Phase Technologies CI-6.0 VIII QM Guide de configuration

T E C H N O L O G Y

CI-6.0 VIII QM CI-6.1 VIII QM CI-6.2s VIII QM CI-7.2 VIII QM CI-7.3 VIII QM

Install instructions for CI round ush mount models:

Universal ange & grille

assembly (CI-FGR QM)

(purchase separately)

Flange clamp (4x)

The CI-FGR QM will clamp

material up to 1 1/2” thick.

Speaker/bae

assembly

Flange clamp

screw (4x)

Tweeter adjustment

Grille Bae clamp screw (4x)

Thank you for purchasing Phase Technology CI custom installation

speakers. This eighth generation of high performance ceiling

mounted speakers features the same superb sonic performance as

our acclaimed PC Series cabinet speakers in addition to great

exibility and easy installation. The most striking change to the series

VIII QM is a new look with the o-axis tweeter design. This feature

maximizes the speaker’s clarity and imaging by creating an

asymmetrical loading or diraction patter, reducing the amount of

diraction normally caused by a ange-to-ceiling junction.

The net result is the best sonic realism you can buy in an in-ceiling

speaker. All CI series speakers include self-resetting solid-state PTC

protection circuits. This unique system is able to detect when the

speaker is being over-driven and lowers the speaker volume until the

problem is corrected. Other features include liquid-cooled tweeters

for greater power handling, moisture-resistant materials in all of the

critical speaker components, galvanized steel speaker grilles and

stainless steel hardware for improved corrosion resistance.

The CI VIII QM in-ceiling series incorporates a new patent-pending

CI-FGR Quick Mount QM SAFETY-LOC™ mounting system. No longer

will you have to suer through holding the speaker in place overhead

while tightening the screws. The breakthrough comes from a newly

developed system of clamps that engage to hold the speaker in the

ange while you safely tighten the clamps with a screwdriver. The

new QM SAFETY-LOC™ system makes installation of the CI VIII QMs

the easiest you’ve ever done.

All Phase Technology CI speakers are covered by a limited lifetime

warranty (see warranty card).

218-1240

Choose the appropriate mounting location for each speaker.

When deciding upon a location, consider the following:

• Be certain your speaker wires can be run to or are accessible from these

locations.

• Make certain the wall or ceiling material is sturdy enough to support the

weight and vibration of the speakers.

• It is recommended that our pre-construction rough-in brackets (part

number RB-17*) be used whenever possible in new construction.

• Be certain the area behind the speaker is free of obstacles such as wall

studs, electrical wiring, pipes, etc.

• Each speaker should be positioned properly, relative to the listening area

for good coverage.

• Audio performance and room-to-room isolation will be improved if there is

some berglass insulation placed loosely behing the speaker.

*The RB-17 rough-in bracket is available for installations in new construction.

Install instructions for CI round ush mount models, Page 2

1. Using the supplied cutout template,

carefully mark the area to be cut out. Using

a drywall knife or saw, cut a hole in the

drywall and prepare the speaker wires for

connection to the speaker terminals.

2. Remove the grille from the mounting

ange by pressing it from behind. Insert the

mounting ange into the hole. Loosen the

ange clamping screws one turn (counter

clockwise) to release the clamp. Next,

tighten all four ange clamp screws evenly

to secure the ange to the wall. It is best to

tighten each screw with the same amount of

force (torque). CAUTION: Do not over-tighten.

Flange Installation:

3. Connect the speaker wires to the

spring-loaded input terminals on the rear of

the speaker, making sure no loose strands

are exposed. If connecting the CI-6.2s VIII QM,

see wiring options below.

Speaker Installation:

Red/positive Black/negative

5. Using some familiar source material,

listen to the tweeter’s balance with the level

control in each of its three positions to nd

your favorite.

6. Carefully replace the grille by pressing it

into the gap between the ange and the

bae. Enjoy your new Phase Technology

speakers!

Grille

4. Carefully place the speaker in the ange.

While exerting upward pressure, rotate the

speaker until it ts snugly and the speaker

surface is even with or slightly recessed

into the surface of the ange. Twist the

speaker counter-clockwise (left) to secure

it in place. This will engage the QM SAFETY-LOC™

clamps on the back of the ange. Finish by

tightening the four clamp screws on the

speaker. CAUTION: Do not over-tighten.

QM SAFETY-LOC™ Clamp

Wiring options for the CI-6.2s

Right ChannelRight Channel

Stereo Point Source FIG.2 – 8 ohms:

Use this configuration to combine left

and right channels for full fidelity sound

from a single loud-speaker stereo source.

Set jumper plugs in the stereo position.

Connect right and left signal wires to the

spring-loaded terminals on the rear of

the speaker.

Jumper Plugs

stereo position

Jumper Plugs

stereo position

Mono/S tereo

FIG.3 – 4 ohms: Use

this configuration to drive one channel

(left or right ) of a stereo pair with a 4

ohm speaker load. Set jumper plugs in

the mono position. Connect the right or

left signal wire to the left set of posts

on the rear of the speaker. Acoustic

output of the speaker is increased by

3 dB in the configuration.

Bi-pole/Di -pole

FIG.4

–

4 ohms: Use this

configuration for home theater surround

applications. For bi-pole mode, connect

as in the Mono/ Stereo instructions (FIG.3):

one speaker to each surround channel.

For di-pole mode, connect speaker

inputs the same as Mono/ Stereo

instructions (FIG.3), but reverse the +and –

connections of the markedtweeter wires

to put one of the tweeters out of phase.

Left Channel Left Channel

Stereo

FIG. 1 – 8 ohms: Use this

conguration to drive one channel

(left or right ) of a stereo pair. Set

jumper plugs in the stereo position.

Connect the right or left signal wire to

the right set of terminals on the rear of

the speaker.

Jumper Plugs

mono position (Bi-pole/di-pole)


FIG.4

NOTE: Special instructions for non-QM

Flanges

If you are installing a CI round speaker with

the QM clamps in a CI-FGR (non-QM ange)

remove the QM clamp feet by unscrewing

them from the speaker bae. Insert the

speaker bae into the ange and reuse the

screws from the clamp feet to attach the

speaker to the ange.
