Sx TAG IP Modes

Quick Start Guide



Software Release 2.01



Revision 1a

About this Guide

This Quick Start Guide is intended to help you quickly to get up-and-running with the SMPTEST2110

and 2022-6 IPfunctions of the PHABRIX SxTAG;to provide a short overview of the main user

interface and controls, and to summarize the screens related to the IP setup and functions of the unit.

This guide is not intended as a complete guide to the Sx TAG. For more detailed information, please

refer to the Sx TAG User Manual available from the PHABRIXSupport web page:

https://www.phabrix.com/products/sxtag/



Notice

The information in this document has been produced by PHABRIX Ltd with care and is believed to be

accurate. PHABRIX Ltd does not assume responsibility for loss or damage resulting from errors,

omissions or inaccuracies herein. This document is subject to change, and revisions may be made

and issued to include such changes.

No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form

or by any means, electronic, mechanical, recorded or otherwise without the prior written consent of

PHABRIX Ltd.

Ltd and are protected by international treaty provisions and national copyright laws.

HDMI ® is the registered trademark of HDMI Licensing and is used within the document for

identification purposes only.



PHABRIX® Limited



Omega House

Enterprise Way,

Thatcham, Berkshire

RG19 4AE



United Kingdom 



Phone: +44 (0)1635 873030



Email: [email protected]



Website:www.phabrix.com

Revision

This guide is a revision controlled document. Any changes to any page content will be reflected in the

overall revision status of the whole manual.



Release Date Software Version Updates Include:

1a May 2021 2.01 New release of document

Page 2

PHABRIX Sx TAG

Quick Start Guide

Table of Contents

About this Guide

Notice

Revision

Setting-up the Sx TAG

1-1

General Set-up Checklist

1-1

What's in the Box?

1-2

Side Panel Connectors

1-3

Inserting the SFP+ Interface Module

1-4

Powering the Unit On and Off

1-5

Checklist for 2110 Testing

1-6

Checklist for 2022-6 Testing

1-7

Networking Connection Example

1-8

About the Sx TAG User Interface

2-1

Using the Front Panel Controls

2-1

Setting the Sx TAG Control IP Address

2-7

SFPMode & Management

3-1

Switching SFP Mode

3-1

SFPSetup

3-2

SFP Setup Management Interface

3-3

SFPSetup:Management Interface Dialog

3-4

Using ST 2110 Decap Mode

4-1

Overview of the 2110 Decap Status Screens

4-1

2110 Decap Video Flows

4-2

Working in the 2110 Decap Video Flows Dialog

4-3

2110 Decap:Setup Other Flows and PTP

4-4

Working with the 2110 Decap Other Flows

4-5

Using ST 2110 Encap Mode

5-1

Overview of the 2110 Encap Status Screens

5-1

2110 Encap Video Flows

5-2

Working in the 2110 Encap Video Flows Dialog

5-3

2110 Encap: Setup Other Flows and PTP

5-4

Working with the 2110 Encap Other Flows

5-5

Using ST 2022-6 Decap Mode

6-1

Overview of the 2022-6 Decap Status Screens

6-1

2022-6 Decap Video Flows

6-2

Working in the 2022-6 Decap Video Flows Dialog

6-3

Using ST 2022-6 Encap Mode

7-1

Overview of the 2022-6 Encap Status Screens

7-1

2022-6 Encap Video Flows

7-2

Working in the 2022-6 Encap Video Flows Dialog

7-3



PHABRIX Sx TAG

Quick Start Guide Page 3

Setting-up the Sx TAG 1

General Set-up Checklist

Before starting to use the Sx TAG for testing in an IPenvironment (2110 or 2022-6) be sure to

complete each of the steps in the following checklist:



Check Task Description

1Make sure that you have received all ordered components. See:

"What's in the

Box?" on the next page

2Insert the power supply connector into the unit and plug-in to a power source.

See:

"Side Panel Connectors" on page1-3

3Insert the Optical SFP+Transceiver into the SFPcage (Option:PHSFP-10SR-

IP).See:

"Inserting the SFP+ Interface Module" on page1-4

4Press the red button on the front panel to power-up the unit. See:

"Powering the

Unit On and Off" on page1-5

5Insert the RJ-45 Control Ethernet connector to connect the Sx TAGto your con-

trol network. See:

"Side Panel Connectors" on page1-3

6Insert the LC-LCMultimode optical cable connector to connect the Sx TAGto

your 2022-6 or 2110 test network. See:

"Side Panel Connectors" on page1-3

7Insert any of the optional connectors required for you testing requirements, e.g.,

Audio I/O D-type, audio headphone jack, or any BNCconnectors. See:

"Side

Panel Connectors" on page1-3

8Configure the Sx TAGIPaddress for use in the control network, using either

DHCPor by supplying a static IPaddress. See:

"Setting the Sx TAG Control IP

Address" on page2-7



PHABRIX Sx TAG

Quick Start Guide Page 1-1

What's in the Box?

The Sx TAG is supplied with the following as standard:

lSx TAG Analyzer, Generator, Monitor, and IP Handheld Unit including built-in MSA/Non-MSA

SFP+ Cage.

l5 V 4ADC Power Adapter.

lPHABRIX Soft Carry Case.

lSFP Cage fitted.

Optional Accessories

In addition to the standard equipment supplied with the Sx TAG, you may also have ordered the

following optional components, depending on your test requirements:

lVarious SFPInterface Modules, including:

lOptical SFP+Transceiver (Option:PHSFP-10SR-IP) for generation, analysis and mon-

itoring of SMPTE ST 2110-10/20/30/31/40 with NMOS IS-04/IS-05/IS-08 and ST 2022-6 IP

formats.

Also provides SDI-to-IP and IP-to-SDI Gateway conversion of 3G, HD, SD-SDI signals with

up to 16 channels of audio.

lElectrical SFPTransceiver (Option:PHSFP-RT30-HDBNC) for closed-loop testing in

SDIenvironments.

lOptical SFPTransceiver 1310 or 1550 nm (Options: PHSFP-RT30-1310 or PHSFP-RT30-

1550) for closed-loop testing in optical fiber environments.

lHDMIInput SFP (Option:PHSFP-HDMI-IN) to convert HDMIsignal to SDI for analysis.

lHDMIOuput SFP (Option:PHSFP-HDMI-OUT) to convert Sx TAGSDIOutput to

HDMIwithout scaling artifacts.

lAudio break-out cable (Option:PHSXC-1)



Page 1-2

PHABRIX Sx TAG

Quick Start Guide

Side Panel Connectors

Figure 1-1: Sx TAG Side Panel Connectors

PHABRIX Sx TAG

Quick Start Guide Page 1-3

Inserting the SFP+ Interface Module

Insert the SFP+interface module into the cage as shown below. Push the module into the slot until

you feel a small click.

Figure 1-2: Inserting the SFP+Interface Module



To remove the module, pull down the lever on top of the unit and pull gently out of the cage.



Note: The IPfunction key (2110Encap, 2110Decap, 2022Encap, or 2022 Decap) is displayed

only when an SFPmodule is inserted in the unit.



Note: When running a new Sx TAGin IPmode alongside an older unit, you may notice that the

fan sounds slightly louder in the new unit. From serial number 6382, the Sx TAGfan was

upgraded to dissipate any addiitonal heat generated by the optical SFP+transceiver (option:

PHSFP-10SR-IP).



Page 1-4

PHABRIX Sx TAG

Quick Start Guide

Powering the Unit On and Off

You can choose to operate the unit by connecting to the mains power using the supplied adapter, or

alternatively, run the unit for approximately 1.5 hours from the built-in battery.

To power-on the unit:

lPress the small red button at the top right-hand corner of the front panel.

To power-off the unit:

lPress the red button on the front panel again.

The detected IP SFP mode is displayed in the right-hand button of the Main Menu.

PHABRIX Sx TAG

Quick Start Guide Page 1-5

Checklist for 2110 Testing

Before starting to test in a 2110 environment, make sure that you have access to the following:

lNetwork domain providing an ST 2059 compatible Grandmaster PTPtiming signal.

lOptionally an NMOS-compatible, configuration, monitoring and control utility for in-band,

remote control of the IPSFP, for example, Riedel MNSET (available from the PHABRIXSupport

website under PHABRIXProduct Utilities.)



Check Task Description

1Configure the SFP+ IPaddress for use in the test network using either DHCPor

by supplying a static IPaddress. See:

"SFP Setup Management Interface" on

page3-3

2Select the correct SFPMode. See:

"SFPMode & Management" on page3-1

3Configure PTPby setting the PTP Communication mode and Domain number.

See:

"Setting-up Precision Time Protocol (PTP)for 2110 Decap Flows" on page4-6

"Setting-up Precision Time Protocol (PTP)for 2110 Encap Flows" on page5-6

4Configure NMOSusing either MNSETor a similar control application (if using

NMOS.) See the

MNSETUser Guide

5For 2110 Encap, configure the following:

lGenerator or SDI-to-IP Gateway.

lVideo Flow(s):Set destination IPAddress and enable flow(s) etc.

lAudio Mapping.

lAudio Flow:Set destination IPAddress and enable flow(s) etc.

lANC Flow:Set destination IPAddress and enable flow(s) etc. (if

using the gateway)

lOptionally set the Source IPaddress to match the SFPManagement

IPaddress using the Copy Management Source IP button.

lOptionally enable the synchronizer on the SFP Setup page.

See:

"2110 Encap Video Flows" on page5-2

and

"2110 Encap: Setup Other Flows

and PTP" on page5-4

6For 2110 Decap, configure the following:

lConfigure the Video Flow(s): Set Destination Multicast IP Address for

Video, Audio and ANC and enable flow(s).

lConfigure the Audio Mapping.

lConfigure the Audio Flow:Set source IPAddress and enable flow(s)

etc.

lConfigure the ANC Flow: Set source IPAddress and enable flow(s)

etc.

See:

"2110 Decap Video Flows" on page4-2

and

"2110 Decap:Setup Other Flows

and PTP" on page4-4



Page 1-6

PHABRIX Sx TAG

Quick Start Guide

Checklist for 2022-6 Testing

Before starting to test in a 2110 environment, make sure that you set-up the following:



Check Task Description

1Configure the SFP+ IPAddress for use in the test network using either DHCPor

by supplying a static IPaddress. See:

"SFP Setup Management Interface" on

page3-3

2Select the correct SFPMode. See:

"SFPMode & Management" on page3-1

3For 2022-6 Encap, configure the following:

lConfigure the Video Flow(s):Set destination IPAddress and enable

flow(s) etc.

See:

"2022-6 Encap Video Flows" on page7-2

4For 2022-6 Decap, configure the following:

lConfigure the Video Flow(s):Set Destination Multicast IPAddress

and enable flow(s) etc.

See:

"2022-6 Decap Video Flows" on page6-2



PHABRIX Sx TAG

Quick Start Guide Page 1-7
