Philips CD1802B/90 Manuel utilisateur

Quick start guide

CD180

Important safety instructions

Use only the power adapter listed in the technical data.•

Do not allow the product to come into contact with liquids.•

Risk of explosion if battery is replaced by an incorrect type.•

Dispose of used batteries according to the instructions. (Refer to the user manual online)•

Overview

Find handsets.•

handsets.

Earpiece

Microphone

In call In idle mode In menu

MENU/OK Enter the option

Enter the option

Conrmselection

REDIAL/C Enter the redial list Enter the redial list Cancel operation

Increase the volume Enter the

phonebook

Scroll up

Decrease the

volume

Enter the call log Scroll down

Make and receive

calls

End calls Turn handset on/off

(press and hold)

Exit menu/operation

Mute/unmute the

microphone

RRecall key*

*network dependent

It displays the connection between

the handset and the base.The more

the bars are shown, the better the

connection is.

It indicates a received call in the call log.

It indicates an outgoing call in the

redial list.

Itasheswhenthereisanewmissed

call.

It remains steadily on when browsing

the missed calls in call log.

Itasheswhenreceivingincomingcall.

It remains steadily on during a call.

The ringer is off.

If you are using a voice mailbox from

yourprovider,thisiconasheswhen

there is a new message.

It remains steadily on when the voice

messages are already viewed in the

call log.

The icon is not shown when there is

no voice message.

* This is network dependent

It displays when you scroll up/down

a list or increase and decrease the

volume.

There are more digits on the right.

Press REDIAL/C to read.

Connect the base station

Telephone

socket

Power

socket

Power

adapter

Power

socket

Extra

handset

charger

Telephone

base station

2 1 3

Connect each end of the power adapter to:1

the DC input jack at the bottom of the base station;•

the power socket on the wall.•

Connect each end of the line cord to:2

the telephone socket at the bottom of the base station;•

the telephone socket on the wall.•

For multi-handset version only:

Connect each end of the power adapter to:3

the DC input jack at the bottom of the extra handset charger.•

the power socket on the wall.•

1Connect

2Get started

Congure your phone

The batteries are pre-installed in the handset. Pull the battery tape off1

from the battery door before charging.

Whenusingyourphoneforthersttime,youseeawelcome2

message (country dependent).

After the welcome message, press MENU/OK.

Please set the country and language if prompted.3

Set the date and time.4

If the time is in 12-hour format, press• / key to select [AM] or

[PM].

Charge your phone

Charge 8 hours

Place the handset on the base station to charge the handset.When

the handset is placed correctly on the base station, you hear a docking

sound.

The handset starts charging.»

NoteChargethebatteriesfor8hoursbeforerstuse.

Check the battery level

When the handset is off the base station/charger, the bars

indicate the battery level (full, medium and low).

When the handset is on the base station/charger, the bars

ashuntilchargingcompletes.

Theemptybatteryiconashesandyouhearanalerttone.

The battery is low and needs recharging.

3Enjoy

Call

To make a call, press• and dial the

phone number.

To answer a call, press• when the

phone rings.

To end a call, press• .

Earpiece volume

Press or to adjust the volume

during a call.

Phonebook

Add record

Press1 MENU/OK, then select

[PHONEBOOK] > [ADD NEW],

then press MENU/OKtoconrm.

Enter the name, then press

MENU/OKtoconrm.

Enter the number, then press

MENU/OKtoconrm.

Call from the phonebook

Press1 or, press MENU/OK >

[PHONEBOOK] > [VIEW] to

access the phonebook list.

Select a contact.

Press3 to make the call.

Direct access memory

You have 2 direct access memories

(Keys 1 and 2).To dial the saved phone

number automatically, press and hold

on the keys in idle mode.

Depending on your country, Keys 1

and 2 are preset to [1_VOICEMAIL]

(voice mail number) and [2_INFO

SVC] (information service number)

of your network operator respectively

(network dependent).

Call log

Press1 and select a record.

To make a call

Press2 .

To view more details

Press2 MENU/OK.

Select

3 [VIEW].

To save a call record to the

phonebook

Press2 MENU/OK.

Select

3 [SAVE NUMBER].

Press

4 MENU/OKtoconrm.

Enter the name.

Press6 MENU/OKtoconrm.

Press

7 MENU/OK to save.

To delete a call record

Press2 MENU/OK.

Select

[DELETE]

[DELETE ALL]

Press4 MENU/OKtoconrm.

Redial list

Press1 REDIAL/C and select a record.

To make a call

Press2 .

To save a call record to the

phonebook

Press2 MENU/OK.

Select

3 [SAVE NUMBER].

Press

4 MENU/OKtoconrm.

Enter the name.

Press6 MENU/OKtoconrm.

Press

7 MENU/OK to save.

To delete a call record

Press2 MENU/OK.

Select

[DELETE]

[DELETE ALL]

Press4 MENU/OKtoconrm.

You can register additional handsets to

the base station.The base station can

Press

1 MENU/OK on the handset.

Select2 [SERVICES] > [REGISTER],

then press MENU/OKtoconrm.

Press and hold3 on the base

station for 5 seconds.

Enter the system PIN (0000).

Press

5 MENU/OKtoconrmthePIN.

Registration is completed in less»

than 2 minutes.

Technical data

Battery

CORUN: 2 x AAA NiMH 1.2V Rechargeable 500mAh•

batteries

SANIK: 2 x AAA NiMH 1.2V Rechargeable 500mAh•

batteries

Power adapter

Base and charger:

Salom:•

SSW-1920UK-2:

Input: 100-240V 50/60Hz 0.2A;

Output: 6V 500mA

Tenpao:•

S003PB0600050:

Input: 100-240V 50/60Hz 0.2A;

Output: 6V 500mA

Restore default settings

You can reset your phone settings to the original factory

settings.

Press

1 MENU/OK.

Select

2 [SERVICES] > [RESET], then press

MENU/OKtoconrm.

Thehandsetdisplaysaconrmationrequest.»

Press

3 MENU/OKtoconrm.

All settings are reset»

The welcome screen displays.»
