PERFECTPRO Fatbox Manuel utilisateur

FIN

Operating instruction

Gebruiksaanwijzing

Bedienungsanleitung

Bruksanvisning

käyttöohjeet

instruksjon

Mode d’emploi

instruktioner

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7.Do not block any ventilation openings. Install in accordance with

the instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves or other apparatus ( including amplifiers )

that produce heat.

9. Do not defect the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with one

wider than the other. A grounding type plug has two blades and

a third grounding prong. The wide blade or the third prong are

provided for your safety. If the provided plug does not fit into

your outlet, consult an electrician for replacement of the obsolete

outlet – USA version only.

10. Protect the power cord from being walked on or pinched

particularly at plug, convenience receptacles, and the point

where they exit from the apparatus.

11. Only use attachments/accessories specified by

the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified

by the manufacturer, or sold with the apparatus. When a cart

is used, use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused

for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way,

such as power-supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate

normally, or has been dropped.

15. To reduce the risk of fire or electric shock, Do not expose this

appliance to Rain or Moisture.

16. The Shock Hazard Marking and AssociatedGraphical Symbol

is provided on the bottom panel of unit.

17.Apparatus shall not be exposed to dripping or splashing and no

objects filled with liquids, shall be placed on the apparatus.

18. For outdoors use, to avoid electric shock, use battery only

during a raining day or the weather is wet.

Controls

Power On/Off

Charge LEDS

Stereo/Mono switch

EQ ( Equalizer )

Loudness On/Off

Volume Control

LCD display

Tuning Control/Time Set

Band Selection

Preset Stations

Aux In 1 socket

Aux In 2 socket/MP3 player compartment

Back up battery compartment

Main battery compartment

Alkaline/NiMH/NiCad Rechargeable battery switch

10-14V DC In socket

Power cord

FM rubber antenna

LCD Display

Band Indicator and AM/PM

Battery power

EQ indicator

Loudness On

Stereo

Memory preset

Time and Frequency

Power the radio

A. Battery operation

1. Installing the batteries, first turn battery cover fixtures

anti-clockwise to loosen and pull down the battery cover.

Note:

Before you insert the batteries, if you use non-rechargeable

batteries, make sure the NiMH/NiCad /Alkaline switch which located

inside the battery compartment is switched toAlkaline position.

If you use rechargeable batteries, make sure to switch

NiMH/NiCad/Alkaline switch toNiMH/NiCad position.

2. Insert 8 xD size ( UM-1 ) battery into the compartment.

Ensure the battery is inserted in accordance with the

diagram shown.

3. Insert x 2AA size ( UM-3 ) battery into the back up

battery compartment.

Note:

The back up battery is for time and memory station back up during

power failure. It is suggested to replace the back up battery every

six months to avoid battery leakage.

Run time of the radio on batteries varies strongly depending on

the quality and capacity (mAh) of the batteries, temperature,

volume level etc.

4. Close the battery cover and fasten the fixture by turning

clockwise.

If the radio is not to be used for any extended period of time, it is

recommended that the batteries are removed from the radio.

Reduced power, distortion and a “ stuttering sound “ or low battery

sign is flashing on the display are all signs that the batteries

need replacing or recharging ( see below Charging the batteries ).

B. AC operation

Before plug the AC power cord into the AC socket, be sure the

voltage is correct. If you have batteries in the radio and connect the

AC power cord into the AC socket, the batteries will automatically

be disconnected.

Charging the batteries

Reduced power, distortion and a “ stuttering sound “ or low battery

sign “ “ is flashing on the display are all the signs that the

batteries need to be recharged if you use rechargeable batteries to

power the radio.

Note:

The batteries can be charged only when the radio is off.

Connect theAC power cord into the AC socket to charge

the batteries. Be sure the battery type switch is set toNiNH/NiCad

Rechargeable position.

Battery charging function of this radio only applies to the 8 D-size

( UM-1 ) batteries and not to the AA-size ( UM-3 ) back-up

batteries.

When the batteries are being charged, the red Charge LEDAand

B will be on. LEDAand B will turn into green when the batteries of

charge group A or B are fully charged. Charge until both LEDAand

B are green.

Charging time can take up to approx. 10 hours depending on

capacity of the rechargeable batteries.

Charge new batteries fully the first time before first use.

This can take longer depending on the capacity of the

rechargeable batteries.

Do not use a mix of old and new rechargeable batteries.

Do not use a mix of full and empty rechargeable batteries.

Do not use batteries that have a different mAh capacity.

Do not use damaged or leaking batteries.

Charge the batteries in car

The batteries can also be charged in the radio using a 12V car

( cigarette lighter ) adaptor, voltage range 10V-14V, maximum

current of 2.5 A, DC dimension 2.0 mm inner diameter with positive

pole and 6.3mm outer diameter with negative pole. To charge,

connect the adaptor to the car ( cigarette lighter ) socket andDC IN

socket located on the back of the radio.

Setting the clock

The clock can be set either when the radio is on or off.

Press in the Tuning Control/Time set knob until display Hour digit

flashes. Rotate Tuning Control/Time set knob to select required

hour time then press the Tuning control knob again to confirm hour

set. The minute digit will flash, rotate Tuning Control/Time set knob

to select required minute time then press the Tuning control knob

again to confirm minute set.Display will show clock time when time

set is completed.

Radio Operation

1. Press the Power button to turn on the radio.

2. Select the required waveband by pressing the Band button.

3. Stand up the FM rubber antenna properly to get best reception.

For AM ( MW ) band, rotate the radio to get best signal.

4. Rotate the Tuning Control knob will change the frequency in the

following increments.

FM: 50 or 100 kHz

AM ( MW ): 9 or 10 kHz

5. Select required EQ and stereo/mono mode.

6. Rotate the volume control to get required sound level.

7. To turn off the radio, press the Power button.

Display will show OFF.

Memory preset stations

There are 6 memory presets for each waveband. Storing stations

in preset memories, follow below steps.

1. Press the Power button to turn on the radio.

2. Tune to required station pressing Band button and rotate

Tuning Control.

3. Press and hold down the required preset until the display M

stop flashing. The preset number will appear in the display

together with M and the station will be stored under chosen

preset button.

4. Repeat this procedure for the remaining presets.

5. Stations stored in preset memories can be over written by

following above procedures.
