IOLAN SDG1 LA/LE Hardware Installation Guide
Updated: January 2021
Version: A3-20-01-2021
Document Part#:5500409-10(Rev. E)
www.perle.com
IOLAN SDG1 LA/LE Hardware Installation Guide
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS GUIDE ARE SUBJECT TO CHANGE
WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS GUIDE ARE BELIEVED TO BE
ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE
FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in
accordance with this hardware guide may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own
expense.
Modifications to this product not authorized by Perle could void the FCC approval and negate your authority to operate the product.
Perle reserves the right to make changes without further notice, to any products to improve reliability, function, or design.
Perle, the Perle logo, and IOLAN SDG1 LA/LE are trademarks of Perle Systems Limited.
©2021 Perle Systems Limited.
Table of Contents
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IOLAN SDG1 LA/LE (Top View) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IOLAN SDG1 LA/LE (Side Views) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Ethernet and Serial Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Button/Switch Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ethernet Port Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting the Serial Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Connecting Data Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Resetting the IOLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Resetting the IOLAN to Factory Default Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Configuring the IOLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Appendix A - Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Appendix B - Mechanical Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Appendix C - Sample Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Appendix D - Cabling and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Appendix E - IOLAN Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Contacting Perle Systems Limited . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
2
IOLAN SDG1 LA/LE Hardware Installation Guide
Hardware
Preface
Audience
This guide is for the network or computer technician responsible for installing the Perle
IOLAN SDG1 LA/LE. Familiarity with the concepts and terminology of Ethernet and local
area networks is required.
Purpose
This document describes the hardware and physical characteristics of the Perle IOLAN
SDG1 LA/LE. It covers hardware features as well as installation and basic configuration
and operation of the product. For detail information on configuring the various features
of the IOLAN please see the “IOLAN Secure User’s Guide”.
Document Conventions
This document contains the following conventions:
Most text is presented in the typeface used in this paragraph. Other typefaces are used
to help you identify certain types of information. The other typefaces are:
Note: Means reader take note: notes contain helpful suggestions.
Caution: Means reader be careful. In this situation, you might perform an action that
could result in equipment damage or loss of data.
Warning: IMPORTANT SAFETY INSTRUCTIONS
Means danger. You are in a situation that could cause bodily injury. Before you work on
any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Only qualified personnel should con-
nect power to this unit.
IOLAN SDG1 LA/LE Hardware Installation Guide
Overview
This guide provides information on installing and doing the initial configuration on the
IOLAN SDG1 LA/LE unit.
The IOLAN SDG1 LA/LE has one RJ-45 serial port.
IOLAN SDG1 LA/LE (Top View)
IOLAN SDG1 LA/LE Hardware Installation Guide
IOLAN SDG1 LA/LE (Side Views)
Ethernet and Serial Ports
10/100/1000Base-T Port
The Ethernet port provides the standard Gigabit Ethernet interface speeds of 10/100/
1000 Mbps through twisted pair (UTP) cables of up to 100 meters (328ft) in length.
Serial / Console Port
The unit has one RJ-45 port. The port can be used to connect a serial device. When used
to connect a serial device, the port can operate in EIA-232, EIA-422 or EIA-485 mode.
When port 1 is used to connect a console, the port can be used to fully configure and
manage the IOLAN. For details on how to connect to the serial ports see Connecting the
Serial Port .
For details on the serial port pin-out see Appendix D - Cabling and Connectors .
Button/Switch Functions
Reset Button
The inset “Reset” button will reboot the IOLAN if pushed in and released quickly. It will
reset the IOLAN to factory defaults if pushed in and held for more than three seconds.
For more details on the operation of the Reset button see “Resetting the IOLAN ”
Console / Serial DIP Switch
Serial port 1 can act as a console port or a serial port. The mode of operation is deter-
mined by the position of the “console/serial port” DIP switch. The DIP is set in the fac-
tory to serial (up position). Unless you plan to attach a console to the IOLAN, leave the
DIP switch in the serial position. In console mode, this port can be used to provide access
to the IOLAN management function using the industry standard CLI command set (see
Console Port Mode ).
See the IOLAN Command Line Interface Reference Guide for a complete set of the com-
mands available via the console.
IOLAN SDG1 LA/LE Hardware Installation Guide
WPS Button
Insert a paper clip into the inset hole labeled as “WPS” and gently press inwards. Pressing
this button for less than 3 seconds will put the IOLAN SDG1 LA/LE in WPS mode, greater
than 4 seconds will put the unit in Soft-AP mode.
IOLAN SDG1 LA/LE Hardware Installation Guide
LED Indicators
Power/Ready
Link 10/100/1000
WWAN
Signal strength
Ethernet Port Status Indicators
State Description
Green - solid System Ready
Green - flashing System is booting or dip switch is
in console mode
Amber - flashing System is booting
Red Error condition
State Description
Green 1000 Mbps (flashes with activity)
Green/Amber 100 Mbps (flashes with activity)
Amber 10 Mbps (flashes with activity)
Off No LAN connection
State Description
Green - solid A cellular connection has been
established
Green - flashing Data is being transmitted over the
cellular network
Off no cellular connection established
State Description
Amber/ Green Wireless signal strength from
amber LEDS to green LEDS with
green being the strongest signal
strength
IOLAN SDG1 LA/LE Hardware Installation Guide
Port Link / Speed
State Description
Green 1000 Mbps (flashes with activity)
Green/Amber 100 Mbps (flashes with activity)
Amber 10 Mbps (flashes with activity)
Off No LAN connection
IOLAN SDG1 LA/LE Hardware Installation Guide
Installation
General Cautions and Warnings
Warning: Power sources must be off prior to beginning the power connection steps.
Read the installation instructions before you connect the unit to its power source.
Warning: Ensure that the voltage and current ratings of the intended power source are
appropriate for the IOLAN as indicated on the product label.
Warning: Ensure that the installation and electrical wiring of the equipment is performed
by trained and qualified personnel and that the installation complies with all local and
national electrical codes.
Warning: The working voltage inputs are designed for operation with Safety extra low
Voltage (SELV). Connect only to SELV circuits with voltage restrictions in line with IEC
62368-1:2018
Warning: If this equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
Warning: Transient protection shall be provided that is set at a level not exceeding 140%
of the peak rated voltage value at the supply terminals to the equipment.
Warning: In case of malfunction or damage, no attempts at repair should be made. Do
not dismantle the product. All repairs need to be made by a qualified Perle
representative.
Warning: This unit should be installed in a restricted access location where access can
only be gained by service personnel or users who have been instructed about the reasons
for the restrictions applied to the location and about any precautions that shall be taken;
and access is through the use of a tool or lock and key, or any means of security, and is
controlled by the authority responsible for the location.
