PEUGEOT RT3 Manuel utilisateur
RT3 GPS
AUDIO/TELEPHONE
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page couvA
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page couvB
SAFETY
WARNING
For safety reasons,
the driver must carry out
operations which require
prolonged attention when
STATIONARY.
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page couvC
03RT3.0041 Version 5.4 Anglais
Automobiles PEUGEOT RCS Paris B 552 144 503 - Produced by iPage - Designed by 4DCONCEPT - Printed in the E.U. 09/03
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page couvD
1
This guide is intended to make operation of the RT3 GPS audio/
telephone easy.
It introduces the basic functions of the telephone, the GPS
navigation-guidance and the spoken commands.
For radio operation, and for more detailed information about all of
the functions offered by your GPS audio/telephone, refer to your
vehicle's handbook.
Simple and quick
to use
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page 1
CONTENTS
Introduction
- The control panel 4-5
- The steering wheel control 6-7
- The main menu and the configuration
CD-ROM 8-9
Telephone
- The main functions 10-11
- Dialling a telephone number using
the numeric keypad 12-13
- Taking or refusing a call 14-15
GPS Navigation-Guidance
- Main functions 16-17
- Entering a new address and
activating guidance 18-21
- Storing a new address 22-23
Spoken commands
- Voice recognition 24
- Recalling a stored radio station 25
- Playing a track on a CD in the changer 25
- Changing the function displayed 25
- Recording a spoken description
in the directory 26-29
- Using a spoken description 30
- Spoken reading of a text message (SMS) 31
Special equipment
- The 807 additional control 32
- The colour screen: map 33-35
- The TMC RDS traffic information 36
32
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page 2
Press = on / off /
switching off of
the audio source
Rotation = volume
adjustment CD eject (audio
or navigation)
Services menu
Press for between
2 and 8 seconds =
SIM card flap
SIM card eject
Pick up
Telephone menu
Alphanumeric
inputting keypad
Cancelling the current
operation
Press for more than 2 seconds =
clearing of the superimposed displays
Press = confirmation of the
function - menu of
the function displayed
Rotation = moving around
the menu or the screen -
adjustment - map zoom
1st press: displaying of
the upper band
2nd press: cutting off of
the brightness
3rd press: return to
the function displayed
Press for more than 5 seconds =
restarting of the system (Reset)
"PEUGEOT assistance"
Changing
the function
displayed
Press for more than 2 seconds =
general information
Main menu
Press for more
than 2 seconds -
Help menu
Press for
between 2 and
8 seconds =
emergency call
54
Hang up
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page 4
Radio: automatic search for a higher frequency
CD / CD changer: selection of the next track -
continuous press until release = fast forward playing
Selection of the next element
Selection of the previous element
Pick up - Hang up - Confirmation of the selection - Change of
sound source
Press for more than 2 seconds = displaying of the Telephone menu
INTRODUCTION
76
HANDY
HINT
Increase volume
Mute
(cutting off of the sound) =
1and 2simultaneously
4
Radio: automatic search for a lower frequency
CD / CD changer: selection of the previous track -
continuous press until release = fast reverse playing
7
6
2
Decrease volume
5
THE STEERING WHEEL CONTROL
1
3
Press
Press
Rotation
Rotation
Press behind
Press behind
Press
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page 6
INTRODUCTION
98
MAIN MENU
Press the "MENU" button to access the main
menu and select one of the following
applications:
Map* Video*
* With the colour screen only.
ConfigurationTelematics
DirectoryTrip
computer
AudioNavigation-
Guidance
Monochrome screen
Colour screen
This CD enables you to change certain parameters (male / female voice,
language).
To do this: "Configuration" menu and select the element to be
changed.
Observe the instructions written on the CD sleeve.
THE CONFIGURATION CD-ROM
HANDY
HINT
For greater ease, use
the steering wheel
control:
To move around the main menu,
use the dial on the right:
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page 8
TELEPHONE
Selection
of an element
on a menu
- When entering the PIN code, you can choose to store it by confirming the
"Store PIN" option.
You will no longer be asked to enter the PIN, if you leave the SIM card in the
holder.
- To copy the SIM card directory to the RT3 directory and vice versa:
- go to the "Directory" menu
- select "Directory files management"
- then "Exchange with the SIM card"
- finally, select the directory file(s) to be exchanged and the direction of the
exchange.
Hang up
- end of call
- refuse an
incoming call
Confirmation
of an element on
a menu
MAIN FUNCTIONS
1110
HINTS AND TIPS
Pick up
- Telephone menu:
dial
directory
list of calls
voice mail
- take an incoming call
RT3_V5-4-ANGLAIS-ed02-03.qxd 8/12/03 11:18 Page 10
