Philips TCD308/4P Manuel utilisateur

INSTRUKCJA U˚YTKOWNIKA



INSTRUCTIONS FOR USE

Diga-anglais-mp 25/04/00 17:45 Page 1

Standby

mode

SECURITY

SETTINGS

MESSAGES

NETWORK

CALL

METERS

SERVICES

CUSTOMIZE

Languages

Backlight

Ringer types

Ring volume

Autoredial

Welcome text

Hotkeys

Key tones

Restriction of

identification

Status of services

Call waiting

Call barring

Call

forward

Anykey answer

Call

restriction

Keypad lock

Change

security code

Change PIN

Change PIN 2

PIN code

Voice mail

Read new

Read all

Send message

Delete

Incoming alert tone

Broadcast messages

Accumulated

cost

Charge rate

Info during call

Call timers

Last call

info

Contrast

Own number

Battery alarm

network

••• • • ••

••••

•••••

•• •• ••

•••

•

•••••

•

11 12 13 14 15 16

21 22 23 24 25 26 27

45 44 43 42 41

55 54 53 52 51

66 65 64 63 62 61

73 72 71

Preferred networks

311127613673

Diga-anglais-mp 25/04/00 17:45 Page 2

Before you start

Basic functions

Phone book

List of accessories

A problem ?

Using network services

Using the menus

Diga-anglais-mp 25/04/00 17:45 Page 3

Earpiece

Display

Microphone

Soft key

Antenna ring

Fit your favorite colour

antenna ring

Scroll keys

On/Off

Clear key

Antenna

Keypad

Diga-anglais-mp 25/04/00 17:45 Page 4

A: Symbols

Battery charge: 4 bars means battery charged.

Telephone: Tel. steady means that a call is in

progress.Tel. flashing means that your phone is rin-

ging.

Roaming: means that you are using a network

other than your home network.

Mail: mail steady means that you received a new text

message. Mail flashing means that the memory is full.

Network: means that the phone is registered

with a network.

Reception quality: 4 bars means the best reception.

Before you start

Description of the phone

Option End

Diga-anglais-mp 25/04/00 17:45 Page 5

Before you start

D: Scroll keys

Use these keys to ‘scroll’ through menus, phone

book or messages.When it is possible to scroll up

and down, the scroll indicators are shown on

the display.

In standby mode, press to select the Redial

list or to select the Reply list. During a call,

use these keys to set the volume.

E: On/Off button

Press and hold to switch the phone on or off.

F: Right and Left keys

Use these keys to move the cursor right or left

when you enter a text message.When it is possible

to move the cursor, are shown on the display.

G: Clear key

Use this key to clear the display or delete mistakes

you made. Press and hold this key to go back to

standby mode from the Menu options.

H: Index

The index displays one, two characters or nothing

depending on what you are doing.The indications

displayed are as follows: position in the menu or in

a list, number of the active call when receiving two

calls, ‘S’ if the silent mode is activated, ‘*’ to

indicate the currently selected option.

▼

B & C: Soft keys

The phone has two ‘soft keys’ (C).The soft keys

do different things at different times. A label (B)

on the display shows what the soft key will do. In

this guide, when we say ‘press End’, what we

mean is ‘press the soft key under the label End’.

Diga-anglais-mp 25/04/00 17:45 Page 6

Security

Radio waves

Your cellular phone is a radio transmitter/receiver. It

transmits and receives radio waves in the GSM

frequency. The GSM network controls the power at

which the phone transmits (between 0.02 watts and

2 watts).

Your cellular phone complies with all relevant safety

standards.The CE mark on your cellular phone means

that it is compliant with the European directive on

electromagnetic compatibility 89/336/EEC and the

low voltage directive 73/23/EEC.

Safety precautions

Careless use of the phone can result in harm to you

or others. Please read and follow all the security

instructions given here and inquire about local laws

and regulations.

■Vehicles: check with the manufacturer that

electronic equipment used in your vehicle will not

be affected by radio energy. Avoid using your

phone while driving (it affects your concentration).

Respect the local laws and regulations.

■Aircraft: switch your phone off when in an aircraft.

It is illegal to use your cellular phone when airborne.

Before you start

Diga-anglais-mp 25/04/00 17:45 Page 7

Before you start

■ Hospital: switch your phone off near hospitals or

medical equipment. Ask the manufacturer about

the radio wave shielding of any electronic medical

devices which you may use (pacemakers, hearing

aids).

■ Blasting areas: switch your phone off where

blasting is in progress (quarries).

■ Flammable atmospheres: switch your phone

off in areas with a potentially flammable atmosphere

(petrol stations, fuel depots or chemical plants).

■ Safety: use your phone in the normal operating

position (to ear). Do not touch the antenna while a

call is in progress. Do not use your phone with a

damaged antenna (risk of minor skin burn).

■ Children: keep your phone in a safe place, out of

reach of small children.

Using your phone efficiently

To improve the performance of your phone and reduce

radio energy emission and battery consumption:

■ Avoid low reception areas (tunnels or between tall

buildings).If the shows less than 2 bars,move to

another location.

Diga-anglais-mp 25/04/00 17:45 Page 8

Before you start

■ Always let your battery discharge completely before

recharging it.

■ Do not use any battery chargers other than those

specified in the PHILIPS catalog. Using another

charger may be dangerous and will invalidate any

approval given to the phone.

■ Do not allow metal objects to short circuit the

battery contact (such as keys in your pocket).

■ Switch the phone off if you are going to leave it

unused for a long time.

■ Store the phone in a clean, dust free place.

■ Keep the phone away from heat.

■ Do not try to disassemble the phone. If it is not

working properly, call the PHILIPS Helpline.

■ Keep the phone dry and do not use harsh chemicals

(such as solvents or detergents) to clean it.To clean

the phone, wipe it with a soft cloth dampened with

a midly soapy water solution.

The SIM card

To use your phone, you must insert a valid SIM card

supplied by your GSM service provider.

When you switch the phone on,it may ask for the PIN

code.The PIN code is the secret code of the SIM card.

You cannot use the SIM card without the PIN code.

Diga-anglais-mp 25/04/00 17:45 Page 9

Before you start

The SIM card contains your subscription number and

phone number. It also contains a memory in which

you can store phone numbers and messages. If you

use your SIM card on another phone, you still retain

the same phone number and phone book.

Inserting the SIM card

■ Remove the battery.

■ Slide card into the grooves in the phone (the chip

must be facing inwards and towards the bottom of

the phone).

The battery

Your phone is powered by a rechargeable battery.

Charge the battery after purchase.

Battery charge is shown by the symbol. Each bar

shown represents 25% of charge. If the phone emits a

warning signal and the symbol is shown, you

should charge the battery.

?@@@@@@@@@@@@@6Ke?

?@he?I4@@??

?@ @??

?@ ?

?@ @??

?@he?O2@@??

?@@@@@@@@@@@@@0Me?

▼

Diga-anglais-mp 25/04/00 17:45 Page 10
