Pfeiffer Vacuum MVP 040-2 Manuel utilisateur

Betriebsanleitung • Operating Instructions

PU 0050 BE/A (0809)

Diaphragm Pumps

MVP 040-2, MVP 070-3/3C

Translation of the Original Operating Instructions

Table of contents

1Aboutthismanual......................................3

1.1 Validity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.2 Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2Safety................................................4

2.1 Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.2 Proper use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.3 Improper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3Transportandstorage..................................6

3.1 Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4Productdescription....................................7

4.1 Product identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4.2 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5Installation...........................................10

5.1 Setting up the pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.2 Connecting the vacuum side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.3 Connecting the exhaust side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.4 Connecting to the mains power supply . . . . . . . . . . . . . . . . . . . . . . 11

6Operation............................................13

6.1 Before switching on the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.2 Switching on the pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.3 Pumping condensable vapours. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

6.4 Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

7Maintenance..........................................15

7.1 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

7.2 Cleaning and replacing diaphragm and valves . . . . . . . . . . . . . . . . 16

7.3 Replacing the device fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

8Decommissioning.....................................26

8.1 Shutting down for longer periods. . . . . . . . . . . . . . . . . . . . . . . . . . . 26

9Malfunctions.........................................27

9.1 Rectifying malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

10 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

11 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

12 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

13.1 Substances in contact with the media . . . . . . . . . . . . . . . . . . . . . . . 33

13.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

About this manual

1Aboutthismanual

1.1 Validity

This operating manual is for customers of Pfeiffer Vacuum. It describes the func-

tioning of the designated product and provides the most important information for

safe use of the unit. The description follows applicable EU guidelines. All informa-

tion provided in this operating manual refer to the current state of the product's de-

velopment. The documentation remains valid as long as the customer does not

make any changes to the product.

Up-to-date operating instructions can also be downloaded from

www.pfeiffer-vacuum.net.

Applicable docu-

ments

*also available via www.pfeiffer-vacuum.net

For information about other certifications, if applicable, please see the signet on

the pump or:

•www.tuvdotcom.com

•TUVdotCOM-ID0000021320

1.2 Conventions

Safety instructions The safety instructions in Pfeiffer Vacuum operating manuals are the result of risk

evaluations and hazard analyses and are oriented on international certification

standards as specified by UL, CSA, ANSI Z-535, Semi-S1, ISO 3864 and DIN 4844.

In this document, the following hazard levels and information are considered:

MVP 040-2, MVP 070-3/3C Operating instructions

Safety information for vacuum pumps "Safety Guide" PT 0300 BN*

Declaration of Conformity Part of this document

Operating instructions for accessories (order-specifically) see section "accessories"*

DANGER

Immediate danger

Death or very severe injuries occur.

WARNING

Possible danger

Death or injuries may occur.

CAUTION

Possible danger

Medium to slight injuries may occur.

NOTE

Command or note

Command to perform an action or information about properties, the disregarding of

which may result in damage to the product.

Safety

Pictograph

definitions

Instructions in the

text

!Work instruction: here you have to do something.

Abbreviations used C version: Corrosive gas version

Symbols used The following symbols are used consistently throughout in all illustrations:

Vacuum connection

Exhaust

Gas ballast valve

Power connection

2Safety

2.1 Safety precautions

•Beforepumpingdangerous,corrosiveorenvironmentallyhazardousmedia,

take suitable precautions:

–Testthecompatibilitywithsubstancesincontactwiththemedia.

–Preventthereleaseofprocessgasesandtheirreactionproductsandby-pro-

ducts or dispose of them according to the relevant regulations.

–Safetymeasures(e.g.wearingprotectiveclothingandsafetygoggles)topre-

vent inhalation and skin contact.

•Beforepumpinggaseswhichcouldformignitablemixtures,takesuitablepre-

cautions:

– By implementing the required safety measures, prevent potentially explosive

mixtures from occurring in the housing and from being ignited in the event of

a diaphragm crack by mechanically produced sparks, hot surfaces or static

electricity.

Prohibition of an action or activity in connection with a

source of danger, the disregarding of which may result in

serious accidents.

Warning of a displayed source of danger in connection

with operation of the unit or equipment.

Command to perform an action or task associated with a

source of danger, the disregarding of which may result in

serious accidents.

NOTE

Duty to inform

Each person involved in the installation, operation or maintenance of the vacuum

pump must read and observe the safety-related parts of these operating instructions.

!The operator is obligated to make operating personnel aware of dangers originating

from the vacuum pump, the pumped medium and the entire system.

Safety

–Ifnecessary,useinertgasforgasballastsupplyorventilation.

•Connectthevacuumpumptoashockproofsocketonly.

–Useonlyundamagednetworkcableswhichcomplywiththeregulations.

–Makesurethatthegroundingissufficient.

•Donotexposeanybodypartstothevacuum.

•Observethesafetyandaccidentpreventionregulations.

•Checkregularlythatallsafetyprecautionsarebeingcompliedwith.

•Donotcarryoutanyunauthorisedmodificationsorconversionstothepumps.

• Depending on the operating and ambient conditions, the surface temperature of

the pumps may rise above 70 °C. Use suitable finger guards if necessary.

• When returning the pumps to us please note the instructions in the Service sec-

tion.

2.2 Proper use

•Thevacuumpumpmayonlybeusedtogenerateavacuum.

• Installation, operating and maintenance regulations must be complied with.

•Otheraccessoriesthanthosedescribedinthismanualmustnotbeusedwithout

the agreement of Pfeiffer Vacuum.

• When pumping gases which could form explosive or ignitable mixtures, take

suitable precautions:

–Ifnecessary,connectinertgasforventilationorgasballastsupply.

2.3 Improper use

Improper use will cause all claims for liability and guarantees to be forfeited. Im-

proper use is deemed to be all use for purposes deviating from those mentioned

above, especially:

•Pumpingofcorrosivegases(exception:pumpsinCversion).

•Pumpingofexplosivemedia.

•Operationofthepumpinpotentiallyexplosiveareas.

• Pumping of gases containing impurities such as particles, dusts and condensate;

note the vapour compatibility levels of the pump.

•Pumpingofsubstancesthattendtosublime.

•Useofthevacuumpumptogeneratepressure.

•Pumpingofliquids.

•Connectiontopumpsorunitswhicharenotsuitableforthispurposeaccording

to their operating instructions.

•Connectiontounitswhichhaveexposedvoltage-carryingparts.

Improper use of the equipment automatically invalidates all warranty and liability

claims.

NOTE

CE conformity

The manufacturer's declaration of conformity becomes invalid if the operator modifies

the original product or installs additional components.

!Following installation into a plant and before commissioning, the operator must

check the entire system for compliance with the valid EU directives and reassess it

accordingly.

Transport and storage

3Transportandstorage

3.1 Transport

!Remove the locking cap from the vacuum and fore-vacuum flange immediately

before connecting!

!Use only the handles provided for that purpose to lift the pump.

–Donotusetheinterheadconnectionsonthetopsideofthepumptocarrythe

pump.

Fig. 1: Lifting and transporting the pump

3.2 Storage

!Check that all the openings on the pump are securely closed.

!Store the pump in a cool, dry place; preferably at room temperatures (approx.

20°C).

–Foralongerperiodofstorage,sealthepumpinaPEbagwithdryingagents

enclosed.

Product description

4Productdescription

4.1 Product identification

To corr ec t l y i dent i f y t h e p rod u ct w hen comm u nicati n g w ith Pf eiffe r Va c uum, al -

ways have the information from the rating plate available.

• Pump model and model number

• Serial number

•Dateofmanufacture

Scope of delivery •Pumpwithmainspowersupply(switchable)viarubbersocket

•Lockingcapsforvacuumandexhaustflange

•Operatingmanual

Differences between

the pump versions Pump type Pump designs

MVP 040-2

Standard version:

•G1/4"elbowunionwithenclosedhose10/8,1000mmwithanelbowunion

in G 1/4" at the end

MVP 070-3

Standard version:

•G1/4"elbowunion+enclosedhose10/8,1000mmwithaelbowunionin

G 1/4" at the end

MVP 070-3C C version:

•ForDN16ISO-KF

Product description

4.2 Function

The diaphragm vacuum pumps of the series MVP 070-3 are three stage and those

of the MVP 040-2 series are two stage, dry compressor vacuum pumps. The pumps

are positive displacement pumps with a periodic change of size of the suction

chamber produced by the movement of the diaphragm. The gas flow causes the

valves to open and close automatically. The pump units are directly connected to

the drive motor.

Fig. 2: MVP 040-2

Fig. 3: MVP 070-3

A1 Vacuum connection

2.1 Exhaust (with silencer)

ADiaphragmhead1

BDiaphragmhead2

NPowerswitch

UVoltageselectorswitch

23 Hose connection

40 Gas ballast valve

A1 Vacuum connection

2.1 Exhaust (with silencer)

NPowerswitch

UVoltageselectorswitch

23 U N 2.1 40

A A1 B

2.1 U N

Product description

Fig. 4: MVP 070-3C

A1 Vacuum connection

2.1 Exhaust

NPowerswitch

UVoltageselectorswitch

40 Gas ballast valve

2.1

U N

Installation

5 Installation

5.1 Setting up the pump

Installation location Observe the following requirements when setting up the pump:

•Notetheload-bearingcapacityofthemountingsurface.

•Maximuminstallationaltitude2000m(abovemeansealevel)

• Permissible ambient temperature: +12 ... 40°C

•Maximumrelativehumidity85%

!Always place the pump on a firm, even surface.

– Where stationary installation is involved, anchor the pump on site.

!When installing the pump in a closed housing, ensure there is sufficient air cir-

culation.

–Voltageandfrequencyinformationgivenonthemotorratingplatemustbe

visible.

–Ifvacuumpumpisinstalledabove1000mabovemeansealevelcheckcom-

patibillity with applicable safety requirements, e.g. DIN EN 61010 (motor may

overheat due to insufficient cooling).

5.2 Connecting the vacuum side

!Remove locking cap on intake connection and connect vacuum pump to the ap-

paratus.

!The connection between the pump and the recipient should be kept as short as

possible.

–Dependingonthepumptype,usemetallichosesorPVChoseswithflange

connections.

–Separators,filtersetc.maybeinstalledupstreamtoprotectthepump(seeac-

cessories). However, please observe the loss of pumping capacity due to the

conductivity of the accessories.

5.3 Connecting the exhaust side

!Choose the cross-section of the exhaust line to be at least the size of the nominal

connection diameter of the vacuum pump's exhaust connection.

!Piping to the pump must be suspended or supported.

–Physicalforcesfromthepipingsystemmustnotbeallowedtoactonvacuum

pumps.

!Lay piping from the pump sloping downward so that no condensate can flow

back into the pump; otherwise fit a condensate separator.

–Ifanairtrapiscreatedinthesystem,thenadevicefordrainingcondensation

water must be provided at the lowest point.

CAUTION

High pressure in the exhaust line!

Danger of damage to the seals and danger of the pump bursting.

!Install the line without shut-off valves on the exhaust side.

!Pumpe nicht mit Überdruck am Einlass betreiben; max. zulässige Drücke und Druck-

differenzen beachten.

Autres manuels pour MVP 040-2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Pfeiffer Vacuum Pompe à eau

Pfeiffer Vacuum

Pfeiffer Vacuum TPH 2301 P Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum UnoLine UNO 200 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum Pascal Series Instructions d'utilisation et d'entretien

Pfeiffer Vacuum

Pfeiffer Vacuum Hipace 80 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HISCROLL 6 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HiPace 60 P Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HILOBE 2704 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum OKTA 1000 M Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HICUBE PRO Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum TMH 521 Guide rapide

Pfeiffer Vacuum

Pfeiffer Vacuum TSH 071 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HIPACE 1200 C Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HIPACE 10 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum MVP 020-3 AC Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HILOBE 8104 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HiPace 400 P Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum Compact Turbo TMH 262 N Guide rapide

Pfeiffer Vacuum

Pfeiffer Vacuum SMARTVANE 55 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum OKTA 1000 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum A 124H Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum OKTA 4000 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HILOBE 2704 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HEPTA DRY 100 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum ACP 15 Manuel utilisateur

Manuels Pompe à eau populaires d'autres marques

Neptun

Neptun NPHW 5500 Manuel utilisateur

Sensidyne

Sensidyne Gilian BDX-II Instructions d'installation et d'utilisation

Draper

Draper 47808 Manuel utilisateur

Trolla

Trolla 12820 Manuel utilisateur

Sunfab

Sunfab SVH Series Manuel utilisateur

WilTec

WilTec 50740 Manuel utilisateur

Fieldmann

Fieldmann FVC 5015 EK Manuel utilisateur

Everbilt

Everbilt EFSUB5-122HD Manuel utilisateur

Graco

Graco Husky 3300e Manuel utilisateur

esotec

esotec 101018 Manuel utilisateur

moyno

moyno 2000 CC Manuel utilisateur

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuel utilisateur

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guide de dépannage

DUROMAX

DUROMAX XP WX Series Manuel utilisateur

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuel utilisateur

Franklin Electric

Franklin Electric IPS Manuel utilisateur

Xylem

Xylem e-1532 Series Manuel utilisateur

Milton Roy

Milton Roy PRIMEROYAL Manuel utilisateur
