Perfect Aire PA50 Manuel utilisateur

CONTENTS

SAFETY PRECAUTIONS

Warning .................................................................................................................................2

Caution ..................................................................................................................................2

Electrical information .............................................................................................................3

OPERATIING THE UNIT

When using the unit ..............................................................................................................6

Removing the collected water ...............................................................................................7

CARE AND MAINTENANCE

Care and cleaning the dehumidifier ......................................................................................8

TROUBLESHOOTING TIPS

Troubleshooting tips .............................................................................................................9

CONTROL PADS ON THE DEHUMIDIFIER

Control pads...........................................................................................................................4

Other features.........................................................................................................................4

IDENTIFICATION OF PARTS

Identification of parts ............................................................................................................5

Positioning the unit ...............................................................................................................6

To prevent injury to the user or other people and property damage, the following instructions must be

followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The

seriousness is classified by the following indications.

This symbol indicates the possibility of death or serious injury.

Meanings of symbols used in this manual are as shown below.

WARNING

Always do this.

Never do this.

CAUTION

This symbol indicates the possibility of injury or damage to property.

Do not exceed the rating

of the power outlet or

connection device.

Do not modify power cord

length or share the outlet

with other appliances

Disconnect the power if

strange sounds, smell, or

smoke comes from it.

Otherwise, it may cause electric

shock or fire due to heat

generation.

excess

It may cause electric shock or

fire due to heat generation.

It may cause fire and electric

shock.

It may cause electric shock or fire

due to heat generation.

It may cause electric shock.

It may cause failure of machine

or electric shock.

It contains contaminants and

could make you sick.

It may cause electric shock or fire.

Plastic parts may melt and cause

a fire.

It may cause electrical shock or

injury.

It may cause electric shock.

It may cause an explosion or fire.

Do not operate or stop the

unit by switching on or off

the power.

Do not insert or pull out

plug with wet hands.

You should never try to take

apart or repair the unit by

yourself.

Do not drink or use the

water drained from air

conditioner.

Do not damage or use an

unspecified power cord.

Do not place the unit near

a heat source.

Before cleaning, turn off

the power and unplug the

unit.

Do not open the unit

during operation.

Do not use the machine near

flammable gas or combustibles, such

as gasoline, benzene, thinner, etc.

WARNING

SAFETY PRECAUTIONS

CAUTION

When using in closets or

other small spaces, be

sure to keep doors open.

Lack of ventilation can cause

overheating and fire.

Do not put in places where

water may splash onto the

unit.

Water may enter the unit and

degrade the insulation. It may

cause an electric shock or fire.

Place the unit on a

level, sturdy section of

the floor.

If the unit falls over, it may

cause water to spill and

damage belongings, or

cause electrical shock or

fire.

Do not cover the intake or

exhaust openings with

cloths or towels.

A lack of air flow can lead

to overheating and fire.

Do not clean unit when

power is on as it may cause

fire and electric shock, it may

cause an injury.

When the unit is to be

cleaned, switch off, and turn

off the circuit breaker.

Do not use in areas

where chemicals are

handled.

This will cause the unit

deterioration due to

chemicals and solvents

dissolved in the air.

Care should be taken when

using the unit in a room with

the following persons:

Infants, children, elderly people,

and people not senstive to

humidity.

You may be injured if you

fall or if the unit falls over.

Water may spill inside the

unit, causing insulation

failure and electrical

shock or fire.

It may cause failure of

appliance or accident.

There is danger of fire or

electric shock.

Do not place heavy object on the

power cord and take care so that

the cord is not compressed.

Operation without filters

may cause failure.

Always insert the filters

securely. Clean filter

once every two weeks.

CAUTION

Do not climb up on

or sit on the unit.

If water enters the unit, turn

the unit off and disconnect the

power , contact a qualified

service technician.

Do not place flower

vases or other water

container on top of

the unit.

The manufactures nameplate is located on the rear panel of

the unit and contains electrical and other technical data

specific to this unit.

Be sure the air conditioner is properly grounded. To minimize

shock and fire hazards, proper grounding is important. The

power cord is equipped with a three-prong grounding plug

for protection against shock hazards.

Your air conditioner must be used in a properly grounded wall

receptacle. If the wall receptacle you intend to use is not

adequately grounded or protected by a time delay fuse or

circuit breaker, have a qualified electrician install the proper

receptacle.

Ensure the receptacle is accessible after the unit installation.

However, if it is necessary to use an extension cord, use

an approved air conditioner extension cord only (available

at most local hardware stores).

To avoid the possibility of personal injury, always disconnect

the power supply to the unit, before installing and/or servicing.

Do not use extension cords or an adapter plugs with this

unit.

Electrical Information

Do not, under any

circumstances, cut,

remove, or bypass

the grounding prong.

This unit is grounded through the

power cord plug when plugged

into a matching wall outlet.

SAFETY PRECAUTIONS

CONTROL PADS ON THE DEHUMIDIFIER

Power on

indicator light

Continuous

operation on

indicator light

Bucket full

indicator light

High fan

indicator

light

Normal fan

indicator light

Control pads

POWER Pad

Press to turn the dehumidifier on and off.

Continue Pad

Select for the dehumidifier to operate

continuously for maximum dehumidification

until the bucket is full. The Humdity set

control pads cannot be used when

Continuous operation is on.

Humidity Set Control Pads

The humidity level can be set within a

range of 35%RH(Relative Humidity) to

80%RH(Relative Humidity) in 5%

increments.

For drier air, press the pad and set

to a lower percent value(%).

For damper air, press the pad and

set a higher percent value(%).

Fan speed Pads

Control the fan speed. Press to select either High or Normal

fan speed. Set the fan control to High for maximum moisture

removal. When the humidity has been reduced and quiet

operation is preferred, set the fan control to Normal.

Display

Shows the set % humidity level while setting, then shows

the actual(+5% accuracy) room % humidity level.

Error Codes:

E1- Humidity sensor error--Unplug the unit and plug it back

in. If error repeats, call for service.

E2- Temperature sensor error-- Unplug the unit and plug it

back in. If error repeats, call for service.

P1- Unit is defrosting-- Allow the unit time to automatically

defrost. The error will clear after the unit self defrosts.

P2- Bucket is full-- Empty the bucket and replace in

the right position.

Other features

Bucket Full Light

Glows when the bucket is ready to be

emptied, or when the bucket is removed

or not replaced in the proper position.

Auto Shut Off

The water level control switch shuts off the

dehumidifier when the bucket is full, or when

the bucket is removed or not replaced in the

proper position. When the setting humidity

is reached, the unit will be shut off automatically.

When frost builds up on the evaporator coils, the

compressor will cycle off and the fan will continue to

run until the frost disappears.

Power Outage

In the case of a power outage or interruption, the unit will

automatically re-start, in the settings last used, after the

power is restored.

Auto Defrost

Power

Continuous

Full

Humidity%

Turbo

Normal

Fig.1

IDENTIFICATION OF PARTS

Power Cord

Air Outlet grille

Drain hose outlet

(see Fig.8)

Air filter

Power Plug

Power cord hook or Band

(depending on models)

(Used only when storing

the unit.)

Front

Rear

Control panel

Air intake

grille

Water bucket

Water level

window

Handel Air outlet

grille

Caster

Identification of parts

Air outlet

grille

Control panel

Air intake

grille

Water bucket

Water level

window

Handel

NOTE: All the pictures in the manual are for explanation purposes only. The actual shape

of the unit you purchased may be slightly different, but the operations and functions

are the same.

Fig.2

Fig.3

OPERATING THE UNIT

When using the unit

When first using the dehumidifier, operate the unit continuously 24 hours.

This unit is designed to operate with a working environment between 5 C and 35 C.

If the unit has been switched off and needs to be switched on again quickly, allow approximately

three minutes for the correct operation to resume.

Do not connect the dehumidifier to a multiple socket outlet, which is also being used for other electrical appliances.

Select a suitable location, making sure you have easy access to an electrical outlet.

Plug the unit into a 115V~ 60Hz electrical socket-outlet with earth connection.

Make sure the Water bucket is correctly fitted otherwise the unit will not operate properly.

Casters(At four points on the bottom of unit)

Casters can only move laterally.

Do not force casters to move over carpet,

nor move the unit with water in the bucket.

(The unit may tip over and spill water.)

A dehumidifier operating in a basement will have little or no effect in drying an adjacent enclosed

storage area, such as a closet, unless there is adequate circulation of air in and out of the area.

Air outlet grille

Air intake

grille

20cm or more

20cm or more 20cm or more

20cm or more

40cm or

Positioning the unit

Do not use outdoors.

This dehumidifer is intended ofr indoor residential

applications only. This dehumidifier should not be used

for commercial or industrial applications.

Place the dehumidifier on a smooth, level floor strong

enough to support the unit with a full bucket of water.

Allow at least 20cm of air space on all sides of the unit

for good air circulation.

Place the unit in an area where the temperature will not

falll delow 5 C(41 F). The coils can become covered with

frost at temperatures below 5 C(41 F), which may reduce

performance.

Place the unit away from the clothes dryer, heater or radiator.

Use the unit to prevent moisture damage anywhere books

or valuables are stored.

Use the dehumidifier in a basement to help prevent

moisture damage.

The dehumidifier must be operated in an enclosed

area to be most effective.

Close all doors, windows and other outside openings

to the room.

Fig.4

OPERATING THE UNIT

Removing the collected water 1. Pull out the bucket a little.

2. Hold both sides of the bucket

with even strength, and pull it

out from the unit.

3. Pour the water out.

There are two ways to remove collected water.

1. Use the bucket

When the bucket is full, the unit will automatically stop

running, and the Full indicator light will flash.

Slowly pull out the bucket. Grip the left and right handles

securely, and carefully pull out straight so water does

not spill. Do not put the tank on the floor because the

bottom of the bucket is uneven. Otherwise the bucket

will fall and cause the water to spill.

Throw away the water and replace the bucket. The

bucket must be in place and securely seated for the

dehumidifier to operate.

The machine will re-start when the bucket is restored

in its correct position.

NOTES:

When you remove the bucket, do not touch any parts

inside of the unit. Doing so may damage the product.

Be sure to push the bucket gently all the way into the

unit. Banging the bucket against anything or failing to

push it in securely may cause the unit not to operate.

NOTE: When the continuous drain feature is not being

used, remove the drain hose from the connector and

attach the back drain hole with the rubber plug shown

in Fig.1.

Remove the water bucket from the front of the unit, you will

find a section of hose located above the bucket.

Remove the rubber plug from the back of the unit and store

it in a safe location(see Fig.8).

Insert the water hose through the hole in the back of the unit

and securely press it onto the connector on the front of the

unit(see Fig.9). Then lead the water hose to the floor drain or

a suitable drainage facility.

Replace the bucket in the unit. The bucket must be in place and

securely seated.

2. Continuous draining

Water can be automatically emptied into a floor

drain by attaching the unit with a water hose

(not included).

Remove the

rubber plug

Push the hose

into the drain

hole

Fig.5

Fig.6

Fig.7

Fig.8

Connector

Fig.9

Drain hose

3. Clean the air filter

The air filter behind the front grille should be

checked and cleaned at least every 30 days

or more often if necessary.

Grip the tab on the filter and pull it out as shown

in Fig.A.

Clean the filter with warm, soapy water. Rinse and

let the filter dry before replacing it. Do not clean the

filter in a dishwasher.

Insert the air filter into the unit from the side and push

it in. See Fig.C

DO NOT operate the dehumidifier without a filter

because dirt and lint will clog it and reduce

performance.

NOTE: DO NOT RINSE OR PUT THE FILTER

IN AN AUTOMATIC DISHWASHER.

To remove:

To attach:

CAUTION:

Fig. A

Fig. B

Fig. C

After turning off the unit, wait one day before

emptying the tank.

Clean the main unit, bucket and air filter.

Twist the excess cord onto the power cord hook.

Cover the unit with a plastic bag.

Store the unit upright in a dry, well-ventilated place.

4. When not using the unit for long time periods

CARE AND MAINTENANCE

Care and cleaning of the dehumidifier

Turn the dehumidifier off and remove the plug

from the wall outlet before cleaning.

1. Clean the Grille and Case

Use water and a mild detergent. Do not use bleach

or abrasives.

Do not splash water directly onto the main unit. Doing

so may cause an electrical shock, cause the insulation

to deteriorate, or cause the unit to rust.

The air intake and outlet grilles get soiled easily, so use

a vacuum attachment or brush to clean.

2. Clean the bucket

Every few weeks, clean the bucket to prevent growth of mold,

mildew and bacteria. Partially fill the bucket with clean water

and add a little mild detergent. Swish it around in the bucket,

empty and rinse.

Do not use a dishwasher to clean the bucket.

After clean, the bucket must be in place and securely

seated for the dehumidifier to operate.

NOTE:

Thinner

Household

Drain

Cleaner

Hook

Power cord

TROUBLESHOOTING TIPS

Before calling for service, review the chart below first yourself.

Problem What to check

Unit does not start

Make sure the dehumidifier s plug is pushed completely into the

outlet.

Check the house fuse/circuit breaker box.

Dehumidifier has reached its preset level or bucket is full.

Tank is not in the proper position.

Dehumidifier does not

dry the air as it should

Did not allow enough time to remove the moisture.

Make sure there are no curtains, blinds or furniture blocking the

front or back of the dehumidifier.

The humidity control may not be set low enough.

Check that all doors, windows and other openings are securely

closed.

Room temperature is too low, below 5 C(41 F).

There is a kerosene heater or something giving off water vapor

in the room.

The unit makes a loud

noise when operating

The air filter is clogged.

The unit is tilted instead of upright as it should be.

The floor surface is not level.

Frost appears on the

coils

This is normal. The dehumidifier has Auto defrost feature.

Water on floor Hose to connector or hose connection may be loose.

Intend to use the bucket to collect water, but the back

drain plug is removed.

E1, E2, P1 or P2 appear

in the display

These are error codes. See the

section.

CONTROL PADS ON THE

DEHUMIDIFIER

Table des matières

Autres manuels Perfect Aire Déshumidificateur

Perfect Aire

Perfect Aire 1PAD8 Manuel utilisateur

Perfect Aire

Perfect Aire 3PMP50 Manuel utilisateur

Perfect Aire

Perfect Aire 4PAD30 Manuel utilisateur

Perfect Aire

Perfect Aire 3PMP50 Manuel utilisateur

Perfect Aire

Perfect Aire ProAire PROCD150 Manuel utilisateur

Perfect Aire

Perfect Aire Damp2Dry 2PACD200 Manuel utilisateur

Perfect Aire

Perfect Aire 1PED30 Manuel utilisateur

Perfect Aire

Perfect Aire 1PDP60 Manuel de réparation

Perfect Aire

Perfect Aire Damp2Dry 2PACD200 Manuel utilisateur

Perfect Aire

Perfect Aire 3PAD95 Manuel utilisateur

Perfect Aire

Perfect Aire 1PFD22 Manuel utilisateur

Perfect Aire

Perfect Aire PAD30 Manuel utilisateur

Perfect Aire

Perfect Aire 3PFD22 Manuel utilisateur

Perfect Aire

Perfect Aire PROAIRE PROCD200 Manuel utilisateur

Perfect Aire

Perfect Aire Damp2Dry 1PACD250 Manuel utilisateur

Perfect Aire

Perfect Aire Damp2Dry 1PACD150 Manuel utilisateur

Perfect Aire

Perfect Aire PMP50 Manuel utilisateur

Perfect Aire

Perfect Aire 3PAD30 Manuel utilisateur

Perfect Aire

Perfect Aire 1PDQW45 Manuel utilisateur

Perfect Aire

Perfect Aire PADP50 Manuel utilisateur

Perfect Aire

Perfect Aire 2PFD22 Manuel utilisateur

Perfect Aire

Perfect Aire 3PAD11 Manuel utilisateur

Manuels Déshumidificateur populaires d'autres marques

Daitsu

Daitsu CD031IU-DFA Manuel utilisateur

Fehom

Fehom PDGT701BE Manuel utilisateur

Hitachi

Hitachi RD-190GX Manuel utilisateur

Westpoint

Westpoint MDF1-30AE Manuel utilisateur

SOLIS

SOLIS easy dry compact Manuel utilisateur

ENVIROBOSS

ENVIROBOSS EB240 Manuel utilisateur

Sinclair

Sinclair R-9112 Manuel utilisateur

Kenmore

Kenmore 580.54701 Manuel utilisateur

Demargo

Demargo DM828NF Manuel utilisateur

Altrad Lescha

Altrad Lescha LDH 600 Manuel utilisateur

BOMANN

BOMANN LE 1150 CB Manuel utilisateur

SPT

SPT SD-46 Manuel utilisateur

REMKO

REMKO SLN 40 Manuel utilisateur

Haier

Haier HD458 Manuel utilisateur

Logik

Logik L20DHW12 Manuel utilisateur

Frigidaire

Frigidaire FDR30S1 - 30 Pint Capacity Dehumidifier Guide de démarrage rapide

Blitz

Blitz HHD Series Manuel utilisateur

Prem-I-Air

Prem-I-Air PD14DEN Manuel utilisateur
