PerkinElmer Lambda 365 Peltier Temp Ctrl Unit Multi Manuel utilisateur
09931463A
PerkinElmer, 710
Bridgeport Avenue,
Shelton, CT 06484-
4794, U.S.A
Produced in the USA.
Lambda 365 Peltier Temp Ctrl Unit Multi
Installation Instructions
This instruction sheet describes the installation of this accessory which is used with the Lambda 365
Spectrophotometer.
NOTE:
Read these instructions before you install this accessory.
Contacting PerkinElmer
Supplies, replacement parts, and accessories can be ordered directly from PerkinElmer, using the part
numbers.
See our website:
http://perkinelmer.com
PerkinElmer's catalog service offers a full selection of high-quality supplies.
To place an order for supplies and many replacement parts, request a free catalog, or ask for
information:
If you are located within the U.S., call toll free 1-800-762-4000, 8 a.m. to 8 p.m. EST. Your order will be
shipped promptly, usually within 24 hours.
If you are located outside of the U.S., call your local PerkinElmer sales or service office.
Features
•Full software control
•Liquid cooling system
•N2gas purging available
Figure 1 Peltier Temp Ctrl Unit Multi w/Ref Heat [P/N: N4101062] or Peltier Temp
Ctrl Unit Multi no Ref Heat [P/N: N4101063]
09931463A
2
Dimensions and Specifications
Peltier Temperature Controller 201
Physical Characteristic Specification
Power 100-240 VAC, 50/60 Hz, 380W
Temperature Range -5 to 100°C (Maximum Internal Temperature)
Maximum Ambient Operating Temperature 40°C
Dimensions 295 (W) x 416 (D) x 283 (H) mm
(11.6 (W) x 16.4 (D) x 11.1 (H) in)
Weight 16.0 kg (35.2 lb)
Coolant Volume 1 L
Coolant Available 1.5 bar
N2Gas Available 1 bar
Liquid Cooling System
Magnetic Stirrer Control Available
6-Position Peltier Controlled Cell Changer (with and without heated reference)
Physical Characteristic Specification
The number of Sample Cells 6
The number of Reference Cell 1 (with or without heated reference)
Dimensions 134.5 (W) x 384 (D) x 142.5 (H) mm
(5.3 (W) x 15.1 (D) x 5.6 (H) in)
Weight With heated reference: 3.4 Kg (7.5 lb)
Without heated reference: 3.0 Kg (6.6lb)
Temperature Accuracy ±0.1°C
Temperature Precision <0.1°C
Temperature Stability <0.1°C
Ramping Time (from 0 to 100°C) 5 minutes
09931463A
3
Safety Warnings
WARNING
AVERTISSEMENT
When this label is attached to an instrument it means refer to the
manual.
Lorsque cette étiquette est attachée à un instrument, il est
nécessaire de voir le manuel.
WARNING
AVERTISSEMENT
There is risk of receiving a fatal electric shock if the fuses are
replaced with the power cord connected.
Il y a un risque d’électrocution si les fusibles sont remplacés tandis
que le cordon d'alimentation est encore branché.
See the following figure for the location of warning labels on the back of the instrument:
Warning
FUSE
Avertissement
FUSE
Warnin
g
To prevent electrical shock,
do not open cover.
Refer all servicing to qualified
personnel.
Avertissement
Afin d’éviter tout risque
d’électrocution ne pas enlever ce
couvercle.
Faire appel au service Après-Vente.
Warning
For continued protection against electrical
shock, replace with same type and ratings of
fuse.
Avertissement
Pour assurer la protection contre le risque de
choc électrique, remplacez le fusible
seulement avec le même type et la même
valeur nominale.
09931463A
4
Configuration of Peltier Temp. Ctrl Unit Multi
6-Position Peltier Controlled Cell Changer (with heated reference or without heated reference)
Peltier Temperature Controller 201
Power Cord, 3 each
Interface Cable (USB), 1 each
Spare Fuse (AC 250V T5AL), 2 each
Temperature Probe, 1 each
Magnetic Stirrer, 6 each
Coolant Hose, 1 each
Coolant, 2 each
Waste Basket for Coolant, 1 each
Waste Hose for Coolant, 1 each
Hose for Coolant circulation, 1 each
Phillips round h d screw with washer, 2 each
Macro Cell with PTFE Stopper, 2 each
NOTE:
Peltier Temp Ctrl Unit Multil includes two (2) macro cells in the standard configuration. Additionally
required macro cells for the 6-Position Peltier Controlled Cell Changer must be purchased separately.
Description
6-Position Peltier Controlled Cell Changer (with heated reference or without
heated reference)
Figure 2-1 Lambda 365 6-Position Peltier Controlled Cell Changer (with heated
reference)
09931463A
5
Figure 2-2 Lambda 365 6-Position Peltier Controlled Cell Changer (without heated
reference)
a. Interface connector between 6-Position Peltier Controlled Cell Changerand Peltier
Temperature Controller 201
b. N2Gas fitting
c. Coolant Inlet/Outlet Quick Coupler
d. Interface slot for Temperature Probe
e. Cell Lifting knob for sample cells
f. Cell Lifting knob for reference cell
g. Phillips round headscrew with washer
Used to fix a cell holder, a base plate or a front plate for the Lambda 365.
Spare screws (2each) are enveloped with the accessory.
Figure 3 Phillips round headscrew with washer (M4 *12L)
h. Macro Cell with PTFE stopper
Figure 4 Macro Cell with PTFE stopper
i. Temperature Probe
Figure 5 Temperature probe
09931463A
6
Peltier Temperature Controller 201
Front View of Peltier Temperature Controller 201
Figure 6 Front view
a. Flow Gauge: Indicator of the flow rate of N2 gas
b. Coolant Inlet
c. LED Indicators: Display the status of the operation of Coolant Circulation, Fan, Pump, etc.
(If there is any problem in the components, Red LED will flash with beep alarm.).
d. Display pad: Display temperature of sample and reference block.
e. Stirrer ON/OFF button: It is used for controlling of the stirring.
f. AC Power: Main power ON/OFF
Switch symbol
IEC 60417-5268 (2002-10) In position of a bi-stable push control
IEC 60417-5269 (2002-10) Out position of a bi-stable push control
09931463A
7
Rear View of Peltier Temperature Controller 201
Figure 7 Rear view
a. Air Vent Manual button: It is used to identify the cause of alarm that sounds when the
trouble occurs with Peltier. The cause of the alarm is as follows;
i. When the air occur in the coolant hose.
ii. When the liquid coolant does not flow.
iii. Lack of liquid coolant
NOTE:
Air Vent Manual button is recommended to be manipulated by service engineer.
b. Buzzer: It makes an alarm sound. If there is any problem before the measurement or the
malfunction occurs during the operation, Buzzer beeps.
c. USB port
d. Fuse: AC socket + Fuse Holder
e. Interface: Interface cable is connected with the 6-Position Peltier Controlled Cell Changer
f. Quick Coupler of Coolant lnlet/Outlet
g. Quick Coupler of Coolant Drain
h. N2Gas Inlet/Outlet ports
NOTE:
N
2
gas is not always required [Tube for N
2
gas is not supplied with the accessory].
09931463A
8
How to Fill or Drain the coolant
How to Fill the coolant
NOTE:
When the Peltier Temp Ctrl Unit Sgl is installed for the first time, the enclosed Coolant should be filled as
the following procedures.
1. Prepare the Peltier Temperature Controller 201 in a location that is compatible with the required
environmental conditions for the operation.
2. Connect the hose for coolant circulation to the Peltier Temperature Controller 201.
Figure 8 Connect the hose for coolant circulation
3. Connect the power cord to the Peltier Temperature Controller 201.
Figure 9 Connect the power cord
4. Remove the Phillips screws (4 each) on the Air Vent Manual cover using Phillips screwdriver.
Figure 10 Removing Phillips screws
09931463A
9
5. Push the Air Vent Manual Button on.
Figure 11 Push the button
6. Turn on the AC power switch of the Peltier Temperature Controller 201.
Figure 12 Turn on the AC power switch
7. Check if the LEDs of LOW LEVEL and FLOW SENSOR are lit on.
Figure 13 LEDs of LOW LEVEL and FLOW SENSOR
09931463A
10
8. Open the lid of the coolant inlet on top of the Peltier Temperature Controller 201 and fill up the
liquid coolant using the funnel.
Figure 14 Lid of coolant inlet
9. Keep the amount of liquid coolant to level where the indicator is located between the ‘L’ (low)
and ‘H’ (high) mark in the scale on the left side of the Peltier Temperature Controller 201.
Figure 15 Coolant level
CAUTION
ATTENTION
Liquid coolant should be used as refrigerant. Do not use any water (tab
water, DI, etc.). If water is used as refrigerant, the PeltierTemperature
Controller 201’s components might be corroded and its performance may
be deteriorated.
Use any kind of liquid coolant of normal grade that is available. (e.g. liquid
coolant including Distilled Water 70 wt%, Propylene Glycol 27 wt%,
Additives 3 wt%).
Le liquide de refroidissement doit être utilisé comme réfrigérant. N'utilisez
jamais d'eau (eau du robinet, eau déminéralisée, etc.) L'eau risque en
effet de corroder les composants du contrôleur Peltier et de réduire les
performances de ce dernier.
Utilisez un liquide de refroidissement du commerce de qualité normale (par
exemple, un liquide de refroidissement à base d'eau distillée à 70 % M/V,
de propylène glycol à 27 % M/V et d'additifs à 3 % M/V).
