Philips Xenium CTX703GRY/00 Manuel utilisateur

Discover your phone

Philips continuously strives to improve its products. Therefore, Philips reserves the rights to revise

this user guide or withdraw it at any time without prior notice. Philips provides this user guide "as is"

and does not accept, except as required by the applicable law, liability for any error, omission or

discrepancy between this user guide and the product described. The device is meant to be connected

to GSM/GPRS/EDGE networks.

Power on/off

key,

Unlock/lock

key

Side

volume

key

Camera key

Status pull-

down menu

TFT LCD

Back key

3.2MP

Camera

lens

Loudspeaker

Light sensor

3.5mm

headset jack

Microphone

Shortcut icons

Multimedia

key

USB port/

charger

How to ...

Switch the phone On/Off Long press the Power on/off key )on the left side of the

phone..

Enter your PIN code Enter your PIN code through the on-screen keypad and

tap on OK to confirm.

Lock the keypad Short press )on the left side of the phone.

Unlock the keypad Short press )on the left side of the phone or slide the

lock icon on the idle screen to unlock.

Make a call On the idle screen, tap on to select a contact, or

to enter a phone number, and then tap on Dial (Call).

Answer a call When the phone rings, tap on Answer.

Mute the ringing call or

sounding alarm

When the phone/ alarm rings, turn over the phone, front

side to the back, or back side to the front (if you have

turned on the options in > Settings > General > Motion

sensor).

Activate/Deactivate handsfree

mode

During a call, tap on Options to access the options list,

select to turn on or off the option Handsfree.

End a call Tap on the option End.

Access received messages/

missed calls

On the idle screen, tap on the icon for new messages or

missed calls.

Check all calls history On the idle screen, press the Back key ,.

Check or write messages On the idle screen, tap on .

Access the main menu On the idle screen, tap on .

Quickly return to idle when

browsing menus

Press the Back key ,.

Quickly access to the

multimedia screen

On the idle screen, press the multimedia key Mto quickly

access to the multimedia screen. Tap on the desired

multimedia fuctional icon (Browser, Image viewer,

Multimedia player, Music player and FM radio) to access the

corresponding menu. For more details, refer to

"Multimedia screen" on page 5.

Access the status pull-down

Tap on at the top of idle screen. Tap to select

options.

Enter the camera/video mode On the idle screen, press the Camera key C. Tap

/to select the camera/video mode.

Select on-screen input keypads/

modes

Qwerty keypad : On the editing screen, turn the

phone counter clockwise by 90 degrees, vertical to

horizontal.

Alphanumeric keypad : Turn the horizontal

phone clockwise by 90 degrees, horizontal to vertical.

Handwriting recognition mode : Tap on /

to switch between the two modes.

Tap on the language, numeric, or input method icon to

select.

Quick access to functions

You can quickly access functions directly from

the idle screen (using the shortcut icons, the

multimedia key M, or status pull-down menu),

or through the main menu.

Shortcut icons

On the idle screen, the four shortcut icons lead

you directly to four functional displays.

: Quick access to messaging

: Quick access to phonebooks

: Quick access to dial pad

: Quick access to main menu

Main menu

The main menu gives you access to all the

different features of your mobile phone. The

table below summarizes the functional icons on

the main menu. To find more information about

their functions, refer to the pages.

App Browser Multimedia

page 55 page 46 page 57

Camera Messaging My files

page 48 page 24 page 64

Tools Contacts Profiles

page 39 page 34 page 73

Bluetooth Calls Settings

page 70 page 67 page 74

Tap on on idle screen to access the main

menu. To select your option, tap on the icons

and lists, and then OK. Tap on Options to access

the options related to the selected item. Tap on

Back to return to the previous menu. Press ,

to return to the idle screen.

Multimedia screen

On the idle screen, press the multimedia key M

to quickly access the multimedia functional

screen. As the following picture:

On this multimedia functional screen, you can

tap on the Browser icon to go to the internet; tap

on the Image viewer icon to enjoy pictures; tap

on the Multimedia player or Music player icon to

play video and audio files; tap on FM radio to

listen to the radio programs. For more details,

refer to "Multimedia" on page 57.

Functional displays

On the idle screen, you can switch between up

to 6 displays. You can select a functional display.

With such functional displays, you can quickly

check world clock (World clock); or check or edit

to-do list (Calendar) or memos (Quick notes); or

conveniently send messages to up to 3 recent

contacts/numbers of outgoing messages

(Messaging); or place a call to preset contacts

just by a long tap (Quick call); or show clock time

(Clock).

Customize functional displays

Select up to 6 functional displays as needed.

Go to Settings > Dashboard.

Select your option. Tap on Select/Cancel to

select or unselect.

Tap on Done to finish setting.

Switch between different displays

• Slide the bar below displays.

•Or,tapon / .

Status pull-down menu

By dragging at the top of the idle screen,

you can quickly turn on/off the alarm, GPRS

connection, Bluetooth, or silent mode; check

battery level; and select your desired profile, or

ring type for incoming calls or messages.

Stylus

The touch screen allows you to enter text by

directly writing on the screen, or tap to select

the desired option. The supplied stylus makes it

easier to do so.

The first time you switch on the phone, you are

asked to do calibration for the stylus. Thus,

strokes or taps by the stylus will be precisely

displayed on the screen.

You can also do the calibration in Settings >

General

> Pen calibration by following the screen

instructions.

Sensor

With built-in motion and light sensors, the

phone can react to motion and ambient

luminance as desired or necessary.

To use the motion sensor

•InSettings > General > Motion sensor > Mute

incoming call or Snooze alarm, select On.

If a call rings, turn over the phone (front side to

back, or back side to front) to mute the

ringtone.

To interrupt the sounding alarm in the same

way, check that the Snooze is set to a time

interval in Tools > Alarm (see "To set an alarm"

on page 42). To stop the alarm, tap on Stop.

To use the light sensor

•InSettings > Display > Light sensor, select On.

The phone will adjust backlight level

automatically according to ambient brightness.

For power-saving purposes, always turn on the

light sensor.

Power-saving mode

After the set time span, the phone has the idle

screen turned off automatically. To exit the

power-saving mode, press any key. For power-

saving purpose, set the time span to a low value

in Settings > Display > Backlight duration.

Auto screen lock

In the idle mode, your phone can have the

screen locked automatically after the set time

span.

To set the auto screen lock

Go to Settings > General > Auto screen lock. Select

the desired time span.

Select the option Off to cancel the auto screen

lock.

To unlock the screen

Short press )on the left side of the phone or

slide the lock icon on the idle screen to unlock.

To lock the screen manually

Short press )on the left side of the phone.

8Table of contents

Table of contents

1 Getting Started 11

Insert the SIM card 11

Charge the battery 13

Set clock 14

Insert the Micro-SD card 15

2 Text Entry 16

Using the Qwerty keypad 16

Using the supplied stylus

(the handwriting recognition mode) 16

Using the alphanumeric keypad 17

3 Calling 20

Making a call 20

Answering and ending a call 21

Options during a call 21

Handling multiple calls

(Network-dependent) 22

Making an emergency call 23

4 Messaging 24

Creating messages 24

Organizing your messages 26

Defining your message settings 28

E-mail 30

Broadcast messages 33

5 Contacts 34

Adding or editing contacts 34

Searching for a contact 35

Managing your contacts 35

Sharing contact information

with others 36

Backing up important contacts 37

Special numbers 37

6 Tools 39

Table of contents 9

Using your business organizer

Create your to-do list 39

Check your calendar 40

Edit your to-do list 40

Delete expired tasks 41

Using your business assistant

Record a sound memo 41

Alarm 42

World clock 43

Stopwatch 43

Text reader 43

Others

Firewall 44

Calculator 45

Currency converter 45

7 Browser 46

Managing your browser 46

Accessing web sites 46

Enabling/disabling push messages 46

STK 47

8 Camera 48

Camera 48

Video recorder 52

9 App 55

Java 55

Sensor games 56

10 Multimedia 57

Multimedia player 57

Music player 58

FM radio 60

Image viewer 63

11 My files 64

Table des matières
