CI-110 II Installation Guide

Thank you for purchasing the Phase Technology CI-110 II high definition in-wall speaker system. The mounting frame of

extruded aluminum has a uniquely designed self-aligning clamping system to secure the flange assembly to the drywall.

This patent pending design simplifies installation and reduces unwanted wall vibration resulting in improved performance

and definition.

Getting Started

For an efficient installation you will need the following tools:

Electric screwdriver (drill) with philips bit Drywall saw or knife

Tape measure Bubble level

Stud-finder Pencil

3/32” standard screwdriver

When selecting the speaker mounting location, it is prudent to take a few extra minutes to carefully inspect and measure

the wall or ceiling area where you intend to mount the CI-110 II. An inspection of the room or rooms that back-up to the

wall you have selected for mounting the CI-110 II, can often alert you to potential obstacles. For example, if the wall you

want to mount into happens to be the common wall for a bathroom or kitchen, there is a good chance you will encounter

water or sewer pipes in the wall that will not be detected by a stud-finder. An electronic stud-finder is a useful tool to

assist you in selecting the speaker placement, however be cautious as they often give false readings. Drilling a ½”

inspection hole will save you time and eliminate the need to elaborate drywall repair. If you are unable to see into the

hole, use a stiff piece of wire or coat hanger with a right angle bend 5” – 6” from one end. Insert the wire into the

inspection hole and spin in all directions. If you do not hit any obstructions, such as wood or pipes, it is usually safe to

proceed. If any obstructions are detected, an alternate location should be selected. You will want to center the speaker

equidistant between studs when possible – if your mounting position places the speaker flange close to a stud, you may

remove the clamp assembly on that side and secure the flange directly to the stud using drywall or wood screws.

Step 1

The CI-110 II uses the same cutout template as the CI-110 and CI100. The cutout opening is 20 1/2” X 8 7/8”. Place the

cutout template against the wall surface and align it using your bubble level. Hold, tape or staple the template in place

and trace around the perimeter of the template with a pencil. Remove the template and begin cutting on the pencil line.

Step 2

When the cutout is complete, carefully remove the drywall piece from the opening. You now have a large opening to

facilitate pulling your speaker wire. We recommend 16 gauge or heavier wire be used with the CI-110 II. Contact your

Phase Technology Dealer for a recommendation.

Step 3

We recommend a piece of fiberglass insulation for maximum performance. It is available from your local home center.

Be careful not to overstuff the cutout – one piece the length of the opening will be adequate.

Step 4

Carefully remove the speaker baffle from the aluminum frame assembly and set aside. Remove the flange assembly from

the packing carton. The flange assembly must make a good seal to insure maximum performance. You will find two L-

shaped foam gasket pieces in the bottom of the carton. Peel the removable tape from the gasket and stick the adhesive

side to the backside of the flange. Upon installation of the flange assembly gasket will contact the front wall surface to

form an airtight seal.

Step 5

When you remove the flange assembly from the packing carton, you will notice the screws used to retain the clamp

assembly are fully extended. To place the flange assembly into the wall push the clamp assemblies toward the center of

the flange opening; the holes in the flange will allow the mounting screws to tilt toward the center opening enough to

insert the flange assembly into the wall. Insert the right side into the wall cutout and slide the complete assembly to the

right. This will enable you to then fit the left side clamp assembly into the cutout. Center the entire assembly in the

opening.

Step 6

Pinch the self-aligning clamp assembly inside the wall until it contacts the backside of the drywall surface. This will force

the three retaining screws to protrude from the front of the flange. Continue to hold the clamp with one hand and use the

electric screwdriver to tighten the center screw of the flange. Once snug, repeat the procedure on the other clamp

assembly. Using your level, verify the mounting frame is correctly aligned in the opening. Make any necessary

adjustments then tighten the remaining screws until the frame is snug and securely clamping the wallboard. Avoid over-

tightening the screws.

Step 7

You are now ready to install the speaker baffle into the mounting flange. An Euro-connector is supplied on the crossover

board. This is a two-piece connector intended to make installation easier. Unplug the male portion of the connector from

the circuit board. Insert the positive and negative conductors of your speaker wire into the screw terminal using care to

properly connect the + & - leads correctly. Using a 3/32” standard screwdriver, tighten the screws in the connector to

secure the wire.

Step 8

When mounting the speaker baffle into the flange, pay particular attention to insure the speaker is mounted right side up.

The rear panel of the baffle is marked for correct installation. Optimum performance may only be achieved when the

speaker is mounted correctly. Plug the connector into the crossover observing the correct polarity then install the baffle

into the flange assembly. Six screws are supplied to secure the baffle to the flange. Hold the baffle in position until you

have at least two screws properly secured.

Step 9

Insert the grill assembly by applying light pressure at each corner of the grill until flush with the flange assembly. A paint

shield is supplied with each grill to protect the drivers in the event the customer wants the grill and flange assembly

painted to match the wall color. Once the paint has dried remove the paint shield and re-insert the grill.

Note: A paper clip bent to have a small hook approximately 1/8” long makes a convenient tool for removing CI grills

without scratching the finish.

218-1107
