Pepwave AP One AC mini Manuel utilisateur

Pepwave AP One Series:

AP One Enterprise / AP One AC mini / AP One In-Wall / AP One 300M / AP One Flex 300M

Pepwave AP Pro Series:

AP Pro / AP Pro 300M / AP Pro Duo

May 2023

Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of

their respective owners.

Table of Contents

1 Introduction and Scope 4

2 Product Features and Benefits 5

3 Package Contents 6

3.1 AP One Enterprise 6

3.2 AP One AC mini 6

3.3 AP One In-Wall 6

3.4 AP One 300M 6

3.5 AP One Flex 300M 6

3.6 AP Pro / AP Pro 300M / AP Pro Duo 6

4 Hardware Overview 7

4.1 AP One Enterprise 7

4.2 AP One AC mini 8

4.3 AP One In-Wall 9

4.4 AP One 300M 10

4.5 AP One Flex 300M 11

4.6 AP Pro / AP Pro 300M / AP Pro Duo 12

5 Installation 13

5.1 Installation Procedures 14

6 Using the Dashboard 15

6.1 General 15

6.2 AP 17

7 Configuration 19

7.1 System 19

7.1.1 Admin Security 19

7.1.2 Firmware 21

7.1.3 Time 21

7.1.4 Event Log 22

7.1.5 SNMP 23

7.1.6 Controller 25

7.1.7 Configuration 26

http://www.pepwave.com

7.1.8 Reboot 27

7.2 AP 27

7.2.1 Wireless SSID 27

7.2.2 Settings 37

7.2.3 WDS 40

7.3 Network 41

7.3.1 WAN 41

7.3.2 LAN 43

7.3.3 PepVPN 46

8 Tools 49

8.1 Ping 49

8.2 Traceroute 49

8.3 Nslookup 50

9 Monitoring Device Status 51

9.1 Device 51

9.2 Client List 51

9.3 WDS Info 52

9.4 Portal 52

9.5 Rogue AP 53

9.6 Event Log 53

10 Restoring Factory Defaults 54

11 Appendix 55

12 Datasheets 55

http://www.pepwave.com

1 Introduction and Scope

Our AP Series of enterprise-grade 802.11b/g/n Wi-Fi access points is engineered to

provide fast, dependable, and flexible operation in a variety of environments, all

controlled by an easy-to-use centralized management system. From the small but

powerful AP One AC mini to the top-of-the-line AP One 300M our AP Series offers

wireless networking solutions to suit any business need, and every access point is

loaded with essential features such as multiple SSIDs, VLAN, WDS, and Guest Protect.

A single access point provides as many as 32 virtual access points (16 on single-radio

models), each with its own security policy (WPA, WPA2, etc.) and authentication

mechanism (802.1x, open, captive portal, etc.), allowing faster, easier, and more

cost-effective network builds. Each member of the AP Series family also features a

high-powered Wi-Fi transmitter that greatly enhances coverage and performance while

reducing equipment costs and maintenance.

http://www.pepwave.com

2Product Features and Benefits

Key features and benefits of AP Series access points:

● High-powered Wi-Fi transmitter enhances coverage and lowers cost of

ownership.

● Independent security policies and encryption mechanisms for each virtual access

point allow fast, flexible, cost-effective network builds.

● Centralized management via InControl reduces maintenance expense and time.

● WDS support allows secure and fast network expansion.

● Guest Protect support guards sensitive business data and subnetworks.

● WMM (Wi-Fi Multimedia) and QoS (Quality of Service) support keeps video and

other bandwidth-intensive data flowing fast and lag-free.

http://www.pepwave.com

3Package Contents

3.1 AP One Enterprise

1 x AP One Enterprise

1 x Instruction sheet

3.2 AP One AC mini

1 x AP One mini

1 x Omni-directional antenna

1 x Power supply

1 x Instruction sheet

3.3 AP One In-Wall

1 x AP One In-Wall

1 x Mounting kit

1 x Instruction sheet

3.4 AP One 300M

1 x AP One 300M

2 x Omni-directional antennas

1 x Power supply

1 x Instruction sheet

3.5 AP One Flex 300M

1 x AP One Flex 300M

1 x Pepwave Passive PoE Injector

1 x Power supply

1 x Instruction sheet

3.6 AP Pro / AP Pro 300M / AP Pro Duo

1 x AP Pro / AP Pro 300M / AP Pro Duo

1 x Instruction sheet

1 x Installation guide

http://www.pepwave.com

4Hardware Overview

4.1 AP One Enterprise

Bottom View Top View Front View

LED Indicators

Status

RED – Access point initializing

GREEN – Access point ready

LAN 1

OFF – No device connected to Ethernet port

BLINKING – Ethernet port sending/receiving data

ON – Powered-on device connected to Ethernet port

Note that LAN 5 displays the status of the uplink connection

http://www.pepwave.com

4.2 AP One AC mini

Front View Rear Panel View

LED Indicators

Status

RED – Access point initializing

GREEN – Access point ready

Wi-Fi

OFF – 2.4/5GHz Wi-Fi radio off

BLINKING – AP sending/receiving data

GREEN – 2.4/5GHz Wi-Fi radio on

Note that this model includes a 2.4GHz Wi-Fi radio and a 5GHz Wi-Fi radio that can

operate simultaneously to increase speed and reduce interference.

http://www.pepwave.com

4.3 AP One In-Wall

Front View (US) Front View (International)

Rear Panel View Top View

LED Indicators

Status

RED – Access point initializing

GREEN – Access point ready

WLAN 1/2

OFF – 2.4/5GHz Wi-Fi radio off

BLINKING – AP sending/receiving data

GREEN – 2.4/5GHz Wi-Fi radio on

Note that this model includes a 2.4GHz Wi-Fi radio and a 5GHz Wi-Fi radio that can

operate simultaneously to increase speed and reduce interference. WLAN1 displays

the status of the 2.4GHz Wi-Fi radio, while WLAN2 displays the status of the 5GHz

Wi-Fi radio.

LAN 1-5

OFF – No device connected to Ethernet port

BLINKING – Ethernet port sending/receiving data

ON – Powered-on device connected to Ethernet port

Note that LAN 5 displays the status of the uplink connection

http://www.pepwave.com

4.4 AP One 300M

Front View Rear Panel View

LED Indicators

Power

On – Power On

OFF – Power Off

Status

RED – Access point initializing

GREEN – Access point ready

Wireless

OFF – 2.4/5GHz Wi-Fi radio off

BLINKING – AP sending/receiving data

GREEN – 2.4/5GHz Wi-Fi radio on

Note that this model can operate in either 2.4GHz or 5GHz mode, depending on Wi-Fi

radio settings.

http://www.pepwave.com
