USER MANUAL
US
Corpus/X850
Seat system for electric wheelchair
How to contact Permobil
Head Office of the Permobil group
Permobil Inc. USA
6961 Eastgate Blvd.
Lebanon, TN 37090
USA
Email: [email protected]
Phone: 800-736-0925
Fax: 800-231-3256
Permobil AB
Box 120
861 23 Timrå
Sweden
E-mail: [email protected]
Tel: +46 60 59 59 00
Fax: +46 60 57 52 50
Produced and published by Permobil AB, Sweden
Version no.: 1 - 2009-06
Product code: 205244-US-0
Corpus/X850
Seat system for electric wheelchair
ContentsUser Manual Corpus
Important information about this user manual ............................................6
Technical support ..............................................................................................7
Accessories and spare parts..............................................................................7
Disposal of seat ................................................................................................7
Warranty ............................................................................................................7
Safety instructions......................................................................................8-15
Design and function ........................................................................................16
General ........................................................................................................16
Seat Elevator ................................................................................................18
Seat angle ....................................................................................................18
Electric backrest............................................................................................19
Electric legrest ..............................................................................................19
Seat Control Switchbox ................................................................................20
Manual seat functions - Backrest angle........................................................22
Settings ............................................................................................................23
Armrest..........................................................................................................23
Lumbar Support ............................................................................................24
Lateral Support ............................................................................................25
Headrest........................................................................................................26
Control panel ................................................................................................28
Positioning Belt ................................................................................................29
Transport ..........................................................................................................30
Care and maintenance ....................................................................................32
Accessories......................................................................................................33
Technical specifications....................................................................................34
Important information about the user manual
6
User Manual Corpus
Important Information about this Owner’s Manual
We congratulate you on your choice of a product from Permobil. Our goal is for
you to continue to feel satisfied with your choice of both vendor and product.
Before you begin using your seat and wheelchair, it is important that you read
and understand the content of these operating instructions and in particular the
Safety Instructions.
These operating instructions are primarily intended to acquaint you with the
functions and characteristics of the seat and how you can use them in the best
manner possible. They also contain important safety and maintenance informa-
tion, as well as describing possible problems that can arise during use.
Always keep these operating instructions handy in connection with your wheel-
chair, since the need for important information can arise concerning its use, safe-
ty and maintenance.
It is also possible to obtain information concerning our products from our home
page on the Internet. You can find us at www.permobil.com.
All information, pictures, illustrations and specifications are based upon the
product information that was available at the time that these operating instruc-
tions were printed. Pictures and illustrations that are found in these operating
instructions are representative examples and are not intended to be exact depic-
tions of the various parts of the seat.
We reserve the right to make changes to the product without prior notice.
Ordering of Documentation
If you are in need of another copy of the Owner’s Manual, it can be ordered
from Permobil, ask for item No. 205244-US-0.
Technical support, warranty, etc.
7
User Manual Corpus
A warranty registration card is attached to each new wheelchair. The Permobil
Inc. Product Warranty Information sets forth the conditions of the warranty.
Contact your dealer or Permobil Inc USA for information about the warranty
period for this wheelchair and seat.
Spare parts and accessories must be ordered through your dealer.
In the event of technical problems, you should contact your equipment
provider or Permobil Inc USA at 1-800-736-0925.
Always state the wheelchair chassis serial number when contacting Permobil
to ensure that the correct information is provided.
TECHNICAL SUPPORT
SPARE PART & ACCESSORIES
WARRANTY
Contact Permobil Inc. for information about scrapping agreements.
SCRAPPING THE SEAT
Safety instructions
8
User Manual Corpus
Safety instructions - General
The seat is heavy and contains numerous moving parts and must therefore be
handled with great care. Carefully read through and follow all instructions and
warnings in this manual before using your seat/wheelchair. Incorrect use could
both injure the user and damage the seat.
The user manual contains the following “warning labels” which are intended to
draw attention to situations which could lead to personal injury or damage to the
seat etc.
Take care here.
Take extra care here.
Risk of personal injury or damage to the wheelchair and its surroundings.
CAUTION
Permobil accepts no liability for personal injury or damage to property
which may arise from the failure of the user or other persons to follow the
recommendations, warnings and instructions given in this user manual.
CAUTION
WARNING
Safety instructions
9
User Manual Corpus
Safety instructions - General
This seat may have been adjusted precisely to your needs on delivery, so you
should always ask the advice of the person who ordered the seat on your behalf
before making any changes or adjustments to the seat. Certain adjustments may
impair the seat’s safety/functions or its suitability for your needs.
To minimize incorrect use of your seat, it is also extremely important to take the
necessary time to familiarize yourself with the seat and its accessories, the var-
ious buttons and function or steering controls, and with the various adjustment
options, etc. before starting to use it.
Do not set out alone on your first test ride. Make sure you have assistance close
by if you should need help
.
To ensure that the seat has not been damaged during transport to you, please
check the following before initial use:
• Check that all products ordered are included in the delivery. If you suspect
that something is missing, contact your mobility aids center or Permobil as
soon as possible for further information.
• Check that no transport damage or other damage has occurred to the seat
and its accessories. If you discover any damage or see any other problem,
contact your mobility aids center or Permobil as soon as possible for further
information before you continue the check.
Safety instructions
10
User Manual Corpus
Safety instructions
Risk of pinching
Please note that the seat is heavy and contains many moving parts, which
means there will always be some risk of pinching.
Use the seat’s electric seat functions with the greatest care. Above all: when
you have moved up to or under a table or other fixed or moveable objects,
always make sure there are no items in the immediate vicinity which could
interfere with the seat’s moving parts.
Operation of seat elevator/seat angle/backrest angle
Make sure that there is nothing which could get caught between the chassis
and the seat when the seat elevator/seat angle or backrest angle functions are
being used. Using these functions alters the center of gravity, which always
means an increased risk of tipping. Always drive at low speed and only use
these seat functions on a level surface and not on slopes, ramps, hills or other
gradients.
Center of gravity
Note that the following factors may affect the center of gravity of the
seat/wheelchair and thus the risk of tipping:
• Raising the seat elevator
• Height and angle of seat
• Position or weight distribution of the body
• Driving on sloping surfaces, for example a ramp or hill
• When wearing a backpack or using other accessories, due to the extra
weight.
If your wheelchair starts to move in an unexpected way, immediately let go of
the joystick to stop the wheelchair. Except in an emergency, NEVER use the
on/off key to stop the wheelchair. This could lead to the wheelchair stopping
suddenly and violently, resulting in personal injury.
WARNING
