Philips AZ1133/58 Manuel utilisateur

AZ1133CD Soundmachine

User Manual

уководство пользователя

AC MAINS~

PHONES

6 x R14 • UM-2 • C-CELLS

MP3

REPEAT ALL

MP3

SHUFFLE

ALBUM

MP3

PROG

English Controls/Power Supply

Supplied Accessories

– AC power cord

Top/front panels (See 1)

Source selector:CD/MP3

MW or

OFF

–

selects CD/MP3, FM or MW source of

sound

–

power off switch

–

starts or pauses CD/MP3 playback

§ ∞

–

selects the next/previous track

– fast searches forwards/backwards

(press and hold the button)

PROG – programs tracks

–

stops CD playback;

–

erases a CD program

Display

–

shows the CD functions

MODE

– selects different play modes:

e.g. REPEAT or SHUFFLE (random

order)

5ALBUM

+– For MP3-CD only: selects

albums

6OPEN•CLOSE – opens/ closes the CD

door

7TUNING

– tunes to radio stations

VOLUME

–

adjusts volume level

Back/bottom panels (See 1)

9Telescopic antenna – improves FM

reception

0Battery door – open to insert 6 x 1.5V

R-14/UM-2/C-cells

!p–3.5 mm stereo headphone socket

Helpful hints: The speakers will be muted

when headphones are connected to the set.

@AC MAINS~ – inlet for power cord

CAUTION

Use of controls or adjustments or

performance of procedures other

than herein may result in unsafe

operation.

Power Supply

Whenever convenient, use the power supply

cord if you want to conserve battery life.

Make sure you remove the plug from the set

and wall outlet before inserting batteries.

Batteries (not included)

1Open the battery door and insert 6 batteries,

type R-14,UM-2 or C-cells, (preferably

alkaline) with the correct polarity as indicated

by the "+" and "–" symbols inside the com-

partment (See 1).

2Replace the battery door, making sure the bat-

teries are firmly and correctly in place.The set

is now ready to operate.

Power Supply Basic Operation/ Radio

• Incorrect use of batteries can cause

electrolyte leakage and will corrode the

compartment or cause the batteries to burst:

• Do not mix battery types: e.g. alkaline with car-

bon zinc. Only use batteries of the same type

for the set.

• When inserting new batteries, do not try to mix

old batteries with the new ones.

• Remove the batteries if the set is not to be used

for a long time.

Batteries contain chemical substances, so

they should be disposed of properly.

Using AC power

1Check if the power voltage, as shown on

the type plate located on the

bottom of the set, corresponds to your

local power supply. If it does not, consult your

dealer or service center.

2Connect the power cord to the

AC MAINS~ inlet and the wall socket.The

set is now connected and ready for use.

3To switch the set off completely, withdraw the

power cord from the wall socket.

4Install the unit near the AC outlet and where

the AC power plug can be easily reached.

• Disconnect the power cord from the wall

socket to protect your set during heavy thun-

derstorms. Children could seriously injure

themselves as the free end of the cable may

still be live if only the connector is removed

from the MAINS socket at the back of the

unit.

The type plate is located on the

bottom of the set.

Helpful hints:

–To avoid unnecessary energy consumption,

always adjust the

Source selector

OFF

after using the set.

Basic operation

Switching on and off and selecting the

function

1To select your sound source, adjust the

Source selector to: CD/MP3,

2To switch off the set, adjust the

Source selector to

OFF

position.

Adjusting volume

Adjust the sound with the VOLUME control.

Radio reception

1Adjust the Source selector to

to select your desired waveband.

2Tu r n TUNING to tune to a station.

Helpful hints:

To improve radio reception

• For FM, extend, incline and turn the telescop-

ic antenna for best reception. Reduce its

length if the signal is too strong.

• For MW, the set uses a built-in antenna.

Direct this antenna for best reception by

turning the whole set.

About MP3

The music compression technology MP3

(MPEG1 Audio Layer 3) significantly reduce

the digital data of an audio CD while

maintaining CD quality sound.

•Getting MP3 files: you can either download

legal music files from the internet to your

computer hard disc, or create such files by

converting audio CD files in your computer

through appropriate encoder software.

(128kbps bit rate or higher is recommended

for MP3 files.)

•Creating a MP3 CD: burn the music files

from your computer hard disc on a CDR or

CDRW using your CD burner.

Helpful hints:

– Make sure that the file names of the MP3 files

end with .mp3.

– Number of albums: maximum 99

– Number of tracks: maximum 400

– The length of file names affects the number of

tracks for playback. With shorter file names,

more files can be burned on a disc.

Playing a disc

This player plays Audio Discs including CD-R/

CD-RW, MP3 CD. Do not try to play a CD-

ROM, CD-I, CDV,VCD, DVD or computer

CD.

IMPORTANT!

•CDs encoded with copyright protection

technologies by some record companies may

be unplayable by this product.

1Adjust the Source selector to CD/MP3.

2Open the CD door.

3Insert a CD with the printed side facing up,

then press the CD door gently to close.

➜Display shows ---, and later the total

number of tracks.

4Press

to start playback.

5To pause playback, press

➜

Display: 2and the current track number

flash

(See 2).

6To resume, press

again.

7To stop playback, press

Helpful hints:

CD play will also stop when:

–you open the CD door;

–you select

OFF

;

–the disc has reached the end.

Selecting a different track

•Press

∞/§

once or repeatedly until the

desired track number appears in the display.

For MP3-CD: First press ALBUM+ once

or more to find your album.

➜

“ALBUM” and the selected album number

will be displayed and flashed briefly

(See 3).

•In the pause/stop position, press 2; to start

playback.

Finding a passage within a

track

1During playback, press and hold ∞or § .

➜ The CD is played at high speed and with

reduced volume.

2When you recognize the passage you want,

release ∞or §to resume normal playback.

Helpful hints:

–When your searching reaches the end of the

last track, the disc goes to stop mode.

CD/MP3 Player

Programming tracks

You may store up to 20 tracks (MP3: 10

tracks) in the desired sequence. If you like,

store any track more than once.

1In the stop position, press PROG to start

programming.

➜Display shows P01 indicating the start of

the program. PROG flashes (See 4).

2Press

∞

to select your desired track

number.

For MP3-CD: First press ALBUM + once

or more to find your album.

➜

“ALBUM” and the selected album number

will be displayed and flashed briefly

(See 3).

3Press PROG to store the desired track.

➜Display shows P02, indicating the next

program location available.

4Repeat steps 2to 3to select and store all

desired tracks.

5Press

to play the program.

➜“PROG” is displayed.

Helpful hints :

– If you try to store more than 20 tracks (MP3:

10 tracks), no track can be stored and the

display will show flashing ---.

To erase a program

You can erase a program by:

– pressing

(twice during playback or once

in the stop position);

– selecting FM,MW or OFF position;

– opening the disc door.

➜Display:“PROG” disappears. from the

display.

Different play modes:

REPEAT and SHUFFLE

(See 5,6)

You can play the current track or the whole

disc repeatedly, and combine REPEAT modes

with PROGRAM.

REPEAT – plays the current track

continuously.

REPEAT ALL – repeats the entire CD/

program.

SHUFFLE – plays all tracks in random

order.

1To select play mode, press MODE once or

more.

➜ The display shows the selected mode.

2Press 2; to start playback if in the stop/pause

position.

➜ Disc playback will start automactically after

few seconds when shuffle mode is selected.

3To return to normal playback, press MODE

repeatedly until the modes are no longer

displayed.

–You can also press 9to cancel your play

mode.

Helpful hints:

–Shuffle play is not available in the program

mode.

CD/MP3 Player

CD player and CD handling

• If the CD player cannot read CDs correctly,

use a cleaning CD to clean the lens before

taking the set to repair.

• The lens of the CD player should never be

touched!

• Sudden changes in the surrounding

temperature can cause condensation on the

lens of your CD player. Playing a CD is then

not possible. Do not attempt to clean the

lens but leave the set in a warm environment

until the moisture evaporates.

• Always close the CD-tape door to avoid dust

on the lens.

• To clean the CD, wipe in a straight line from

the center towards the edge using a soft,

lint-free cloth. Do not use cleaning agents as

they may damage the disc.

• Never write on a CD or attach any stickers

to it.

Safety information

• Place the set on a flat, hard and stable surface

so that the system does not tilt.

• Do not expose the set, batteries, CDs to

humidity, rain, sand or excessive heat caused

by heating equipment or direct sunlight.

• The apparatus shall not be exposed to drip-

ping or splashing.

• Adequate ventilation with a minimum gap of

15cm (6 inches) between the ventilation

holes and surrounding surfaces is necessary

to prevent heat build-up.

• Do not cover the ventilation openings with

items such as newspapers, table-cloths, cur-

tains, etc.

• No objects filled with liquids, such as vases,

shall be placed on the apparatus.

• No naked flame sources, such as lighted can-

dles, should be placed on the apparatus.

• The mechanical parts of the set contain

self-lubricating bearings and must not be oiled

or lubricated.

• To clean the set, use a dry cloth. Do not use

any cleaning agents containing alcohol,

ammonia, benzene or abrasives as these may

harm the housing.

Maintenance & Safety (See 7)

Environmental information

All unnecessary packaging material has been omitted.The packaging can be easily separated

into three materials: cardboard, polystyrene and plastic.

Your set consists of materials which can be recycled if disassembled by a

specialized company. Please observe the local regulations regarding the

disposal of packaging, dead batteries and old equipment.

Problem

–Possible cause

• Remedy

No hay sonido/energía

–Volume not adjusted

• Adjust the VOLUME

–Power cord not securely connected

• Connect the AC power cord properly

–Batteries dead/ incorrectly inserted

• Insert (fresh) batteries correctly

–Headphones connected to the set

•

Disconnect headphones.

–CD contains non-audio files

• Press

∞,§

once or more to skip to a CD audio

track, instead of the data file.

Display does not function properly / No

reaction to operation of any of the

controls

–Electrostatic discharge

• Switch off and unplug the set. Reconnect after a

few seconds

Severe radio hum or noise

–Electrical interference: set too close to TV, VCR or

computer

•Increase the distance

Poor radio reception

–Weak radio signal

•FM: Adjust the FM telescopic aerial

no indication

–No CD inserted

•

Insert a CD

–CD badly scratched or dirty

•

Replace/ clean CD, see Maintenance

–Laser lens steamed up

• Wait until lens has cleared

–CD-R/CD-RW is blank or not finalized

•

Use a finalized CD-R/CD-RW or suitable CD

Audio disc only

Note:

Make sure the CD is not encoded with

do not conform to the Compact Disc stan-

dard.

The CD skips tracks

–CD damaged or dirty

• Replace or clean CD

–Program/Shuffle is active

• Quit program/shuffle mode

Note: A CD badly scratch or dirty may result in

improper operation.

Sound skips during MP3 playback

–MP3 file made at compression level exceeding

320kbps

•Use a lower compression level to record CD

tracks into MP3 format

–Disc damaged or dirty

•Replace or clean disc.

Troubleshooting

If a fault occurs, first check the points listed below before taking the set for repair.

If you are unable to remedy a problem by following these hints, consult your dealer or service centre.

WARNING:Do not open the set as there is a risk of electric shock. Under no

circumstances should you try to repair the set yourself, as this will inval-

idate the guarantee.

Printed in China PDCC-JH-0720

CLASS 1

LASER PRODUCT

AZ 1133

Meet Philips at the Internet

http://www.philips.com

English Русский

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Lecteur CD

Philips

Philips Soundmachine AZ382/12 Manuel utilisateur

Philips

Philips Expanium EXP 210 Manuel utilisateur

Philips

Philips AZ1310 Manuel utilisateur

Philips

Philips CDC 936 Manuel utilisateur

Philips

Philips AZ7882 Manuel utilisateur

Philips

Philips ACT7580 Manuel utilisateur

Philips

Philips AX2500/00 Manuel utilisateur

Philips

Philips Magnavox AZ 7337 Manuel utilisateur

Philips

Philips AZ6822 - Portable Radio Cass Rec Manuel utilisateur

Philips

Philips AZ7360/00 Manuel utilisateur

Philips

Philips DE-AZ1040 Manuel utilisateur

Philips

Philips Jogproof AX5112 Manuel utilisateur

Philips

Philips AZ6834 - Portable Radio Cass Rec Manuel utilisateur

Philips

Philips AZ1032/05 Manuel d'utilisation

Philips

Philips CDR 765 Manuel utilisateur

Philips

Philips AZ7267/00 Manuel utilisateur

Philips

Philips AZ7900 Manuel utilisateur

Philips

Philips CDR-795 Manuel utilisateur

Philips

Philips CDR785BK99 Manuel utilisateur

Philips

Philips Portable CD Player Manuel utilisateur

Philips

Philips Jogproof AX7101 Manuel utilisateur

Philips

Philips AX5200 Manuel utilisateur

Philips

Philips AZ1837/73 Manuel utilisateur

Philips

Philips AZ1140 Guide de référence

Manuels Lecteur CD populaires d'autres marques

RCA

RCA RP-7923 Manuel utilisateur

Pioneer

Pioneer DEH-P3550MP XM Manuel utilisateur

Lasonic

Lasonic MSU-2020 Manuel utilisateur

THOMSON

THOMSON RCD150 Manuel utilisateur

Denon

Denon DCD-1420 Manuel utilisateur

Panasonic

Panasonic SJ-MR100 Manuel utilisateur

Onkyo

Onkyo DX-7210 Manuel utilisateur

Sony

Sony MZ-R3 Manuel utilisateur

Denon

Denon DVM-4800 Manuel utilisateur

JBL

JBL MR-32 Manuel utilisateur

RCA

RCA RCD152 Manuel utilisateur

Technics

Technics SL-PS770A Manuel utilisateur

Clarion

Clarion compact disc Manuel utilisateur

Sony

Sony MZ-M10 Manuel utilisateur

Rotel

Rotel RCD 975 Manuel utilisateur

Pioneer

Pioneer CLD-D790 Manuel utilisateur

Optimus

Optimus CD-8250 Manuel utilisateur

Audiovox

Audiovox CE101A - annexe 1 Manuel utilisateur
