Philips BDP7700 Manuel utilisateur

transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without

the prior permission of Philips.

Blu-ray Disc Player

Version 1.2Version 0.0

LASER PRODUCT

TABLE OF CONTENTS

Page

Production Speciﬁcations ...............................................................................................1-2

Brife guide ......................................................................................................................1-

Mechanical and Dismantling Instructions .......................................................................2-1

Software Version & Upgrades.........................................................................................3-1

Trouble Shooting Chart .....................................................................................................-1

Set Mechanical Exploded view ....................................................................................... -1

Revision List ...................................................................................................................

Location of PCB Boards & version variation & repair scenario matrix.....................1-1

CLASS 1

313978536050

Published by Helen-RY 1209Service Audio Printed in The Netherlands Subject to modification

Set Block & Wiring Diagrams ............................................................................5-1

Electrical Diagrams and PCB layouts ................................................................6-1

Remote control ...............................................................................................................1-

Safety Instruction, Warning & Notes...............................................................................1-

8-1

Version 1.0

BDP7700/12/51/

98/ 39

Version Variation

BDP7700

Type/Versions

Features /12 /51 /93 /98

Power supply rating:220-240V ,50Hz X X

Power supply rating:110-240V ,50Hz,60Hz X X

Power consumption:20W X X X X

Repair Scenario Matrix

BDP7700

Type/Versions

Board in used /12 /51 /93 /98

Main Board Bd C C C

Power Board Bd Bd C C

AV Board Bd Bd C C

Front Board Bd Bd C C

ASSY-Touch Display Board Bd Bd C C

*Bd:Board Level Replacement

*C:Component Level Repair

Specifications

Note

6SHFLÀFDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH

Region code

7KLVSOD\HUFDQSOD\GLVFVZLWKWKHIROORZLQJ

region codes.

DVD Blu-ray &RXQWULHV

Europe,

United

Kingdom

Playable media

 BD-Video, BD 3D

 DVD-Video, DVD+R/+RW, DVD-R/-RW,

'9'55'/'XDO/D\HU

 9&'69&'

 $XGLR&'&'5&'5:03PHGLD

:0$PHGLD-3(*ÀOHV

 'LY;8OWUD'LY;3OXV+'PHGLD0.9

media

 USB storage device

File container

 9LGHRDYLGLY[PSPYPNYDVIZPY

.mpg/mpeg, .m2ts

 $XGLRDDFPDPSZPDPND

 3LFWXUHMSJJLISQJ

Video

 6LJQDOV\VWHP3$/176&

 &RPSRVLWHYLGHRRXWSXW9SSRKP

 +'0,RXWSXWLLSSS

LSS+]

Audio

 &KDQQHODQDORJRXWSXW

 $XGLR)URQW/59UPV!

NRKP

 &KDQQHODQDORJRXWSXW

 $XGLR)URQW/59UPV!

NRKP

 $XGLR6XUURQG/59UPV!

NRKP

 $XGLR&HQWHU9UPV!NRKP

 $XGLR6XEZRRIHU9UPV!

NRKP

 $XGLR5HDU/59UPV!NRKP

 'LJLWDORXWSXW9SSRKP

 2SWLFDO&RD[LDO

 +'0,RXWSXW

 6DPSOLQJIUHTXHQF\

 03N+]N+]N+]

 :0$N+]N+]

 &RQVWDQWELWUDWH

 03NESVNSEV

 :0$NSEVNSEV

USB

 &RPSDWLELOLW\+L6SHHG86%

 &ODVVVXSSRUW86%0DVV6WRUDJH&ODVV

 )LOHV\VWHP)$7)$7

 86%SRUW9 P$IRUHDFKSRUW

 6XSSRUW+''DSRUWDEOHKDUGGLVFGULYH

DQH[WHUQDOSRZHUVRXUFHPD\EHQHHGHG

Main unit

 3RZHUVXSSO\UDWLQJ$&9a+]

 3RZHUFRQVXPSWLRQ:

 3RZHUFRQVXPSWLRQLQVWDQGE\PRGHIDVW

ZDNHXSGLVDEOHG:

 'LPHQVLRQVZ[K[G[[

PP

 1HW:HLJKWNJ

Accessories supplied

 Remote control and batteries

 $&SRZHUFDEOH

 User manual

 &'520EXLOWLQPXOWLOLQJXDOXVHUPDQXDO

&RQWLQHQWDO(XURSHRQO\

/DVHU6SHFLÀFDWLRQ

 /DVHU7\SH'LRGH$O*D,Q1%'$O*D,Q3

'9'&'

 :DYHOHQJWKaQP%'a

QP'9'aQP&'

 2XWSXWSRZHU0D[UDWLQJVP:%'

P:'9'P:&'

BDP7700/12/51

1-2

Specifications

Note

6SHFLÀFDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH

Region code

This player can play discs with the following

region codes.

DVD Blu-ray Countries

$VLD3DFLÀF

Taiwan, Korea

Playable media

 BD-Video, BD 3D

 DVD-Video, DVD+R/+RW, DVD-R/-RW,

DVD+R/-R DL (Dual Layer)

 VCD/SVCD

 Audio CD, CD-R/CD-RW, MP3 media,

:0$PHGLD-3(*ÀOHV

 DivX (Ultra)/DivX Plus HD media, MKV

media

 USB storage device

File container

 Video: .avi, .divx, .mp4/m4v, .mkv, .asf/wmv,

.mpg/mpeg, .m2ts, .rmvb, .rm

 Audio: .aac/m4a, .mp3, .wma, .mka

 Picture: .jpg, .gif, .png

Video

 Signal system: PAL / NTSC

 Composite video output: 1 Vp-p (75 ohm)

 HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p, 1080p/24Hz

Audio

 2 Channel analog output

 Audio Front L + R : 2 Vrms

(> 1 kohm)

 7.1 Channel analog output

 Audio Front L + R : 2 Vrms

(> 1 kohm)

 Audio Surrond L + R : 2 Vrms

(> 1 kohm)

 Audio Center : 2 Vrms (> 1 kohm)

 Audio Subwoofer : 1.15 Vrms

(> 1 kohm)

 Audio Rear L + R: 2 Vrms (> 1 kohm)

 Digital output: 0.5 Vp-p (75 ohm)

 Optical, Coaxial

 HDMI output

 Sampling frequency:

 MP3: 32 kHz, 44.1 kHz, 48 kHz

 WMA: 44.1 kHz, 48 kHz

 Constant bit rate:

 MP3: 112 kbps - 320 kpbs

 WMA: 48 kpbs - 192 kpbs

USB

 Compatibility: Hi-Speed USB (2.0)

 Class support: USB Mass Storage Class

 File system: FAT16, FAT32

 USB port: 5V , 500mA (for each port)

 Support HDD (a portable hard disc drive):

an external power source may be needed.

Main unit

 Power supply rating: AC 110-240V~,

50Hz/60Hz

 Power consumption: 20 W

 Power consumption in standby mode (fast

wakeup disabled): < 0.15 W

 Dimensions (w x h x d): 435 x 42 x 230

(mm)

 Net Weight: 1.51 kg

Accessories supplied

 Remote control and batteries

 AC power cable

 User manual

/DVHU6SHFLÀFDWLRQ

 Laser Type (Diode): AlGaInN (BD), AlGaInP

(DVD/CD)

 Wave length: 398 ~ 412nm (BD), 650 ~

664nm (DVD), 784 ~ 796nm (CD)

 Output power (Max ratings): 20mW (BD),

7mW (DVD), 7mW (CD)

BDP7700/98

1-3

Specifications

Note

6SHFLÀFDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH

Region code

This player can play discs with the following

region codes.

DVD Blu-ray Countries

China

Playable media

 BD-Video, BD 3D

 DVD-Video, DVD+R/+RW, DVD-R/-RW,

DVD+R/-R DL (Dual Layer)

 VCD/SVCD

 Audio CD, CD-R/CD-RW, MP3 media,

:0$PHGLD-3(*ÀOHV

 DivX (Ultra)/DivX Plus HD media, MKV

media

 USB storage device

File container

 Video: .avi, .divx, .mp4/m4v, .mkv, .asf/wmv,

.mpg/mpeg, .m2ts, .rmvb, .rm

 Audio: .aac/m4a, .mp3, .wma, .mka

 Picture: .jpg, .gif, .png

Video

 Signal system: PAL / NTSC

 Composite video output: 1 Vp-p (75 ohm)

 HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p, 1080p/24Hz

Audio

 2 Channel analog output

 Audio Front L + R : 2 Vrms (> 1 kohm)

 7.1 Channel analog output

 Audio Front L + R : 2 Vrms (> 1 kohm)

 Audio Surrond L + R : 2 Vrms

(> 1 kohm)

 Audio Center : 2 Vrms (> 1 kohm)

 Audio Subwoofer : 1.15 Vrms

 (> 1 kohm)

 Audio Rear L + R: 2 Vrms (> 1 kohm)

 Digital output: 0.5 Vp-p (75 ohm)

 Optical, Coaxial

 HDMI output

 Sampling frequency:

 MP3: 32 kHz, 44.1 kHz, 48 kHz

 WMA: 44.1 kHz, 48 kHz

 Constant bit rate:

 MP3: 112 kbps - 320 kpbs

 WMA: 48 kpbs - 192 kpbs

USB

 Compatibility: Hi-Speed USB (2.0)

 Class support: USB Mass Storage Class

 File system: FAT16, FAT32

 USB port: 5V , 500mA (for each port)

 Support HDD (a portable hard disc drive):

an external power source may be needed.

Main unit

 Power supply rating: AC 110-240V~,

50Hz/60Hz

 Power consumption: 20 W

 Power consumption in standby mode (fast

wakeup disabled): < 0.15 W

 Dimensions (w x h x d): 435 x 42 x 230

(mm)

 Net Weight: 1.51 kg

Accessories supplied

 Remote control and batteries

 AC power cable

 User manual

/DVHU6SHFLÀFDWLRQ

 Laser Type (Diode): AlGaInN (BD), AlGaInP

(DVD/CD)

 Wave length: 398 ~ 412nm (BD), 650 ~

664nm (DVD), 784 ~ 796nm (CD)

 Output power (Max ratings): 20mW (BD),

7mW (DVD), 7mW (CD)

1-4

&RQJUDWXODWLRQVRQ\RXUSXUFKDVHDQG

ZHOFRPHWR3KLOLSV7RIXOO\EHQHÀWIURP

WKHVXSSRUWWKDW3KLOLSVRIIHUVHJSURGXFW

VRIWZDUHXSJUDGHUHJLVWHU\RXUSURGXFWDW

ZZZSKLOLSVFRPZHOFRPH

Basic play control

'XULQJSOD\SUHVVWKHIROORZLQJEXWWRQVWR

control.

Button Action

7XUQRQWKHSOD\HURUVZLWFKWR

standby.

Access the home menu.

/ Stop play.

3UHVVDQGKROGPRUHWKDQ

VHFRQGVWRRSHQRUFORVHWKH

disc compartment.

Pause play.

3UHVVUHSHDWHGO\WRVORZIRUZDUG

frame by frame.

Start or resume play.

/ Skip to the previous or next track,

FKDSWHURUÀOH

/ )DVWEDFNZDUGRUIRUZDUG

Press repeatedly to change the

search speed.

Press once, and then press

WRVORZIRUZDUG

AUDIO Select an audio language or

channel.

SUBTITLE Select a subtitle language.

DISC

MENU /

POP-UP

Access or exit the disc menu.

TOP

Access the main menu of a video

disc.

Color

buttons

Select tasks or options for Blu-ray

discs.

Navigate the menus.

Press to rotate a picture

FORFNZLVHRUFRXQWHUFORFNZLVH

GXULQJVOLGHVKRZ

OK &RQÀUPDVHOHFWLRQRUHQWU\

Return to a previous display menu.

Access more options during play.

Remote Control

1-5

www.philips.com/welcome

EN User manual

BDP7700

PC & Mac

( )

HDMI VIDEOVIDE

COAXIAL OPTICAL

5.1CH

7.1CH

2CH

Brife Guide

1-6



1 HDMI

2 VIDEO+2CH

1-7

5.1 CH

5.1CH

7.1 CH

HUR UN

5.1CH

OPTICAL

HDMI

COAXIAL

1-8



SOURCE

1-9

Autres manuels pour BDP7700

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Lecteur Blu-ray

Philips

Philips BDP2100/79 Manuel utilisateur

Philips

Philips BDP2600/94 Manuel utilisateur

Philips

Philips BDP5500/12 Manuel utilisateur

Philips

Philips BDP2285/96 Manuel utilisateur

Philips

Philips BDP7501 Manuel utilisateur

Philips

Philips BDP7200/98 Manuel utilisateur

Philips

Philips BDP2900 Manuel utilisateur

Philips

Philips BDP7200/12 Manuel utilisateur

Philips

Philips BDP7200/12 Manuel utilisateur

Philips

Philips Qdeo BDP9700 Manuel utilisateur

Philips

Philips Qdeo BDP9600/12 Manuel utilisateur

Philips

Philips BDP7500S2 Manuel utilisateur

Philips

Philips BDP5180 Manuel utilisateur

Philips

Philips BDP7310/F7 Manuel utilisateur

Philips

Philips BDP5180 Manuel utilisateur

Philips

Philips BDP5320/F7 Manuel utilisateur

Philips

Philips BDP-6000 Manuel utilisateur

Philips

Philips HTB5575D/51 Manuel utilisateur

Philips

Philips BDP2100 Manuel utilisateur

Philips

Philips BDP3282/05 Manuel utilisateur

Philips

Philips BDP7200 Manuel utilisateur

Philips

Philips BDP9000 Manuel utilisateur

Philips

Philips BDP9600 Manuel utilisateur

Philips

Philips BDP5150/F7 Manuel utilisateur

Manuels Lecteur Blu-ray populaires d'autres marques

Samsung

Samsung BD-F5900 Manuel utilisateur

Samsung

Samsung BD-P4600 Manuel utilisateur

Sharp

Sharp BD-HP17U - AQUOS 1080p Blu-ray DiscTM Player Manuel utilisateur

Pioneer

Pioneer BDP-140 Manuel d'installation et d'exploitation

Samsung

Samsung BD-D8200A Manuel utilisateur

LG HLX50W Manuel utilisateur

Sony

Sony BDP-S300 - Blu-Ray Disc Player Manuel utilisateur

Marantz

Marantz UD9004 Manuel utilisateur

Panasonic

Panasonic DMR-HCT230 Manuel utilisateur

LG BD611 Manuel utilisateur

Panasonic

Panasonic Diga DMR-PWT420 Manuel utilisateur

LG BD611 Manuel utilisateur

Marantz

Marantz BD7004 Guide de démarrage rapide

Kogan

Kogan KABRP3DWFIA Manuel utilisateur

Toshiba

Toshiba BDX2700 Manuel utilisateur

Samsung

Samsung BD-E5400 Manuel utilisateur

Samsung

Samsung BD-F5100 Manuel utilisateur

LG UBK80.DUSALLK Manuel utilisateur
