Philips CAM200WH/00 Manuel utilisateur

www.philips.com/welcome

User manual

CAM200

Philips Consumer Lifestyle

Philips Consumer Lifestyle AMB 544-9056

HK-1152-CAM300WH Year 2011

........................................................ ........................................................................................

(Report No. / Numéro du Rapport) (Year in which the CE mark is affixed / Année au cours

de laquelle le marquage CE a été apposé)

EC DECLARATION OF CONFORMITY

(DECLARATION DE CONFORMITE CE)

We / Nous, PHILIPS CONSUMER LIFESTYLE B.V.

(Name / Nom de l’entreprise)

TUSSENDIEPEN 4, 9206 AD DRACHTEN, THE NETHERLANDS

(address / adresse)

Declare under our responsibility that the electrical product(s):

(Déclarons sous notre propre responsabilité que le(s) produit(s) électrique(s):)

PHILIPS.................... CAM200WH/00......................

(brand name, nom de la marque) (Type version or model, référence ou modèle)

Digital Video

..................................................................

(product description, description du produit)

To which this declaration relates is in conformity with the following harmonized standards:

(Auquel cette déclaration se rapporte, est conforme aux normes harmonisées suivantes)

(title, number and date of issue of the standard / titre, numéro et date de parution de la norme)

EN60950-1:2006+A11:2009

EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003

EN61000-3-3:2008 EN61000-3-2:2006+A1:2009+A2:2009

EN301489-1 V1.8.1 :2008 EN301489-17 V2.1.1 : 2009

EN300328 V1.7.1:2006 EN62311:2008

Following the provisions of :

(Conformément aux exigences essentielles et autres dispositions pertinentes de:)

1999/5/EC (R&TTE Directive)

2006/95/EC (Low Voltage Directive)

2004/108/EC (EMC Directive)

And are produced under a quality scheme at least in conformity with ISO 9001 or CENELEC

Permanent Documents

(Et sont fabriqués conformément à une qualité au moins conforme à la norme ISO 9001 ou aux Documents Permanents CENELEC)

PHOENIX TESTLAB/0700 Notified Body Opinion

The Notified Body.....................................................performed ........................................

(L’Organisme Notifié) (Name and number/ nom et numéro) (a effectué) (description of intervention /

description de l’intervention)

11-114607

And issued the certificate, ......................................................

(et a délivré le certificat) (certificate number / numéro du certificat)

Remarks:

(Remarques:)

Drachten, Netherlands, Jan.04, 2012 A.Speelman, CL Compliance Manager

........................................................... ..............................................................................................

(place,date / lieu, date) (signature, name and function / signature, nom et fonction)

3EN

Contents

1 Important 4

Safety 4

Notice 4

2 Your camcorder 6

Introduction 6

What's in the box 6

Functional overview 7

3 Get started 8

Load the Micro SD card 8

Turn on 8

First-time setup 8

Charge the built-in battery 10

4 Use your camcorder 11

Record video 11

Take pictures 11

Play 11

Share your movies or pictures wirelessly 12

Adjust settings 14

5 Use more of your camcorder 15

View video or pictures onTV through

HDMI 15

Install and use the camcorder software 15

  17

7 Frequently asked questions (FAQ) 18

4EN

1 Important

Safety

a Read these instructions.

b Keep these instructions.

c Heed all warnings.

d Follow all instructions.

e Do not use this apparatus near water.

f Clean only with dry cloth.

g Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

h Do not install near any heat sources such

as radiators, heat registers, stoves, or



produce heat.

i Only use attachments/accessories



j 

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

k Apparatus shall not be exposed to

dripping or splashing.

l Do not place any sources of danger on



lighted candles).



device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

Notice

This product complies with the radio

interference requirements of the European

Community.

The device can be operated in the EU without

restrictions indoor, but cannot be operated

outdoors in France in the whole of the band

until further notice.

This product complies with the requirement of

the 1999/5/EC directive.

The minimum distance between the user and/

or any bystander and the radiating structure of

the transmitter is 15cm.

To check the EC DECLARATION OF

CONFORMITY, go to http://download.p4c.





Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is

attached to a product it means that the product

is covered by the European Directive 2002/96/

EC.

Please inform yourself about the local separate

collection system for electrical and electronic

products.

5EN

Please act according to your local rules and

do not dispose of your old products with your

normal household waste. Correct disposal of

your old product helps to prevent potential

negative consequences for the environment and

human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed with normal household

waste.Please inform yourself about the local

rules on separate collection of batteries

because correct disposal helps to prevent

negative consequences for the environmental

and human health.

Note

 The safety logo and power rating information are

located at the inner side of the protective cover at the

bottom of the camcorder.

Always bring your product to a professional to

remove the built-in battery.

6EN

2 Your camcorder

Introduction

With this portable camcorder, you can:

 take full HD (1080P) orVGA movies

 take pictures

 play recorded movies or pictures on the

large screen of aTV wirelessly or through

HDMI connection

 upload recorded movies or pictures to the

Internet wirelessly or through a PC/Mac

What's in the box

Make sure that the following items are packed

in the box:

 Camcorder

 Quick start guide

 USB cable (with a mini USB connector)

 Pouch

 Hand strap

7EN

Functional overview

a Touch screen

b Tripod socket

c MICRO SD

 Load a Micro SD card.

d +/-

 

 During video play, change the volume.

e Video shutter button (red)

 



 

video recording.

 In play mode, switch to video



f Hand strap hole

g Mini HDMI socket

 Connect to aTV through an HDMI

cable with a mini HDMI connector

(type C).

hgi

h RESET

 Restore default settings.

i Mini USB socket

 Connect to a PC/Mac through the

supplied USB cable.

j Picture shutter button ( )

 



 

picture.

 In play mode, switch to picture



 Turn on/off the camcorder.

l Built-in microphones

m Flashlight

n Lens

o Built-in speaker

8EN

3 Get started

Load the Micro SD card

1 Flip open the protective cover on the

Micro SD card socket.

2 Insert a Micro SD card (not supplied) into

the socket.

 Make sure that the Micro SD card is

not write-protected.

 Make sure that the metal contact of

the card faces down.

3 Close the protective cover securely.

Turn on

 Press .

» 

language selection is displayed (see

'First-time setup' on page 8).

Tip

 To save energy, the camcorder turns off automatically

after being idle for 3 minutes.To turn on the camcorder

again, press .

To turn off the camcorder:

 Press again.

» The backlight on the touch screen

turns off.

First-time setup

More setting options are described in the

'Adjust settings' section (see 'Adjust settings' on

page 14).



time, a menu for OSD language selection is

displayed.

1 On the touch screen, tap the scroll bar

( / ) to move upward/downward.

2 Tap a language to highlight it.

3 Tap [Done]

» A date setting menu is displayed.

4 Tap / to set the day, month, and year

successively.

5 Tap [OK]

» A time setting menu is displayed.

6 Tap / to set the hour and minute

successively.

7 Tap [OK]

» 

» The camcorder enters video



» A settings bar is displayed at the

bottom of the touch screen.

Tip

 To hide the settings bar, tap any blank area on the touch

screen.To show the settings bar again, tap at the

bottom right corner of the touch screen.

Select a resolution

1  to access the

settings menu.

2 Tap [Resolution].

3 Tap [Video] or [Photo].

4 Tap a video or photo resolution you like to

highlight it.

5 Tap [Done]

9EN

Select a special effect

You can select one of the following special

effects: [Normal], [Black & White], [Sepia] and

.

1  to access

[Effects] setting.

2 Tap / to select a special effect you

like.

3 Tap [OK]

Select a scene

You can select one of the following scenes:

[Auto], [Skin], [Snow/Beach], [Night],

[Backlight] and [Sunset].

1  to access

[Scene] setting.

2 Tap / to select a scene you like.

3 Tap [OK]



  repeatedly to



 

 

Set up Wi-Fi connection

1  to access the

settings menu.

2 Tap [Connectivity] -> [WiFi] to access

Wi-Fi setting.

3 Tap [On] to highlight the option, then tap

[Done]

» The camcorder starts to detect Wi-Fi

networks available.

» After a while, a list of detected Wi-Fi

networks is displayed.

4 Tap your home Wi-Fi network in the list.

5 Tap [OK]

6 Enter your Wi-Fi password (if set).

7 Tap [OK]

» After successful connection, a signal

icon ( ) is displayed at the top right

corner of the touch screen.

Tip

 When the camcorder is powered off and then

powered on again, the camcorder is connected to the

same Wi-Fi network automatically.

 To switch to another Wi-Fi network, repeat the above

procedures.

10 EN

Charge the built-in battery

1 Open the protective cover at the bottom

of the camcorder.

2 Connect the camcorder to a PC through

the supplied USB cable.

» The charge status is shown on the

touch screen of the camcorder.

3 When the battery is full, disconnect the

USB cable and close the protective cover.

Tip

 

 It takes about 3 hours to fully charge the built-in

battery through a PC.

You can also charge the camcorder through a

USB adaptor (not supplied) connected to mains

power.The charge time is about 2 hours.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips caméscope

Philips

Philips CAM300WH Manuel utilisateur

Philips

Philips CAM100BU Manuel utilisateur

Philips

Philips CAM101 Manuel utilisateur

Philips

Philips Explorer M821 Manuel utilisateur

Philips

Philips CAM101BL/12 Manuel utilisateur

Philips

Philips M 621/21 Manuel utilisateur

Philips

Philips miniExplorer VKR9015 Manuel utilisateur

Philips

Philips CAM300WH Manuel utilisateur

Philips

Philips Explorer VKR 9300 Manuel utilisateur

Philips

Philips M 640/21 Manuel utilisateur

Philips

Philips VKR6843 Manuel utilisateur

Philips

Philips Explorer VKR6860 Manuel utilisateur

Philips

Philips Explorer VKR 9300 Manuel utilisateur

Philips

Philips Explorer VKR6847 Manuel utilisateur

Philips

Philips CAM101BL/00 Manuel utilisateur

Philips

Philips M 826 Manuel utilisateur

Philips

Philips CAM150 Manuel utilisateur

Philips

Philips Explorer VKR6853 Manuel utilisateur

Philips

Philips Key019 Manuel utilisateur

Philips

Philips CAM101BL/00 Manuel utilisateur

Philips

Philips VideoTracer DVT3120 Manuel utilisateur

Philips

Philips Explorer M620 Manuel utilisateur

Philips

Philips WKR 9300 Manuel utilisateur

Philips

Philips Explorer VKR6880 Manuel utilisateur

Manuels caméscope populaires d'autres marques

Toshiba

Toshiba CAMILEO Z100 Manuel utilisateur

Panasonic

Panasonic NV-VS40B Manuel utilisateur

Canon

Canon RC 260 Manuel utilisateur

Sony

Sony Handycam DCR-DVD7E Manuel utilisateur

Brinno

Brinno TimeLapse TLC200 Manuel utilisateur

JVC

JVC GR-SXM68AC Guide de démarrage rapide

Panasonic

Panasonic AG-HMC152EN Manuel utilisateur

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur

MYDLINK

MYDLINK DCS-6100LH Manuel utilisateur

Sony

Sony video Hi8 Handycam CCD-TR555 Manuel utilisateur

SECURECOM

SECURECOM V-5014B Manuel utilisateur

Panasonic

Panasonic HDC-SD100 Manuel utilisateur

Sharper Image

Sharper Image U-VIDEO Manuel utilisateur

JVC

JVC AA-V15EG Manuel utilisateur

Canon

Canon LEGRIA HV40 Manuel utilisateur

Sony

Sony Handycam DCR-VX2000 Manuel utilisateur

RCA

RCA CC616 Manuel utilisateur

Panasonic

Panasonic NVM40 Manuel utilisateur
