»You can listen to the newly

recorded announcement on the

handset.

You can register additional handsets

to the base station.The base station

can register up to 4 handsets.

1 Press MENU/OK on the

handset.

2 Select [SERVICES] >

[REGISTER], then press

MENU/OKtoconrm.

3 Press and hold on the base

station for 5 seconds.

Enter the system PIN (0000).

Press

MENU/OKtoconrm

the PIN.

»Registration is completed in

less than 2 minutes.

Restore default

settings

You can reset your phone settings

to the original factory settings.

1 Press MENU/OK.

2 Select [SERVICES] >

[RESET], then press

MENU/OKtoconrm.

»The handset displays a

conrmationrequest.

3 Press MENU/OKtoconrm.

»All settings are reset

»The welcome screen displays.

Technical data

Battery

• GP: PH50AAAHC: 2 x AAA NiMH 1.2V

Rechargeable 500mAh batteries

• BYD: H-AAA500A-Z: 2 x AAA NiMH 1.2V

Rechargeable 500mAh batteries

Adapter

Base and charger:

• Philips:

SSW-1920EU-2/SSW-1920UK-2/

S003PV0600050/S003PB0600050:

Input: 100-240V 50/60Hz 0.2A;

Output: 6V 500mA

Note Hereby Philips Consumer Lifestyle,

declares that the CD181/CD186 is in

compliance with the essential requirements

and other relevant provisions of Directive

1999/5/EC.YoucanndtheDeclarationof

Conformity on www.p4c.philips.com.
