PAD19 – In Wall Micro Dimmer
Description and features
It can only needs to connect two wires, single wire (L) and load
(NO1),or three wires, two wire (L、N) and load (NO1)
This device is a security enabled Z-Wave lus™ product that uses en-
crypted Z-Wave lus™ messages to communicate to other security
enabled Z-Wave lus™ products. Z-Wave™ enabled devices display-
ing the Z-Wave™ logo can also be used with this device regardless of
the manufacturer, and this device can also be used in other manufac-
turer’s Z-Wave™ enabled networks.
All mains operated nodes within the network will act as repeaters re-
gardless of vendor to increase reliability of the network. The product
supports an Over the Air (OTA) feature for the products firmware up-
grade
•Main features of hilio's In Wall Micro dimmer,
•Compatible with any Z-Wave™ or Z-Wave™ lus Controller,
•Supports Z-Wave™ network Security Modes: S2,
•To be installed with LED dimmer or incandescent lamp,
•A single live without neutral lead,
•To be installed in-wall switch boxes.
Specification
Operating Rated 100-240Vac 50Hz-60Hz 0.7A
Output load Max. 0.7A (100-240VAC)
160W (Dimmable LED bulbs or Incandescent
lamp)(230Vac)
80W (Dimmable LED bulbs or Incandescent
lamp)(120Vac)
Fuse information Built-in Thermal Cut-off Fuses protection.
Rated Temperature :150 °C; Rated: 2A 250V.
LED minimum Min. 20W for Dimmable LED bulb not flickering
Operating Temperature 0°C - 40°C
Humidity Up to 85% max
Storage Temperature -20°C - 60°C
Location Indoor use only
Frequency Range 868.40MHz, 869.85MHz EU
908.4MHz, 916.0MHz US,
922.5MHz, 923.9MHz, 926.3MHz (J )
920.9MHz, 921.7MHz, 923.1MHz
(TW/KR/Thai/SG)
1
RF Maximum ower +10dBm ( eak), -10dBm (Average)
Transmission Range Up to 40m indoors or up to 100m outdoors
(depending on building materials)
OTA Support
Dimensions 47.5x39x16 mm
Wire 0.75mm² ; 18AWG
** Specifications are subject to change and improvement without notice.
Troubleshooting
Symptom ause of Failure Recommendation
The dimmer does
not work and LED
off
1.The dimmer does
not connect the
electrical wire
properly
2.The dimmer break
down
1. Check power connections
2. Don’t open up the dimmer
and send it for repair.
The device can
not join to Z-
Wave™ network
The device may in a
Z-Wave™ network.
Exclude the device then include
again.
Flashing during
dimming
Minimum load is
less than 20W
Replace larger load
Installation steps
There are two wiring methods for AD19.
A. Connect the AC L line and the bulb load end.
B. S1 Can be connect externally switches.C. COM is for S1 connect port.
Fig 1. Assembling & Wiring
Fig 2. Assembling & Wiring
Important: Read all instructions prior to installation
2
IMPORTANT
Installation must be performed by skilled technicians who are informed about the
standards and technical requirements of the appliance and its proper installation.
Check your local codes as they apply to your situation. If the house wiring is of
aluminum, consult with an electrician about proper wiring methods.
Before proceeding with the installation, TURN OFF THE OWER TO THE LIGHTING
CIRCUIT AT THE CIRCUIT BREAKER OR FUSE BOX TO AVOID ELECTRICAL
SHOCK.
For Instruction to http://www.philio-tech.com
Danger
Danger of electrocution!
All works on the device may be performed only by a qualified and licensed
electrician. Observe national regulations. Any works introducing changes into the
configuration must be always performed with disconnected voltage.
Choosing a Suitable Location
1. Do NOT place the module/device direct under sunlight, in a humid place or in
any location where they may contact moisture, dirt, dust.
2. Do NOT place the module/device where exists combustible substance or any
source of heat, fires, radiators, boiler etc.
3. When the module/device be used, the module/device might get warm. This is
a normal condition.
4. After putting it into use. The body of Module will bexome a little bit hot of
which phenomenon is normal.
Adding to Z-Wave™ Network
In the front of the device, there is an on/off button with an LED light indicator which is
used to dim on and off, carry out inclusion, exclusion, reset or association. When
powered for the first time, the device’s LED light will flash on and off alternately and
repeatedly at 1 second intervals. This implies that no node ID has been assigned,
and auto inclusion is ready to start.
3
This product can be operated in any Z-Wave™ network with other Z-Wave™ certified
devices from other manufacturers. All non-battery operating nodes within the network
will act as repeaters regardless of the vendor in order to increase reliability of the net-
work.
The table below provides a summary of operations of basic Z-Wave™ functions.
lease refer to the instructions for your Z-Wave™ Certified rimary Controller to ac-
cess the Setup function, and to Add/Remove/associate devices.
Function Description Annotation
No node ID The Z-Wave™ Controller does not allocate a
node ID to the Switch.
LED light flashes once
every one second and
last for 30 seconds.
Add
(Classic Inclu-
sion)
1. ut your Z-Wave™ controller into inclu-
sion mode by following the instructions
provided by the controller manufacturer.
2. ress the include button three times within
3 seconds to enter inclusion mode.
SmartStart 1. The product has a DSK string. Key in the
first five digits to initiate the SmartStart
process, or scan QR code.
Ex: DSK: 18112-24021- 48001-62259-
57092-27453-08187-47408
2. SmartStart enabled products can be added
into a Z-Wave™ network by scanning the
Z-Wave™ QR Code on the product, with
a controller providing SmartStart inclusion.
No further action is required and the
SmartStart product will be added automat-
ically to the closest network within 10 min-
utes of being switched on.
Notice:
The QR Code can be found on the device
AD19 or in the box.
Remove (Ex-
clusion)
1. ut your Z-Wave™ controller into exclu-
sion mode by following the instructions
provided by the controller manufacturer.
2. ress the include button three times within
3 seconds to enter exclusion mode.
3. Node ID will be excluded. LED light flashes once
every one second and
last for 30 seconds
Reset 1. ress the include button four times within
3 seconds and hold on the button press
without releasing.
LED light will be on sta-
tus
4
2. Keep pressing the button for 3 seconds
then LED will be off, release the button
within 2 seconds.
3. Device has been reset. LED light flashes once
every one second and
last for 30 seconds.
Adding a node ID allocated by Z-Wave™ Controller means inclusion. Removing
a node ID allocated by Z-Wave™ Controller means exclusion.
Failed or success in including/excluding the node ID can be viewed from the Z-
Wave™ Controller.
Function Reset: lease use this procedure only when the network primary con-
troller is missing or otherwise inoperable.
LED Light Indication
To identify what mode the switch is in, view the following table for LED light identifica-
tion.
State Type LED Indication
No node ID Under normal operation, when the Switch has not been allocated a node ID,
the LED light will flash on and off alternately at 1-second intervals. By press-
ing the On/Off button, LED light will stop flashing temporarily.
Learning Flashes when learning is successful
Over-load LED flashes one time every 0.4 seconds.
Manual dim level control:
Long press the button, the light will increase the lighting slowly.
Short press the button, the light will be on/off.
You can set Z-Wave™ Configuration 1 as value 2,
S1 only increasing the light.
key Type Config 6 set Long ress Short ress
Learn button DIMMER ON/OFF
S1 0 DIMMER ON/OFF
1 TOGGLE
Over-load
When overload occurred, device will launch protection mechanism and cut off power
of loading. LED will quick flash one time every 0.4 seconds. Device will also send
"Over-load detected" as Z-Wave™ Notification. Device will not accept any control un-
til AC off/on.
Z-Wave™ Function
Basic Command Class/Multilevel Switch Command Class
5
The dimmer will respond to BASIC and MULTILEVEL SWITCH commands that are
part of the Z-Wave™ system. If AD19 is included as a secured node, it will only re-
spond to the security encapsulation command of BASIC and MULTILEVEL SWITCH.
The Basic Command Class is mapped according to the following table.
Basic Command Mapped Command
Basic Set (Value) Multilevel Switch Set (Value)
Basic Report (Current Value, Duration) Multilevel Switch Report (Value, Dura-
tion).
Z-Wave™ Association Groups
The AD19 can be set to send reports to associated Z-Wave™ devices. It supports
one association group with five nodes support for group 1.
For group 1, the dimmer will report MULTILEVEL_SWITCH_RE ORT, NOTIFICA-
TION_RE ORT and DEVICE_RESET_LOCALLY_NOTIFICATION.
1. Grouping 1 Lifeline (Maximum 5 nodes).
2. MULTILEVEL_SWIT H_REPORT
When “on” or “off” state has been changed,
it will send Multilevel Switch Report to the nodes of Grouping 1.
3. NOTIFI ATION_REPORT
When overload occurred.
4. DEVI E_RESET_LO ALLY_NOTIFI ATION
When AD19 is reset manually, it will send
DEVICE_RESET_LOCALLY_NOTIFICATION to the nodes of group 1.
Z-Wave™ configuration
No. Name Size
(Byte)
Default Value Description (Info)
1 ower-on recov-
ery status set
1 0 0~2 To set dimmer level when AC
power on.
Setting value:
0: OFF-0%
1: ON-last level
2: ON-100%
2 RF report set 1 1 0~1 To set if device send Multilevel
Switch report to gateway when
dimming finished.
Setting value:
1: report ON
0: report OFF
3 Maximum level 1 99 (Minimum
level+1)~99
To set dimming level maximum
value. Dimming level will not over
the setting value.
Setting value:
Cannot be lower than the Mini-
6
mum level
4 Minimum level 1 0 0~(Maxi-
mum level-
1)
To set dimming level minimum
value. Dimming level will directly
go to 0% when dimming value is
lower than the setting value.
Setting value:
Cannot be higher than the Maxi-
mum level
5 Basic duration
set
1 2 0~127 Unit: second
To set dimming finished duration
time when physical switch used.
Ex: When setting is 2, it will take 2
seconds from switch on action to
dimming finished.
6 Switch Set 1 1 0~1 0: Long ress:dimmer
Short ress:ON/OFF
1: Toggle(no dimmer function)
Notice 1: Always remove a Z-Wave™ device before trying to add it to
a Z-Wave™ network.
Notice 2: This product can be operated in any Z-Wave™ network with
other Z-Wave™ certified devices from other manufacturers. All non-
battery operated nodes within the network will act as repeaters regard-
less of vendor to increase reliability of the network.
Over The Air Firmware Update
The device support the Z-Wave™ firmware update via OTA.
Let the Z-WaveTM Controller into the firmware update mode, choose
the hex file to update. Wait for 10~15 minutes.
At that time, please don't remove the power, otherwise it will
cause the firmware broken, and the device will no function.
Result will show in Z-WaveTM Controller log.
Z-Wave™ Supported ommand lass
Command Class Version Required Security Class
Z-Wave™ lus Info 2 None
Security 1 None
Security 2 1 None
Supervision 1 None
Transport Service 2 None
Association 2 Highest granted Security Class
Association Group Informa-
tion
3 Highest granted Security Class
Device Reset Locally 1 Highest granted Security Class
Firmware Update Meta Data 5 Highest granted Security Class
Indicator 3 Highest granted Security Class
Manufacturer Specific 2 Highest granted Security Class
7
Multi Channel Association 3 Highest granted Security Class
owerlevel 1 Highest granted Security Class
Version 3 Highest granted Security Class
Configuration 4 Highest granted Security Class
Notification 8 Highest granted Security Class
Multilevel Switch 4 Highest granted Security Class
Basic 2 Highest granted Security Class
Disposal
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the
return and collection systems or contact the retailer where the
product was purchased. They can take this product for
environmentally safe recycling.
Philio Technology orporation
8F., No.653-2, Zhongzheng Rd., Xinzhuang Dist., New Taipei ity 24257,
Taiwan(R.O. )
www.philio-tech.com
F Interference Statement
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to art 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interfer-
ence in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications.
However, there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment off and on, the user is en-
couraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with art 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party re-
sponsible for compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other an -
tenna or transmitter.
警語:
「取得審驗證明之低功率射頻器材，非經核准，公司、商號 使用者均不得擅自變更頻
率、加大功率 變更原設計之特性及功能。
8
低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應
立即停用，並改善至無干擾時方得繼續使用。
前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通
信 工業、科學及醫療用電波輻射性電機設備之干擾。」
9
Table des matières
Autres manuels Philio Variateur
